PRICE LIST - MARCH 2018

ANNUNCIATORS

ELECTROMAGNETIC LOCKS

POWER SUPPLIES & CONTROLLERS

3000 SERIES ELECTRIC STRIKES

8000 SERIES ACCESS CONTROL SYSTEMS

ACCESSORIES

4000 SERIES

5000 SERIES

6000 SERIES

7000 SERIES

DORTRONICS SYSTEMS, INC

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963

3/01/2018

TABLE OF CONTENTS

PHONE: (800) 906-0137

FAX: (631-725-8148

www.dortronics.com

MAGNETIC LOCKS

PART #

DESCRIPTION

LIST PRICE

MINI SERIES CABINET & DRAWER LOCKS

MINI-MITE LOC

K

MM-300 300 LB MINI-MITE LOCK 12/24 VDC (DUAL VOLTAGE)

WITH STAINLESS STEEL HOUSING $210.00

(3-1/4" x 2-1/4" x 1-3/4" OVERALL)

MM-300 TJMM-300 FOR INSWING APPLICATIONS INCLUDES

Z-BRACKET $310.00

MM-D1 ACCESSORY ARMATURE ANGLE BRACKET $50.00

MM-D2 TJ BACK MOUNTING BRACKET $50.00

MM-ZD1 MINI MITE Z- BRACKET $80.00

NARROW MINI-MITE LOC

K

MM-ZD1

MM-300N 300 LB NARROW LINE MINI-MITE LOCK (SPECIFY 12

OR 24 VDC) STAINLESS STEEL ENCLOSURE

$230.00

TJMM-300N FOR INSWING APPLICATIONS INCLUDES

Z-BRACKET $330.00

MM-N1 NARROW ANGLE BRACKET 1-1/2 x 1-1/2 x 6" $40.00

MM-N2 TJ BACK MOUNTING BRACKET $40.00

MM-ZN1 NARROW MINI-MITE Z- BRACKET $60.00

MM-300N

1000 SERIES INDUSTRIAL ELECTROMAGNETIC LOCKS

INDUSTRIAL LOCK - OUTSWING DOORS

1000 1200 LB LOCK 12/24 VDC (DUAL VOLTAGE - FIELD

SELECTABLE) FOR SURFACE MOUNTING ON

OUTSWING DOORS STAINLESS STEEL HOUSING

$395.00

1000 TJ-1000 1200 LB LOCK 12/24 VDC (DUAL VOLTAGE - FIELD

SELECTABLE) FOR SURFACE MOUNTING ON

INSWINGING DOORS INCLUDES ANGLE MOUNTING

BRACKET AND ARMATURE "Z" BRACKET

$480.00

1095-00 1095-00

OPTIONAL MOUNTING BRACKET

$50.00

USE FOR GATE OR SLIDING DOOR APPLICATIONS

1099-00

GATE/INSWING - CONVERSION KIT

$168.00

1096-00 Z-BRACKET

KIT INCLUDES 1095-00 ANGLE BRACKET & 1096-00 Z-

BRACKET FOR MOUNTING OF CONDUIT FITTED

LOCKS OR TOP JAMB MOUNTING (IN-SWING DOORS)

OF STANDARD INDUSTRIAL LOCK

(KIT INCLUDED WITH TJ-1000)

1000 SERIES OPTIONS

xD ADD SPDT DOOR POSITION SWITCH (SINGLE) $45.00

xCF ADD CONDUIT FITTING (FOR 1/2" RIGID CONDUIT)

(THE 1000XCF COMES WITH 10' LEADS) $20.00

1000XCF

FILLER PLATES & ANGLE BRACKETS pgs. 8-12

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 2 1000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

MAGNETIC LOCKS

PART #

DESCRIPTION

LIST PRICE

1100 SERIES ELECTROMAGNETIC LOCKS

650 LB SINGLE MAGLOC

K

1106 JUNIOR 650 LB LOCK 12/24 VDC DUAL VOLTAGE -

(NOT AVAILABLE WITH XEDR USE 1107XEDR) $365.00

600LB DELAYED EGRESS ACTUATING LOC

K

1107 NARROW 600 LB LOCK 12/24 VDC DUAL VOLTAGE

**ADD xD or xEDR OPTIONS ONLY - NO FINISHES** $375.00

1200 LB SINGLE MAGLOC

K

1110 SINGLE DOOR 1200 LB LOCK 12/24 VDC (DUAL

VOLTAGE - FIELD SELECTABLE

)

$415.00

600 LB. SPLIT ARMATURE MAGLOC

K

1115 SPLIT ARMATURE DOUBLE LOCK 12/24 VDC (DUAL

VOLTAGE - FIELD SELECTABLE

)

$455.00

1200 LB DOUBLE MAGLOC

K

1120 DOUBLE DOOR 1200 LB 12/24 VDC (DUAL VOLTAGE -

FIELD SELECTABLE

)

$830.00

1500 LB SINGLE MAGLOC

K

1150 SINGLE DOOR 1500 LB 12/24 VDC (DUAL VOLTAGE -

FIELD SELECTABLE

)

$465.00

1500 LB DOUBLE MAGLOC

K

1152 DOUBLE DOOR 1500 LB 12/24 VDC (DUAL VOLTAGE -

FIELD SELECTABLE

)

$930.00

750 LB. SPLIT ARMATURE MAGLOC

K

1155 SPLIT ARMATURE DOUBLE LOCK 12/24 VDC (DUAL

VOLTAGE - FIELD SELECTABLE

)

$535.00

1100 SERIES MORTISED LOCK APPLICATIONS

MORTISED MAGLOCKS

ML-1100 MORTISED 1000 LB LOCK INCLUDES RECESSED

MOUNTING BRACKET & ARMATURE 24 VDC ONLY $500.00

ALUMINUM DOOR PULLS

DPA1100 DOOR PULL FOR #ML-1100 MORTISED LOCK $400.00

(SUFFIX) ADD

XDBA FOR DARK BRONZE ANODIZED FINISH PULL $180.00

OTHER FINISHES AVAILABLE CHECK WITH FACTORY

If DPA pull & ML lock are ordered together the armature

will be factory mounted in the DPA pull

M

A

G

N

E

T

PULL HANDLE

DOOR

JAMB

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 3 1000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

MAGNETIC LOCKS

PART #

DESCRIPTION

LIST PRICE

TJ1100 SERIES IN-SWINGING DOOR APPLICATIONS

650 LB SINGLE MAGLOC

K

TJ1106 JUNIOR 650 LB LOCK 12/24 VDC (DUAL VOLTAGE - w/

Z-BRACKET FOR ARMATURE $445.00

(

NOT AVAILABLE WITH XEDR USE TJ1107XEDR

)

600LB DELAYED EGRESS ACTUATING LOC

K

TJ1107 NARROW 600 LB LOCK 12/24 VDC (DUAL VOLTAGE,

INCLUDES Z-BRACKET FOR ARMATURE)

**ADD xD or xEDR OPTIONS ONLY - NO FINISHES**

$495.00

1200 LB SINGLE MAGLOC

K

TJ1110 SINGLE DOOR 1200 LB LOCK 12/24 VDC (DUAL

VOLTAGE - FIELD SELECTABLE, INCLUDES TOP

JAMB LOCK HOUSING w/ Z-BRACKET FOR

A

RMATURE

)

$505.00

600 LB. SPLIT ARMATURE MAGLOC

K

TJ1115 SPLIT ARMATURE DOUBLE LOCK 12/24 (DUAL

VOLTAGE - FIELD SELECTABLE, INCLUDES TOP

JAMB LOCK HOUSING w/ Z-BRACKET FOR

A

RMATURE

)

$585.00

1200 LB DOUBLE MAGLOC

K

TJ1120 DOUBLE DOOR 1200 LB 12/24 (DUAL VOLTAGE -

FIELD SELECTABLE, INCLUDES TOP JAMB LOCK

HOUSING w/ Z-BRACKET FOR ARMATURE

)

