zCICS
Application Programming Guide
v11
Automated Software Tools Corporation.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.

zCICS Application Programming Guide
Table of Contents
Introduction
Assembly Notes
VSAM Notes
Basic Mapping Support
zCOBOL Support
Extra Parameters
Supported EXEC CICS commands (summary by type)
Supported EXEC CICS commands (detail by type)
Appendicies
Keypress information
Change Summary
References
Trademarks
Credits
General
HANDLE AID
HANDLE CONDITION
IGNORE CONDITION
POP HANDLE
PUSH HANDLE
ADDRESS
ASSIGN
Terminal Control
RECEIVE
SEND
SEND CONTROL
File Control
READ
STARTBR
READNEXT
READPREV
ENDBR
RESETBR
Storage Control
FREEMAIN
GETMAIN
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
2

zCICS Application Programming Guide
Temporary Storage Control
DELETEQ
READQ
WRITEQ
Program Control
ABEND
HANDLE ABEND
LINK
LOAD
RELEASE
RETURN
XCTL
Interval Control
ASKTIME
DELAY
FORMATTIME
START
RETRIEVE
CANCEL
Task Control
ENQ
DEQ
BMS
RECEIVE MAP
SEND MAP
DUMP CONTROL
DUMP
System
INQUIRE FILE
SET FILE
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
3
zCICS Application Programming Guide
Introduction
The EXEC CICS commands and parameters listed here are the only ones currently
supported in the zCICS environment.
Differences between mainframe operation and zCICS are explained.
For the operation of each command and parameter please refer to the Manuals
listed in the Reference section at the end of this document.
If you create your own zCICS applications, it would be wise to create a .BAT file that
re-assembles them all in one go. The internal interfaces are volatile at present and
this will be a frequent instruction.
The current zCICS environment and all test programs can be re-assembled using
DFHALL.BAT. The test VSAM catalog and files can be rebuilt using DFHALLV.BAT.
Assembly notes
CICS must be added as an option to CALL MZ390.
PROLOG and EPILOG are defaults.
NOEPILOG is supported but not fully tested, testing and correct usage is scheduled
for a future release of zCICS.
PROLOG inserts the following:
DFHEISTG -- Define the prefix areas of the Dynamic Storage Area (DSA).
DFHEIEND – Replaces the END statement and defines the end of the DSA.
DFHEIENT – Replaces the first CSECT statement
Establish linkage and base registers
GETMAIN the DSA
Establish addressability to the EIB and TCTTE
Some COMMAREA management
Other macros...
DFHEIBLK -- EIB DSECT
DFHPCT -- Transaction definition
DFHFCT – File definitions and options
EXEC -- Converts EXEC CICS statements into a unique macro call with a
parameter list
DFHREGS – A synonym for EQUREGS
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
5
zCICS Application Programming Guide
Copy books...
DFHAID Standard CICS equates for AID keys
DFHBMSCA Mapping support equates
DFHPCTUS User transaction codes
DFHFCTUS User file definitions
Inclusion of the macro DFHREGS/EQUREGS is mandatory.
Register Usage...
R0 Reserved for internal use
R1 Reserved for internal use
R10 TCTTE address, must not be modified
R11 EIB address, must not be modified
R12 Default base register
R13 DSA address, must not be modified
R14 Reserved for internal use
R15 Reserved for internal use
Multiple base registers (assembler only)
The standard entry for a CICS program is as follows:
e.g. DFHEISTG DSECT
MYFIELD DS CL100 demo user field
...
MYPROG CSECT
This standard method with the PROLOG option (default) will generate a single code
base of R12 and a single DSA base of R13.
If you want to extend the code base and/or the DSA base registers, convert your
code in line with the sample given, and include the NOPROLOG option in CALL
MZ390.
e.g. DFHEISTG
MYFIELD DS CL100 demo user field
...
MYPROG DFHEIENT CODEREG=(R8,R5),DATAREG=(R13,R6,R7)
Notes:You cannot override the first DATAREG value, it will always be R13
i.e. if you code DATAREG=(R6,R7) you will get DATAREG=(R13,R7).
There is no cross-checking for register conflicts.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
6
zCICS Application Programming Guide
EXEC CICS command syntax (Assembler only)
There is no formal definition of an EXEC CICS command in any IBM Manual.
These assembler syntaxes are currently supported...
a) In-line space separated
name EXEC CICS function subfunction parm parm()
b) In-line comma separated
name EXEC CICS function,subfunction,parm,parm(), parm ()
c) Split, space separated
Non-blank in column 72 is assumed for all lines except the last.
Comments are only allowed following a dot or comma delimiter on the last line.
name EXEC CICS function
subfunction
parm
parm() parm (). a nice comment
d) Split, comma separated
Non-blank in column 72 is assumed for all lines except the last.
Comments are allowed on all lines that end with comma+space.
name EXEC CICS function, some
subfunction, very
parm, nice
parm(),parm (), comments
name is supported and optional.
EXEC CICS is expected, EXECUTE CICS is not currently supported.
subfunction is optional and depends on the function but must follow function,
e.g. EXEC CICS WRITEQ TS
parm() without spacing and parm () with spacing are allowed.
VSAM Notes
See the zCICS VSAM Guide for guidance in the setup of a VSAM environment.
This document also contains extensions to the VSAM facilities currently available.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
7
zCICS Application Programming Guide
Basic Mapping Support
The commands RECEIVE MAP, SEND MAP and SEND CONTROL are documented
here.
For general BMS documentation and the mapping macros DFHMSD, DFHMDI and
DFHMDF see the zCICS BMS Guide.
zCOBOL support
EXEC CICS command format follows the rules for COBOL.
Each command must end END-EXEC (a following dot may affect the logic).
Parameters like SET() which address imported structures may use the ADDRESS
OF special register.
LENGTH, FLENGTH and KEYLENGTH which would normally allow a numeric option
may use the LENGTH OF special register.
Extra Parameters
You can add NOEDF to any EXEC CICS command if you wish that command to be
excluded from a CEDF session.
You can add NOEDF to the CALL MZ390 if you wish all CEDF intercepts in that
program excluded.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
8
zCICS Application Programming Guide
Supported EXEC CICS commands (summary by type)
1) General commands (02)
a) HANDLE AID key() key
b) HANDLE CONDITION condition() condition
c) IGNORE CONDITION condition
d) POP HANDLE
e) PUSH HANDLE
f) ADDRESS
g) ASSIGN
2) Terminal Control (04)
a) RECEIVE INTO() LENGTH() NOHANDLE
b) SEND FROM() LENGTH()
3) File Control (06)
a) READ FILE()/DATASET() INTO()/SET() LENGTH()/FLENGTH()
RIDFLD() RBA/XRBA/RRN/GENERIC GTEQ/EQUAL KEYLENGTH()
b) STARTBR FILE()/DATASET() RIDFLD() REQID()
RBA/XRBA/RRN/GENERIC GTEQ/EQUAL KEYLENGTH()
c) READNEXT FILE()/DATASET() INTO()/SET() LENGTH()/FLENGTH()
RIDFLD() REQID() RBA/XRBA/RRN KEYLENGTH()
d) READPREV FILE()/DATASET() INTO()/SET() LENGTH()/FLENGTH()
RIDFLD() REQID() RBA/XRBA/RRN KEYLENGTH()
e) ENDBR FILE()/DATASET() REQID()
f) RESETBR FILE()/DATASET() RIDFLD() REQID()
RBA/XRBA/RRN/GENERIC GTEQ/EQUAL KEYLENGTH()
4) Storage Control (08)
a) FREEMAIN DATA()/DATAPOINTER()
b) GETMAIN SET() LENGTH()/FLENGTH() INITIMG()
5) Temporary Storage Control (0A)
a) DELETEQ TS QUEUE()/QNAME()
b) READQ TS QUEUE()/QNAME() INTO()/SET() LENGTH()/FLENGTH()
NUMITEMS() ITEM()/NEXT
c) WRITEQ TS QUEUE()/QNAME() FROM() LENGTH()/FLENGTH()
NUMITEMS() ITEM() REWRITE
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
9
zCICS Application Programming Guide
6) Program Control (0E)
a) ABEND ABCODE() CANCEL NODUMP
b) HANDLE ABEND CANCEL/RESET/LABEL()/PROGRAM()
c) LINK PROGRAM() COMMAREA() LENGTH() CHANNEL()
d) LOAD PROGRAM() ENTRY()/SET() LENGTH() FLENGTH()
e) RELEASE PROGRAM()
f) RETURN TRANSID() COMMAREA() LENGTH() CHANNEL() IMMEDIATE
g) XCTL PROGRAM() COMMAREA() LENGTH() CHANNEL()
7) Interval Control (10 and 4A)
a) ASKTIME ABSTIME()
b) DELAY REQID()/INTERVAL()/TIME() FOR/UNTIL HOURS() MINUTES()
SECONDS()
c) FORMATTIME all parameters
d) START TRANSID() INTERVAL()/TIME() TERMID() CHANNEL()
REQID() FROM() LENGTH() QUEUE() RTRANSID() RTERMID()
AFTER/AT HOURS() MINUTES() SECONDS()
e) RETRIEVE INTO()/SET() LENGTH() RTRANSID() RTERMID() QUEUE()
f) CANCEL REQID()
8) Task Control (12)
a) ENQ RESOURCE() LENGTH() NOSUSPEND
b) DEQ RESOURCE() LENGTH()
9) BMS (18)
a) RECEIVE MAP(name) MAPSET(name) INTO()
b) SEND MAP(name) MAPSET(name)
CURSOR/CURSOR() DATAONLY/MAPONLY ERASE/ERASEAUP
FROM() LENGTH() ALARM FREEKB FRSET
SET()
c) SEND CONTROL CURSOR/CURSOR() ERASE/ERASEAUP
ALARM FREEKB FRSET
10) Dump Control (1C)
a) DUMP TRANSACTION DUMPCODE() COMPLETE
FROM() LENGTH()/FLENGTH()
SEGMENTLIST() LENGTHLIST() NUMSEGMENTS()
11) Inquire (4C)
a) INQUIRE FILE
b) SET FILE
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
10
zCICS Application Programming Guide
12) Channels and Containers (34 and 96)
a) GET CONTAINER() CHANNEL() INTO()/SET()/NODATA FLENGTH()
b) PUT CONTAINER() CHANNEL() FROM() FLENGTH()
c) DELETE CONTAINER() CHANNEL()
d) MOVE CONTAINER() AS() CHANNEL() TOCHANNEL()
e) STARTBROWSE CONTAINER CHANNEL() BROWSETOKEN()
f) GETNEXT CONTAINER() BROWSETOKEN()
g) ENDBROWSE CONTAINER BROWSETOKEN()
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
11

