Dongguan Hele Electronics QQ800 Bluetooth speaker User Manual
Dongguan Hele Electronics Co., Ltd. Bluetooth speaker
User manual
Overview
Indicator
Mic
On/Off
TF card slot
“M” Button
Multi-function
button(MFB) USB port
Start Up
Turn it on then it auto enters pairing mode
Connect with cellphone
Slide to turn it on
Slide to turn it on and it will auto enter pairing mode
(indicator flashes blue)
On cellphone, activate Bluetooth facility then search
for "QCY-QQ800" and tap to connect
Note: In Bluetooth mode, hold “M”button for 3s to enter
pairing mode. In Bluetooth /TF card mode, it will
auto switch off when no music plays in 10 minutes
How to Charge
LED will be on when charging and turn off when fully
charged
Low battery will be warned by voice prompt,"Low
battery, please recharge"
Play Music in TF Card Mode
Once plug TF card into the slot, the device will auto play
music from the TF card
In Bluetooth mode, press "M" button to switch the device
to TF card mode and auto play music from the TF card
Play/pause
In standby status, press MFB to play and press it again
to pause
Press
Press
Answer/end call
Press MFB to answer incoming call(indicator flashes
blue), press it again to end the call
Reject call
Hold MFB for 2s to reject incoming call(indicator
flashes blue)
Hold for 2s
Hold for 2s
Volume control
Slide MFB to left/right to adjust volume when
playing music
Skip track
Hold to slide MFB to left/right to skip track
backward/forward when playing music
Switch audio output between speaker and cellphone
Hold the MFB for 1s to switch audio output when
answering call
Hold for 1s Left/right slide
Hold to slide it to left/right Hold to slide the MFB to right/left
Mute
Slide the MFB to right/left to switch on/off mute
Features
With optimal li-polymer battery, it delivers super
long battery life.
“M” button press to swith between TF and Bluetooth
mode.
Unique sloping structure of speaker improves
transmitting efficiency of sound stage.
Basic parameters
Model No:QQ800
Weight:167g
Bluetooth range: 10m
Music time: 7 or 10hrs
Battery type: li-polymer
Charging time: approx. 1.5hrs
Bluetooth profiles: HFP/A2DP/HSP/AVRCP
Bluetooth version:2.1+EDR
Battery capacity:3.7V 950mAh
Input parameter:5V 600mA
Size:71.2 x 66.2 x 58mm
For any after service, please contact QCY customer-service
QCY-QQ800
QCY-QQ800
BLUETOOTH
a.m.
Turn on Bluetooth
Visibility
Device name
Visible to all Bluetooth devices nearby
Available Devices
Available Devices
Available Devices
After Service and Support
Warranty period:
12 months following the purchase date
Free service:
Under warranty, if there is any breakdown caused by
manufacturing defects, please contact our dealers to enjoy
freemaintenance. You will always need this Warranty Card
and yourreceipt or other proof of purchase to claim
warranty.
Free maintenance won’t be available under the following
circumstances：
1.Without Warranty Card or intact maintenance label
2.Damage caused by improper disassembly or repair
3.Damage resulting from liquid or dropping, and other
artificial mechanical defects
4.Damage caused by any force majeure
Perform standard: Q/HL 1-2016
Web: www.qcybluetooth.com
Customer-service email: kefu@qcymall.com
Manufacturer: Dongguan Hele Electronics Co.,Ltd.
Address: Dalingya Industrial Zone, Daojiao Town, Dongguan
City, Guangdong Province(QCY Environmental Zone,
Dalingya No.5, Yuehui Road)
5
This form is made by SJ/T 11364 regulation.
O：means that hazardous substance content in the homogeneo us materials
of this part is within the limitsof GB/T 26572 regulation.
X ：means that hazardous substance content in, at least,one certain
homogeneous material of this part is beyond the limits of GB/T 26572
regulation.
Ｌｉｆｅｓｐａｎ：
As the booklet states, the eco-lifespan of the item is 5 yearswhile using it
in normal ways. During the period, no dangerous material will be leaked.
The item must be recycled by the local law.
Hazardous substances and their contents in the item
（Pb） （Hg） （Cd） （Cr(VI)）（PBB） （PBDE）
Hazardous Substances
Part Name
Main body
Battery
Accessories
Charging cable
Ｔｉｐｓ
1.Before using the headset, please read the manual carefully and keep
it for future references.
2.The headset need to be fully charged prior to first-timeuse.
3.If the headset is left unused for over two weeks, please recharge it periodically.
4.Please use the chargers made by qualified manufacturer.
5.If the headset cannot be searched by your phone, please check whether it
is in pairing mode; if left unconnected for a long while, the headset will
exit pairing mode, please re-enter the mode; if a procedure error of your
phone occurs, reboot it; if a procedure error of the headset occurs,
reboot or reset it.
Ｃａｖｅａｔｓ
1.Never disassemble or modify your headset for any reasons to avoid
any damages and danger.
2.Do not store the headset in extreme temperatures (under 0℃ or over
45℃).
3.Do not use this headset during a thunderstorm to avoid irregular function
and increased risk of electric shock.
4.Do not use harsh chemicals or strong detergents toclean the headset.
5.Keep the headset dry.
Notes: Please arrange using time properly since your hearing may be
damaged by using the device for a long time.
Redial
When playing music or standby, hold MFB for 2s to
redial last outgoing number
Note: Last outgoing number may vary with different
cellphone systems
BLUETOOTH SPEAKER
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for
help.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