$1,010.00

1500 LB SINGLE MAGLOC

K

TJ1150 SINGLE DOOR 1500 LB 12/24 (DUAL VOLTAGE - FIELD

SELECTABLE, INCLUDES TOP JAMB LOCK HOUSING

w/ Z-BRACKET FOR ARMATURE

)

$585.00

1500 LB DOUBLE MAGLOC

K

TJ1152 DOUBLE DOOR 1500 LB 12/24 (DUAL VOLTAGE -

FIELD SELECTABLE, INCLUDES TOP JAMB LOCK

HOUSING w/ Z-BRACKET FOR ARMATURE

)

$1,170.00

750 LB. SPLIT ARMATURE MAGLOC

K

TJ1155 SPLIT ARMATURE DOUBLE LOCK 12/24 (DUAL

VOLTAGE - FIELD SELECTABLE, INCLUDES TOP

JAMB LOCK HOUSING w/ Z-BRACKET FOR

A

RMATURE

)

$815.00

TYPICAL Z-BRACKET FOR MOUNTING ARMATURE

INCLUDED WITH EACH TOP JAMB LOCK

SEE PAGE 41 FOR Z-BRACKET PRICING AS A SPARE

PART ONLY

(ALL TJ LOCKS INCLUDE A Z-BRACKET)

1196 Z-BRACKET

1095-07

1107 SERIES INSWING - CONVERSION KIT

1107 INSWING KIT $180.00

1095-07XEDR

1107xEDR SERIES INSWING - CONV. KIT

KIT INCLUDES 1107301 ANGLE BRACKET , 1196-06 Z-

BRACKET W/SHIM & SPRING LOADED PLATE FOR

TOP JAMB MOUNTING

(KIT INCLUDED WITH TJ1107xEDR)

$230.00

KIT INCLUDES 1107302 ANGLE BRACKET & 1196-06 Z-

BRACKET FOR TOP JAMB MOUNTING (IN-SWING

DOORS) (KIT INCLUDED WITH TJ1107)

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 4 1000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

MAGNETIC LOCKS

PART #

DESCRIPTION

LIST PRICE

1100 SERIES OPTIONAL MAGNETIC LOCK FEATURES

(SUFFIX)

1100 SERIES OPTIONS (ADD TO LOCK):

(ADD)

xL ADD 1 LED (BICOLOR RED / GREEN) $30.00

xD ADD SPDT DOOR POSITION SWITCH (SINGLE) $45.00

x2D ADD 2 SPDT DOOR POSITION SWITCHES

(

1115/1120/1152/1155

)

$90.00

XDD ADD DPDT DOOR POSITION SWITCH

(NOT AVAILABLE FOR 1000 SERIES) $90.00

xB

A

DD 1 MAGNETIC BOND SENSOR

(NOT AVAILABLE FOR 1000,1115,1155 SERIES

LOCKS)

$90.00

x2B ADD 2 MAGNETIC BOND SENSORS

DOUBLE(1120/1152) $180.00

xCF ADD CONDUIT FITTING (FOR 1/2" RIGID CONDUIT) $10.00

(1000XCF HAS 10' LEADS, NOT AVAILABLE FOR 1107)$20.00

xCT ADD COVER TAMPER SWITCH $44.00

xTS ADD TAMPER RESISTANT SCREWS/DRIVER $12.00

xEDR ADD ATTEMPTED EGRESS SWITCH & DOOR SWITCH

w/ ARMATURE MOUNTING ASSEMBLY

(

FOR SINGLE DOOR w/ EDR SYSTEM-101

)

$225.00

ONLY AVAILABLE WITH 1107 & 1110 SERIES

FULL WIDTH HOUSINGS (ADD TO LOCK):

(ADD)

LW- ADD TO 1106/1110/1150 MAGLOCK FOR SINGLE

LOCK HOUSINGS UP TO 48" WIDE $450.00

LW- ADD TO 1115/1120/1152 MAGLOCK FOR DOUBLE

LOCK HOUSINGS UP TO 72" WIDE $500.00

FULL HEIGHT HOUSINGS (ADD TO LOCK):

(ADD)

LV- ADD TO 1106/1110/1150 MAGLOCK - FOR SINGLE

LOCK HOUSINGS UP TO 96" LONG $480.00

LV- ADD TO 1120/1152 MAGLOCK - FOR DOUBLE LOCK

HOUSINGS UP TO 96" LONG $530.00

FOR OTHER CUSTOM LOCKS OR HOUSINGS (CALL

FOR QUOTE)

FOR CUSTOM FINISHES (CALL FOR QUOTE)

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 5 1000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

MAGNETIC LOCKS

PART #

DESCRIPTION

LIST PRICE

11

00

S

ERIE

S

O

PTI

O

NAL

S

PE

C

IAL L

OC

K FINI

S

HE

S

(SUFFIX)

ANODIZING (ADD TO LOCK PRICE):

xDBA DARK BRONZE ANODIZE (US10D) - (ADD)

ADD FOR 1106 SERIES $50.00

1107 SERIES ANODIZING NOT OFFERED N/A

ADD FOR 1110 , 1115 SINGLE SERIES $60.00

ADD FOR 1120 DOUBLE SERIES $90.00

ADD FOR 1150, 1155 SINGLE SERIES $70.00

ADD FOR 1152 DOUBLE SERIES $100.00

ADD FOR TJ1106 TOP JAMB JR. $70.00

ADD FOR TJ1110, TJ1115 TOP JAMB SINGLE $75.00

ADD FOR TJ1120 TOP JAMB DOUBLE $120.00

ADD FOR TJ1150, TJ1155 TOP JAMB SINGLE $80.00

ADD FOR TJ1152 TOP JAMB DOUBLE $140.00

(SUFFIX)

PLATING (ADD TO LOCK PRICE):

XUS26 POLISHED CHROME -

XUS26D SATIN CHROME -

XUS3 POLISHED BRASS - (ADD)

XUS4 SATIN BRASS -

ADD FOR 1106 SERIES $300.00

1107 SERIES PLATING NOT OFFERED N/A

ADD FOR 1110 , 1115 SINGLE SERIES $370.00

ADD FOR 1120 DOUBLE SERIES $500.00

ADD FOR 1150, 1155 SINGLE SERIES $380.00

ADD FOR 1152 DOUBLE SERIES $540.00

ADD FOR TJ1106 TOP JAMB JR. $420.00

ADD FOR TJ1110,TJ1115 TOP JAMB SINGLE $590.00

ADD FOR TJ1120 TOP JAMB DOUBLE $800.00

ADD FOR TJ1150, TJ1155 TOP JAMB SINGLE $610.00

ADD FOR TJ1152 TOP JAMB DOUBLE $840.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 6 1000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