zCICS Application Programming Guide
Supported EXEC CICS commands (detail by type)
1) General commands (02)
a) HANDLE AID
Name Operation Operands
name EXEC CICS HANDLE AID
key(label) key etc.
The following parameters are not supported...
CLRPARTN, LIGHTPEN, OPERID, TRIGGER
The manual is not clear about ANYKEY (no label). I have assumed that it
clears all settings for CLEAR, PA and PF keys.
label may take three forms:
Direct reference
Indirect reference
Adcon literal
e.g. EXEC CICS HANDLE AID PA1(GOPA1) PA2(INDGOPA1) PA3(=A(GOPA1))
...
GOPA1 DS 0H
...
INDGOPA1 DC A(GOPA1)
Notes:
There is a current limit of 30 AIDs, please request more if needed.
Errors
AN INTERNAL ERROR HAS OCCURRED
NO PARAMETERS SPECIFIED
NUMBER OF AIDS EXCEEDS 30
BAD PARM
HANDLE TYPE NOT RECOGNISED
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
12

zCICS Application Programming Guide
b) HANDLE CONDITION
Name Operation Operands
name EXEC CICS HANDLE CONDITION
condition(label) condition etc.
label may take three forms:
Direct reference
Indirect reference
Adcon literal
See HANDLE AID for examples of these forms.
Notes:
There is a current limit of 30 conditions, please request more if needed.
DSIDERR is supported as a synonym to FILENOTFOUND.
Errors
AN INTERNAL ERROR HAS OCCURRED
NUMBER OF CONDITIONS EXCEEDS 30
BAD PARM
HANDLE TYPE NOT RECOGNISED
c) IGNORE CONDITION
Name Operation Operands
name EXEC CICS IGNORE CONDITION
condition...
Notes:
Ignoring an error may lead to unpredictable abends.
There is a current limit of 30 conditions, please request more if needed.
INVREQ, PGMIDERR or ERROR by default...
The EXEC CICS command treated as never existed.
INVREQ on EXEC CICS RETURN will abend the task ASRA as I cannot
ignore a RETURN.
LENGERR or ERROR by default...
NOHANDLE and any outstanding HANDLE AID will not invoke this
condition.
DSIDERR is supported as a synonym to FILENOTFOUND.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
13

zCICS Application Programming Guide
Errors
BAD PARM
IGNORE TYPE NOT RECOGNISED
AN INTERNAL ERROR HAS OCCURRED
NO PARAMETERS SPECIFIED
NUMBER OF CONDITIONS EXCEEDS 30
d) POP HANDLE
Name Operation Operands
name EXEC CICS POP HANDLE
For the HANDLE ABEND, a POP is the equivalent of a HANDLE ABEND
RESET.
Errors
BAD PARM
POP TYPE NOT RECOGNISED
Conditions (RESP/RESP2)
INVREQ/0
e) PUSH HANDLE
Name Operation Operands
name EXEC CICS PUSH HANDLE
For the HANDLE ABEND, a PUSH is the equivalent of a HANDLE ABEND
CANCEL.
Errors
BAD PARM
PUSH TYPE NOT RECOGNISED
f) ADDRESS
Name Operation Operands
name EXEC CICS ADDRESS
COMMAREA(label)
CWA(label)
EIB(label)
CWA has a different implementation in zCICS.
See "CWA Management" in "zCICS Diagnosis Reference"
Errors
BAD PARM
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
14

zCICS Application Programming Guide
g) ASSIGN
Name Operation Operands
name EXEC CICS ASSIGN
The following parameters are not supported:
ACTIVITY,ACTIVITYID,ALTSCRNHT,ALTSCRNWD,APPLID,
ASRAINTRPT,ASRAKEY,ASRASPC,ASRASTG,BRIDGE,
DELIMITER,DESTCOUNT,DESTID,DESTIDLENG,GCHARS,GCODES,I
NITPARM,INITPARMLEN,INPARTN,
LDCMNEM,LDCNUM,NETNAME,NUMTAB,OPCLASS,OPERKEYS,
OPID,OPSECURITY,ORGABCODE,PAGENUM,
PARTNPAGE,PARTNPAGE,PRINSYSID,PROCESS,
PROCESSTYPE,QNAME,SIGDATA,STATIONID,SYSID,
TELLERID,USERID,USERNAME
Note: zCICS allows a CWA size greater than 32K. If the CWA
does exceed 32K, then ASSIGN CWALENG() will return an
incorrect value.
Conditions (RESP/RESP2)
INVREQ/2
INVREQ/5
Errors
BAD PARM
2) Terminal Control (04)
a) RECEIVE
Name Operation Operands
name EXEC CICS RECEIVE
INTO(label)
LENGTH(label)
NOHANDLE
INTO(label) and LENGTH(label) are mandatory.
LENGTH must point to a 2-byte field.
Although MAXLENGTH is not implemented yet, there is an internal
maximum length set to the implied length of the INTO label.
NOHANDLE is optional.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
15

zCICS Application Programming Guide
Errors
BAD PARM
BOTH INTO AND LENGTH ARE REQUIRED
LENGTH ERROR
Conditions (RESP/RESP2)
NOTALLOC/0
LENGERR/0
b) SEND
Name Operation Operands
name EXEC CICS SEND
FROM(label)
LENGTH()
FROM(label) is mandatory.
label may take three forms:
Direct reference
Indirect reference
Adcon literal
LENGTH
Can be specified as LENGTH(value) or LENGTH(label)
LENGTH(value) supports the use of the length attribute.
label must point to a 2-byte hex value.
The parameters TERMINAL, WAIT, DEFAULT and TEXT are discarded.
Errors
BAD PARM
FROM IS MANDATORY
LENGTH IS MANDATORY
Conditions (RESP/RESP2)
INVREQ/0
Note: Attempt to execute this in a non-terminal attached task.
This is not documented in the Manual.
LENGERR/E1
c) SEND CONTROL
Name Operation Operands
name EXEC CICS SEND CONTROL
CURSOR/CURSOR()
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
16

