Dongguan Taide BT018 Wireless Speakers User Manual 15 BT018 UserMan
Dongguan Taide Industrial Co., Ltd. Wireless Speakers 15 BT018 UserMan
15_BT018 UserMan
Wireless Slim Speaker
Model #: BT8500BLK
User Manual
All trademarks are trademarks or registered trademarks of their respective
companies. The Bluetooth word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by Gear Head is under license.
Other trademarks and trade names are those of their respective owners.
86(5¶65(&25'
To provide quality customer service and technical support, it is suggested that you keep the
following information as well as your store receipt and this user manual.
Date of Purchase: ________________________________
Model Number: ________________________________
Product Rev Number (located below the UPC on the package): ____________________
PACKAGE CONTENTS:
Your new speaker will ship with the following items:
Wireless Slim Speaker
USB to Micro USB Charging Cable
User Manual and Warranty Information
SYSTEM REQUIREMENTS:
Works with:
Bluetooth wireless technology enabled devices.
INDICATION:
NOTE: The pictures shown in this User Manual are for demonstration purposes only. Your
speaker may look slightly different.
1. Power-on state:
Switch on the speaker. The speaker will give out a warning tone and the Bluetooth indicator light
flashes Blue.
2. Bluetooth connection:
1. Please turn your device and speaker on, then search the pairing model number ³GH_BT8500´
and pair it manually.
2.At first, the speaker will give out a warning tone, Bluetooth indicator light flashes Red and
Blue alternately during pairing, it will flash Blue slowly after successful connection and also you
will hear a warning tone .If Bluetooth speaker fails to detect any equipments, about 10 minutes,
the speaker will shut itself down automatically.
3. To make another connection, it is necessary to switch on. The Bluetooth device once
connected successfully ,which means the Bluetooth is activated ,and it will be connected
automatically next time.
3. Smart automatic quick charge: Charging the speaker, one side, insert an available USB
power cable into the Micro USB charge port of the speaker ,another side , connect with computer
USB port or an USB charger. At the beginning, the charging indicator light flashes Red and Blue
alternately at standby state or flashes Red at switch-off state, while it will finally change to Blue
light after full charging.
Power
Switch
Indicator
light
Micro USB
charge port
CONSIDERATE HINTS:
1) If connection fails, please switch off the device to restart. It may be low power with battery.
Please charge it.
2) Pairing should be in the valid distance or it may fail to work.
3) Do not turn up the volume to a fair high level constantly as this could shorten the service life
of this product or impair your hearing.
4) The Bluetooth transmission range or connectivity could be affected by low battery power. In
that case, please recharge immediately.
5) When encountering any faults during operation, please cut off the power supply and
disconnect the USB cable to prevent further damage to the speaker or other components.
TROUBLESHOOTING
Problems
Solutions
Unable to pair with other
devices
1. Check whether the speaker is still in the process of searching or
switch it off and then turn it on.
2. Check whether the speaker is in the valid range of pairing.
3. There are too many Bluetooth devices in the proximity that may cause
difficulties in connection. Please turn them off.
The sound is rather low or
distorted
1. Check the Bluetooth device¶s volume and then adjust it to a proper
level on your mobile devices or your computer.
2. Recharge the speaker if necessary.
The music stops from time to
time
1. Check whether the speaker is in the effective transmission range.
2. There is an obstacle standing between the speaker and Bluetooth
devices.
The Bluetooth indicator
remains off
1. It suggests the battery power drops quite low and retry once being
recharged.
2. Turn it on again.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Thisdevicecomplieswithpart15oftheFCCrules.Operationissubjecttothefollowingtwo
conditions:
(1)thisdevicemaynotcauseharmfulinterference,and
(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause
undesiredoperation.
Changesormodificationstothisunitnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser'sauthoritytooperatetheequipment.
