Dongguan Taide BT140 Bluetooth Speaker User Manual
Dongguan Taide Industrial Co., Ltd. Bluetooth Speaker Users Manual
user manual
BT140 User’s Manual
PRECAUTIONS
1. Please store and use this product at the ambient temperature;
2. Do not expose this product to the rain or damp surroundings;
3. Prevent this product from falling that could result in serious damage;
4. Do not dismantle, repair or modify this product on your own;
5. In order to avoid any risk, do not dispose this product inappropriately or toss it into the fire as there is
a built-in lithium battery.
CONSIDERATE HINTS
1. Do not turn up the volume to a fair high level constantly as this could shorten the service life of this
product or impair your hearing;
2. When encountering any fault during operation, please cut off the power supply and disconnect the
USB cable to prevent further damage to the speaker or other components;
3. The Bluetooth transmission range or connectivity could be affected by low battery power. In that case,
please recharge immediately.
OVERVIEW
Volume down
Volume up
Power on/ Power off
Play/ Pause/ Hands-free Call
Next track
Last track
Power on or Power off
Hands-free call control button/Play/Pause
Volume up
Volume down
select last track
select next track
BLUETOOTH OPERATION
1. Press for 3 seconds to turn on the speaker. The indicator light will flash to detect Bluetooth enabled
devices near you. The indicator light will go off if no Bluetooth device is detected within 5 minutes.
2. Pair the speaker with the desired Bluetooth device.
3. Press on top of the speaker to play/pause. Press shortly to decrease the volume, press shortly
to select last track. Press shortly to increase the volume. Press shortly to select next track
4. When you want to play music from another Bluetooth device, disconnect the speaker and
restart the Bluetooth speaker and re-pair.
SPEAKER PHONE OPERATION
Press to answer an incoming call; press to hang up.
Keep pessing to reject an incoming call.
Double click to redial the last phone number.
AUX PLAYBACK OPERATION
1. Turn on the speaker.
2. Insert an 3.5mm audio cable into the aux jack, connecting to any audio device such as mobile phones
or computers with the other end of the cable.
3. Play/pause as desired by pressing ，control the volume by pressing or .
CHARGING THE SPEAKER
The speaker has a built-in Lithium battery. The battery is rechargeable and provides approx 3.5 hours
continuous operation when fully charged.
Use the micro-USB cable to charge the speaker. The red indicator light will glister. The red indicator light
will go off when the speaker is fully charged.
SPECIFICATION
Product Model：BT140
Bluetooth Specifications：Bluetooth V4.2
Transmission Distance：≤10M (depending upon operation environment and devices to which it connects)
USB Recharge Voltage: DC 5V-500mA-1000mA
Built-in Battery: Lithium battery 2500mAh*2/3.7V
Output Power: 8W*2
Frequency Response: 90Hz-20KHz
Sensitivity: 80db±2db
Signal to Noise Ratio (SNR):≥80dB
product standard：203*72.8MM
Accessories
Speaker * 1
Micro USB charging cable * 1
Manual *1
Aux cable*1
COMPATIBILITY
Device equipped with BLUETOOTH 4.2 or higher version (for details please refer to the relevant
agreements, general specification), such as the IPAD, IPHONE (the second generation and IPHONE with
updated IPHONE 3.1 software), IPOD TOUCH, MAC with Bluetooth, and most of smart phone or
computer support Bluetooth.
Bluetooth 4.2 including agreements as：A2DP, AVRCP, HFP
Trouble shooting
Faults Phenomena
Solutions
Unable to pair up with other
devices
1.Check if the speaker is still in the process of search or switch it off and then
on.
2.There are too many enabled Bluetooth devices within 10 metres circle that
cause difficulty in connection. If so, please turn these Bluetooth devices off.
The sound is rather low or
distorted
1.Check the Bluetooth device’s volume and then adjust it to a proper level.
2.Recharge the battery
The music stops from time to
time
Check whether the speaker’s effective transmission range is exceeded or
there is an obstacle between the speaker and enabled Bluetooth device.
The Bluetooth indicator
remains off
1.It suggests the battery power drops quite low and retry once being
recharged.
2. Turn it on again.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
