Dongguan Taide BT023 Bluetooth Speaker User Manual
Dongguan Taide Industrial Co., Ltd. Bluetooth Speaker
Contents
- 1. User Manual
- 2. user manual
user manual
TAIDE ELECTRONICS
User’s Manual for the Bluetooth Speaker
BT023
Distinguished Customers,
Thank you for purchasing this Bluetooth speaker BT023. Before getting started, please read the user's manual carefully so
as to ensure proper operation and optimized performance of this product. With stylish outer appearance, compact
structure, high fidelity sound and multi-functionality, it has obtained patents concerning its outer appearance and adopted
advanced electric and sound technology in the industry, ultimately making itself the best choice to hook up with your
devices such as tablet, cellphone and digital music player etc. perfectly by presenting you exceptional stereo effect either
you are at home, on vacation or at work.
I. Precautions
Please store and use this product at the ambient temperature;
Do not expose this product to the rain or damp surroundings;
Prevent this product from falling that could result in serious damage;
Do not dismantle, repair or modify this product on your own;
In order to avoid any risk, do not dispose this product inappropriately or toss it into the fire as there is a built-in
lithium battery.
II. Considerate Hints
1) Do not turn up the volume to a fair high level constantly as this could shorten the service life of this product or
impair your hearing;
2) When encountering any fault during operation, please cut off the power supply and disconnect the USB cable to
prevent further damage to the speaker or other components;
3) The Bluetooth transmission range or connectivity could be affected by low battery power. In that case, please
recharge immediately.
Outer Appearance and Function Buttons
/：Click to pause during Bluetooth play and click to play during Bluetooth pause. Click to receive calls at Bluetooth
state. Hold down the button to refuse the calls.
Power switch
Micro USB charge interface
3.5 Aux input interface
Indicator light and functional buttons
键键
Placement position of Mobile
phone and Tablet
Support
III. Product Parameters
Product Model：BT023
Bluetooth Specifications：Bluetooth V2.1+EDR
Transmission Distance：≤10M （depending upon operation environment and devices to which it connects)）
USB Recharge Voltage：DC 5V
Built-in Battery：Lithium battery 500mAH
Output Power: 3W×2
Frequency Response: 90Hz-20KHz
Sensitivity: 80db±2db
Signal to Noise Ratio (SNR): ≥76dB
Product Dimensions：24.5*70*48mm
Ⅳ. System Composition
1. Speaker 1 set
2．USB Power Cable 1 set
3. User's Manual 1copy
Ⅴ．Common Function Description
Power-on state: Switch on the power supply of speaker. The speaker will give out prompt tone of “click-click” and the
Bluetooth indicator light flashes at the same time.
Bluetooth Connection: after the power supply is switched on, the speaker will enter Bluetooth search state automatically.
For automatic pairing, Bluetooth equipments will ask whether to pair or not. Click pairing, Bluetooth
indicator light will flash slowly after successful connection and the speaker gives out prompt tone of
“toot”. If Bluetooth speaker fails to detect any equipment within five minutes during the power is
switched on, Bluetooth will shut itself down automatically. To make another connection, it is necessary
to switch on. This device is provided with back connection function. The Bluetooth equipments that are
connected successfully will connect automatically when Bluetooth is activated next time.
Considerate hints: if connection fails, please switch off the device to restart. It may be that the electric
quantity of battery is not sufficient. Please charge.
Bluetooth music playback: after Bluetooth connection is successful, the equipment will play music directly. Press and
hold“ ” to pause during playback; Press “ ” to play during pause.
Hand free calls: After connected with the mobile phone successfully, the speaker beeps when a call comes in. Press
to pick it up and to talk with the person involved instead of mobile phone. press again to hang up
to terminate the talk. When a call comes, Hold down the button to refuse coming calls. Double click on
“ ” button to redial the last phone number at Bluetooth connection state.
AUX playback: insert the video cable into AUX audio input interface of speaker or the audio interface of players,
and the AUX indicator light is on. The player begins to play. The device will start music
immediately. Size of volume, song selection, etc is controlled by the player at ease.
Considerate hints: at AUX playback state, press “/” to enter mute mode and press “ /”
again to release sound.
Smart automatic quick charge: charge at standby or switch-off state. Insert the MICRO USB end of USB power code
provided with accessories into USB power jack of the speaker. Another end is connected with computer
USB port or USB charger. Charging begins. The charging indicator light will be off after charging.
Ⅵ. Compatibility
Wireless：Devices configured with Bluetooth V2.1+EDR or higher version such as IPAD, IPHONE (at least the second
generation IPHONE installed the IPHONE software 3.1), IPOD TOCH and MAC as well as a majority of
intelligent phones or computers that support Bluetooth.
Bluetooth V2.1+EDR consists of protocols like A2DP, AVRCP and HFP and so on.
Ⅶ. Toubleshooting
Faults
Phenomena
Solutions
Unable to pair up with other
devices
1. Check whether the speaker is still in the process of search or switch it off and
then on.
2. There are too many Bluetooth devices in the proximity that cause difficulty in
connection. Please turn them off.
The sound is rather low or
distorted
1. Check the Bluetooth device’s volume and then adjust it to a proper level.
2. Recharge the battery
The music stops from time to
time
1. Check whether the speaker’s effective transmission range is exceeded or there
is
an obstacle standing between the speaker and other Bluetooth devices.
The Bluetooth indicator remains
off
1. It suggests the battery power drops quite low and retry once being recharged.
2. Turn it on again.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