MAGNETIC LOCKS

PART #

DESCRIPTION

LIST PRICE

1180 SERIES FILLER PLATES

3/8" FILLERS

1183-00 3/8 x1" 1000 SERIES FILLER 8-1/4" LONG $33.00

1183-06 3/8 x1" 1106 SERIES FILLER 8-1/4" LONG $33.00

1183-07 3/8 x1-1/4" 1107 SERIES FILLER 8-1/4" LONG $54.00

1183-10 3/8 x1" 1110/1115 SERIES FILLER 12-1/2" LONG $45.00

1183-20 3/8 x1" 1120 SERIES FILLER 23" LONG $53.00

1183-50 3/8 x1" 1150/1155 SERIES FILLER 12" LONG $45.00

1183-52 3/8 x1" 1152 SERIES FILLER 24" LONG $56.00

EXTRA WIDE FILLER PLATES

1183-00-W EXTRA WIDE 3/8 x 1-1/2" 1000 FILLER 8-1/4" LONG $41.00

1183-06-W EXTRA WIDE 3/8 x 1-3/4" 1106 FILLER 8-1/4" LONG $41.00

1183-10-W EXTRA WIDE 3/8 x 1-3/4" 1110/1115 FILLER 12-1/2" $53.00

1183-20-W EXTRA WIDE 3/8 x 1-3/4" 1120 FILLER 23" LONG $64.00

1183-50-W EXTRA WIDE 3/8 x 2" 1150/1155 FILLER 12" $53.00

1183-52-W EXTRA WIDE 3/8 x 2" 1150/1155 FILLER 24" $64.00

1/2" FILLERS

1184-00 1/2"x1" 1000 SERIES FILLER 8-1/4" LONG $37.00

1184-06 1/2"x1" 1106 SERIES FILLER 8-1/4" LONG $37.00

1184-07 1/2 x1-1/4" 1107 SERIES FILLER 8-1/4" LONG $58.00

1184-10 1/2"x1" 1110/1115 SERIES FILLER 12-1/2" LONG $47.00

1184-20 1/2"x1" 1120 SERIES FILLER 23" LONG $60.00

1184-50 1/2"x1" 1150/1155 SERIES FILLER 12" LONG $47.00

1184-52 1/2"x1" 1152 SERIES FILLER 24" LONG $60.00

EXTRA WIDE FILLER PLATES

1184-00-W EXTRA WIDE 1/2 x 1-1/2" 1000 FILLER 8-1/4" LONG $47.00

1184-06-W EXTRA WIDE 1/2 x 1-3/4" 1106 FILLER 8-1/4" LONG

$

47.00

1184-10-W EXTRA WIDE 1/2 x 1-3/4" 1110/1115 FILLER 12-1/2" $57.00

1184-20-W EXTRA WIDE 1/2 x 1-3/4" 1120 FILLER 23" LONG $70.00

1184-50-W EXTRA WIDE 1/2 x 2" 1150/1155 FILLER 12" LONG $57.00

1184-52-W EXTRA WIDE 1/2 x 2" 1152 FILLER 24" LONG $70.00

5/8" FILLERS

1185-00 5/8"x1" 1000 SERIES FILLER 8-1/4" LONG $41.00

1185-06 5/8"x1" 1106 SERIES FILLER 8-1/4" LONG $41.00

1185-07 5/8 x1-1/4" 1107 SERIES FILLER 8-1/4" LONG $62.00

1185-10 5/8"x1" 1110/1115 FILLER 12-1/2" LONG $49.00

1185-20 5/8"x1" 1120 SERIES FILLER 23" LONG $64.00

1185-50 5/8"x1" 1150/1155 SERIES FILLER 12" LONG $50.00

1185-52 5/8"x1" 1152 SERIES FILLER 24" LONG $64.00

EXTRA WIDE FILLER PLATES

1185-00-W EXTRA WIDE 5/8 x 1-1/2" 1000 FILLER 8-1/4" LONG $53.00

1185-06-W EXTRA WIDE 5/8 x 1-3/4" 1106 FILLER 8-1/4" LONG $53.00

1185-10-W EXTRA WIDE 5/8 x 1-3/4" 1110 FILLER 12-1/2" LONG $61.00

1185-20-W EXTRA WIDE 5/8 x 1-3/4" 1120 FILLER 23" LONG $76.00

1185-50-W EXTRA WIDE 5/8 x 2" 1150 FILLER 12" LONG $61.00

1185-52-W EXTRA WIDE 5/8 x 2" 1152 FILLER 24" LONG $76.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 7 1000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

MAGNETIC LOCKS

PART #

DESCRIPTION

LIST PRICE

1180 SERIES CUSTOM FINISHES - STANDARD FILLER PLATES

(SUFFIX)

SPECIAL FINISHES ADD TO FILLER PLATES

(ADD)

xDBA ADD FOR DARK BRONZE ANODIZED - $30.00

xUS26 ADD FOR POLISHED CHROME -

xUS26D ADD FOR SATIN CHROME -

xUS3 ADD FOR POLISHED BRASS -

xUS4 ADD FOR SATIN BRASS -

1106 (SINGLE LOCK) FILLER PLATES $85.00

1107 FINISHES NOT OFFERED N/A

1110/1115 (SINGLE LOCK) FILLER PLATES $90.00

1150/1155 (SINGLE LOCK) FILLER PLATES $100.00

1120 (DOUBLE LOCK) FILLER PLATES $130.00

1152 (DOUBLE LOCK) FILLER PLATES $120.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 8 1000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

MAGNETIC LOCKS

PART #

DESCRIPTION

LIST PRICE

1190 SERIES ANGLE BRACKETS

1" x 1" ANGLE BRACKET

1191-00 1"X1" 1000 SERIES ANGLE 8-1/4" LONG $42.00

1191-06 1"X1" 1106 & 1107 SERIES ANGLE 8-1/4" LONG $42.00

1191-10 1"X1" 1110/1115 SERIES ANGLE 12-1/2"LONG $55.00

1191-20 1"X1" 1120 SERIES ANGLE 23" LONG $75.00

1191-50 1"X1" 1150/1155 SERIES ANGLE 12"LONG $55.00

1191-52 1"X1" 1152 SERIES ANGLE 24" LONG $75.00

1-1/2" x 1-1/2" ANGLE BRACKET

1192-00 1-1/2"X 2" 1000 SERIES ANGLE 8-1/4"LONG $44.00

1192-06 1-1/2"X1-1/2" 1106 & 1107 SERIES ANGL 8-1/4"LONG $44.00

1192-10 1-1/2"X1-1/2" 1110/1115 SERIES ANGLE 12-1/2"LONG $58.00

1192-20 1-1/2"X1-1/2" 1120 SERIES ANGLE 23" LONG $75.00

1192-50 1-1/2"X1-1/2" 1150/1155 SERIES ANGLE 12"LONG $58.00

1192-52 1-1/2"X1-1/2" 1152 SERIES ANGLE 24" LONG $75.00

DEPTH X HEIGHT

2" x 1-1/2" ANGLE BRACKET

1193-00 2"X 2" 1000 SERIES ANGLE 8-1/4" LONG $60.00

1193-06 2"X1-1/2" 1106 & 1107 SERIES ANGLE 8-1/4" LONG $60.00

1193-10 2"X1-1/2" 1110/1115 SERIES ANGLE 12-1/2"LONG $77.00

1193-20 2"X1-1/2" 1120 SERIES ANGLE 23" LONG $95.00

1193-50 2"X1-1/2" 1150/1155 SERIES ANGLE 12"LONG $77.00

1193-52 2"X1-1/2" 1152 SERIES ANGLE 24" LONG $95.00

DEPTH X HEIGHT

2-1/2" x 2" ANGLE BRACKET

1194-00 2-3/8"X2" 1000 SERIES ANGLE 8-1/4" LONG $65.00

1194-06 2-1/2"X2" 1106 & 1107 SERIES ANGLE 8-1/4" LONG $65.00

1194-10 2-1/2"X2" 1110/1115 SERIES ANGLE 12-1/2"LONG $80.00

1194-20 2-1/2"X2" 1120 SERIES ANGLE 23" LONG $100.00

1194-50 2-1/2"X2" 1150/1155 SERIES ANGLE 12"LONG $80.00

1194-52 2-1/2"X2" 1152 SERIES ANGLE 24" LONG $100.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 9 1000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

MAGNETIC LOCKS

PART #

DESCRIPTION

LIST PRICE

1190 SERIES CUSTOM FINISHES - ANGLE BRACKETS

(SUFFIX)

SPECIAL FINISHES ADD TO ANGLE BRACKET

S

(ADD)

xDBA ADD FOR DARK BRONZE ANODIZED - $30.00

ALL STANDARD ANGLE BRACKETS

xUS26 ADD FOR POLISHED CHROME -

xUS26D ADD FOR SATIN CHROME -

xUS3 ADD FOR POLISHED BRASS -

xUS4 ADD FOR SATIN BRASS -

1106 (SINGLE LOCK) ANGLE BRACKETS $95.00

1107 FINISHES NOT OFFERED N/A

1110/1115 (SINGLE LOCK) ANGLE BRACKETS $105.00

1150/1155 (SINGLE LOCK) ANGLE BRACKETS $120.00

1120 (DOUBLE LOCK) ANGLE BRACKETS $180.00

1152 (DOUBLE LOCK) ANGLE BRACKETS $190.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 10 1000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

