Dongguan Pinmi Electronic Technology Co., Ltd. On-board Music Charger Users Manual
Users Manual
Car Bluetooth FM Transmitter
User guide
Product Introduction
This device is a Bluetooth MP3 player developed for
car-used, which equipped with professional
high-performance Bluetooth module and MP3 decoder
chip.
It can play and transmit the music from TF card to car
stereo via FM radio signal.
It can transmit your mobile phone’s music to car
stereo via Bluetooth.
It can also be used as a hands-free car kit during
driving.
This device transmits signal by wireless method, no
need to modify anything in car. It can be used both as
the music player in entertainment purpose or
hands-free car kit in safety purpose during driving.
Product Introduction
1.Please plug this device into car cigarette lighter, then it
will be on automatically; when it is on work, the screen will
display the voltage of car battery, and monitor the car
battery in any time.
2.Noise and wind suppressed by CVC technology to create
full duplex sound quality.
3.Support mobile’s A2DP function. Music will be played
directly while the mobile phone is connected.
4.Mobile phone can be connected automatically when the
device turns on.
5.Support an external TF card, can play music files in
MP3/WMA format.
6.Integrated car charger of output 5V – 2100mA, is
available for charging handheld devices in car.
Operation Instructions:
1. Device Power-on
(1). Device turns on automatically when plug its integrated
car charger to car cigarette lighter power.
(2). Select any of a frequency.
(3). Turn on car FM stereo and select the frequency same
as that of the device.
2. Frequency and Volume Adjustment
(1). This device support frequency of 87.5-108.0MHz
which can be adjusted CH+ and CH- .
(2). Adjust the volume by rotating
3. Playing Music from TF card
(1). Insert the TF card into the device, it will automatically
detect and play the MP3/WMA/WAV format music in the
TF card.
(2). Music selection: press button of and to
select your favorite songs.
4. Connection to Bluetooth Devices:
(1). This device equipped with build-in Bluetooth chip, can
connect to other handheld Bluetooth devices.
(2). The pairing function will be activated automatically
when the device is power on. With the LED indicator ’s 1
time/second blinking, search this device with the name of
“T10”, and then connect it.
(3). This device has memory function. It will automatically
connect to its memorized paired Bluetooth devices when
power on.
(4). If you want to remove the memorized devices, please
press and hold the Frequency button to remove.
5. Playing Music from Mobile Phone:
(1). After successfully connecting mobile phone to the
device via Bluetooth, play music from mobile phone, the
device will wirelessly transmit the signal to car stereo.
(2). You can operate music playing of
Volume/Play/Pause/Previous/Next on mobile phone, or on
the device.
6. Switching Music File Sources
(1). It can play the music from TF card and the device with
bluetooth function, you can switch the file source between
TF card and device with bluetooth by press longer
7. make a call
(1) can make a call and answer the phone through this
device after connecting by bluetooth.
(2)Double tap can redial the last phone number.
(3)Reject a call: long tap last for 5 seconds to reject
a call while a calling coming.
8. AUX import/output:
(1). AUX import:This device supports import from outside ,
accepting music source by AUX connector eg.MP4.CD.etc
Then music source will be transtered ino FM
signal,accepted by radio.
(2). AUX output: This device support music soccrce’s
output from inside, it can be accepted by combined sound,
car sound and protable heedphone.
9.Part Description
Operation
Instruction
FM Transmitter
1. How to pair
mobile
Plug the device to cigarette
lighterpower
2. How to play and
pause
Press button to play,
pressagain to pause
3. How to adjust
volume
set Adjust the volume by
rotatong
In a song
Frequency decreases
Dispay
The line in the interface
TF card slot
The frequency and
The multifunction button/volme
Hose
The positive power supply
The Negative power supply
USB Charging Port
And the volume reduction
The next son g
4. How to set
frequency
Press CH+ and CH- to
adjust shorthyf
5. How to select
music
Press button to play next
song
Press button to play
previous song
6. How to answer
and stop a call
Press button shortly to
answer an incoming call.
Press button to shortly stop
the call during call answering
Press button longer during
calling to refuse call double
Press button to re-call last
phone No. during no calling
7. Switching mode long tap last for 5s, then it
will
switch to TF card or Bluetooth
mode.
Note: This device is compatible with most of the
mobile phones, except of a few mobile phones that are not
available to use parts of above functions.
Product features will be upgraded without any notice.
