Apartment Complex/Gated Communities • College Residence Halls • Mixed Use Buildings
Residential • Commercial/Industrial • Parking • Self Storage • Maximum Security
Access control
Door &
Gate Locks
MaGnetic & eLectric
Door Sensor
Permanent
Magnet
Mechanical
Sensor
Shear Locks | Magnetic Door Locks
Gate Locks | Magnetic Gate Locks
Deadbolts | Electric Door & Gate Locks
Custom Mounting
Welding
Weld the pre-drilled brackets directly to
the gate before attaching the magnetic
lock, allowing for hassle-free installation,
maintenance & replacement.
Magnet shifts armature into place upon closure, creating a tight
seal but quickly releasing upon entry for easy, reliable access.
Magnetic Tight Closure
High Strength
Shear locks offer 2000 lbs. (907Kg)
of holding force by combining high
strength magnets with mechanically
interlocking steel tabs that click into
place and help prevent forced entry.
Brackets can be fitted to pedestrian
and vehicular gates of any shape or
angle, allowing for custom mounting
of magnetic locks with up to 1200
lbs. (544Kg) of holding force.
Hardware provided.
Dual Sensors
Stainless steel deadbolts can't be fooled, with both
magnetic and mechanical sensors, door closure is
ensured before securing deadbolt.
Adjustable Auto Re-lock
Locked when
energized, and in the
event of power failure
will unlock for safe
exit and entry.
Set a custom automatic re-lock time of 0-5
seconds – instantly relocking upon closure
for high security applications or with a longer
grace period for convenient delivery access.
Fail-Safe
Access control
Features
• Built-in relay on selected models for gate lock status indication
• Predrilled/tapped electrical enclosure conduit holes
• Mounting brackets are predrilled/tapped for easy welding to the gate
and assembly to the mag lock (brackets included), making for easy
installation, repairs, and replacement
DKGL-S12 1200 Lb
Maglock and Armature with Welding Mounting Brackets
DKGL-S6 600 Lb
Maglock and Armature
DKML-S12 1200 Lb
Armature and Maglock
DKML-S6 600 Lb
Armature and Maglock
Single Gates
600 and 1200 Lb (272 and 544 Kg) lock strength
• LED (R/G) lock status indicates if the lock is secured
(green) or not secured (red)
• Built-in time delay eliminates the need for costly
add-on exit delay timers
• Shear locks provide both a magnetic and mechanical
connection offering superior locking strength
Single and Double Doors
300, 600, 1200, and 2000 Lb lock strength
(136, 272, 544, 907 Kg)
• Superior reliability, strength, and safety
• Fast and easy installation
• No residual magnetism
• Fail-safe operation assures that fire exit
paths are unlocked during power outages
• MOV surge protection protects locks from
transient voltage spikes
• No moving parts to wear out or break
assures a long life cycle
Magnetic Gate & Door Lock Features
Magnetic locks can
be programmed to be
automatically unlocked
in emergency situations
such as fires or power
outages, ensuring fail-safe
escape routes for
all occupants.
No moving parts to wear
out or break which assures
a locking device with an
extremely long life
Emergency Safety
Long Lasting
DKGL Magnetic Locks
for Vehicular Gates
DKML Magnetic Locks for Doors
Available for double door
applications - DKML-S12 and
DKML-S6
DKEB Deadbolt DKES-C1 Strike DKES-C2 Strike
Electric dead bolts
• Provide superior security and safety with
fail-safe operation
• Operate on 12-volt DC power
• 5/8 inch (15.875 mm) stainless steel bolt
with 5/8 inch throw
Electric strikes
• Suitable for most cylindrical door locks
• Easily retrofit into most door or
gate frames
• Operate on 12-volt DC power
• Door strikes are available in both
fail-safe and fail-secure models
• 11/32" (8.73mm) or 20/32"
(15.875mm) keeper
DKML-S6 600 Lb
Armature and Maglock
DKML-S3 300 Lb
Armature and Maglock
DKSL-M20 2000 Lb
Armature and Maglock
Single and Double Doors
300, 600, 1200, and 2000 Lb lock strength
(136, 272, 544, 907 Kg) Single Door or Gate
Strikes & Deadbolts
Electric Gate & Door Lock Features
Program a custom automatic re-lock
time of 0-5 seconds for different
access points and uses.
