CONNECTLAND –MS-152OR Mouse – Guide
1. CONTENTS
The Connectland wireless optical mouse is included with the following accessories: a nano
USB 2.4GHz receiver, two LR03 AAA 1.5V batteries and a quick user’s guide.
Please contact immediately your vendor if one of them is missing.
2. INSTALLATION
a) Press battery cap button and open battery cap.
b) Insert two LR03 AAA 1.5V batteries (caution to the polarity).
c) Take out the nano USB receiver and replace the cap.
Switch on the mouse. Plug the nano receiver into your computer’s USB port.
System will recognize the new USB device and installed by itself. Then user will see “device
can be used », after successfully installed.
Battery cap button
2x Batteries AAA
compartment
ON/OFF
USB receiver 2.4GHz
compartment
PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
2
CONNECTLAND –MS-152OR Mouse – Guide
3. SYSTEMS SUPPORTED
The wireless mouse is compliant with the following operating systems:
- Microsoft Windows 98SE/ME/2000/2003/XP/VISTA
(Insert Microsoft Windows CDROM if asked)
- IBM and PC compatible
4. KEY-PRESS INSTRUCTION
CPI adjustable instruction (Count Per Inch) :
The mouse has 2 sensitive modes: 800cpi and 1600cpi.
To activate normal use mode: 800cpi
Press the CPI button. CPI light indicator will flash on 4 times.
To activate sensitive use mode: 1600cpi
Press the CPI button again. CPI light indicator will flash on 8 times.
Back
CPI and battery
CPI/DPI adjustable
Scroll wheel
Right
Forward
Left button
PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly
approved by the party responsible for compliance could void the user’s authority to
operate this equipment. (Example- use only shielded interface cables when connecting
to computer or peripheral devices).
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment and it also complies with Part 15 of FCC RF Rules.
Operation is subject to the following two conditions:
1) This device may not cause interference and
2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Caution!
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user
authority to operate the equipment.
