Dongguan Taide BT183 Bluetooth Speaker User Manual
Dongguan Taide Industrial Co., Ltd. Bluetooth Speaker
user manual
THANK YOU
User's Manual
Bluetooth® Speaker
Precautions
Please store and use this product at room temperature.
Do not expose this product to rain or damp surroundings.
Prevent this product from falling as that could result in serious damage.
Do not dismantle, repair or modify this product on your own.
In order to avoid any risk, do not dispose this product inappropriately or toss
it into the re as there is a built-in lithium battery.
Tips
1) Do not turn up the volume to maximum for a long time as this could
shorten the service life of this product or impair your hearing.
2) When encountering any fault during operation, please cut off the power
supply and disconnect the USB cable to prevent further damage to the
speaker or other components.
3) The Bluetooth transmission range or connectivity could be affected by low
battery power. In that case, please recharge immediately.
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
□Reorient or relocate the receiving antenna.
□Increase the separation between the equipment and receiver.
□Connect the equipment into a circuit different from that to which the
receiver is connected.
□Consult the dealer or an experienced radio TV technician for help Changes or p.
WARNING: This appliance is intended for domestic household use only and
should not be used for any other purpose or in any other application, such as
for non domestic use or in a commercial environment.
WARNING: The ventilation should not be impeded by covering the ventilation
openings with items such as newspapers, table cloths, and curtains. Allow at
least a 10 cm gap all around the product.
WARNING:
on the speaker.
Item #1000 000 000
Model #BT183 Product Parameters Compatibility
Trouble Shooting
Common Function Description
Part Parameters
Product Model
Bluetooth Specications
Transmission Distance
USB Recharge Voltage
Built-in Battery
Output Power
Product Dimensions
BT183
Bluetooth 2.1+EDR
≤10M (depending upon operation environment and
devices to which it connects)
DC 5V 500mAh
1050mAh
3W×2
180 x 75 x 54mm
Thank you for purchasing this Bluetooth® speaker (BT183). Before getting started please
read the user's manual carefully to ensure proper operation and optimal performance of
this product. This item is under multiple patents covering the appearance, advanced
electronics and sound technology making this speaker the best choice to connect with your
wireless devices. The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth
SIG, Inc. and any use of such marks by Dongguan Taide Industrial Co., Ltd. is under license.
Other trademarks and trade names are those of their respective owners.
A B C
Part Description
ATurn up Volume/Next
BTurn down Volume/Previous
CPause/Play/Pick up the call Button
D E F
G
Part Description
DAudio In
EMicro USB 5V
FPower Switch
GCharging Cable
Phenomena
Faults Solutions
Unable to pair up with other devices
The sound is rather low or distorted
The music stops from time to time
The Bluetooth indicator remains off
1. Check whether the speaker is still in the
process of search or switch it off and then
on.
2. There are too many Bluetooth devices in
the proximity that cause difculty in
connection. Please turn them off.
1. Check the Bluetooth device’s volume and
then adjust it to a proper level.
2. Recharge the battery.
1. Check whether the speaker’s effective
transmission range is exceeded or there
is an obstacle standing between the
speaker and other Bluetooth devices.
1. It suggests the battery power drops quite
low and retry once being recharged.
2. Turn it on again.
G
E
AUX cable （not included）
E
Power-on Status: Switch the Power Button to turn the speaker on and it beeps
simultaneously with the blue indicator flashing.
Bluetooth Connection: Once switched on, the speaker starts searching for other
Bluetooth technology equipped devices automatically and at the same time, the blue
indicator flashs. When Bluetooth technology equipped device is found, the speaker
prompts whether to pair up or not. If selected Yes, it pairs up with the device and
meanwhile, the blue indicator flashes slowly and the speaker beeps. If failed to
detect any other Bluetooth technology equipped device within 5 minutes, the
speaker will shut itself down. Turn it back on again to start search. All the paired
devices will engage automatically the next time.
Hints: Please recharge when the battery is low, otherwise it may fail to connect.
Music Playback: When connected, the speaker plays immediately. Press (A) and (B)
to select tracks upwards or downwards.
Long press (A) and (B) to adjust the volume. While playing music, press (C) to pause
and resume.
Call Pick-up: After connected with the cellphone successfully, the speaker beeps
when a call comes in. Press (C) to pick it up; and to terminate conversation, press (C)
one more time.
AUX Playback: Use the supplied audio cable to connect the speaker to another music
player such as computer by plugging one end to the speaker's AUX port and the other
end to the music player's audio port. When the music player starts playing music, the
speaker sounds right away. Tracks can be selected and volume adjusted only by the
music player.
Note: 3 buttons of (A), (B) and (C) are functionless in the AUX playback mode and the
volume is controlled by the music player.
Intelligent Quick Recharge: Recharge can be performed in the standby mode or
power-off situation. Before recharging, plug the micro-USB end of the supplied USB
cable to the speaker's USB port and the other end to the USB port of the computer or
the USB recharger. When fully recharged, the red indicator goes off.
This speaker is compatible with most Bluetooth technology equipped
devices congured with Buletoot 2.1+EDR or higher version. This would
include most tablets, smart phones or computers that support Bluetooth
2.1+EDR which consists of protoclos like A2DP, AVRCP and HFP.
Outer Appearance and Function Buttons
Multifunction Control Button
1. Jump to the next track/Turn up the volume: Press button (A) to
select tracks or long press it to bring up the volume.
2. Jump to the last track/Turn down the volume: Press button (B) to
select tracks or long press it to turn down the volume.
3. Pause/Play/Pick up the call: Press button (C) to pause, to resume
normal operation or pick up the incoming calls.
BC
modifications not evpressly approved by the
party responsible for compliance could void
the user's authority to operate the equipment