Holding force of 300 Lb (136Kg)
to 2000 Lb (907Kg)
Strength
Adjustable Auto Re-lock Dual Security
Deadbolt door locks have both
mechanical and magnetic closure
sensors for ensured security and will
automatically lock even when the
power is disconnected.
DKML Magnetic Locks for Doors DKE Electric Locks for
Doors & Gates MAGNETIC GATE LOCKS MAGNETIC DOOR LOCKS ELECTRIC LOCKS
DKGL-S12
1216-080
DKGL-S12
1216-081
DKGL-S6-1 DKML-S12
DKML-S6
DKML-M6
DKML-S3
DKML-M3
DKSL-M20
Shear
Strikes
DKES-
Deadbolts
1200 Lb
(544Kg) 4 4 –4– – – – –
600 Lb
(272Kg) – – 4–4– – – –
300 Lb
(136Kg) – – – – – 4– – –
2000 Lb
(907Kg) – – – – – – 4– –
Mounting Surface Surface Surface Surface Both* Both* Mortise Mortise Mortise
12 Volt DC 4 4 4 4 4 4 4 4 4
24 Volt DC 4 4 4 4 4 4 4 – –
LED
green/red 4** 4**
Double door 4 4
Fail-Safe 4 4 4 4 4 4 4 4 4
Fail-Secure – – – – – – – 4–
Status Relay –4 4 4 4 –4– –
Accessories
Compatible with these DKS
telephone and access devices
Basic Telephone Access PlusKeypadsStand Alone Card Readers 1830 Series
Back-up Power Supply / Battery Charger
• Magnetic locks power supplies for
backup DC power when primary
(AC) power is interrupted
• Features filtered and electronically
regulated output, as well as short
circuit and thermal overload
protection
• Built-in battery charger
• Enclosure accommodates up to two
(2) 12 VDC / 7AH batteries
• Batteries are not included with these systems
Transformer Box and Transformers
• Magnetic Locks 12,
24 Volt DC
• Transformer box
holds up to 4
transformers, and is
suitable for indoor
and outdoor use
• DC transformers and
Regulated DC transformers available
• Use the 350mA transformers for 300 Lb (136Kg) locks,
500mA transformers for 600 Lb (272Kg) locks and the
500mA or 1000mA transformer for 1200 Lb (544Kg) locks
MAGNETIC GATE LOCKS MAGNETIC DOOR LOCKS ELECTRIC LOCKS
DKGL-S12
1216-080
DKGL-S12
1216-081
DKGL-S6-1 DKML-S12
DKML-S6
DKML-M6
DKML-S3
DKML-M3
DKSL-M20
Shear
Strikes
DKES-
Deadbolts
1200 Lb
(544Kg) 4 4 –4– – – – –
600 Lb
(272Kg) – – 4–4– – – –
300 Lb
(136Kg) – – – – – 4– – –
2000 Lb
(907Kg) – – – – – – 4– –
Mounting Surface Surface Surface Surface Both* Both* Mortise Mortise Mortise
12 Volt DC 4 4 4 4 4 4 4 4 4
24 Volt DC 4 4 4 4 4 4 4 – –
LED
green/red 4** 4**
Double door 4 4
Fail-Safe 4 4 4 4 4 4 4 4 4
Fail-Secure – – – – – – – 4–
Status Relay –4 4 4 4 –4– –
* DKML-S6 & S3 are surface mount. DKML-M6 & M3 are mortise mount.
** Models available with and without LED light.