zCICS Application Programming Guide
ERASE/ERASEAUP
ALARM
FREEKB
FRSET
TERMINAL and WAIT are accepted and discarded.
ACCUM and SET are not supported.
CURSOR() refers to the 24x80 screen.
CURSOR is not documented.
SEND CONTROL CURSOR ERASEAUP means erase all input fields
and don't move the cursor.
Errors
BAD PARM
CURSOR POSITION AND SYMBOLIC CURSOR SPECIFIED
ERASE AND ERASEAUP SPECIFIED
Conditions (RESP/RESP2)
INVREQ/0
Note: Attempt to execute this in a non-terminal attached task.
This is not documented in the Manual.
3) File Control (06)
Notes:
FLENGTH and XRBA are extensions; do not use these parameters if the
source code is likely to be ported back to a mainframe environment.
RBA access to a KSDS is not supported.
DATASET is supported for legacy applications. It is noted that this parameter
no longer appears in the Manuals.
When conditions are raised as a result of a VSAM error, the RPL feedback codes
(2nd and 4th bytes) are placed in EIBRCODE +1 and +2.
a) READ
Name Operation Operands
name EXEC CICS READ
FILE()/DATASET()
INTO()/SET()
LENGTH()/FLENGTH()
RIDFLD()
RBA/XRBA/RRN/GENERIC
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
17
zCICS Application Programming Guide
GTEQ/EQUAL
KEYLENGTH()
LENGTH
Can be specified as a constant, literal or label.
A constant must not exceed 32767.
A literal or label must be 2 bytes and must not exceed 32767.
FLENGTH
Can be specified as a constant, literal or label.
A constant must not exceed 2G-1.
A literal or label must be 4 bytes and must not exceed 2G-1.
LENGTH/FLENGTH notes:
If SET is specified, LENGTH/FLENGTH are ignored and LENGERR
cannot occur.
If INTO is specified and LENGTH/FLENGTH are not, then the implied
length of INTO is used. This may raise the LENGERR condition if the
data length is larger.
If LENGTH/FLENGTH is numeric then it specifies the maximum data
length that can be received. LENGERR can be raised if the data length
is larger.
If LENGTH/FLENGTH is a label then it specifies the maximum data
length that can be received. LENGERR can be raised if the data length
is larger. The true data length is returned in label.
KEYLENGTH
Can be specified as a constant or label.
A constant must not exceed 32767.
A label must be 2 bytes and must not exceed 32767.
Keylengths greater than 128 are ignored.
The parameter is ignored for ESDS and RRDS.
KEYLENGTH and GENERIC must be paired.
If KEYLENGTH is zero by constant or label then parameters are
changed internally:
GENERIC/EQUAL or GENERIC/GTEQ
Becomes KEYLENGTH(1) Key=X'00' GENERIC GTEQ
RBA RIDFLD has a 4-byte RBA
XRBA RIDFLD has an 8-byte RBA
RRN RIDFLD has a 4-byte relative record number
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
18

zCICS Application Programming Guide
GTEQ/EQUAL
The parameter is ignored for ESDS and RRDS.
GENERIC
KEYLENGTH must be specified.
The parameter is ignored for ESDS and RRDS.
Errors
BAD PARM
BOTH FILE AND DATASET ARE SPECIFIED
BOTH GTEQ AND EQUAL ARE SPECIFIED
BOTH INTO AND SET ARE SPECIFIED
BOTH LENGTH AND FLENGTH ARE SPECIFIED
BOTH RBA AND XRBA ARE SPECIFIED
BOTH RRN AND (X)RBA ARE SPECIFIED
FILE OR DATASET MUST BE SPECIFIED
GENERIC CANNOT BE SPECIFIED WITH RRN OR (X)RBA
GENERIC REQUIRES KEYLENGTH
INTO OR SET MUST BE SPECIFIED
INVALID FILE OR DATASET
KEYLENGTH REQUIRES GENERIC
RIDFLD IS MANDATORY
Conditions (RESP/RESP2)
FILENOTFOUND/1
DISABLED/50
ILLOGIC/110
INVREQ/20
INVREQ/25
INVREQ/42
LENGERR/E1
NOTFND/80
NOTOPEN/60
b) STARTBR
Name Operation Operands
name EXEC CICS STARTBR
FILE()/DATASET()
RIDFLD()
REQID()
RBA/XRBA/RRN/GENERIC
GTEQ/EQUAL
KEYLENGTH()
REQID
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
19
zCICS Application Programming Guide
Can be specified as a constant, literal or label.
A constant must not exceed 32767.
A literal or label must be 2 bytes and must not exceed 32767.
If omitted, zero is assumed.
RBA RIDFLD has a 4-byte RBA
XRBA RIDFLD has an 8-byte RBA
RRN RIDFLD has a 4-byte relative record number
KEYLENGTH
Can be specified as a constant or label.
A constant must not exceed 32767.
A label must be 2 bytes and must not exceed 32767.
Keylengths greater than 128 are ignored.
The parameter is ignored for ESDS and RRDS.
KEYLENGTH and GENERIC must be paired.
If KEYLENGTH is zero by constant or label then parameters are
changed internally:
GENERIC/EQUAL or GENERIC/GTEQ
Becomes KEYLENGTH(1) Key=X'00' GENERIC GTEQ
GTEQ/EQUAL
The parameter is ignored for ESDS and RRDS.
GENERIC
KEYLENGTH must be specified.
The parameter is ignored for ESDS and RRDS.
Errors
BAD PARM
BOTH FILE AND DATASET ARE SPECIFIED
BOTH GTEQ AND EQUAL ARE SPECIFIED
BOTH RBA AND XRBA ARE SPECIFIED
BOTH RRN AND (X)RBA ARE SPECIFIED
FILE OR DATASET MUST BE SPECIFIED
GENERIC CANNOT BE SPECIFIED WITH RRN OR (X)RBA
GENERIC REQUIRES KEYLENGTH
INVALID FILE OR DATASET
KEYLENGTH REQUIRES GENERIC
RIDFLD IS MANDATORY
Conditions (RESP/RESP2)
DISABLED/50
FILENOTFOUND/1
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
20

zCICS Application Programming Guide
ILLOGIC/110
INVREQ/20
INVREQ/25
INVREQ/33
INVREQ/42
NOTFND/80
NOTOPEN/60
Note: NOTFND cannot occur for an ESDS or RRDS
c) READNEXT
Name Operation Operands
name EXEC CICS READNEXT
FILE()/DATASET()
INTO()/SET()
LENGTH()/FLENGTH()
RIDFLD()
REQID()
RBA/XRBA/RRN
KEYLENGTH()
LENGTH
Can be specified as a constant, literal or label.
A constant must not exceed 32767.
A literal or label must be 2 bytes and must not exceed 32767.
FLENGTH
Can be specified as a constant, literal or label.
A constant must not exceed 2G-1.
A literal or label must be 4 bytes and must not exceed 2G-1.
LENGTH/FLENGTH notes:
If either is not a label then...
If INTO is specified, then the length received is the implied length of
INTO. This may raise the LENGERR condition if the data length is
larger.
If SET is specified, the complete record is returned and LENGERR
cannot occur.
If either is a label then...
If INTO or SET is specified, then it specifies the maximum data
length that can be received. LENGERR can be raised if the data
length is larger. The true data length is returned in label.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
21
zCICS Application Programming Guide
REQID
Can be specified as a constant, literal or label.
A constant must not exceed 32767.
A literal or label must be 2 bytes and must not exceed 32767.
If omitted, zero is assumed.
RBA RIDFLD has a 4-byte RBA
XRBA RIDFLD has an 8-byte RBA
RRN RIDFLD has a 4-byte relative record number
KEYLENGTH
Can be specified as a constant or label.
A constant must not exceed 32767.
A label must be 2 bytes and must not exceed 32767.
Keylengths greater than 128 are ignored.
The parameter is ignored for ESDS and RRDS.
If KEYLENGTH is zero by constant or label then parameters are
changed internally:
GENERIC/EQUAL or GENERIC/GTEQ
Becomes KEYLENGTH(1) Key=X'00' GENERIC GTEQ
Errors
BAD PARM
BOTH FILE AND DATASET ARE SPECIFIED
BOTH INTO AND SET ARE SPECIFIED
BOTH LENGTH AND FLENGTH ARE SPECIFIED
BOTH RBA AND XRBA ARE SPECIFIED
BOTH RRN AND (X)RBA ARE SPECIFIED
FILE OR DATASET MUST BE SPECIFIED
INTO OR SET MUST BE SPECIFIED
INVALID FILE OR DATASET
RIDFLD IS MANDATORY
THIS TYPE OF INTO REQUIRES LENGTH/FLENGTH
Conditions (RESP/RESP2)
DISABLED/50
ENDFILE/90
FILENOTFOUND/1
ILLOGIC/110
INVREQ/20
INVREQ/25
INVREQ/26
INVREQ/34
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
22