MAGNETIC LOCKS

PART #

DESCRIPTION

LIST PRICE

1190 SERIES "Z" BRACKET ACCESSORIES

Z-BRACKET SPACERS & BLOCKS

1176-06S1 1/8" SPACER FOR 1106 & 1107 $40.00

1176-00S1 1/8" SPACER FOR 1000 $42.00

1176-10S1 1/8" SPACER FOR 1110/1150 (1120/1152, 2 $44.00

1176-15S1 1/8" SPACER FOR 1115/1155 (2 REQUIRED) $38.00

1176-06S2 1/4" SPACER FOR 1106 & 1107 $46.00

1176-00S2 1/4" SPACER FOR 1000 $50.00

1176-10S2 1/4" SPACER FOR 1110/1150 (1120/1152, 2 $52.00

1176-15S2 1/4" SPACER FOR 1115/1155 (2 REQUIRED) $42.00

1176-06B1 1" BLOCK FOR 1106 & 1107 $88.00

1176-00B1 1" BLOCK FOR 1000 $92.00

1176-10B1 1" BLOCK FOR 1110/1150 (1120/1152, 2 REQUIRED) $96.00

1176-15B1 1" BLOCK FOR 1115/1155 (2 REQUIRED) $84.00

SPECIAL FINISH Z-BRACKETS, SPACERS & BLOCKS

(Call for quote)

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 11 1000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

MAGNETIC LOCKS

PART #

DESCRIPTION

LIST PRICE

1190 SERIES ARMATURE MOUNTING BRACKETS

2" x 2" ARMATURE BRACKET w/ SEX NUT

1195-06 ARMATURE BRACKET FOR 1106 & 1107 LOCKS $60.00

1195-10 ARMATURE BRACKET FOR 1110 LOCKS $72.00

1195-15L ARMATURE BRACKET FOR LEFT ARMATURE 1115 $58.00

1195-15R ARMATURE BRACKET FOR RIGHT ARMATURE 1115 $58.00

2-1/2" x 2-1/2" BRACKET w/ SEX NUT

FOR 1000 & 1150 SERIES LOCKS

1195-50

A

RMATURE BRACKET FOR 1150 & 1000 LOCKS $80.00

1195-55L

A

RMATURE BRACKET FOR 1155 LEFT ARMATURE $66.00

1195-55R

A

RMATURE BRACKET FOR 1155 RIGHT ARMATURE $66.00

2-1/2" x 2-1/2" BRACKET w/ SEX NUT

1197-06 ARMATURE BRACKET FOR 1106 & 1107 LOCKS $76.00

1197-10 ARMATURE BRACKET FOR 1110 LOCKS $86.00

2-1/2" x 3" BRACKET w/ SEX NUT

FOR 1000 & 1150 SERIES LOCKS

1197-50 ARMATURE BRACKET FOR 1150 & 1000 LOCKS $98.00

SPECIAL FINISH ARMATURE BRACKETS

(Call for quote)

1190 SERIES HERCULITE GLASS DOOR BRACKETS

1198 SERIES GLASS DOOR U-BRACKETS

SATIN STAINLESS STEEL FINISH (SPECIFY

GLASS THICKNESS)

1198/50-06 1106 & 1107 SERIES U-BRACKET FOR 1/2" THICK $132.00

1198/75-06 1106 SERIES U-BRACKET FOR 3/4" THICK GLASS $140.00

1198/50-10 1110/1120 U-BRACKET FOR 1/2" THICK GLASS DOOR $132.00

1198/75-10 1110/1120 U-BRACKET FOR 3/4" THICK GLASS DOOR $140.00

1198/50-15 1115 SERIES U-BRACKET FOR 1/2" THICK GLASS $100.00

1198/75-15 1115 SERIES U-BRACKET FOR 3/4" THICK GLASS $110.00

1198/50-50 1150&1000 SERIES U-BRACKET FOR 1/2" GLASS $150.00

1198/75-50 1150&1000 SERIES U-BRACKET FOR 3/4" GLASS $160.00

1198/50-55 1155 SERIES U-BRACKET FOR 1/2" THICK GLASS $110.00

1198/75-55 1155 SERIES U-BRACKET FOR 3/4" THICK GLASS $120.00

(SUFFIX)

U-BRACKET SPECIAL FINISHES

(ADD)

xUS3 ADD FOR POLISHED BRASS $150.00

xUS4 ADD FOR SATIN BRASS $150.00

xUS26 ADD FOR POLISHED CHROME $150.00

STANDARD FINISH IS SATIN STAINLESS

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 12 1000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ELECTRIC STRIKES

PART #

DESCRIPTION

LIST PRICE

3300 SERIES ELECTRIC STRIKES

STANDARD ANSI STRIKES

3300 12/24 DC ANSI STRIKE - FIELD SELECTABLE FAIL-

SAFE/FAIL-SECURE FOR METAL DOOR FRAME $205.00

3300xD 12/24 DC ANSI STRIKE WITH LATCH BOLT MONITOR

SWITCH (SPDT) - FIELD SELECTABLE FAIL-SAFE/FAIL-

SECURE FOR METAL DOOR FRAME

$280.00

3311

WOOD FRAME STRIKE PLATE ONLY

CONVERTS ANSI STYLE TO 9" TALL STRIKE FOR

WOOD DOOR FRAME $22.00

JAMB EXTENSION BRACKETS

FOR USE WITH DEEP DOOR JAMB APPLICATIONS

3381 1 INCH JAMB EXTENSION BRACKET $20.00

3382 2 INCH JAMB EXTENSION BRACKET $20.00

3400 SERIES ELECTRIC DROPBOLT

3412 RECESS MOUNT DROPBOLT FAIL-SAFE 12VDC WITH

BOLT MONITOR SWITCH (SPDT) - & FIELD

SELECTABLE RELOCK TIMER. FOR HOLLOW METAL,

OR WOOD DOOR FRAMES

$335.00

3402 SURFACE MOUNT DROPBOLT & RECEIVER FAIL-SAFE

12VDC WITH BOLT MONITOR SWITCH (SPDT) - &

DOOR POSITION SWITCH (SPDT) WITH FIELD

SELECTABLE RELOCK TIMER.

$510.00

3404 HERCULITE DOOR U-BRACKET & RECEIVER HOUSING

FOR UP TO 1/2" THICK FRAMELESS GLASS DOORS $160.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 13 3000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

POWER SUPPLIES

PART #

DESCRIPTION

LIST PRICE

4000 SERIES PLUG-IN POWER SUPPLIES

WALL MOUNT PLUG IN POWER SUPPLIES

4012 12 VOLT PLUG-IN POWER SUPPLY $75.00

(1 AMP 12 VDC FOR USE WITH 1100 SERIES MAGLOCKS)

4024 24 VOLT PLUG-IN POWER SUPPLY $75.00

(1 AMP 24 VDC FOR USE WITH 1100 SERIES MAGLOCKS)

4200 SERIES POWER SUPPLIES

12/24 VDC POWER SUPPLIES

4202 2 AMP POWER SUPPLY/CONTROLLER 12/24 VDC

(FIELD SELECTABLE)

$615.00

w/ SWITCHING REGULATOR / FILTER / SURGE

PROTECTION, BATTERY CHARGING CIRCUIT & FIRE

A

LARM RELAY

FURNISHED IN 16" x 12" x 4" ELECTRICAL BOX - SEE

SERIES 4200 OPTIONS

4204 4 AMP POWER SUPPLY / CONTROLLER 12/24 VDC

(FIELD SELECTABLE) SAME AS ABOVE

$650.00

4200 SERIES POWER SUPPLY OPTIONS

4200 SERIES OPTIONS:

(SUFFIX)

