Dongguan xiangshang smart Technology XSSAM01 Round mini socket User Manual
Dongguan xiangshang smart Technology Co.,Ltd Round mini socket
User Manual
10 11 12 13 14 17
1615
9
Aenon: Due to Google Home APP's known bug, you
could use only one Google account to control “Home
Control Acon”. If you sign in Google Home APP with
several accounts, only the first account you signed in can be
used for “Home Control”.
Tap “Home Control” in the hamburger menu on the Google
Home App's Home Page, then tap “+”.
Link Smart Life account in
Home Control
Control your smart devices
through Google Home
Find “Smart Life” in the list. In the new window, select your
Smart Life account region, type your Smart Life account and
password, then tap “Link Now”. Aer you assign rooms for
devices, your devices will be listed in the Home Control
page.
Quick Guide of Using Amazon Echo
Preparation
Amazon Alexa APP and account.
Smart Life APP and account.
An Echo device, including Echo, Echo Dot and Echo Tap.
Smart device.
Sign in with Smart Life account, add the device, then
change the name to a easily recognized word or phrase, like
“bedroom light”.
Set up Echo with Amazon Alexa APP
Sign in with Amazon account. Tap the Homepage on the
top le, tap “Sengs” and “Set up a new device”. Then
follow the instrucons.
Select an Echo device, long press the dot buon on the
device unl the orange light shows up and tap “Connue”.
Then select your Wi-Fi network and connect it to your
device according to the instrucons. This may take several
minutes.
Enable our skill in Alexa APP
Tap the Homepage, select “Skills”, then search “Smart Life”.
Select “Smart Life” and tap “Enable Skill” to enable the
Smart Life Skill.
You will be redirected to the account link page. Type your
Smart Life account and password, do not forget to select
the country/region where your account belongs to. Then
tap “Link Now” to link your Smart Life account. When
“Alexa has been successfully linked with Smart Life” shows
up, you can leave this page. (Note: If a Smart Life account
has been linked before, you can use it directly, or you can
also tap “Disable Skills” to remove it).
Control your smart device
through Echo
Now you can control your smart devices through Echo. You
can use following commands to control your devices
(e.g.,bedroom light):
Alexa, turn on/off bedroom light.
Alexa, set bedroom light to 50 percent.
Alexa, brighten/dim bedroom light.
Alexa, set bedroom light to red.
You can also set up groups in Alexa APP. Tap “Create group”,
give your group a name like “my smart lights”, select
devices to add them in this group, then tap “Save”. Now
you can control your devices by group. If you say “Alexa
turn on my smart lights”, all the lights will be turned on.
Echo need to discover your smart device before the
control.
You can say “Alexa, discover device” to Echo, or you can
also tap “Discover Device” on APP to discover the smart
devices. Discovered devices will be shown in the list. (Note:
Every me you change the name of devices on Smart Life
APP, Echo must re-discover devices before the control.)
Now you can control your smart device through Google
Home. Take bedroom light as the example, the supported
voice commands are as below:
Ok Google, turn on/off bedroom light.
Ok Google, set bedroom light to 50 percent.
Ok Google, brighten/dim bedroom light.
Ok Google, set bedroom light to red.
.
.
.
.
.
.
.
.
.
.
.
.
. .
.
.
.
.
.
FCC Warnning:
This equipment has been tested and found to comply
with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Caution: Any changes or modifications to this device
not explicitly approved by manufacturer could void
your authority to operate this equipment.
This device complies with part 15 of the FCC
Rules.
Operation is subject to the following two conditions:
(1)This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This equipment should be installed
and operated with minimum distance 20cm between
the radiator and your body.
This transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter.
Mini Smart Socket
Instruction
Scan the QR code to download “Smart Life” APP. You can
also search “Smart Life” in either APP store or Google Play
to install the APP.
Open the “Smart Life” APP, tap “Register” to register a
“Smart Life” account with your phone number or E-mail.
Then sign in the APP.
Download & Registration
1
.
.
2
Parameters
.Product Name: Round mini socket
.Model: XS-SAM01
.Rated Voltage: 100V-240V AC 50HZ/60HZ
.Rated Current: 10A(Max)
.Max. Power: 1100W
.Material: PC
.Support System: Android & IOS
Power Socket
On/Off Buon
Press Long Time
Restore Facory Sengs
Make sure your smart device is energized and your mobile
phone is connected to your Wi-Fi. Long press the power
buon for more than 5 seconds unl the indicator light
begin to flash quickly (2 mes per second about), this
means the device is already for configuraon.
Open your “Smart Life” APP and tap “ + ” on the top right
of the APP. Select Device Type, tap it and “Confirm indicator
light rapidly blink”. These will automacally fetch the
password of the Wi-Fi network that your mobile phone
connects to. Then tap “Confirm” to connect to the device.
When appears “Successfully added 1 device”, it means the
connecon is complete and your device will be listed in
your APP list.
If failed in Easy Mode, users could add devices in AP Mode.
Long press the power buon for more than 5 seconds unl
the indicator light flash quickly, then long press it for
another 5 seconds unl the indicator light flash slowly.
Tap “ + ” on the top right of the APP, Select Device Type.
Then tap “AP Mode” on the top right, “Confirm indicator
light slowly blink” and “Confirm”. Tap “Connect now” to go
to the WLAN Sengs interface in your mobile phone and
select the Wi-Fi network named “SmartLife_XXXX” to
connect it.Return to the “Smart Life” APP, the connecon
will start automacally.
When appears “Successfully added 1 device”, it means the
connecon is complete.
Add Devices in AP Mode
3
Add Devices in
Easy Mode(Recommend)
.
.
.
.
.
.
Now you can control your Mini Smart Socket via your
mobile phone APP anyme and anywhere (Make sure your
mobile phone and Mini Smart Socket are all connected to
the network).
You can share your devices with your friend or family aer
you add your devices successfully. More funcons you will
enjoy refer to the picture.
1. Please check if there is damage caused by transportaon,
if yes, please contact supplier for replacement.
2. Please follow the specificaon instrucon and noce to
keep products in a good and safe use condion.
3. Put the socket in proper condion and out of reach of
the children.
4. Plug in fully to the socket while using.
5. The total power of being electric connected appliances
could not be bigger than the maximum power of the
socket.
6. Do not disassemble or install the socket, otherwise there
may cause security risks.
Preparation
A Google Home device, or an Android phone with Google
Assistant.
Latest Google Home APP (Android only) and a Google
account.
The devise display language must be set to English US.
Smart Life APP and a related account.
Smart device.
Sign in with Smart Life account, add the device, then
change the name to a easily recognized word or phrase, like
“bedroom light”.
6
Notices
Quick Guide of Using Google Home
.
.
.
.
.
5
4
Set up Google Home with
Google Home APP
Open the Google Home APP and sign in a Google account.
Then connect the Google Home APP with your Google
Home device according to the Instrucon of Google Home.
Choose the Wi-Fi network you want to connect to your
Google Home. Then connect it to your Google Home
according to the Instrucon.
Make sure your Google Home APP and Google Home are in
the same Wi-Fi network.
87
.
.