zCICS Application Programming Guide
INVREQ/42
LENGERR/E1
NOTFND/80
NOTOPEN/60
d) READPREV
Name Operation Operands
name EXEC CICS READPREV
FILE()/DATASET()
INTO()/SET()
LENGTH()/FLENGTH()
RIDFLD()
REQID()
RBA/XRBA/RRN
KEYLENGTH()
LENGTH
Can be specified as a constant, literal or label.
A constant must not exceed 32767.
A literal or label must be 2 bytes and must not exceed 32767.
FLENGTH
Can be specified as a constant, literal or label.
A constant must not exceed 2G-1.
A literal or label must be 4 bytes and must not exceed 2G-1.
LENGTH/FLENGTH notes:
If either is not a label then...
If INTO is specified, then the length received is the implied length of
INTO. This may raise the LENGERR condition if the data length is
larger.
If SET is specified, the complete record is returned and LENGERR
cannot occur.
If either is a label then...
If INTO or SET is specified, then it specifies the maximum data
length that can be received. LENGERR can be raised if the data
length is larger. The true data length is returned in label.
REQID
Can be specified as a constant, literal or label.
A constant must not exceed 32767.
A literal or label must be 2 bytes and must not exceed 32767.
If omitted, zero is assumed.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
23
zCICS Application Programming Guide
RBA RIDFLD has a 4-byte RBA
XRBA RIDFLD has an 8-byte RBA
RRN RIDFLD has a 4-byte relative record number
KEYLENGTH
Can be specified as a constant or label.
A constant must not exceed 32767.
A label must be 2 bytes and must not exceed 32767.
Keylengths greater than 128 are ignored.
The parameter is ignored for ESDS and RRDS.
If KEYLENGTH is specified, the value must be equal to the keylength
defined for the file.
Errors
BAD PARM
BOTH FILE AND DATASET ARE SPECIFIED
BOTH INTO AND SET ARE SPECIFIED
BOTH LENGTH AND FLENGTH ARE SPECIFIED
BOTH RBA AND XRBA ARE SPECIFIED
BOTH RRN AND (X)RBA ARE SPECIFIED
FILE OR DATASET MUST BE SPECIFIED
INTO OR SET MUST BE SPECIFIED
INVALID FILE OR DATASET
RIDFLD IS MANDATORY
THIS TYPE OF INTO REQUIRES LENGTH/FLENGTH
Conditions (RESP/RESP2)
DISABLED/50
ENDFILE/90
FILENOTFOUND/1
ILLOGIC/110
INVREQ/20
INVREQ/24
INVREQ/26
INVREQ/41
LENGERR/E1
NOTFND/80
NOTOPEN/60
Note: ENDFILE can occur when a READPREV attempts to read past
the beginning of the file.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
24

zCICS Application Programming Guide
e) ENDBR
Name Operation Operands
name EXEC CICS ENDBR
FILE()/DATASET()
REQID()
REQID
Can be specified as a constant, literal or label.
A constant must not exceed 32767.
A literal or label must be 2 bytes and must not exceed 32767.
If omitted, zero is assumed.
Note: In real CICS, ENDBR cannot cause a file to open, but it will in zCICS.
The ENDBR command will be invalid, and may result in a transaction
abend.
Errors
BAD PARM
BOTH FILE AND DATASET ARE SPECIFIED
FILE OR DATASET MUST BE SPECIFIED
INVALID FILE OR DATASET
Conditions (RESP/RESP2)
DISABLED/50
FILENOTFOUND/1
ILLOGIC/110
INVREQ/20
INVREQ/35
NOTOPEN/60
f) RESETBR
Name Operation Operands
name EXEC CICS RESETBR
FILE()/DATASET()
RIDFLD()
REQID()
RBA/XRBA/RRN/GENERIC
GTEQ/EQUAL
KEYLENGTH()
REQID
Can be specified as a constant, literal or label.
A constant must not exceed 32767.
A literal or label must be 2 bytes and must not exceed 32767.
If omitted, zero is assumed.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
25
zCICS Application Programming Guide
RBA RIDFLD has a 4-byte RBA
XRBA RIDFLD has an 8-byte RBA
RRN RIDFLD has a 4-byte relative record number
KEYLENGTH
Can be specified as a constant or label.
A constant must not exceed 32767.
A label must be 2 bytes and must not exceed 32767.
Keylengths greater than 128 are ignored.
The parameter is ignored for ESDS and RRDS.
KEYLENGTH and GENERIC must be paired.
If KEYLENGTH is zero by constant or label then parameters are
changed internally:
GENERIC/EQUAL or GENERIC/GTEQ
Becomes KEYLENGTH(1) Key=X'00' GENERIC GTEQ
GTEQ/EQUAL
The parameter is ignored for ESDS and RRDS.
GENERIC
KEYLENGTH must be specified.
The parameter is ignored for ESDS and RRDS.
Note: In real CICS, RESETBR cannot cause a file to open, but it will in
zCICS. The RESETBR command will be invalid, and may result in a
transaction abend.
Errors
BAD PARM
BOTH FILE AND DATASET ARE SPECIFIED
BOTH GTEQ AND EQUAL ARE SPECIFIED
BOTH RBA AND XRBA ARE SPECIFIED
BOTH RRN AND (X)RBA ARE SPECIFIED
FILE OR DATASET MUST BE SPECIFIED
GENERIC CANNOT BE SPECIFIED WITH RRN OR (X)RBA
GENERIC REQUIRES KEYLENGTH
INVALID FILE OR DATASET
KEYLENGTH REQUIRES GENERIC
RIDFLD IS MANDATORY
Conditions (RESP/RESP2)
DISABLED/50
FILENOTFOUND/1
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
26

zCICS Application Programming Guide
ILLOGIC/110
INVREQ/20
INVREQ/25
INVREQ/36
INVREQ/42
NOTFND/80
NOTOPEN/60
Note: NOTFND cannot occur for an ESDS or RRDS
4) Storage Control (08)
a) FREEMAIN
Name Operation Operands
name EXEC CICS FREEMAIN
DATA()/DATAPOINTER()
DATA(label)
label may only be an indirect reference to the address.
DATAPOINTER
Must be specified as a permitted general register value.
Errors
BAD PARM
BOTH DATA AND DATAPOINTER ARE SPECIFIED
DATA OR DATAPOINTER MUST BE SPECIFIED
Conditions (RESP/RESP2)
INVREQ/1
b) GETMAIN
Name Operation Operands
name EXEC CICS GETMAIN
SET()
LENGTH()/FLENGTH()
INITIMG()
SET is mandatory
Must be specified as a permitted general register value.
LENGTH
Can be specified as a constant, literal or label.
A constant must not exceed 32767.
A literal or label must be 2 bytes and must not exceed 32767.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
27

zCICS Application Programming Guide
FLENGTH
Can be specified as a constant, literal or label.
A constant must not exceed 2G-1.
A literal or label must be 4 bytes and must not exceed 2G-1.
INITIMG is optional
If omitted, the storage contents are not predictable.
Can be specified as a constant, literal or label.
zCOBOL supports all 3 data types, but for mainframe COBOL programs
only label is supported.
Only the first byte generated by the parameter is used.
Errors
BAD PARM
BOTH LENGTH AND FLENGTH ARE SPECIFIED
LENGTH OR FLENGTH MUST BE SPECIFIED
SET IS MANDATORY
5) Temporary Storage Control (0A)
Note:
FLENGTH is an extension; do not use this parameter if the source code is
likely to be ported back to a mainframe environment.
a) DELETEQ
Name Operation Operands
name EXEC CICS DELETEQ TS
QUEUE()/QNAME()
The parameters MAIN and AUXILIARY are accepted and discarded.
QUEUE may be specified as:
A quoted string which must not exceed 8 bytes.
A label which points to an 8-byte field.
A literal not exceeding 8 bytes.
Only label or literal may be used to specify a QUEUE with hex
characters.
QNAME may be specified as:
A quoted string which must not exceed 16 bytes.
A label which points to a 16-byte field.
A literal not exceeding 16 bytes.
Only label or literal may be used to specify a QNAME with hex
characters.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
28

