Dongguan Liesheng Electronics LYEJ03LM Mi Bluetooth Headset Basic with Dock User Manual

Dongguan Liesheng Electronics Co., Ltd. Mi Bluetooth Headset Basic with Dock

User manual

Charging The Headset Charge The Charging Dock
When the power is low, the indicator will ash red
and send voice alerts.Note: the indicator turns red
while charging, and blue when fully charged.
Charge the charging dock with a USB cable.The
indicator turns red while charging, and blue when
fully charged.Note: if the indicator doesn’t light up
after docking the headset, the charging dock's
power is running low and needs to be recharged
shortly.
1. Charge the headset with a USB cable.
2. Charge the headset with a charging dock.
When charging, press and hold " " till the indicator
ashes red and blue alternately.
Product name: Mi Bluetooth Headset Basic 
Model: /<(-/0
Dimensions: 57×11×24mm
Charging time: 2h
Standby time: 70h
Wireless connections:
Bluetooth 4.1
Battery type: lithium-ion
polymer battery
Weight: 6.5g
Wireless range: 10m
Talk time: 3.5h
Battery capacity: 50mAh
Bluetooth proles:
HFP/A2DP/HSP/AVRCP
Headset specications
Product name: Mi Bluetooth Headset Charging Dock
Model: CDZ01LM
Battery capacity: 320mAh
Output: 5V 200mA
Charging time: 2h
Standby time: 3 months
Dimensions: 54.3×23×25mm
Input: 5v 300mA
Battery type: lithium-ion
polymer battery
Dock specications
LED
Adjust the volume
Press the volume +/- buttons to adjust the
volume.
Press
Key Features
Answer a call
Tap " " to answer an incoming call when the
indicator ashes blue quickly.
Reject a call
Briey press " " to reject an incoming call
when the indicator ashes blue quickly.
Press and hold
Tap
Press and hold
Red and blue
Play/Pause
Tap
Tap " " to listen to music.
Voice assistant
Mute
Double press
Press and hold
Double press " " during a call.
Accept calls from both phones and
switch between calls
Tap " " to answer an incoming call, and double
tap to maintain the rst call and switch to the
second;Double tap again " " to switch between
calls.
Weighs only 6.5g, easy to carry
around.
Oil and ngerprint resistant coating
for convenient clean.
Connect 2 phones
Press and hold
Quick ashing
1. Connect to the rst phone and turn off the
headset.
2. Press and hold " " utill the indicator ashes
blue quickly. Locate and connect Mi Bluetooth
Headset Basic on your second phone.
Your rst phone
Your second phone
3. Locate and connect Mi Bluetooth Headset Basic
on your rst phone again to comrm connection
with 2 phones.
Product features
Bluetooth 4.1 is compatible with most
phones and tablets.
CSR Bluetooth chip and imported
accessories combine to ensure
dependable Bluetooth performance.
Redial the last dialed number
When in standby mode, double tap " " to
redial.Note: 1. due to setting differences between
devices,some phones redial the last dialed
number by default, and some redial the last
number on Recent Calls regardless of dial-ins or
dial-outs; 2. when pairing with both phones, the
number redialed is from the rst phone.
Sound transfer between the headset
and your phone
When in standby mode or listening to music,
press and hold " " for 1 second to activate
voice assistant (for instance, Siri).
Point the tail of the headset to your mouth.
Multi-function Button
Volume+
Volume-
USB Port/Mic
LED Indicator
Eartip
Speaker
SmallLarge Medium
Gently place the headset so that the speaker and
eartip rest comfortably in your ear.
Quick ashing
Press and hold
Press and hold " " to enter pairing mode
(indicator ashes blue quickly)The headset is
ready to be paired when you use it for the rst
time. To pair again, press and hold the button
until the indicator ashes blue quickly.
User Manual
Mi Bluetooth Headset Basic with Dock
Medium eartips suit most people, try them before you
decide to switch to a different size.
Turn on the Bluetooth feature to locate Mi
Bluetooth Headset Basic.
Select and install ear tips How to connect
How to wear
ഥᦚὲH٠ᐰ
ᤳ಴΅
сы֋
94mm
Precautions
1. Please read the user manual before using, and
keep it for your future reference;
2. Make sure to fully charge the product on its
rst use；
3. Charge the product when left unused for over
