Dongguan Newmen Electronics Technology MX168S-HX Dongle User Manual Manual 2015 12 30
Dongguan Newmen Electronics Technology Co.,LTD Dongle Manual 2015 12 30
Manual_2015-12-30_User Manual.pdf
5 6
Left button
Right button
Wheel
CPI
Power on-off
Thank you for purchasing JETech Wireless Optical Mouse. This is a high-tech 2.4G
wireless optical mouse that offers you high precision and improves your work efficiency.
1. Frequency-2.4GHZ
2. Working distance 10 meters
3. Plug & play USB Nano receiver which can be stored at the bottom of the mouse
4. Compatible with Windows 2000/NT/ME/XP/Vista/Win7/Win8/Win10
5. Rated operating voltage: 3V
6. Rated working current: 5mA
7. Mouse size: 88*50*35mm
8. N.W: 55g(75g included battery)
9. Receiver:19*15*6.5mm
10. Resolution: 1000/1600 CPI (adjustable)
1. Install 2 pieces AAA battery into mouse Properly.
2. Turn on the mouse, the red LED indicator will light up.
3.
Take out the USB Nano receiver next to the battery, plug it into the USB port on computer,
wait until the receiver installed successfully.
4. Place the mouse within 50cm from the receiver.
5. The mouse is ready to work.
1. Is the power on?
2. Check the USB Nano receiver; change ports.
3. Check the battery.
4. Try different surface. Remove metallic objects between mouse and the Nano receiver.
5. If the Nano receiver is plugged into a USB hub, try plugging it directly into a USB port
on your computer.
6. Move the Nano receiver to a USB port closer to the mouse.
7. Reconnect the mouse and the Nano receiver.
Note:
The mouse has CPI button, click it to switch between 1000-1600 resolution.
Use the mouse on the smooth/plain surface for the best experience.
If the mouse stay out of work for 10 minutes, it will turn to power saving mode, press
any button to restart it.
Please remove the battery to avoid corrosion if the mouse will not be used for a long
time.
Portable design for travel: Nano receiver can be plug into the slot next to the battery
at the bottom of the mouse.
Package contains small parts. Not for children under 6 years old.
made in China
Attention:
FCC Statement
NOTE:
This device complies with Part 15 of FCC Rules. Operation is subject to the following
two conditions:1) this device may not cause harmful interference， and 2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
CE Statement
Battery Caution:Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructiuons.
Correct Disposal of this product. This marking indicates that this product should
not be disposed with other household wastes throughout the EU. To prevent possible
harm to the environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To return your used
device, please use the return and collection systems or contact the retailer where the
product was purchased. They can take this product for environmental safe recycling.
