Dongguan Hele Electronics BOX2 Bluetooth Speaker User Manual 2017 2 9 box2 v1 0
Dongguan Hele Electronics Co., Ltd. Bluetooth Speaker 2017 2 9 box2 v1 0
User manual
How to Charge
Low battery will be warned by red
blinking LED and voice prompt(please
use USB cable to charge for Speaker)
AUX Mode
When charging or in Bluetooth mode,
plug in AUX cable to trigger AUX mode
and plug it out to return to Bluetooth
mode
Tap to
play/pause
30.001.061899
BOX2英文说明书
105g哑粉3色1专印刷过哑油
折叠页
BLUETOOTH SPEAKER USER GUIDE
Overview
Mic Vol+
Vol-
On/Off
Button
USB Port
AUX-IN
How to Connect
When power off or in standby,
hold On/Off button for 2s to
trigger pairing mode(detect-
able by other devices)
On cellphone, search for
"QCY-BOX2" and tap to
connect(Last device in
records will be auto
connected once power on)
LED blinks blue
Hold for 2s to
trigger pairing mode
Charging
Breathing LED blinks blue
Fully charged
LED will be solidblue whenpowering on
LED will turn off when powering off
Key Function
Hold On/Off Button for 2s
to power on/off
Power On/Off
Key Function
Hold On/Off Button for 1s to ignore
incoming call
Ignore Call
Tap On/Off Button to
answer /end incoming call
Answer/End Call
Hold to
power on/off
LED blinks
blue promptly
Tap to
answer/end
call
In standby mode or playing mode, tap
On/Off Button to play/pause music
Play/Pause Music
LED blinks blue
promptly
Hold for 1s
to ignore
Volume Control
Skip Track
Voice Assistant
Switch Audio Output Between
Speaker and Cellphone
Mute On/Off
When playing or calling(even charging),
tap vol+/-
When playing music(even charging),
hold vol+/- to track forward/backward
When standby or charging, hold On/Off
Button to activate voice assistant(like Siri)
When calling, hold On/Off Button for 1s
to switch audio output
When calling(even charging), double tap
On/Off Button to switch mute on/off
Basic Parameter
Model:QCY-BOX2
Operation Range: 10m
Standby Time: approx. 100hr
Weight: 189g
Input Parameter: 5V 500mA
Size: 90×80×45mm
Bluetooth Version: V4.2
Charging Time: approx. 2hr
Music Time: approx. 5 or 7hr
Bluetooth Profile: HFP/A2DP/HSP/AVRCP
Battery Capacity: 3.7V 1000mAh
Battery Type: Li-ion
Silicone housing is hatter
-resistant, which makes the
speaker safer in outdoor than ever
Music time has been
extended to 6 hours
Both Bluetooth and AUX modes are
available
Bluetooth 4.2 chip brings
about HD using experience
Function
AM
Detection Functionality
Activated, detectable to
BLUETOOTH
Bluetooth ON
Phone Name
Available Devices Available Devices
QCY-BOX2
QCY-BOX2
Lifespan
As the booklet states, the eco-lifespan of the item is 5 years while using it
in normal ways. During the period, no dangerous material will be leaked.
The item must be recycled by the local law.
1.Before using the headset, please read
the manual carefully and keep it for
future references.
2.The headset need to be fully charged
prior to first-time use.
3.If the headset is left unused for over
two weeks,pleaserecharge it periodically.
4.Please use the chargers made by
qualified manufacturer.
5.If the headset cannot be searched by
your phone, please check whether it is in
pairing mode; if left unconnected for a
long while, the headset will exit pairing
mode,please re-enter the mode; if a
procedure error of your phone occurs,
reboot it; if a procedure error of the
headset occurs, reboot or reset it.
1.Never disassemble or modify your
headset for any reasons to avoid any
damages and danger.
2.Do not store the headset in extreme
temperatures(under 0℃ or over 45℃).
3.Avoid using the indicator close to the
eyes of children or animals.
4.Do not use this headset during a
thunderstorm to avoid irregular function
and increased risk of electric shock.
5.Do not use harsh chemicals or strong
deterge nts to clean the headset.
6.Keep the headset dry.
Notes: Please arrange using time
properly since your hearing may be
damaged by using the device for a long
time.
1. Warranty Period
1)Returning: 1 year after you purchase
this item.
2)Repairing: 2 years after you purchase
this item.
2. Free Returning will Only be Accessed
under All of Following
Circumstances
1) 1 year after you purchase this item.
2)Three completed guarantee receipts
have to be provided to distributor(item
model No.,sales date and item serial No.
shall be displayed on invoiceand
warranty card) .
3)Required item has to be with full
package and accessories.
4)Malfunction has to be caused by quality
deficiencies.
Notes: Exchanged item will have the same
model No. and spec.
as your required one’s.
3. Free Repairing will Only be Accessed
under All of Following Circumstances
1) 2 years after you purchase this item.
2)Three completed guarantee receipts
have to be provided to distributor(item
model No.,sales date and item serial
No.shall be displayed on invoiceand
warranty card) .
3) Malfunction has to be caused by
quality deficiencies.
Free repairing & returning will not be
accessed under following circumstances
A: Item is out of warranty period or
effective sales receipt and warranty card
fail to be provided.
B: Breakdowns of housing, bags, gifts
and accessories or any non-functional
fault.
C: Unauthorized disassembly, breakdowns
caused by improper operation or using in
environment which is forbidden in user’s
manual.
D: Artificial damages(including but not
limiting to leaking,damped, dropping off,
squeezing, breaking, burning
anddistortion).
E: Faults caused by force Majeures(such as
earthquake, fire and flood).
For any after service, please
contact local distributor
Manufacturer: Dongguan Hele Electronics
Co.,Ltd.
Address: Dalingya Industrial Zone, Daojiao
Town, Dongguan City, Guangdong
Province(QCY Environmental Zone, Dalingya
No.5, Yuehui Road)
Perform standard:Q/HL 1-2016
This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the
FCC Rules . These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates
uses and can radiate radio frequency
energy and , if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications . However, there is no
guarantee that interference will not occur
in a particular installation . If this
equipment does cause harmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the
user is encouraged to try to correct the
interference by one or more of the
following measures:
-- Reorient or relocate the receiving
antenna.
-- Increase the separation between the
equipment and receiver.
-- Connect the equipment into an outlet
on a circuit different from that to which
the receiver is connected.
-- Consult the dealer or an experienced
radio/TV technician for help.
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference , and ( 2 ) this device must
accept any interference received,
including interference that may cause
undesired operation.
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user's
authority to operate the equipment.
Hazardous substances and their contents in the item
This form is made by SJ/T 11364 regulation.
O：means that hazardous substance content in the
homogeneo us materials of this part is within the
limitsof GB/T 26572 regulation.
（Pb） （Hg） （Cd） （Cr(VI)） （PBB） （PBDE）
Hazardous Substances
Part Name
Main body
Battery
Ear tips
Accessories
Charging cable
X ：means that hazardous substance content in, at
least,one certain homogeneous material of this
part is beyond the limits of GB/T 26572 egulation.
CaveatsTips
After Service and Support
FCC Statement