2weeks;
4. Use only certied chargers supplied by qualied
manufacturers;
5. If your device cannot locate Mi Bluetooth
Headset Basic,please check if the headset is in
pairing mode.The headset will turn off if it fails
to pair for a long time;Reboot your phone or
the headset, or factory reset the headset,
should any program errors occur.
Warnings
1. Do not dismantle or congure the product in
case of re; Electron puncture may damage
the product completely；
2. Do not expose the product in environments
where temperature is extreme (lower than 0℃
or higher than 45℃)；
3. Keep the LED indicator away from the eyes of
children or animals；
4. Do not use the product during thunderstorms.
Thunderstrom may cause the product to
malfunction and result in an increased risk of
electric shock；
5. Do not wipe the product with oil and other
volatile liquid；
PANTONE cool gray 11c
Mi Bluetooth Headset Basic with Dock
Go to www.mi.com to learn more.
When answering calls, press and hold " " for 1
second.
BLUETOOTH
Bluetooth On
Detection Functionality
Activated, detectable to devices nearby
Phone Name
Available Devices
AM
Mi Bluetooth Headset Basic
Available Devices
Mi Bluetooth
Headset Basic
BLUETOOTH
Bluetooth On
Detection Functionality
Activated, detectable to devices nearby
Phone Name
Available Devices
AM
Mi Bluetooth Headset Basic
Available Devices
Mi Bluetooth
Headset Basic
BLUETOOTH
Bluetooth On
Detection Functionality
Activated, detectable to devices nearby
Phone Name
Available Devices
AM
Mi Bluetooth Headset Basic
Available Devices
Mi Bluetooth
Headset Basic
Factory Reset
Go to www.mi.com to learn more.
Principal: Xiaomi Communications Co.,Ltd.
Manufacturer: Dongguan Liesheng Electronics Co., Ltd.
(a Mi Ecosyst em Company)
Address: Floor 5, Building B, North Block, Gaosheng
Tech Park, Nancheng District, Dongguan City,
Guangdong Province
Please contact Xiaomi customer service for after-sales
inquiries.
Regulatory Notice for Users in USA
USA — Federal Communications Commission(FCC)
This device is granted with following FCC ID by
Federal Communications Commission (FCC)
FCC ID: 2AMQ6-LYEJ03LM
By using Mi Bluetooth Headset Basic with Dock
you agree to be bound by the terms and
conditions set forth at http: //www.mi.com/en/
agreement, which including but not limited to the
Xiaomi user agreement, collectively, the
“Agreements”.
By using Mi Bluetooth Headset Basic with Dock
you agree to be bound by the terms and
conditions of the Agreements.
Every Mi Bluetooth Headset Basic with Dock
comes with a one-year limited warranty.
Details are available at
http: //www.mi.com/en/support/
*****************- *
Model: LYEJ03LM
Copyright 2017 Xiaomi Inc.
All rights reserved
c
WARNING:This product contains a chemical
known to the State of California to cause
cancer or other reproductive harm.
6. Keep away from water or other liquid.
)&&6WDWHPHQW
7KLVHTXLSPHQWKDVEHHQWHVWHGDQGIRXQGWRFRPSO\ZLWKWKH
OLPLWVIRUD&ODVV%GLJLWDOGHYLFHSXUVXDQWWR3DUWRIWKH)&&
5XOHV7KHVHOLPLWVDUHGHVLJQHGWRSURYLGHUHDVRQDEOHSURWHFWLRQ
DJDLQVWKDUPIXOLQWHUIHUHQFHLQDUHVLGHQWLDOLQVWDOODWLRQ7KLV
HTXLSPHQWJHQHUDWHVXVHVDQGFDQUDGLDWHUDGLRIUHTXHQF\
HQHUJ\DQGLIQRWLQVWDOOHGDQGXVHGLQDFFRUGDQFHZLWKWKH
LQVWUXFWLRQVPD\FDXVHKDUPIXOLQWHUIHUHQFHWRUDGLR
FRPPXQLFDWLRQV+RZHYHUWKHUHLVQRJXDUDQWHHWKDWLQWHUIHUHQFH
ZLOOQRWRFFXULQDSDUWLFXODULQVWDOODWLRQ,IWKLVHTXLSPHQWGRHV
FDXVHKDUPIXOLQWHUIHUHQFHWRUDGLRRUWHOHYLVLRQUHFHSWLRQZKLFK
FDQEHGHWHUPLQHGE\WXUQLQJWKHHTXLSPHQWRIIDQGRQWKHXVHU
LVHQFRXUDJHGWRWU\WRFRUUHFWWKHLQWHUIHUHQFHE\RQHRUPRUHRI
WKHIROORZLQJPHDVXUHV
5HRULHQWRUUHORFDWHWKHUHFHLYLQJDQWHQQD
,QFUHDVHWKHVHSDUDWLRQEHWZHHQWKHHTXLSPHQWDQGUHFHLYHU
&RQQHFWWKHHTXLSPHQWLQWRDQRXWOHWRQDFLUFXLWGLIIHUHQWIURP
WKDWWRZKLFKWKHUHFHLYHULVFRQQHFWHG
&RQVXOWWKHGHDOHURUDQH[SHULHQFHGUDGLR79WHFKQLFLDQIRU
KHOS
7KLVGHYLFHFRPSOLHVZLWKSDUWRIWKH)&&5XOHV2SHUDWLRQLV
VXEMHFWWRWKHIROORZLQJWZRFRQGLWLRQV
7KLVGHYLFHPD\QRWFDXVHKDUPIXOLQWHUIHUHQFHDQGWKLV
GHYLFHPXVWDFFHSWDQ\LQWHUIHUHQFHUHFHLYHGLQFOXGLQJ
LQWHUIHUHQFHWKDWPD\FDXVHXQGHVLUHGRSHUDWLRQ
&KDQJHVRUPRGLILFDWLRQVQRWH[SUHVVO\DSSURYHGE\WKHSDUW\
UHVSRQVLEOHIRUFRPSOLDQFHFRXOGYRLGWKHXVHUVDXWKRULW\WR
RSHUDWHWKHHTXLSPHQW