ADD FOR LARGER ENCLOSURES AS REQUIRED TO

ACCOMMODATE MULTIPLE OPTIONS BELOW (ADD)

/1518 15" x 18" x 4" ENCLOSURE REQUIRED TO

ACCOMMODATE MULTIPLE FUSED OUTPUT BOARDS

OR RELAY MODULES

$160.00

/2024 20" x 24" x 5" ENCLOSURE REQUIRED TO

ACCOMMODATE MULTIPLE FUSED OUTPUT BOARDS

OR RELAY MODULES

$300.00

xBAT 12/24 VDC - 14 AMP HOUR BATTERY PACK $130.00

INCLUDES 2 EACH 7 AH 12 VOLT RECHARGEABLE

BATTERIES w/ HOOK-UP CABLES

xRM12

xRM24

RELAY MODULE w/ TWO (2) SPDT ISOLATION RELAYS

DIMENSIONS 2" LONG X 1-3/4" WIDE

(SPECIFY 12 OR 24VDC)

$80.00

xFO 8-ZONE FUSED OUTPUT BOARD (POWER

DISTRIBUTION) 4-1/4" LONG X 3" WIDE

$110.00

xFO/AUX 8-ZONE FUSED OUTPUT BOARD (POWER

DISTRIBUTION) w/ AUXILARY POWER INTERRUPT

RELAY 4-1/4" LONG X 3" WIDE

$160.00

xTERM 10 POSITION DOUBLE ROW TERMINAL 6 1/2" LONG $26.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 14 4000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

POWER SUPPLIES

PART #

DESCRIPTION

LIST PRICE

4300 SERIES MANTRAPS & INTERLOCKS

ALL 4300 INTERLOCKS ARE FACTORY PRE-CONFIGURED

A 4204 POWER SUPPLY INCLUDED IN THE 12 x 16 x 4" NEMA

ENCLOSURE PROVIDES 4 AMPS OF 12 or 24 VDC POWER

FOR MAGLOCKS, STRIKES & LED's. A FIRE ALARM RELAY

INPUT IS STANDARD. THE NUMBER OF LOCKS AND TOTAL

CURRENT DRAW MAY REQUIRE ADDITIONAL POWER .

REQUEST MANTRAP / INTERLOCK CHECK LIST FROM FACTORY

TO PROPERLY CONFIGURE 4300 CONTROLLERS

4300 SERIES 2 DOOR MANTRAP INTERLOCKS

43211-U 2-Doors – 1-Room - All Doors Normally Unlocked $980.00

43211-LU 2-Doors – 1-Room - 1-Door Locked & 1-Door Unlocked

43211-L 2-Doors – 1-Room - All Doors Normally Locked

4300020 Controller board onl

y

$350.00

COMMUNICATING BATH CONTROLLER

43211-CB 2-Doors – 1-Room - Doors Normally Unlocked $1,020.00

xBAT 12/24 VDC - 14 AMP HOUR BATTERY PACK $130.00

INCLUDES 2 EACH 7 AH 12 VOLT RECHARGEABLE

BATTERIES w/ HOOK-UP CABLES

SEE 4700 & 4900 SERIES ON FOLLOWING PAGES FOR MORE COMPLEX MANTRAP CONFIGURATIONS

RELAY LOGIC 2-DOOR INTERLOCK CONTROLLERS ARE

OFFERED IN STANDARD CONFIGURATIONS WHICH ALLOW

FOR ONE DOOR STATUS AND ONE R-E-X INPUT PLUS ONE

DPDT LOCK RELAY OUTPUT PER DOOR.

STANDARD CONFIGURATIONS

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 15 4000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

POWER SUPPLIES

PART #

DESCRIPTION

LIST PRICE

4700 SERIES PLC MANTRAPS & INTERLOCKS

ALL 4700 INTERLOCKS ARE FACTORY PRE-PROGRAMMED

A 4204 POWER SUPPLY INCLUDED IN THE NEMA

ENCLOSURE PROVIDES 4 AMPS OF 12 or 24 VDC POWER

FOR MAGLOCKS, STRIKES & LED's. A FIRE ALARM RELAY

INPUT IS STANDARD. THE NUMBER OF LOCKS AND TOTAL

CURRENT DRAW MAY REQUIRE ADDITIONAL POWER .

REQUEST MANTRAP / INTERLOCK CHECK LIST FROM FACTORY

TO PROPERLY CONFIGURE 4700 PLC CONTROLLERS

4700 SERIES 2 DOOR MANTRAP INTERLOCKS

47211-U 2-Doors – 1-Room - All Doors Normally Unlocked $1,320.00

47211-LU 2-Doors – 1-Room - 1-Door Locked & 1-Door Unlocked

47211-L 2-Doors – 1-Room - All Doors Normally Locked

4700 SERIES 3 DOOR MANTRAP INTERLOCKS

47311-U 3-Doors – 1-Room - All Doors Normally Unlocked $1,360.00

47311-L2U 3-Doors – 1-Room - 1-Locked & 2-Unlocked

47311-2LU 3-Doors – 1-Room - 2-Locked - 1-Unlocked (No Lights)

47311-L 3-Doors – 1-Room - 3-Locked (No Lights)

4700 SERIES 4 DOOR MANTRAP INTERLOCKS

47411-U 4-Doors – 1-Room - All Doors Normally Unlocked $1,485.00

xBAT 12/24 VDC - 14 AMP HOUR BATTERY PACK $130.00

INCLUDES 2 EACH 7 AH 12 VOLT RECHARGEABLE

BATTERIES w/ HOOK-UP CABLES

CUSTOM CONFIGURATION PROGRAMMING

47000-PRGM FACTORY PROGRAMMING TO CUSTOM APPLICATION

SPECIFICATIONS QUOTED ON AN HOURLY BASIS

$350.00

THE 4700 SERIES CONTROLLER IS LIMITED TO 6-INPUTS &

4-RELAY OUTPUTS TOTAL FOR DOOR LOCK & TRAFFIC LIGHT

CONTROL.

SEE 4900 SERIES ON NEXT PAGE FOR MORE MANTRAP CONFIGURATIONS

STANDARD CONFIGURATIONS

PLC BASED MULTI DOOR, INTERLOCK & MANTRAP

CONTROLLERS ARE OFFERED IN STANDARD

CONFIGURATIONS WHICH ALLOW FOR ONE DOOR STATUS

AND ONE R-E-X INPUT PLUS ONE DPDT LOCK RELAY

OUTPUT PER DOOR. A MAXIMUM OF 6-INPUTS AND 4-

OUTPUTS CAPABILITY PLUS CUSTOM OPERATIONAL

CHARACTERISTICS INCLUDING SEQUENCING AND TIMING

MAY BE DESIGNED INTO THE UNIT UPON REQUEST.

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 16 4000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

POWER SUPPLIES

PART #

DESCRIPTION

LIST PRICE

4800 SERIES ***NEW USER CONFIGURED INTERLOCKS***

4800 INTERLOCKS ARE FIELD CONFIGURABLE

48501 MOUNTED IN NEMA ENCLOSURE WITH 4AMP SUPPLY

UP TO 5 DOORS FIELD CONFIGURED

$2,020.00

48500 PLC BOARD ONLY (no enclosure) UP TO 5 DOORS FIELD

CONFIGURED

$1,250.00

xBAT 12/24 VDC - 14 AMP HOUR BATTERY PACK $170.00

INCLUDES 2 EACH 7 AH 12 VOLT RECHARGEABLE

BATTERIES w/ HOOK-UP CABLES

REQUIRES 13 X 19-1/2 X 4 ENCLOSURE INCLUDED

SEE 4900 SERIES ON NEXT PAGE FOR MORE INTERLOCK CONFIGURATIONS

THE 4805 MANTRAP CONTROLLER ALLOWS THE USER TO INTERLOCK FROM TWO

TO FIVE DOORS IN ANY COMBINATION AND CONFIGURE THE DOORS FOR LOCKED

OR UNLOCKED, FAIL SAFE OR FAIL SECURE OPERATION IN THE FIELD. THE PLC

BASED LOGIC GIVES THE INSTALLER COMPLETE CONTROL OVER THE INTERLOCK

FUNCTIONS. EACH DOOR IN THE MANTRAP HAS AN INDEPENDENT CONTROL

RELAY WITH OVERCURRENT PROTECTION BY FUSE AND WET OR DRY CONTACT

SELECTOR. EACH DOOR ALSO HAS A DEDICATED TRAFFIC LIGHT OUTPUT THAT IS

POWERED FOR DIRECT CONNECTION TO INDICATORS, A DEDICATED DOOR

STATUS RELAY, A DOOR POSITION INPUT AS WELL AS A R-E-X INPUT FOR

NORMALLY LOCKED DOORS.

