MS-183OR user manual
User Manual
MS-183OR
SIZE 210*148MM
Package contents
Wireless Optical Mouse
USB receiver
2 AAA alkaline batteries
User manual
Installing mouse process
Whenever new batteries are installed, make sure that they are fresh 1.5V
AAA batteries.
Installing the receiver (Diagram 1)
The codes of receiver and mouse were successfully connected in factory.
User can directly use the complete set of products, no worry about the code
connecting.
A)Insert receiver into USB port of PC, the computer system will automatically
detect it and prepare it for full operation.
B)Remove the battery cover.
C) Insert two AAA batteries into the battery compartment, make sure to properly
orient the positive (+) and negative (-) ends as specified by the marks in the
battery compartment. Replace the battery cover and make sure it is locked.
D)Switch on the mouse, the LED in bottom of mouse will blink red light.
E)The mouse may use then.
If the user wrongly operates, please redo the above operating procedures.
"ON/OFF" switch
Without using the mouse, user may turn off it by "ON/OFF" switch for saving
battery power.
(Diagram 2)
Description of keys and DPI adjusting
A)Using "DPI-adjusting key", the resolution of mouse can be switched between
800DPI and1600DPI in turn. That LED light in "DPI-adjusting key" blinks slowly
indicates 800DPI and fast 1600DPI.
B)Backward and Frontward keys for your easily navigating forward and
backward on the Internet
Low-voltage alarming function
When batteries have been used for some time and discover the LED light in
"DPI-adjusting key" blinks automatically, which reminds you that batteries'
voltage is becoming low, suggested you replace the batteries with new ones.
System requirements
Windows 2000/XP/Vista/7
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:(1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
(1) 15.21 statement
changes or modifications not expressly approved by the party responsible
for compliance could void the user s authority to operate the equipment.
(Diagram 1)
Battery cover
ON/OFF switch
Position for storing
receiver
Scrolling wheel
Left key Right key
Frontward key
Backward key DPI-adjusting key