zCICS Application Programming Guide
Errors
BAD PARM
BOTH QUEUE AND QNAME ARE SPECIFIED
DELETEQ TYPE NOT RECOGNIZED
INVALID QUEUE OR QNAME
QUEUE OR QNAME MUST BE SPECIFIED
Conditions (RESP/RESP2)
INVREQ/0
QIDERR/0
b) READQ
Name Operation Operands
name EXEC CICS READQ TS
QUEUE()/QNAME()
INTO()/SET()
LENGTH()/FLENGTH()
NUMITEMS()
ITEM()/NEXT
The parameters MAIN and AUXILIARY are accepted and discarded.
QUEUE may be specified as:
A quoted string which must not exceed 8 bytes.
A label which points to an 8-byte field.
A literal not exceeding 8 bytes.
Only label or literal may be used to specify a QUEUE with hex
characters.
QNAME may be specified as:
A quoted string which must not exceed 16 bytes.
A label which points to a 16-byte field.
A literal not exceeding 16 bytes.
Only label or literal may be used to specify a QNAME with hex
characters.
LENGTH
May be specified as LENGTH(value) or LENGTH(label)
LENGTH(value) supports the use of the length attribute.
label must point to a 2-byte hex value.
FLENGTH
Can be specified as a constant, literal or label.
A constant must not exceed 2G-1.
A literal or label must be 4 bytes and must not exceed 2G-1.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
29

zCICS Application Programming Guide
LENGTH/FLENGTH can be omitted. When they are, the implied length
of INTO is used. LENGTH/FLENGTH is mandatory when SET is used.
ITEM
May be specified as ITEM(value) or ITEM(label)
label must point to a 2-byte hex value.
Errors
BAD PARM
BOTH INTO AND SET ARE SPECIFIED
BOTH ITEM AND NEXT ARE SPECIFIED
BOTH LENGTH AND FLENGTH ARE SPECIFIED
BOTH QUEUE AND QNAME ARE SPECIFIED
INTO OR SET MUST BE SPECIFIED
INVALID QUEUE OR QNAME
ITEM OR NEXT MUST BE SPECIFIED
QUEUE OR QNAME MUST BE SPECIFIED
READQ TYPE NOT RECOGNIZED
SET REQUIRES LENGTH
Conditions (RESP/RESP2)
INVREQ/0
LENGERR/0
ITEMERR/0
QIDERR/0
c) WRITEQ
Name Operation Operands
name EXEC CICS WRITEQ TS
QUEUE()/QNAME()
FROM()
LENGTH()/FLENGTH()
NUMITEMS()
ITEM()
REWRITE
The parameters MAIN and AUXILIARY are accepted and discarded.
QUEUE may be specified as:
A quoted string which must not exceed 8 bytes.
A label which points to an 8-byte field.
A literal not exceeding 8 bytes.
Only label or literal may be used to specify a QUEUE with hex
characters.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
30
zCICS Application Programming Guide
QNAME may be specified as:
A quoted string which must not exceed 16 bytes.
A label which points to a 16-byte field.
A literal not exceeding 16 bytes.
Only label or literal may be used to specify a QNAME with hex
characters.
FROM(label) is mandatory.
label may take three forms:
Direct reference
Indirect reference
Adcon literal
LENGTH
May be specified as LENGTH(value) or LENGTH(label)
LENGTH(value) supports the use of the length attribute.
label must point to a 2-byte hex value.
FLENGTH
Can be specified as a constant, literal or label.
A constant must not exceed 2G-1.
A literal or label must be 4 bytes and must not exceed 2G-1.
LENGTH/FLENGTH can be omitted. When they are, the implied length
of FROM is used.
LENGTH/FLENGTH is mandatory when FROM is an indirect reference.
ITEM
May be specified as ITEM(value) or ITEM(label)
label must point to a 2-byte hex value.
Note: For compatibility with old releases of CICS, ITEM is accepted
without REWRITE and becomes NUMITEMS. ITEM must be a
label in this case.
Errors
BAD PARM
BOTH LENGTH AND FLENGTH ARE SPECIFIED
BOTH QUEUE AND QNAME ARE SPECIFIED
FROM IS MANDATORY
IF NUMITEMS IS SPECIFIED, ITEM AND REWRITE ARE INVALID
INVALID QUEUE OR QNAME
LENGTH/FLENGTH IS MANDATORY FOR INDIRECT FROM
LENGTH WITHOUT FROM
NUMITEMS MUST BE A LABEL (MAY HAVE ORIGINATED AS ITEM)
QUEUE OR QNAME MUST BE SPECIFIED
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
31

zCICS Application Programming Guide
REWRITE REQUIRES ITEM
WRITEQ TYPE NOT RECOGNIZED
Conditions (RESP/RESP2)
INVREQ/0
LENGERR/0
ITEMERR/0
QIDERR/0
6) Program Control (0E)
a) ABEND
Name Operation Operands
name EXEC CICS ABEND
ABCODE()
CANCEL
NODUMP
ABCODE can be specified as ABCODE('xxxx') or ABCODE(label)
label must point to a 4-byte field.
Errors
ABCODE MUST NOT BEGIN WITH 'A'
ABCODE IS INVALID
BAD PARM
b) HANDLE ABEND
Name Operation Operands
name EXEC CICS HANDLE ABEND
CANCEL
Name Operation Operands
name EXEC CICS HANDLE ABEND
RESET
Name Operation Operands
name EXEC CICS HANDLE ABEND
LABEL(label)
label may take three forms:
Direct reference
Indirect reference
Adcon literal
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
32

zCICS Application Programming Guide
Name Operation Operands
name EXEC CICS HANDLE ABEND
PROGRAM()
Can be specified as PROGRAM('xxxxxxxx') or PROGRAM(label)
label must point to an 8-byte field.
Any received COMMAREA when the EXEC CICS HANDLE ABEND is
issued is passed to the handling program when an abend occurs.
Notes:When an XCTL is executed, any HANDLE ABEND LABEL at the
current logical level is cleared as the current program is no longer in
use. HANDLE ABEND PROGRAMs are not cleared.
Errors
BAD PARM
HANDLE TYPE NOT RECOGNISED
INVALID PROGRAM
NO PARAMETERS SPECIFIED
PARMS MISSING OR TOO MANY PARMS
c) LINK
Name Operation Operands
name EXEC CICS LINK
PROGRAM()
COMMAREA(label)
LENGTH()
CHANNEL()
Executes another CICS program.
If COMMAREA is present, the address/length are passed.
Return is to the linker.
In zCICS both CHANNEL and COMMAREA may be specified.
A warning MNOTE is issued.
PROGRAM is mandatory
Can be specified as PROGRAM('xxxxxxxx') or PROGRAM(label)
label must point to an 8-byte field.
COMMAREA(label) is optional
label may take three forms:
Direct reference
Indirect reference
Adcon literal
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
33

zCICS Application Programming Guide
LENGTH
Can be specified as LENGTH(value) or LENGTH(label)
LENGTH(value) supports the use of the length attribute.
label must point to a 2-byte hex value.
LENGTH can be omitted. When it is, the implied length of the
COMMAREA is used. LENGTH is mandatory when COMMAREA is an
indirect reference.
Errors
BAD PARM
INVALID CHANNEL
INVALID PROGRAM
PROGRAM IS MISSING
LENGTH IS MANDATORY FOR INDIRECT COMMAREA
LENGTH WITHOUT COMMAREA
Warning
CHANNEL and COMMAREA specified
Conditions (RESP/RESP2)
CHANNELERR/1
PGMIDERR/3
d) LOAD
Name Operation Operands
name EXEC CICS LOAD
PROGRAM()
ENTRY()/SET()
LENGTH(label)
FLENGTH(label)
Loads a module.
The intention in the zCICS environment is to load a table or some other data,
not an executable program.
PROGRAM is mandatory
Can be specified as PROGRAM('xxxxxxxx') or PROGRAM(label)
label must point to an 8-byte field.
At present, only modules with a suffix of .390 may be LOADed.
ENTRY and SET are optional
Must be specified as a permitted general register value.
Both are equivalent in zCICS.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
34

zCICS Application Programming Guide
LENGTH is optional
LENGTH(label) is the only format.
label must point to a 2-byte field.
FLENGTH is optional
FLENGTH(label) is the only format.
label must point to a 4-byte field.
Note: At task end the LOADed module is not RELEASEd.
Errors
BAD PARM
INVALID PROGRAM
LENGTH AND FLENGTH SPECIFIED
PROGRAM IS MISSING
Conditions (RESP/RESP2)
PGMIDERR/3
e) RELEASE
Name Operation Operands
name EXEC CICS RELEASE
PROGRAM()
Releases a previously LOADed module.
PROGRAM is mandatory
Can be specified as PROGRAM('xxxxxxxx') or PROGRAM(label)
label must point to an 8-byte field.
Errors
BAD PARM
INVALID PROGRAM
PROGRAM IS MISSING
Conditions (RESP/RESP2)
INVREQ/5
INVREQ/6
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
35

