Dongguan Siyoto Electronics SMBT-4083-ANC Bluetooth headset User Manual 15 SMBT 4083 ANC UserMan r1
Dong Guan SiYoTo Electronics CO.,LTD. Bluetooth headset 15 SMBT 4083 ANC UserMan r1
15_SMBT-4083-ANC UserMan, r1.pdf
1
Introduction
The Bluetooth headset Bone SMBT-4083-ANC is a portable hand free communication device
with A2DP profile built on Bluetooth wireless technology. This headset is designed and
manufactured in accordance with Bluetooth specification VR4.1 which supports adaptive
frequency hopping and allows faster connection, the noise immunity within the wireless area
network is better than the BT V2.1 Headset
Product standard
Bluetooth version：V4.1
Talk tine:：up to 35 hours
Standby time：up 850 hours
Battery standard：Rechargeable lithium polymer battery
Power adapter output: DC5V 350mA
Charging the headset
Your headset uses a rechargeable battery,you must charge
The battery fully before using the headset for the first time.
1. Plugging the charging cable in the USB charge port
2. The rde indicator lamp remains solid when charging.
3. The fully charging takes 2-3 hours
4. The red indicator lamp goes out and the red indicator
remains solid when charging completed
Power on/off the headset
User Manual
2
a. To power on: Off mode > Hold MFB 3s Steady Green for 1 sec
b. To power off: Any mode > Hold MFB 3s Steady Green for 1 sec
Voice Prompt
a. When the headset is on, there will be the automatic voice
prompt: power on
b. When the headser is off, there will be the automatic voice
prompt: power off
c. When being connected successfully, there will be voice
telling: connected
d. When the battery is low,there will be voice
telling: low battery
Voice Telling
When there is a telephone, headphones have beep beep
Pair to your Bluetooth phone
1.Pair the Bluetooth headset for the first time
a. The distance between the Bluetooth headset and your
Bluetooth phone would be better within 1 meter when
Pairing ,the closer the better.
b. Press multifunction button for 6 seconds, the headset into
pair statuw. blinking in blue and red alternatively
c. Set the phone to search for Bluetooth device.
d. When phone finds headset, confirm by selecting
“Emirates/F1” from list.
e. Enter pin code “0000” when prompted by phone.
f. Repeat steps B-E if the pairing was unsuccessful.
g. If the pairing is successful, accompanied by a beep, and green light flash
2. Connect to 2 devices at the same time
a. Press multifunction button for 6 seconds the headset into
pair status. Blinking in Green alternatively
b. Set the phone to search for Bluetooth device.
c. When phone finds headset confirm by selecting” Emirates/F1 ”
from list..
d. Enter pin code “0000” when prompted by phone.
e. Repeat steps B-E if the pairing was unsuccessful
f. If the pairing is successful, accompanied by a beep, and green light flash
.Note: Bluetooth headsrt off again,re-open at this time two Bluetooth
Devices will connest automatically.
3
Answering a call
a. Press the answer key on your phone.
b. Press the multifunction button on your headset.
Ending a call
a. Press the end key on your phone.
b. Press the multifunction button on your headset.
Rejecting s call
a. Press the end key on your phone.
b. Ring mode > Hold MFB button 2s
Playing music
Listening to the music you can press play pause , press and hold the vol+ 1s to NEXT
songpress and hold the vol- 1s to PRE song
Volume control
Volume keys to adjust the volume: Press the vol+ button to increase the sound, press the
vol- button growth small
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Thisdevicecomplieswithpart15oftheFCCrules.Operationissubjecttothefollowingtwo
conditions:
(1)thisdevicemaynotcauseharmfulinterference,and
(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause
undesiredoperation.
Changesormodificationstothisunitnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser'sauthoritytooperatetheequipment.