THE SYSTEM FEATURES AN EMERGENCY UNLOCK FOR ALL DOORS WITH AN

ALARM, AN INTERLOCK VIOLATION ALARM, AN ADJUSTABLE DOOR PROPPED

OPEN TIMER, A PAUSE TIMER (TO ALLOW FOR AIR PURGE, AIR EQUALIZATION OR

WASH-DOWN) AND A PANIC RELEASE TIMER.

THE INTERLOCK FUNCTION HAS A SHUNT INPUT THAT DEFEATS THE INTERLOCK

FOR DAY/NIGHT MODE, BUT LEAVES THE ACCESS CONTROL SETTINGS

UNAFFECTED.

A 4204 POWER SUPPLY INCLUDED IN A NEMA ENCLOSURE PROVIDES 4 AMPS OF

12 or 24 VDC POWER FOR MAGLOCKS, STRIKES & LED's. A FIRE ALARM RELAY

INPUT IS STANDARD. THE NUMBER OF LOCKS AND TOTAL CURRENT DRAW MAY

REQUIRE ADDITIONAL POWER .

4800 SERIES 2-5 DOOR MANTRAP INTERLOCKS

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 17 4000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

POWER SUPPLIES

PART #

DESCRIPTION

LIST PRICE

4900 SERIES PLC MANTRAPS & INTERLOCKS

ALL 4900 INTERLOCKS ARE FACTORY PRE-PROGRAMMED

A 4204 POWER SUPPLY INCLUDED IN THE NEMA

ENCLOSURE PROVIDES 4 AMPS OF 12 or 24 VDC POWER

FOR MAGLOCKS, STRIKES & LED's. A FIRE ALARM RELAY

INPUT IS STANDARD. DEPENDENT UPON THE NUMBER OF

LOCKS AND TOTAL CURRENT DRAW, ADDITIONAL POWER

MAY BE REQUIRED.

REQUEST MANTRAP / INTERLOCK CHECK LIST FROM FACTORY

TO PROPERLY CONFIGURE 4900 PLC CONTROLLERS

4900 SERIES 2 DOOR MANTRAP INTERLOCKS

49211-U 2-Doors – 1-Room - All Doors Normally Unlocked $2,350.00

49211-L 2-Doors – 1-Room - All Doors Normally Locked

4900 SERIES 3 DOOR MANTRAP INTERLOCKS

49311-U 3-Doors – 1-Room - All Doors Normally Unlocked $2,550.00

49311-L 3-Doors – 1-Room - All Doors Normally Locked

49311-LU 3-Doors – 1-Room - Doors Locked & Unlocked

4900 SERIES 4 DOOR MANTRAP INTERLOCKS

49411D-U 4-Doors – 1-Room - All Doors Normally Unlocked $3,500.00

49411D-L 4-Doors – 1-Room - All Doors Normally Locked

49411D-LU 4-Doors – 1-Room - Doors Locked & Unlocked

xBAT 12/24 VDC - 14 AMP HOUR BATTERY PACK $130.00

INCLUDES 2 EACH 7 AH 12 VOLT RECHARGEABLE

BATTERIES w/ HOOK-UP CABLES

(NOTE) THIS OPTION CAN ONLY BE USED WITH 1 I/O

BOARD CONFIGURATIONS. OTHERWISE CONTACT

FACTORY FOR LARGER ENCLOSURE SIZES

PROGRAMMABLE I.O. WITH NUMERIC DISPLAY

(SUFFIX)

XDSP

USER SELECTABLE MULTIFUNCTION PROGRAM

TIMER ALLOWS CUSTOM CONFIGURATION OF

INPUT/OUTPUT & TIMING FUNCTIONS

(ADD)

$575.00

CUSTOM CONFIGURATION PROGRAMMING

49000-PRGM FACTORY PROGRAMMING TO CUSTOM APPLICATION

SPECIFICATIONS

Q

UOTED ON AN HOURLY BASIS

$350.00

***MANY OTHER CONFIGURATIONS AVAILABLE CONTACT FACTORY***

("DOORS" REFERS TO EACH OPENING WHICH MAY BE A PAIR OF DOORS)

STANDARD CONFIGURATIONS

PLC BASED MULTI ROOM / MULTI DOOR, INTERLOCK &

MANTRAP CONTROLLERS ARE OFFERED IN STANDARD

CONFIGURATIONS WHICH ALLOW FOR ONE DOOR STATUS

AND ONE R-E-X INPUT PLUS ONE DPDT LOCK RELAY

OUTPUT PER DOOR. ADDITIONAL INPUT AND OUTPUT

CAPABILITY PLUS CUSTOM OPERATIONAL

CHARACTERISTICS INCLUDING SEQUENCING AND TIMING

MAY BE DESIGNED INTO THE UNIT UPON REQUEST.

UP TO 120 TOTAL DOORS MAY BE CONFIGURED

OVER 4 DOORS & UP TO 120 DOORS CONTACT THE FACTORY FOR A QUOTE AS THESE

WILL BE CUSTOM CONFIGURED TO YOUR SPECIFICATIONS

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 18 4000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ACTUATORS

PART # DESCRIPTION LIST PRICE

5100 SERIES KEY SWITCH CONTROLS

5141 SERIES KEY SWITCHES (LESS CYLINDER)

5141-23 FORM Z-DELAY ACTION KEY SWITCH ON SINGLE

GANG PLATE (PNEUMATIC TIME DELAY) $280.00

5141-24 DPDT ALTERNATE ACTION KEY SWITCH ON SINGLE

GANG PLATE $126.00

5141-25 DPDT MOMENTARY ACTION KEY SWITCH ON SINGLE

GANG PLATE $114.00

5141-2/24 TWO POSITION KEY SWITCH ON SINGLE GANG PLATE

w/ 2-DPDT MAINTAINED ACTION CONTACT SWITCHES $179.00

5141-2/25 TWO POSITION KEY SWITCH ON SINGLE GANG PLATE

w/ 2-DPDT MOMENTARY ACTION CONTACT SWITCHES $155.00

5141-25 (MOUNTING KIT INCLUDES CYLINDER NUT, PIN HEX

SCREWS AND PIN HEX ALLEN WRENCH)

(SUFFIX) 5141 KEY SWITCH OPTIONS (ADD TO ABOVE): (ADD)

xK STANDARD 1-1/8" MORTISE CYLINDER & 2 KEYS $40.00

xKNR CYLINDER WITH KEY NON-REMOVABLE IN "ON"

POSITION (single switch Mom. configuration only) $50.00

xP15 ADD SPDT PUSH BUTTON SWITCH $28.00

xCS ADD DC PIEZO SOUNDER (REQUIRES 2-GANG PLATE) $30.00

xL ADD 1 LED (BICOLOR RED / GREEN) $14.00

N5141-25XL2XK

xCT ADD 1 SPDT COVER TAMPER SWITCH $44.00

(SUFFIX) 5141 KEY SWITCH FINISHES (ADD)

xUS26 POLISHED CHROME $40.00

xUS3 POLISHED BRASS FINISH $40.00

xUS4 SATIN BRASS FINISH $40.00

(PREFIX)