zCICS Application Programming Guide
f) RETURN
Name Operation Operands
name EXEC CICS RETURN
TRANSID()
COMMAREA(label)
LENGTH()
CHANNEL()
IMMEDIATE
Returns to the last caller.
In zCICS both CHANNEL and COMMAREA may be specified.
A warning MNOTE is issued.
TRANSID
Optional, but when COMMAREA is specified, TRANSID is mandatory.
Can be specified as TRANSID('xxxx') or TRANSID(label)
label must point to a 4-byte field.
COMMAREA(label) is optional
label may take three forms:
Direct reference
Indirect reference
Adcon literal
LENGTH
Can be specified as LENGTH(value) or LENGTH(label)
LENGTH(value) supports the use of the length attribute.
label must point to a 2-byte hex value.
LENGTH can be omitted. When it is, the implied length of the
COMMAREA is used. LENGTH is mandatory when COMMAREA is an
indirect reference.
Errors
BAD PARM
IMMEDIATE REQUIRES TRANSID
INVALID CHANNEL
INVALID TRANSID
TRANSID IS MISSING
LENGTH IS MANDATORY FOR INDIRECT COMMAREA
LENGTH WITHOUT COMMAREA
Warning
CHANNEL and COMMAREA specified
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
36

zCICS Application Programming Guide
Conditions (RESP/RESP2)
See the section on IGNORE for these conditions. Go here
CHANNELERR/1
INVREQ/1
INVREQ/2
g) XCTL
Name Operation Operands
name EXEC CICS XCTL
PROGRAM()
COMMAREA(label)
LENGTH()
CHANNEL()
Executes another CICS program.
In zCICS both CHANNEL and COMMAREA may be specified.
A warning MNOTE is issued.
If COMMAREA is present and both the address and length are the same as
passed to the current program, then address/length are passed to the new
program.
If the address or length differs, then a copy of the COMMAREA is taken and
the new address/length are passed to the new program.
Return is to the last linker.
PROGRAM is mandatory
Can be specified as PROGRAM('xxxxxxxx') or PROGRAM(label)
label must point to an 8-byte field.
COMMAREA(label) is optional
label may take three forms:
Direct reference
Indirect reference
Adcon literal
LENGTH
Can be specified as LENGTH(value) or LENGTH(label)
LENGTH(value) supports the use of the length attribute.
label must point to a 2-byte hex value.
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
37

zCICS Application Programming Guide
LENGTH can be omitted. When it is, the implied length of the
COMMAREA is used. LENGTH is mandatory when COMMAREA is an
indirect reference.
Errors
BAD PARM
INVALID CHANNEL
INVALID PROGRAM
PROGRAM IS MISSING
LENGTH IS MANDATORY FOR INDIRECT COMMAREA
LENGTH WITHOUT COMMAREA
Warning
CHANNEL and COMMAREA specified
Conditions (RESP/RESP2)
CHANNELERR/1
PGMIDERR/3
7) Interval Control (10 and 4A)
Note:
FLENGTH is an extension; do not use this parameter if the source code is
likely to be ported back to a mainframe environment.
a) ASKTIME
Name Operation Operands
name EXEC CICS ASKTIME
ABSTIME()
Errors
BAD PARM
b) DELAY
Name Operation Operands
name EXEC CICS DELAY
REQID()
INTERVAL()/TIME()
FOR/UNTIL
HOURS()
MINUTES()
SECONDS()
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
38
zCICS Application Programming Guide
INTERVAL
Can be specified as INTERVAL(s) through to INTERVAL(hhmmss).
i.e. INTERVAL(234) means wait for 2 minutes 34 seconds.
INTERVAL(label) is also permitted (extension).
label must point to a 6-byte character field with leading character zeros
as needed.
e.g. INTERVAL(MYTIME)
...
MYTIME DC C'000234'
TIME
Can be specified as TIME(s) through to TIME(hhmmss).
i.e. TIME(234) means resume the task at 2 minutes 34 seconds after
midnight. Expiration time rules apply; see the IBM Application
Programming Guide.
TIME(label) is also permitted (extension).
label must point to a 6-byte character field with leading character zeros
as needed.
e.g. TIME(MYTIME)
...
MYTIME DC C'000234'
FOR HOURS() MINUTES() SECONDS()
FOR is an alternative to INTERVAL.
HOURS/MINUTES/SECONDS must be numeric values.
UNTIL HOURS() MINUTES() SECONDS()
UNTIL is an alternative to TIME.
HOURS/MINUTES/SECONDS must be numeric values.
The result from the parameters is a time-of-day.
e.g. UNTIL SECONDS(10000) means resume the task at 02:46:40.
Expiration time rules apply; see the IBM Application Programming Guide.
If no parameters are specified, then DELAY INTERVAL(0) is assumed.
Errors
BAD PARM
BOTH FOR AND UNTIL ARE SPECIFIED
BOTH INTERVAL AND TIME ARE SPECIFIED
FOR/UNTIL SPECIFIED, BUT NO TIME PARMS
HOURS/MINUTES/SECONDS ARE INVALID WITH INTERVAL OR TIME
HOURS/MINUTES/SECONDS ARE SPECIFIED WITHOUT FOR/UNTIL
INTERVAL/TIME CANNOT BE SPECIFIED WITH FOR/UNTIL
INTERVAL/TIME MUST BE 1 TO 6 BYTES
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
39

zCICS Application Programming Guide
INVALID REQID
Conditions (RESP/RESP2)
INVREQ/4
INVREQ/5
INVREQ/6
c) FORMATTIME
Name Operation Operands
name EXEC CICS FORMATTIME
all parameters
Notes:
STRINGFORMAT is discarded as there is only one option.
DATESEP(label) and TIMESEP(label) are added as extensions.
Only the first byte is used.
DATESTRING returns the following 25-byte string.
The time zone (e.g. GMT) is not returned.
e.g. "Mon, 17 Dec 2007 10:20:30"
Errors
ABSTIME IS MANDATORY
BAD PARM
Conditions (RESP/RESP2)
INVREQ/1
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
40

zCICS Application Programming Guide
d) START
Name Operation Operands
name EXEC CICS START
TRANSID()
INTERVAL()/TIME()
TERMID()
REQID()
FROM()
LENGTH()/FLENGTH()
CHANNEL()
QUEUE()
RTRANSID()
RTERMID()
AFTER/AT
HOURS()
MINUTES()
SECONDS()
USERID is not supported.
In zCICS both CHANNEL and other parms may be specified.
A warning MNOTE is issued.
INTERVAL and TIME follow the same syntax and rules as for DELAY.
AFTER and AT follow the same syntax and rules as FOR and UNTIL in
DELAY above.
Errors
AFTER/AT SPECIFIED, BUT NO TIME PARAMETERS
BAD PARM
BOTH AFTER AND AT ARE SPECIFIED
BOTH INTERVAL AND TIME ARE SPECIFIED
BOTH LENGTH AND FLENGTH ARE SPECIFIED
FROM/(F)LENGTH MUST BOTH BE MISSING OR BOTH SPECIFIED
HOURS/MINUTES/SECONDS ARE INVALID WITH INTERVAL OR TIME
HOURS/MINUTES/SECONDS ARE SPECIFIED WITHOUT AFTER/AT
INTERVAL/TIME CANNOT BE SPECIFIED WITH AFTER/AT
INTERVAL/TIME MUST BE 1 TO 6 BYTES
INVALID CHANNEL
INVALID QUEUE
INVALID REQID
INVALID RTERMID
INVALID RTRANSID
INVALID TERMID
INVALID TRANSID
TRANSID IS MANDATORY
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
41

zCICS Application Programming Guide
Warning
CHANNEL AND OTHER PARMS SPECIFIED BUT ALLOWED
Conditions (RESP/RESP2)
CHANNELERR/1
INVREQ/0
INVREQ/4
INVREQ/5
INVREQ/6
IOERR
LENGERR
TERMIDERR
TRANSIDERR
e) RETRIEVE
Name Operation Operands
name EXEC CICS RETRIEVE
INTO()/SET()
LENGTH()/FLENGTH()
RTRANSID()
RTERMID()
QUEUE()
WAIT is not supported.
Errors
BAD PARM
BOTH INTO AND SET ARE SPECIFIED
BOTH LENGTH AND FLENGTH ARE SPECIFIED
INTO OR SET MUST BE SPECIFIED
INVALID QUEUE
INVALID RTERMID
INVALID RTRANSID
LENGTH OR FLENGTH MUST BE A LABEL
SET REQUIRES LENGTH OR FLENGTH
Conditions (RESP/RESP2)
INVREQ/0
ENDDATA
ENVDEFERR
LENGERR
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
42

