User Manual
MS-225OR
210*148MM
(Diagram 1)
Description of keys and DPI adjusting
Low-voltage alarming function
When battery has been used for some time and discover the LED light in
"DPI-adjusting key" blinks automatically, which reminds you that battery's
voltage is becoming low, suggested you replace the battery with new one.
System requirements
Windows 2000/XP/Vista/7
Specifications and functions
1. USB nano receiver can be stored inside battery compartment
2. 2.4GHz, operating distance up to 8 meters
3. Power ON/OFF function
4. Low-voltage alarming function
5. Resolution: 1200DPI adjustable
Scrolling wheel
Left key Right key
(Diagram 2)
ON/OFF switch
Battery cover
Position for storing
receiver
Package contents
Wireless Optical Mouse
USB receiver
2 AAA alkaline batteries
User manual
Installing the battery (Diagram 1)
Whenever new batteries are installed, make sure that they are fresh 1.5V
AAA batteries.
A)Remove the battery cover.
B) Insert two AAA batteries into the battery compartment, make sure to properly
orient the positive (+) and negative (-) ends as specified by the marks in the
battery compartment. Replace the battery cover and make sure it is locked.
C)Switch on the mouse, the LED in bottom of mouse will blink.
Installing the receiver (Diagram 2)
The codes of receiver and mouse were successfully connected in factory.
User can directly use the complete set of products, no worry about the code
connecting.
A)Insert receiver into USB port of PC, the computer system will automatically
detect it and prepare it for full operation.
B)The mouse may use then.
If the user wrongly operates, please redo the above operating procedures.
"ON/OFF" switch (Diagram 1)
Without using the mouse, user may turn off it by "ON/OFF" switch for saving
battery power.
(1) 15.21 statement
changes or modifications not expressly approved by the party responsible
for compliance could void the user s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:(1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment. (Example- use only
shielded interface cables when connecting to computer or peripheral devices).
This equipment complies with Part 15 of FCC RF Rules. Operation is subject to the following two conditions:
1) This device may not cause interference and
2) This device must accept any interference, including interference that may cause undesired operation of
the device.
Caution!
The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user authority to operate the
equipment.
Canada Statement
This Device complies with RSS-210 of the IC Rules; Operation is subject to the following two
conditions:
(1). This device may not cause interference and
(2). This device must accept any interference received,, including interference that may cause undesired
operation.
