Dongguan Taide WBT026 Wireless speaker User Manual
Dongguan Taide Industrial Co., Ltd. Wireless speaker Users Manual
User Manual
Dear user,
Thank you very much for choosing WBT026 Speaker. Please read this user manual carefully in
order to operate this device in the correct manner.
I. THINGS TO REMMEBER.
Please store and use this product at normal temperature;
DO NOT expose this product to rain or dampness
DO NOT toss this product and prevent it from falling and being damaged
DO NOT disassemble, repair and modify this product
As it is inbuilt with lithium battery, DO NOT place it in fire to avoid danger!
II. GENTLE REMINDER
1. To prolong the speaker‘s life span and for your well being, please don't listen to music with max
volume for a long time to avoid hearing damage.
2. When something is wrong with the speaker, please immediately put it of, unplug the USB, to
prevent the speaker and other parts from getting damaged.
III. OVERVIEW
Function:
Power on or Power off
Handsfree icon
Mode
AUX line in
DC 5V jack
Battery indicator icon
Bluetooth indicator icon
Wifi indicator icon
Decrease volume
Increase volume
Play or Pause
Scene Lamp Switch
Increase Lightness
Decrease Lightness
IV. SPECIFICATIONS
Model: WBT026
Bluetooth specification: Wifi MTK, Bluetooth V2.1
Transmission distance : ≦ 10M
USB charging voltage: DC 5V/500mA
Built-in battery: Lithium battery, 4000mAh
Output power: 6W x 2
Frequency response: 90Hz-20KHz
Sensitivity: 80db±2db
S/N ratio: ≥ 76dB
V. PACKING LIST
1. Speaker * 1
2. USB cable * 1
3. User manual * 1
VI. FUNCTION DESCRIPTION
WIFI OPERATION
1. Turn on the speaker. The white indicator light will flash, select the wifi ID and open your App to
searching the speaker, press to connect the speaker.
2. Log in your Amazon ID.
3. You can play the music by your special App.
4. Push to button each time, then talk to the speaker to select the music or go shopping etc.
5. Play/pause as desired by pressing.
BLUETOOTH OPERATION
6. Turn on the speaker. Press mode button to Bluetooth mode. The blue indicator light will flash
to detect Bluetooth enabled devices near you. The blue indicator light will go out if no
Bluetooth device is detected within 5 minutes.
7. Pair the speaker with the desired Bluetooth device.
8. Play/pause as desired by pressing.
AUX PLAYBACK OPERATION
1. Turn on the speaker.
2. Insert a 3.5mm audio cable into the aux jack on the back of the speaker, connecting to any
audio device such as mobile phones or computers with the other port.
3. press to enter mute mode and re-press to release the sound.
LAMP LIGHT OPERATION
1. Press to turn on the lamp light
2. Press to control the lightness.
CHARGING THE SPEAKER
The speaker has a built-in Lithium battery. The battery is rechargeable and provides approx 18
hours of continuous operation when fully charged.
Use the micro-USB cable to charge the speaker. The red indicator light will illuminate. The red
indicator light will go of when the speaker is fully charged.
VIII. COMPATIBILITY
Device equipped with BLUETOOTH 2.1 or higher version, such as the iPad, iPhone, iPod Touch
as well as a majority of "Smartphone” that support Bluetooth.
Bluetooth 2.1 including agreements as：A2DP, AVRCP, HFP.
VIII. TROUBLESHOOTING
PROBLEM
SOLUTION
Failure in connection
and pairing
1. Inspect whether the speaker is in search mode or restart
the devise.
2. If many Bluetooth enabled devices are switched on then it
will cause difficulty in searching the device. So, please
switch off other Bluetooth devices.
The sound is less or
distorted
1. Inspect the volume of the Bluetooth devices and adjust the
volume.
2. The power of the battery might be insufficient. Please
charge the speaker.
Discontinuous music
Check if the effective connection distance is exceeded or
whether there are obstacles between the speaker and the
bluetooth device.
The indicator for
Bluetooth mode is not
ON
1. This indicates that the power of the battery is not sufficient.
Please try again after charging it.
2. Restart the device.
Hints: Another trouble, please consult the dealer or an experienced IT technician for help.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
This device is acting as slave and operating in the 2.4 GHz (2412 ~2462 MHz) band.
Ad Hoc function is supported but not able to operate on non-US frequencies.
FCC Radio Frequency Exposure Statement
The device has been evaluated to meet general RF exposure requirements. The device
can be used in mobile/portable exposure conditions. The min separation distance is
20cm.
