Dongguan Taide BT080 Bluetooth Speaker User Manual

Dongguan Taide Industrial Co., Ltd. Bluetooth Speaker

Contents

user manual

INSTRUCTION MANUAL FOR BT080
WARNINGS
This appliance is intended for domestic household use only and should not be used for any other purpose
or in any other application, such as for non domestic use or in a commercial environment.
I. Precautions
1. Please store and use this product at the ambient temperature;
2. Do not expose this product to the rain or damp surroundings;
3. Prevent this product from falling that could result in serious damage;
4. Do not dismantle, repair or modify this product on your own;
5. In order to avoid any risk, do not dispose this product inappropriately or toss it into the fire as there is a
built-in lithium battery.
II. Considerate Hints
1. Do not turn up the volume to a high level constantly as this could shorten the service life of this product or
impair your hearing;
2. When encountering any fault during operation, please cut off the power supply and disconnect the USB
cable to prevent further damage to the speaker or other components;
3. The Bluetooth transmission range or connectivity could be affected by low battery power. In that case,
please recharge immediately.
4. Please remove audio cables for the use of Bluetooth.
III. Functional buttons
Click to pause during Bluetooth play and click to play during Bluetooth pause. Click to receive calls
at Bluetooth state. Hold down the button to refuse the calls.
Push to shortly to select songs upwards, keep pushing to decrease the volume.
Push to + shortly to select songs downwards, keep pushing to increase the volume.
Keep pushing to turn ON/OFF the speaker
Micro USB Port
On/off Switch
Aux Jack
Volume Control;
IV. Bluetooth function
1. Turn on the speaker. The white indicator light will flash to detect nearing Bluetooth enabled devices. The
white indicator light will go out if no Bluetooth device is detected within 5 minutes.
2. Pair the speaker with the desired Bluetooth device.
3. Play/pause as desired by pressing
4. When you want to play music or a movie from another Bluetooth device, disconnect and restart the
Bluetooth speaker. Then re-pair both devices.
V. AUX playback operation
1. Turn the speaker on.
2. Insert an 3.5mm audio cable into the aux jack on the back of the speaker, connecting to any audio device
such as mobile phones with the other port.
3. Press “ ” to enter mute mode and re-press to release sound.
VI. Charging the speaker
The speaker has a built-in Lithium battery. The battery is rechargeable and provides approximately 2.5 hours
of continuous operation when fully charged.
Use the micro USB cable to charge the speaker. The red indicator light will illuminate and will only go out
when the speaker is fully charged.
VII. Hands-free calls
When Bluetooth speaker is connected successfully to mobile phone, it will beep when calls are
Incoming:
Press to answer/hang up calls
Press twice to replay the last call appealed.
VIII. Bluetooth specifications
Product ModelBT080
VersionBluetooth V2.1+EDR
Transmission Distance≤10M (depending upon operation environment and devices to which it connects)
USB Recharge Voltage: DC 5V
Type of built-in battery: Lithium battery1050mAh
Output Power: 5W*2
Frequency Response: 90Hz-20KHz
Sensitivity: 80db
Signal to Noise Ratio (SNR): ≥76dB
Size :160.5 *62.1*75.6 mm
Compatibility
WirelessDevices configured with Bluetooth V4.0 or higher version such as iPad, iPhone , iPod Touch and Mac
as well as the most models of Smartphone or computers that support Bluetooth.
V4.0 Bluetooth version consists of protocols like A2DP, AVRCP and HFP and so on.
IX. Packaging includes
1 Speaker
1 User's Manual
Packaging not includes
1 USB cable for the charge of the device
1 AUX Cable
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Troubleshooting
Problem
Solution
Unable to pair up with other
devices
1. Check if the speaker is still in the process of search or switch it off and then
on.
2. There are too many Bluetooth devices in the proximity that cause difficulty
in connection. Please turn them off.
The sound is rather low or
distorted
1. Check the Bluetooth device’s volume and then adjust it to a proper level.
2. Recharge the battery
The music stops from time to
time
1. Check whether the speaker’s effective transmission range is exceeded or
there is an obstacle standing between the speaker and other Bluetooth
devices.
The Bluetooth indicator remains
off
1. It suggests the battery power drops quite low and retry once being
recharged.
2. Turn it on again.
Hints: Another trouble, please consult the dealer or an experienced radio/TV technician for help.
