User Manual
DC1600F
Emitter Specification
Type specification
Technical support
T
T
DC1600 Back side
Setting
button
DC1600
Single - channel emitter
Up button
Stop button
Down button
Version NO. : A/03
Fucntion instructionTechnical specification
Input voltage：3V(CR2450)
Transmitting frequency：433MHz
Transmitting power：10 milliwatt
Operating temperature：-100C—500C
Transmssion distance：200 meters open office，
35 meters on two walls
During the settings,the time between
two operation must be shorter than
4s,otherwise it will quit the setting
A
Additional
function
A
Additional
function
Matchable R tubular motor setting up
A
Additional
function
Matchable DC1680 setting up
Matchable DC136 setting up
Power on
Sound from motor
hear long sound
Power on
Power on
Press (up+down)×1
at the same time
Indicator
flashing
Indicator long
flashing
Indicator flashing
then extinguished
Setting
is ok
Setting
is ok
During the settings,the time between
two operation must be shorter than
6s,otherwise it will quit the setting
During the settings,the time between
two operation must be shorter than
10s,otherwise it will quit the setting
Up×1
Down×1
OK
OK
Delete all the datas of the motor and
the new emitter has been programmed.
Beep once Beep once
Set up is ok.
The up button control
the motor clockwise
Set up is ok.
The down button control
the motor clockwise
Setting button×1
OK
DC136 DC136 DC136 DC136 DC136
Stop×1
OK
DC1680 DC1680 DC1680 DC1680 DC1680
Indicator
flashing
Indicator long
flashing
Indicator flashing
then extinguished
Stop×1Up×1
Run or beep
for hint
Run or beep
for hint
Up×1
P2×1 P2×1
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
Notice: transmitter do not exposed to moisture and strike, so as not to
affect life.When you use transmitter, if found emission distance obviously
short or less sensitive, please change another same new battery. Please
have batteries for recycling.
DC1600 is Single channel emitter