NWITH NARROW 1-3/4" SWITCH PLATE $6.00

DWITH DOUBLE GANG SWITCH PLATE $12.00

WR WITH WEATHER RESISTANT SWITCH PLATE (1-GANG) $8.00

SEE #5240 SERIES & #7286 DOOR PROP ALARMS FOR

OTHER KEY SWITCH CONFIGURATIONS

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 19 5000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ACTUATORS

PART # DESCRIPTION LIST PRICE

5210 SERIES EXIT PUSH BUTTONS

5211 PUSH BUTTONS 1-9/16" DIA

5211-MP23/* 1-9/16" DIA. MUSHROOM PUSH BUTTON (SPECIFY CAP

COLOR) w/ DPST MOMENTARY (1-NO & 1-NC

CONTACT) MOUNTED ON SINGLE GANG PLATE

$118.00

5211-MP24/* 1-9/16" DIA. PALM BUTTON (SPECIFY CAP COLOR) w/

DPST ALT ACTION (1-NO & 1-NC CONTACT) MOUNTED

ON SINGLE GANG PLATE

$160.00

5211-MP23PP/* 1-9/16" DIA. MUSHROOM PUSH-PULL BUTTON (RED

CAP) w/ DPST ALT ACTION (1-NO & 1-NC CONTACT)

MOUNTED ON SINGLE GANG PLATE

$146.00

5211-MP23XE1

5211-LMP23 1-9/16" DIA. ILLUMINATED PUSH BUTTON (RED CAP) w/

DPST MOMENTARY ACTION (1-NO & 1-NC CONTACT)

MOUNTED ON SINGLE GANG PLATE

$185.00

5211-MP23DA/* 1-9/16"DIA. MUSHROOM PUSH BUTTON (SPECIFY CAP

COLOR) w/PNEUMATIC 2-60 DELAY (FORM Z) $336.00

5216 PALM BUTTONS 2-3/8" DIA

5216-MP23/* 2-3/8" DIA. PALM BUTTON (SPECIFY CAP COLOR) w/

DPST MOMENTARY (1-NO & 1-NC CONTACT) $130.00

5216-MP24/* 2-3/8" DIA. PALM BUTTON (SPECIFY CAP COLOR) w/

DPST ALT ACTION (1-NO & 1-NC CONTACT) MOUNTED

ON SINGLE GANG PLATE

$175.00

5216-MP23PP 2-3/8" DIA. PALM BUTTON (RED CAP) PUSH-PULL W/

DPST ALT ACTION (1-NO & 1-NC CONTACT) $156.00

5216-MP23XE3

5216-MP23DA/* 2-3/8" DIA. PALM BUTTON (SPECIFY CAP COLOR) W/

PNEUMATIC 2-60 SEC. DELAY (FORM Z) $346.00

5211/16 LATCHING BUTTONS WITH KEY RESET

5211-MP23/KR 1-9/16" DIA. DURESS PUSH BUTTON (RED CAP) DPST

LATCHING/ KEY RESET (1-NO & 1-NC CONTACT) ON

SINGLE GANG PLATE

$250.00

5216-MP23/KR 2-3/8" DIA. DURESS PUSH BUTTON (RED CAP) DPST

LATCHING WITH KEY RESET (1-NO & 1-NC CONTACT)

ON SINGLE GANG PLATE

$262.00

5211-028L 28 VOLT LAMPS- PKG. OF 4 $16.00

(SUFFIX) 5211 & 5216 PUSH BUTTON OPTIONS: (ADD)

5211-MP23KRXE2

/R * DESIGNATES RED CAP 'N/C

/G * DESIGNATES GREEN CAP (NON STOCK ITEM) 'N/C

/B * DESIGNATES BLACK CAP 'N/C

/BU * DESIGNATES BLUE CAP (NON STOCK ITEM) $10.00

-02CB ADDITIONAL NO CONTACT BLOCK (Requires 2-3/4" $18.00

-03CB ADDITIONAL NC CONTACT BLOCK deep back box) $18.00

xL ADD 1 LED BLACK BEZEL (BI-COLOR RED/GREEN) $14.00

xAT ADJUSTABLE 1-60 SEC. TIMER DPDT OUTPUT $100.00

xFT FIXED 30 SECOND TIMER DPDT RELAY OUTPUT $100.00

XTS TAMPER PROOF SCREWS & HEX KEY $12.00

(SUFFIX) ENGRAVING OPTIONS (RED TEXT) (ADD)

xE1 S/S PLATE ENGRAVED "PUSH TO EXIT" $18.00

xE2 S/S PLATE ENGRAVED "PANIC" $18.00

xE3 S/S PLATE ENGRAVED "EMERGENCY RELEASE" $18.00

xE4 S/S PLATE ENGRAVED "PUSH TO RELEASE" $18.00

5210/COV xE5 ENGRAVED "PULL TO RELEASE" $18.00

xE6 PER PLATE FEE AFTER SET UP $24.00

(ORDER AS LINE ITEM)---- XE6SETUP CUSTOM ENGRAVING 1 SET UP FEE PER RUN $60.00

XHCP HANDICAP LOGO BLUE ENGRAVING $40.00

(PREFIX) 5210 SERIES SWITCH PLATE OPTIONS (ADD)

WR WEATHER RESISTANT 1-GANG PLATE $8.00

DDOUBLE GANG SWITCH PLATE $12.00

NNARROW 1-3/4" PLATE FOR FRAME MOUNTING $6.00

5210/COV ANTI TAMPER PLEXIGLAS BUTTON COVER $65.00

PUSH TO

EXIT

PANIC

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 20 5000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ACTUATORS

PART # DESCRIPTION LIST PRICE

5215 SERIES SQUARE EXIT PUSH BUTTONS

5215 ILLUMINATED SQUARE PUSH BUTTONS

5215-SPB 1-1/2" ILLUMINATED SQUARE PUSH BUTTON (GREEN

COLOR CAP ONLY) w/ SPDT MOMENTARY SWITCH

CONTACTS MOUNTED ON SS SINGLE GANG PLATE

LAMP BULBS ARE RATED @ 28VDC MAX

$68.00

5215-SPBxE1 1-1/2" ILLUMINATED SQUARE PUSH BUTTON

"PUSH TO EXIT" LETTERING ON GREEN CAP w/ SPDT

MOMENTARY SWITCH CONTACTS MOUNTED ON SS

SINGLE GANG PLATE

$72.00

5215-SPBxE1

5215-SPBxE3 1-1/2" ILLUMINATED SQUARE PUSH BUTTON

"EXIT" LETTERING ON GREEN CAP w/ SPDT

MOMENTARY SWITCH CONTACTS MOUNTED ON SS

SINGLE GANG PLATE

$72.00

5215-SPBxL 1-1/2" ILLUMINATED SQUARE PUSH BUTTON (GREEN

CAP ONLY) w/ SPDT MOMENTARY SWITCH CONTACTS

& BICOLOR LED MOUNTED ON SS SINGLE GANG

PLATE

$80.00

5215-SPBxLxE1 1-1/2" ILLUMINATED SQUARE PUSH BUTTON

"PUSH TO EXIT" LETTERING ON GREEN CAP w/ SPDT

MOMENTARY SWITCH CONTACTS & BICOLOR LED

MOUNTED ON SS SINGLE GANG PLATE

$84.00

5215-SPBxLxE3 1-1/2" ILLUMINATED SQUARE PUSH BUTTON

"EXIT" LETTERING ON GREEN CAP w/ SPDT

MOMENTARY SWITCH CONTACTS & BICOLOR LED

MOUNTED ON SS SINGLE GANG PLATE

$84.00

5215-028L 28 VOLT DC MAX REPLACEMENT LAMP $6.00

5215-SPBxE3 (SUFFIX) (ADD)

xAT 1-60 SECOND TIMER DPDT RELAY OUTPUT $100.00

xFT FIXED 30 SECOND TIMER DPDT RELAY OUTPUT

$

100.00

5210/COV

ANTI TAMPER PLEXIGLAS BUTTON COVER

PROTECTS PUSH BUTTON FROM BEING

ACCIDENTALLY ACTUATED MOUNTS OVER SINGLE

GANG SWITCH. 6-1/2"HIGH x 4"WIDE OVERALL $65.00

5210/COV

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 21 5000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ACTUATORS

