Dongguan Taide BT013 Bluetooth Speaker User Manual BT013
Dongguan Taide Industrial Co., Ltd. Bluetooth Speaker BT013
User Manual
User Manual
Bluetooth Speaker
BT013
Dongguan Taide Industrial Co., Ltd.
BT013 EN IB
Dear user,
Thank you very much for choosing BT013 walkman Bluetooth sound box. Please read this user
manual carefully in order to operate this device correctly and bring its excellent performance.
I. Notice
Please store and use this product at normal temperature;
DO NOT expose this product to rain or damp;
DO NOT toss this product and prevent it from falling and being damaged;
DO NOT disassemble, repair and modify this product;
As it is inbuilt with lithium battery, DO NOT cast or place it in fire to avoid danger.
II. Kind Reminder
1, To extend the speaker‘ s service life ,and your physical and mental health, please don't listen to
music under big volume for a long time to avoid hearing damage.
2, When something wrong with the speaker, please immediately shut off the power switch, plug
off the USB ,to prevent the speaker and other parts are damaged.
3, Power shortage will affect Bluetooth distance or Bluetooth easy to disconnect, please charge in
time.
III. Overview
: VOL +/Next
: VOL-/Previous
: Play/ Pause
: Answer/ Hang up the call
Function Keys
Speaker Power on/ off 3.5mm Aux in
USB 5V
IV. Parameters
Model: BT013
Bluetooth specification: Bluetooth V2.1+EDR
Transmission distance: ≦10M (It varies when the environmental factors and the connected
Bluetooth devices are different)
USB charging voltage: DC 5V
Built-in battery: Lithium battery
Output power: 3W*2
Frequency response: 90Hz-20KHz
Sensitivity: 80db±2db
S/N ratio: ≥ 76dB
Dimensions: 58*73*120MM
Unit net weight: 250.00g
V. Packing List
1. Sound box *1
2. 3.5mm audio jack cable*1
3. Micro USB power cable * 1
3. IB*1 piece
VI. Common Functions
Start: Turn on the sound box it would give off “du-du” as tip and the blue light begins to flicker, the
default power is 60%.
Bluetooth connection: When the power is switched on, the blue light begins to flicker at the
same time, the speaker give off “du-du”. At this moment, turn on the Bluetooth device and click
“pair “option in Bluetooth device. BT013 will automatically stop if no Bluetooth device is found
within 5 minutes, so as to save the power.
Tip: If the connection fails, please turn off the machine and restart it or please charge it as there
maybe no sufficient power.
Bluetooth mode: Connect BT013 with Bluetooth device and press / to choose music and keep pressing
/ to increase or decrease the volume. Press to pause of play the music.
Hands-free: Connect BT013 with Bluetooth device when calls in, BT013 would give off “ du-du” as tip. Press
to answer the call and re-press to hang up the call.
AUX source: Insert the attached audio cable into the AUX port on BT013 and the other sider
audio port on PC. The player begins to play. The sound box will start the music. The volume, the
songs are freely controlled by the player.
AUX source: Insert the attached audio cable into the AUX port on the sound box and the music
player audio port on PC or other music player, the player begins to play. The sound box will start
the music. The volume, the songs are freely controlled by the player.
Tip: 、 、 / do not work under AUX mode, volume and music are controlled by the music player.
Smart automatic quick charge: Charge in power-off state. Insert the attached USB power cable
with the micro USB end into the USB power port of BT013 and the other end into the USB port of
PC or the USB charger to start charging. When the charging is over, the red indicator will be off.
VII
I. Compatibility
Device equipped with BLUETOOTH 3.0 or higher version (for details please refer to the relevant
agreements, general specification), such as the IPAD, IPHONE (the second generation and
IPHONE with updated IPHONE 3.1 software), IPOD TOCH, MAC with BLUETOOTH , and
majority of smart phone or computer support BLUETOOTH.
Bluetooth 3.0 including agreements as：A2DP, AVRCP,HFP
VIII. Troubleshooting
Problem Troubleshooting
Failure in connection
and pairing for many
times
1. Inspect whether the sound box is in the status of
searching, or, restart the machine.
2. The surrounding Bluetooth equipments are plentiful, which
causes the difficulty in searching. So, please close the
other Bluetooth equipments.
The sound is small or
distorted
1. Inspect the volume of the Bluetooth equipment and adjust
the volume.
2. The power of battery is insufficient, please charge it.
Discontinuous music See whether the effective connection distance of sound is
exceeded, or, whether there is obstacle between the sound
box and the Bluetooth equipment.
The indicator for
Bluetooth mode is not
on
1. It indicates that the power of the battery is not sufficient.
Please try again after charging it.
2. Restart the machine.
Phenomenon
FCC Warnings Statements:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void
your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement. The device can be used in
portable exposure condition without restriction.
