Dongguan Taide TWSBT142 Bluetooth Speaker User Manual
Dongguan Taide Industrial Co., Ltd. Bluetooth Speaker Users Manual
User Manual
INSTRUCTION MANUAL
WARNINGS
This appliance is intended for domestic household use only and should not be used for any other purpose
or in any other application, such as for non domestic use or in a commercial environment.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine,
fire or the like.
OVERVIEW
Power on or Power off.
short press for entering pairing mode.long press to cancel the pairing mode.
＋ Increase volume or select next track
－ Decrease volume or select last track
Micro USB
Charging Port
Switch on/off,Play/Paus
Volume control
Indicator
BLUETOOTH OPERATION
1. Press for 2 seconds to turn on the speaker. The indicator light will flash to detect Bluetooth enabled
devices near you. The indicator light will go off if no Bluetooth device is detected within 5 minutes.
2. Press on to back of the speaker to play/pause. Push＋shortly to select next track, push and hold ＋
to increase the volume. Push－shortly to select last track, push and hold－to decrease the volume.
3. When you want to play music or movie from another Bluetooth device, disconnect the speaker and
restart the Bluetooth speaker and re-pair.
CHARGING THE SPEAKER
The speaker has a built-in Lithium battery. The battery is rechargeable and provides approx 3.5 hours
continuous operation when fully charged.
Use the micro-USB cable to charge the speaker. The red indicator light will illuminate. The red indicator
light will go off when the speaker is fully charged.
SPEAKER PHONE OPERATION
Press to answer an incoming call.
Press to hang up.
Keep pessing to reject an incoming call.
Double press to redial the last phone number.
SPECIFICATION
FCC ID: OYCTWSBT142
Product Model：TWS BT142
Bluetooth Specifications：Bluetooth V4.2
Transmission Distance：≤10M (depending upon operation environment and devices to which it connects)
USB Recharge Voltage: DC 5V
Built-in Battery: Lithium battery 500mAh*2
Output Power of single speaker: 5W/5W
Frequency Response: 90Hz-20KHz
Sensitivity: 80db±2db
Signal to Noise Ratio (SNR):≥80dB
Accessories
Speaker *2
Micro USB charging cable * 2
User Manual *1
Touble shooting
Faults Phenomena
Solutions
Unable to pair up with other
devices
1. Check whether the speakers are still in the process of search or switch
it off and then on.
2. There are too many Bluetooth devices in the proximity that cause
difficulty in connection. Please turn them off.
The sound is rather low or
distorted
1. Check the Bluetooth device’s volume and then adjust it to a proper
level.
2. Recharge the battery
The music stops from time to
time
1. Check whether the speaker’s effective transmission range is exceeded
or there is an obstacle standing between the speaker and other
Bluetooth devices.
The Bluetooth indicator
remains off
1. It suggests the battery power drops quite low and retry once being
recharged.
2. Turn it on again.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
