Dongguan Taide BT025 Bluetooth Speaker User Manual
Dongguan Taide Industrial Co., Ltd. Bluetooth Speaker
user manual
PRECAUTIONS
1. Please store and use this product at the ambient temperature;
2. Do not expose this product to the rain or damp surroundings;
3. Prevent this product from falling that could result in serious
damage;
4. Do not dismantle, repair or modify this product on your own;
5. In order to avoid any risk, do not dispose this product
inappropriately or toss it into the fire as there is a built-in
lithium battery.
CONSIDERATE HINTS
1. Do not turn up the volume to a fair high level constantly
as this could shorten the service life of this product or impair
your hearing;
2. When encountering any fault during operation, please
cut off the power supply and disconnect the USB cable to
prevent further damage to the speaker or other components;
3. The Bluetooth transmission range or connectivity could be
affected by low battery power. In that case, please recharge
immediately.
OVERVIEW
Power on/off
Play/Pause/
Hands-free Call
- : Volume down or select last track
+:Volume up or or select next track
:Power on or Power off, Hands-free call control button/
Play/Pause
BLUETOOTH OPERATION
1.Press for 3 seconds to turn on the speaker. The indicator
light will flash to detect Bluetooth enabled devices near you.
The indicator light will go off if no Bluetooth device is detected
within 5 minutes.
2.Pair the speaker with the desired Bluetooth device.
3.Press Play / Pause. + Short press select to increase the
volume, press and hold down a switch. - Short press to
decrease volume, press and hold on a jump.
4.When you want to play music from another Bluetooth
device, disconnect the speaker and restart the Bluetooth
speaker and re-pair.
Micro USB Port AUX
Volume down/Last track
SPEAKER PHONE OPERATION
Press to answer an incoming call; press to hang up
Keep pessing to reject an incoming call.
Double click to redial the last phone number.
AUX PLAYBACK OPERATION
1. Turn on the speaker.
2.Insert an 3.5mm audio cable into the aux jack, connecting
to any audio device such as mobile phones or computers with
the other end of the cable.
3.Play/pause as desired by pressing .
4.Press or shortly to increase or decrease the volume.
CHARGING THE SPEAKER
The speaker has a built-in Lithium battery. The battery is
rechargeable and provides approx 3.5 hours continuous
operation when fully charged.
Use the micro-USB cable to charge the speaker. The red
indicator light will glister. The red indicator light will go off
when the speaker is fully charged.
SPECIFICATION
Bluetooth Specifications:Bluetooth V4.0
Transmission Distance: ≤10M (depending upon operation
environment and devices to which it connects)
Built-in Battery: Lithium battery 1050mAh
Output Power: 5W*2
Frequency Response: 90Hz-20KHz
Sensitivity: 80db±2db
Signal to Noise Ratio (SNR) : ≥ 80dB
product dimension:125*58*60mm(LxWxH)
ACCESSORIES
Speaker 1*Enusic 003 Wireless
1*Micro USB charging cable
1*3.5mm Audio cable
1*User Manual
COMPATIBILITY
Device equipped with BLUETOOTH 4.0 or higher version
(for details please refer to the relevant agreements, general
specification), such as the IPAD, IPHONE (the second
generation and IPHONE with updated IPHONE 3.1 software),
IPOD TOUCH, MAC with Bluetooth, and most of smart phone
or computer support Bluetooth.
Bluetooth 4.0 including agreements as:A2DP, AVRCP, HFP.
TROUBLE SHOOTING
The sound is rather low
or distorted
Unable to pair up with
other devices
The music stops from
time to time
The Bluetooth indicator
remains off
1.Check if the speaker is still in the
process of search or switch it off
and then on.
2.There are too many enabled
Bluetooth devices within 10 metres
circle that cause difficulty in
connection. If so, please turn these
Bluetooth devices off.
1.Check the Bluetooth device's
volume and then adjust it to a
proper level.
2.Recharge the battery
Check whether the speaker's
effective transmission range is
exceeded or there is an obstacle
between the speaker and enabled
Bluetooth device.
1.It suggests the battery power
drops quite low and retry once being
recharged.
2. Turn it on again.
Faults
Phenomena
Solutions
MODEL:
Wireless Speaker
AUX D C 5V
尺寸：50*80mm
BT025
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
