Dongguan Taide BT094 Bluetooth Speaker User Manual
Dongguan Taide Industrial Co., Ltd. Bluetooth Speaker
Users Manual
TAIDE INDUSTRIAL
BT094-User Manual
Distinguished Customers,
Thank you for purchasing this Bluetooth speaker BT094. Before getting started, please read the user's
manual carefully so as to ensure proper operation and optimized performance of this product. With
stylish outer appearance, compact structure, high fidelity sound and multi-functionality, it has obtained
patents concerning its outer appearance and adopted advanced electric and sound technology in the
industry, ultimately making itself the best choice to hook up with your devices such as tablet, cellphone
and digital music player etc. perfectly by presenting you exceptional stereo effect either you are at home,
on vacation or at work.
I. Precautions
Please store and use this product at the ambient temperature;
Do not expose this product to the rain or damp surroundings;
Prevent this product from falling that could result in serious damage;
Do not dismantle, repair or modify this product on your own;
In order to avoid any risk, do not dispose this product inappropriately or toss it into the fire as there
is a built-in lithium battery.
II. Considerate Hints
1) Do not turn up the volume to a fair high level constantly as this could shorten the service life of
this product or impair your hearing;
2) When encountering any fault during operation, please cut off the power supply and disconnect
the USB cable to prevent further damage to the speaker or other components;
3) The Bluetooth transmission range or connectivity could be affected by low battery power. In that
case, please recharge immediately.
4) To extend battery lifetime, please recharge it immediately once speaker has “du du du”sound
come out in every 10 seconds.
三 Outer Appearance and Function Buttons
：Keep pushing to turn on/off the speaker；Shortly to answer phone call.
- ：Shortly push to select songs upwards, keep pushing to decrease the volume.
+ ：shortly to select songs downwards, keep pushing to increase the volume.
：Bluetooth Paired button
Function Buttons
DC AUX
IV: Product parameter
Model Number：BT094
Bluetooth spec：Bluetooth V2.1+EDR
Transmission distance：≤10M
USB power supply：DC 5V
Built in battery：800MAH
DC power supply：DC12V\1.0A
Frequency response：90Hz-20KHz
Sensitivity：80db±2db
SNR：≥70dB
V.System composition:
1. Speaker 1pcs
2. Adaptor 1pcs
3. User manual 1pcs
4. USB charging cable 1pcs
VI: Common function description
Power-on Status：Long press“”3 seconds to turn the speaker on and speaker will come out“du-du”
sound with red and blue light flash.
Bluetooth Connection：Once switched on, the speaker starts searching for other Bluetooth devices
automatically and at the same time, the bluetooth indicator goes on and off. When found a
Bluetooth device, the speaker prompts whether to pair up or not. If selected Yes, it pairs up
with the device and meanwhile, the blue indicator flashes slowly and a beep is also
generated by the speaker. If failed to detect any other Bluetooth device within 5minutes,
the speaker will shut itself down. Turn it back on again to start search. All the paired devices
will engage in automatic connection when the speaker is turned on.
Bluetooth music playback: When connected ,the speaker plays music immediately. Long press“-\+”to
adjust the volume，shortly press“-\+” to select songs。Shortly press“ ” to
play/pause music.
Call pick-up：After connected with the cellphone successfully, the speaker beeps when a call comes in.
Press“ ”to pick it up and to terminate conversation. press “ ” to hang up phone
call。Long press“ ” to reject phone call.
Aux playback：
1. Turn the speaker on.
2. Insert an 3.5mm audio cable into the aux jack on the back of the speaker, connecting to any audio
device such as mobile phones or computers with the other port.
Charging the speaker：Recharge can be performed in the standby mode or power-off situation. Before
recharging, plug the mini-USB end of the supplied USB cable to the speaker's USB port
and the other end to the USB port of the computer or the USB recharger.
VII: Compatibility
Wireless：Devices configured with Bluetooth V2.1 or higher version such as iPad, iPhone , iPod Touch and
Mac as well as the most models of Smartphone or computers that support Bluetooth.
V2.1 Bluetooth version consists of protocols like A2DP, AVRCP and HFP and so on.
III. Touble shooting
Faults Phenomena Solutions
Unable to pair up with other
devices
1. Check whether the speaker is still in the process of search or switch it
off and then on.
2. There are too many Bluetooth devices in the proximity that cause
difficulty in connection. Please turn them off.
The sound is rather low or
distorted
1. Check the Bluetooth device’s volume and then adjust it to a proper
level.
2. Recharge the battery
The music stops from time to
time
1. Check whether the speaker’s effective transmission range is exceeded
or there is
an obstacle standing between the speaker and other Bluetooth devices.
The Bluetooth indicator
remains off
1. It suggests the battery power drops quite low and retry once being
recharged.
2. Turn it on again.
Warning
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment .
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