zCICS Application Programming Guide
f) CANCEL
Name Operation Operands
name EXEC CICS CANCEL
REQID()
TRANSID is not supported.
Errors
BAD PARM
INVALID REQID
REQID IS MANDATORY
Conditions (RESP/RESP2)
INVREQ
NOTFND
8) Task Control (12)
a) ENQ
Name Operation Operands
name EXEC CICS ENQ
RESOURCE()
LENGTH()
NOSUSPEND
LENGTH
Can be specified as LENGTH(value) or LENGTH(label)
LENGTH(value) supports the use of the length attribute.
Errors
BAD PARM
RESOURCE IS MANDATORY
*** ENQ ON ADDRESS MAY NOT WORK IN zCICS
*** BUT THE COMMAND WILL BE PROCESSED
*** PLEASE CONTACT THE AUTHOR FOR ADVICE
Conditions (RESP/RESP2)
ENQBUSY
LENGERR/1
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
43

zCICS Application Programming Guide
b) DEQ
Name Operation Operands
name EXEC CICS DEQ
RESOURCE()
LENGTH()
LENGTH
Can be specified as LENGTH(value) or LENGTH(label)
LENGTH(value) supports the use of the length attribute.
Errors
BAD PARM
RESOURCE IS MANDATORY
Conditions (RESP/RESP2)
LENGERR/1
9) BMS (18)
a) RECEIVE MAP
Name Operation Operands
name EXEC CICS RECEIVE MAP()
MAPSET()
INTO()
TERMINAL and ASIS are accepted and discarded.
SET, FROM and LENGTH are not supported.
MAP can be a quoted string, maximum 7 characters or a label pointing to a
7-byte field.
If MAP is a label, then INTO is mandatory.
Note: The map structure will not be cleared before the mapping takes
place.
If MAP is a string, then INTO is optional...
If INTO is omitted, the default is map.I
Note: The map structure will be cleared before the mapping takes place.
MAPSET can be a quoted string, maximum 7 characters or an address
pointing to an 8-byte field containing no more than 7 characters.
If MAPSET is omitted, then the MAPname is used.
Errors
BAD PARM
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
44
zCICS Application Programming Guide
FROM NOT SUPPORTED
INTO IS REQUIRED WHEN MAP IS A LABEL
INVALID MAP NAME
INVALID MAPSET NAME
LENGTH NOT SUPPORTED
MAP IS MANDATORY
Conditions (RESP/RESP2)
Note: EIBRESP2 is an extension for MAPFAIL; please see the zCICS BMS
Guide for more information.
Many of the conditions can arise through a mismatch of map and
structure. Typically a map is re-assembled but the programs using it
are not.
INVMPSZ/0
MAPFAIL/1 The map cannot be found in the mapset.
MAPFAIL/2 A short read key (CLEAR or PA) has been pressed or there
are no modified fields.
MAPFAIL/3 Data has been received, but there are no named fields in the
map.
MAPFAIL/4 An SBA has been located, but there is no field in the map
that matches.
MAPFAIL/5 An SBA has been located, but it matches an unnamed field.
MAPFAIL/6 The data received for this field is longer than the DFHMDF
LENGTH= parameter.
MAPFAIL/7 There has been a mismatch between the physical map and
the DSECT.
MAPFAIL/8 Data to be processed by PICIN is over 31 digits.
Data is not numeric after being PACKed.
Data length is greater than the edit pattern allows.
INVREQ/0
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
45

zCICS Application Programming Guide
b) SEND MAP
Name Operation Operands
name EXEC CICS SEND MAP()
MAPSET()
CURSOR/CURSOR()
DATAONLY/MAPONLY
ERASE/ERASEAUP
FROM()
LENGTH()
ALARM
FREEKB
FRSET
SET()
TERMINAL and WAIT are accepted and discarded.
ACCUM is not supported.
MAP can be a quoted string, maximum 7 characters or a label pointing to a
7-byte field.
If MAP is a label, then FROM is mandatory.
If MAP is a string, then FROM and/or LENGTH are optional...
If FROM is omitted, the default is map.O
If LENGTH is omitted, the default is map.L
LENGTH
LENGTH is supported but the value used is always that of the structure
length.
Can be specified as LENGTH(value) or LENGTH(label)
LENGTH(value) supports the use of the length attribute.
label must point to a 2-byte hex value.
MAPSET can be a quoted string, maximum 7 characters or a label pointing
to an 8-byte field containing no more than 7 characters.
If MAPSET is omitted, then MAP is used.
SET() is currently intended to be an internal parameter.
It does not conform to the standard used for BMS PAGING.
Errors
BAD PARM
CONTROL IS NOT COMPATABLE WITH SEND MAP
CURSOR POSITION AND SYMBOLIC CURSOR SPECIFIED
DATAONLY AND MAPONLY SPECIFIED
ERASE AND ERASEAUP SPECIFIED
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
46

zCICS Application Programming Guide
FROM IS REQUIRED WHEN MAP IS A LABEL
INVALID MAP NAME
INVALID MAPSET NAME
MAP IS MANDATORY
Conditions (RESP/RESP2)
Note: EIBRESP2 is an extension for MAPFAIL, please see the zCICS BMS
Guide for more information.
INVMPSZ/0
MAPFAIL/1 The map cannot be found in the mapset.
MAPFAIL/8 Data to be processed by PICOUT is over 31 digits.
Data is not numeric after being PACKed.
Data length is greater than the edit pattern allows.
MAPFAIL/9 Override field or colour attribute is invalid
INVREQ/0
Note: Attempt to execute this in a non-terminal attached task.
This is not documented in the Manual.
10) Dump Control (1C)
a) DUMP
Name Operation Operands
name EXEC CICS DUMP
TRANSACTION
DUMPCODE()
COMPLETE
FROM()
LENGTH()/FLENGTH()
SEGMENTLIST()
LENGTHLIST()
NUMSEGMENTS()
TRANSACTION is mandatory.
DUMPCODE is mandatory and can be a constant or label.
label must point to a 4-byte field.
No syntax checking is done.
COMPLETE
If there are no storage area parameters then COMPLETE is the default.
Produces a SNAP dump ID=997,TEXT='DUMP dddd COMPLETE'
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
47
zCICS Application Programming Guide
If there are storage area parameters and COMPLETE is not specified,
only the storage areas are dumped.
FROM() LENGTH()/FLENGTH()
Produces a SNAP dump ID=997,TEXT='DUMP dddd AREA'
LENGTH
Can be specified as a constant or label.
A constant must not exceed 32767.
A label must be 2 bytes and must not exceed 32767.
FLENGTH
Can be specified as a constant or label.
A constant must not exceed 2G-1.
A label must be 4 bytes and must not exceed 2G-1.
SEGMENTLIST/LENGTHLIST/NUMSEGMENTS
Produces multiple SNAP dumps ID=997,TEXT='DUMP dddd SEGMENT
nnn'
NUMSEGMENTS
Can be specified as a constant or label.
A constant must not exceed 2G-1.
A label must be 4 bytes and must not exceed 2G-1.
Errors
BAD PARM
BOTH LENGTH AND FLENGTH ARE SPECIFIED
DUMPCODE IS GREATER THAN 4 BYTES
DUMPCODE MUST BE SPECIFIED
LENGTH OR FLENGTH REQUIRES FROM
LENGTH OR FLENGTH MUST BE SPECIFIED
SEGMENTLIST, LENGTHLIST AND NUMSEGMENTS MUST
ALL BE SPECIFIED OR ALL ABSENT
TRANSACTION MUST BE SPECIFIED
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
48

zCICS Application Programming Guide
11) System (4C)
a) INQUIRE FILE
The following formats are supported:
Name Operation Operands
name EXEC CICS INQUIRE FILE START
name EXEC CICS INQUIRE FILE START AT()
name EXEC CICS INQUIRE FILE END
name EXEC CICS INQUIRE FILE() NEXT ...
See parameter list below
name EXEC CICS INQUIRE FILE() ...
See parameter list below
The following parameters are supported:
ACCESSMETHOD, ADD, BASEDSNAME, BROWSE, DELETE,
DSNAME, ENABLESTATUS, KEYLENGTH ,KEYPOSITION, OBJECT,
OPENSTATUS, READ, RECORDFORMAT,
RECORDSIZE, TYPE, UPDATE
BASEDSNAME() and DSNAME() parameters:
The length of data returned is the implied length of the data
area to a maximum of 128 bytes. This can be extended on
request.
Errors
AT() IS SPECIFIED WITHOUT START
BAD PARM
FILE DOES NOT PRECEDE END
FILE DOES NOT PRECEDE START
FILE() CANNOT BE A STRING WHEN NEXT IS SPECIFIED
FILE() IS MISSING
INQUIRE TYPE NOT RECOGNIZED
INVALID AT()
INVALID FILE()
NEXT AND END ARE SPECIFIED
START AND END ARE SPECIFIED
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
49

