•Voiceanddata(PCprogramming)overa

cellularconnection

•EasysetupbyactivatingAT&T4GLTE

cellularservice

•Easytoinstall–notrenching,nowiring

•Turnremotelocationsintoserviceablesites

•BackwardscompatiblewitholderDKS

TelephoneEntrysystems

•Celllinecanbesplitforguardtower/

dualentry

TELEPHONE ENTRY

CELLULAR

CONNECTION

unlimited range

nationwidecoverage

Access control SolutionS

service plans

nolongdistancefees

voice & data

andvoiceonlymodels

turnkey

easyprogrammingfromyourcomputer

withsuppliedDKSsoftware

a sustainable wireless solution for connecting

managers and users to access control systems

Voice & Data (programming)

TheModels1800-080and1800-081areafullycapable

cellularinterfacethatprovidesbothvoicecommunication

andprogrammingviatheAT&T4G-LTECellularnetwork.

TheDKSCellularserviceistheonlyservicethatwill

“push”theprogrammingdatadirectlyfromyourcomputer

totheentrysystemviathecellularnetwork.

Othersystemsclaimtheycanbeprogrammedviathe

cellularnetwork,butitisaccomplishedwithaseriesof

textmessagestotheentrysytem...imaginetryingto

programhundredsoftelephonenumbers,names,card

codes,holidayschedules,permissionlevels,holdopen

timezones,etc.withtextmesages.

Usethe1800-080withthefollowingDoorKingentry

systems:1833,1834,1835,1837,1838.

Usethe1800-081withthefollowingDoorKingentry

systems:1802AP,1808AP,1810AP,1812AP,1838AP

Voice Only

TheModel1801-080isavoiceonlycellulardeviceandis

designedtooperateonnon-pcprogrammablesystems.

Voicecommunicationonly,andcanbeusedinlieuof

POTSlines.

Programmingordatatransferisnotpossiblewithvoice

onlydevice.Thisalsoincludesmodemprogramming

(modemtomodemcommunicationisnotpossibleovera

cellularnetwork).

Usethe1801-080withthefollowingDoorKingentry

systems:1802,1803,1808,1810,1812.

AT&T 4G LTE Network

BothcellularmodelsoperateontheAT&T4G-LTEcellular

network(whereavailable).

Amonthlysubsciptionfeeapplies,justlikeyourcellphone.

DKSCellularserviceprovidesverycompetativemonthly

ratesforyourcellularservice.

DKSCellularserviceisavailableinallstatesincluding

AlaskaandHawaii.ItisalsoavailableinPuertoRico,U.S.

Territories,CanadaandMexico.

DKSCellularserviceisnotavailableinothercountries.

CheckthedoorkingwebsiteforalinktofindAT&T

coverageatyourlocation:doorking.com/cellular.

Electrical

16VACinputpower(transformerprovided).

Miscellaneous

Environmental:10ºFto145ºF(-12°C to 62°C)

Shippingweight

Voice+Data(1800-080,1800-081)

approximately10Lbs(4.5 kg)

Voiceonly(1801-080)approximately8Lbs(3.63 kg)

FCC(US)DUF6VT-12874-OT-T

DOC(CAN)17364528A

CONNECTION

TELEPHONE ENTRY

Technical Features

Distributedby:

Access Control Solutions since 1948

MeMber:

120GlasgowAvenue,Inglewood,California90301U.S.A.

Tel:310-645-0023FAX:310-641-1586www.doorking.com

©2017AllRightsReserved.Productspecificationsmaychangewithoutnotice.

Rev.9/17

Voice + Data

1800-080/1800-081

11.5”Wx12.25”Hx6.0”D

(292mm W x 317.5mm H x 152.4mm D)

Voice Only

1801-080

6.625”Wx9.875”H4.0”D

(168.3mm W x 250.8mm H 101.6 mm D)

entry at&t cellular for use witH power

systems 4g lte service dKs entry systems

up to 2

1830 series Yes Voice & 1833, 1834, 1835, 16 VAC input

systems Data 1837, 1838

up to 2

Access Plus Yes Voice & 1802AP, 1808AP, 16 VAC input

systems Data 1810AP, 1812AP, 1838AP

up to 2

1800 series Yes Voice 1802, 1803, 16 VAC input

systems only 1808, 1810, 1812

1800-080

1800-081

1801-080