zCICS Application Programming Guide
b) SET FILE
The following formats are supported:
Name Operation Operands
name EXEC CICS SET FILE()/DATASET() ...
See parameter list below
The following parameters are supported:
ADD(), ADDABLE, NOTADDABLE, BROWSE(), BROWSABLE,
NOTBROWSABLE, DELETE(), DELETABLE, NOTDELETABLE,
ENABLESTATUS(), ENABLED, DISABLED, OPENSTATUS(), OPEN,
CLOSED, READ(), READABLE, NOTREADABLE, UPDATE(),
UPDATABLE, NOTUPDATABLE
Errors
BAD PARM
BOTH FILE AND DATASET SPECIFIED
FILE OR DATASET MUST BE SPECIFIED
INVALID FILE OR DATASET
MORE THAN ONE ADD PARAMETER
MORE THAN ONE BROWSE PARAMETER
MORE THAN ONE DELETE PARAMETER
MORE THAN ONE ENABLESTATUS PARAMETER
MORE THAN ONE OPEN STATUS PARAMETER
MORE THAN ONE READ PARAMETER
MORE THAN ONE UPDATE PARAMETER
Conditions (RESP/RESP2)
FILENOTFOUND
INVREQ/2
INVREQ/3
INVREQ/4
INVREQ/5
INVREQ/7
INVREQ/12
INVREQ/14
INVREQ/16
INVREQ/17
IOERR
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
50

zCICS Application Programming Guide
12) Channels and Containers (34 and 96)
a) GET
Name Operation Operands
name EXEC CICS GET
CONTAINER()
CHANNEL()
INTO()/FLENGTH()
SET()/FLENGTH()
NODATA/FLENGTH()
Errors
BAD PARM
BOTH INTO AND SET SPECIFIED
CONTAINER IS MANDATORY
INTO AND NODATA SPECIFIED
INTO OR SET OR NODATA IS REQUIRED
INVALID CHANNEL
INVALID CONTAINER
NODATA REQUIRES FLENGTH
SET AND NODATA SPECIFIED
SET OR NODATA REQUIRES FLENGTH AS LABEL
SET REQUIRES FLENGTH
Conditions (RESP/RESP2)
CHANNELERR/2
INVREQ/4
LENGERR/11
b) PUT
Name Operation Operands
name EXEC CICS PUT
CONTAINER()
CHANNEL()
FROM()/FLENGTH()
Errors
BAD PARM
CONTAINER IS MANDATORY
FLENGTH IS MANDATORY FOR INDIRECT FROM
FLENGTH WITHOUT FROM
FROM IS MANDATORY
INVALID CHANNEL
INVALID CONTAINER
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
51

zCICS Application Programming Guide
Conditions (RESP/RESP2)
CHANNELERR/1
CONTAINERERR/18
INVREQ/4
LENGERR/1
c) DELETE
Name Operation Operands
name EXEC CICS DELETE
CONTAINER()
CHANNEL()
Errors
BAD PARM
CONTAINER IS MANDATORY
INVALID CHANNEL
INVALID CONTAINER
Conditions (RESP/RESP2)
CHANNELERR/2
CONTAINERERR/10
d) MOVE
Name Operation Operands
name EXEC CICS MOVE
CONTAINER()
AS()
CHANNEL()
TOCHANNEL()
Errors
BAD PARM
CONTAINER AND/OR AS ARE MISSING
INVALID AS
INVALID CHANNEL
INVALID CONTAINER
INVALID TOCHANNEL
Conditions (RESP/RESP2)
CHANNELERR/1
CHANNELERR/2
CONTAINERERR/10
CONTAINERERR/18
INVREQ/4
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
52

zCICS Application Programming Guide
e) STARTBROWSE
Name Operation Operands
name EXEC CICS STARTBROWSE
CONTAINER
CHANNEL()
BROWSETOKEN()
Errors
BAD PARM
INVALID CHANNEL
BROWSETOKEN IS MANDATORY
STARTBROWSE TYPE NOT RECOGNISED
Conditions (RESP/RESP2)
ACTIVITYERR/2
CHANNELERR/2
f) GETNEXT
Name Operation Operands
name EXEC CICS GETNEXT
CONTAINER()
BROWSETOKEN()
Errors
BAD PARM
BROWSETOKEN IS MANDATORY
CONTAINER IS MANDATORY
Conditions (RESP/RESP2)
END/2
TOKENERR/3
g) ENDBROWSE
Name Operation Operands
name EXEC CICS ENDBROWSE
CONTAINER
BROWSETOKEN()
Errors
BAD PARM
BROWSETOKEN IS MANDATORY
ENDBROWSE TYPE NOT RECOGNISED
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
53

zCICS Application Programming Guide
Condition (RESP/RESP2)
TOKENERR/3
Appendicies
Keypress information
Aid/Function Press
ENTER Enter or Return
CLEAR CTRL+C
PA1-PA3 CTRL+F1 to CTRL+F3
PF1-PF12 F1 to F12
PF13-PF24 CTRL+ALT+F1 to CTRL+ALT+F12
ERASE EOF CTRL+F6
ERASE INPUT CTRL+F7
Change Summary
February 1, 2012
Amended SEND MAP LENGTH parameter description and removed error
message
Added support for FLENGTH on REAQ/WRITEQ TS, START and RETRIEVE
ASSIGN CHANNEL now supported
CHANNEL added to LINK, XCTL, RETURN, START
New Commands: GET, PUT, MOVE, DELETE, STARTBROWSE, GETNEXT,
ENDBROWSE
June 10, 2011
Added DFHREGS
Added Extra Parameters about NOEDF
November 1, 2010
Added INVREQ/1 to RETURN
Added NOTALLOC to RECEIVE
Added INVREQ and extra MNOTE to RECEIVE MAP
Added INVREQ to SEND CONTROL
Added INVREQ to SEND
Added INVREQ and MAPFAIL/9 to SEND MAP
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
54
zCICS Application Programming Guide
Added INVREQ/5 to ASSIGN
New MNOTE for READNEXT and READPREV
Added SET FILE
Added REQID to CANCEL
Added test to HANDLE and IGNORE to detect no parameters
Extended support for the ENQ/DEQ LENGTH parameter
SEND CONTROL moved from BMS to Terminal Control
SEND documents discarded parameters.
August 1, 2009
Added INQUIRE FILE
Added ASSIGN
February 21, 2009
DFHEIGBL has been removed.
zCOBOL support for GETMAIN INITIMG added.
zCOBOL section added for EXEC CICS commands.
EXEC CICS SEND MAP supports SET(), but incompatibly.
November 24, 2008
Logic of READ with SET has changed slightly.
Extra reason for MAPFAIL/8.
GR2 has been eliminated from internal code and is available as a base register
(it isn't advised owing to instructions that may modify it).
DFHEIRET macro has been withdrawn; it is now incorporated into EXEC CICS
RETURN.
Added a section on EXEC CICS command syntax.
SEND MAP has FROM LENGTH and MAP(label) support.
RECEIVE MAP has INTO() support.
DSIDERR is supported for HANDLE/IGNORE CONDITION.
WRITEQ TS supports ITEM without REWRITE, messages changed.
Added START, RETRIEVE and CANCEL commands.
Added IMMEDIATE to EXEC CICS RETURN.
Added ENQ and DEQ commands.
June 27, 2008
Added ERASE EOF and ERASE INPUT to the keypress table
Added commands RECEIVE MAP, SEND MAP, SEND CONTROL and
references to the new BMS document.
January 18, 2008
Added READ/STARTBR/RESETBR parameters:
RRN, GTEQ, EQUAL, GENERIC, KEYLENGTH
Added READNEXT/READPREV parameters RRN, KEYLENGTH
Added ASKTIME, DELAY, FORMATTIME
Added DUMP TRANSACTION
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
55
zCICS Application Programming Guide
References
SC34-6433 CICS Application Programming Guide
SC34-6434 CICS Application Programming Reference
Trademarks
IBM, CICS and VSAM are registered trademarks of International Business Machines
Corporation.
Credits
Author : Melvyn Maltz
Formatting : Walter Petras
Shipping Date : February 1, 2012
Z390 version : V1.5.05
zCICS version: V11
Copyright 2009 Automated Software Tools Corporation.
This is part of z390 distributed under open source GPL License.
56