PART # DESCRIPTION LIST PRICE

5220 SERIES DELAYED ACTION PUSH BUTTONS

5221 PNEUMATIC DELAY PUSH BUTTON

5221-P23DA PNEUMATIC TIME DELAY PUSH BUTTON SWITCH $265.00

(SUFFIX) 5221 TIME DELAY PUSH BUTTON OPTIONS (ADD)

xUS3 POLISHED BRASS PLATE $40.00

xUS4 SATIN BRASS PLATE $40.00

xL ADD 1 LED BLACK BEZEL (BICOLOR RED / GREEN) $20.00

ENGRAVING OPTIONS

xE1 S/S PLATE ENGRAVED "PUSH TO EXIT" $18.00

5221-P23DA xE2 S/S PLATE ENGRAVED "PANIC" $18.00

xE3 S/S PLATE ENGRAVED "EMERGENCY RELEASE" $18.00

xE4 S/S PLATE ENGRAVED "PUSH TO RELEASE" $18.00

xE6 PER PLATE FEE AFTER SET UP $24.00

(ORDER AS LINE ITEM)---- XE6SETUP CUSTOM ENGRAVING 1 SET UP FEE PER RUN $60.00

(PREFIX) 5221 NARROW SWITCH PLATE OPTIONS

NADD NARROW 1-3/4" PLATE FOR FRAME MOUNTING $6.00

5230 SERIES SNAP ACTION PUSH BUTTONS

5231 PUSH BUTTONS 3/8" DIAMETER

5231-P15 1 SPDT MOMENTARY PUSH BUTTON (1-GANG PLATE) $58.00

5231-2P15 2 SPDT MOMENTARY PUSH BUTTON (1-GANG PLATE) $82.00

5231-3P15 3 SPDT MOMENTARY PUSH BUTTON (1-GANG PLATE) $112.00

ENGRAVING OPTIONS SAME AS 5221 ABOVE

5231-P15 (SUFFIX) 5231 SWITCH OPTIONS (ADD): (ADD)

xL ADD 1 LED BLACK BEZEL (BICOLOR RED / GREEN) $20.00

(PREFIX) 5231 NARROW SWITCH PLATE OPTIONS

NADD NARROW 1-3/4" PLATE FOR FRAME MOUNTING $6.00

DADD DOUBLE GANG SWITCH PLATE $12.00

N5231-P15

5236 SERIES SNAP ACTION MINI BOX

5236 PUSH BUTTONS ON MINI-BOX CONSOLE

2-1/2 LONG X 2 WIDE X 1" HIGH

5236-P14 1 SPDT MAINTAINED BUTTON MINI-BOX MOUNTED $90.00

5236-2P14 2 SPDT MAINTAINED BUTTONS MINI-BOX MOUNTED $114.00

5236-3P14 3 SPDT MAINTAINED BUTTONS MINI-BOX MOUNTED $142.00

5236-P15 1 SPDT MOMENTARY BUTTON MINI-BOX MOUNTED $90.00

5236-2P15 2 SPDT MOMENTARY BUTTONS MINI-BOX MOUNTED $114.00

5236-3P15 3 SPDT MOMENTARY BUTTONS MINI-BOX MOUNTED $142.00

5236-P24 1 DPDT MAINTAINED BUTTON MINI-BOX MOUNTED $120.00

5236-2P24 2 DPDT MAINTAINED BUTTONS MINI-BOX MOUNTED $174.00

5236-3P24 3 DPDT MAINTAINED BUTTONS MINI-BOX MOUNTED $232.00

5236-P15 5236-P25 1 DPDT MOMENTARY BUTTON MINI-BOX MOUNTED $115.00

5236-2P25 2 DPDT MOMENTARY BUTTONS MINI-BOX MOUNTED $164.00

5236-3P25 3 DPDT MOMENTARY BUTTONS MINI-BOX MOUNTED $217.00

5236-T24 1 DPDT MAINTAINED TOGGLE MINI-BOX MOUNTED $120.00

HEAVY DUTY ALL METAL BUTTONS

5236-P24-H 1 DPDT MAINTAINED BUTTON MINI-BOX MOUNTED $146.00

5236-2P24-H 2 DPDT MAINTAINED BUTTONS MINI-BOX MOUNTED $196.00

5236-3P24-H 3 DPDT MAINTAINED BUTTONS MINI-BOX MOUNTED $250.00

5236-P25-H 1 DPDT MOMENTARY BUTTON MINI-BOX MOUNTED $146.00

5236-2P25-H 2 DPDT MOMENTARY BUTTONS MINI-BOX MOUNTED $196.00

5236-3P25-H 3 DPDT MOMENTARY BUTTONS MINI-BOX MOUNTED $250.00

(SUFFIX) SWITCH OPTIONS (ADD TO ABOVE): (ADD)

xL ADD 1 LED (BICOLOR RED / GREEN) 2P-15 ONLY $20.00

xL2 ADD 2 LEDS (BICOLOR RED / GREEN) P-15 ONLY $28.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 22 5000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ACTUATORS

PART # DESCRIPTION LIST PRICE

5240 SERIES ELECTRICAL KEY SWITCH CONTROLS

5241 KEY SWITCHES ON SINGLE GANG PLATE

5241-K12 SP N.O. MOM KEY REMOVABLE ONE POSITION $80.00

5241-K24 SPDT-MAINTAIN KEY REMOVABLE TWO POSITIONS $70.00

5241-K331 DPDT MAINT. KEY REMOVABLE IN ONE POSITION $110.00

5241-K332 DPDT MAINT. KEY REMOVABLE IN TWO POSITIONS $110.00

5241-K65-HS SPDT-HIGH SECURITY KEY REMOVABLE 2 POSITIONS $275.00

5246000K SPARE KEY SPECIFY K24 THRU K332 $10.00

52400065 SPARE KEY SPECIFY K65-HS $40.00

D (Prefix) DOUBLE GANG SWITCH PLATE $20.00

5246 KEY SWITCH ON MINI-BOX CONSOLE

3-3/4 LONG X 2-1/2 WIDE X 1-1/2" HIGH

5241-K24x3P15

5246-K24 SPDT KEY SWITCH KEY REMOVABLE IN TWO

POSITIONS ADD PUSH BUTTONS BELOW

AS REQUIRED (3/8" DIA)

$125.00

5246-2K24 DUAL SPDT KEY SWITCHES KEY REMOVABLE IN TWO

POSITIONS ADD MAX 2 PUSH BUTTONS BELOW

AS REQUIRED (3/8" DIA)

$175.00

5246-K331 DPDT KEY SWITCH KEY REMOVABLE IN ONE

POSITION ADD PUSH BUTTONS BELOW

AS REQUIRED (3/8" DIA)

$205.00

5246-K332 DPDT KEY SWITCH KEY REMOVABLE IN TWO

POSITIONS ADD PUSH BUTTONS BELOW

AS REQUIRED (3/8" DIA)

$205.00

5246-K24xP15

5246-K65-HS SPDT HIGH SECURITY KEY SWITCH KEY REMOVABLE

IN ONE POSITION ADD PUSH BUTTONS BELOW

AS REQUIRED (3/8" DIA)

$290.00

5246 ENCLOSURE W/O KEY SWITCH FOR ADDING

OPTIONAL COMPONENTS BELOW $70.00

(SUFFIX) 5246 SWITCH OPTIONS (ADD TO ABOVE) (ADD)

ANY COMBINATION OF 4 LED's OR PUSH BUTTONS

MAY BE COMBINED w/ 1 KEY SWITCH

LEDS

xL ADD 1 LED BLACK BEZEL (BICOLOR RED / GREEN) $14.00

SPDT MAINTAINED BUTTONS

xP14 ADD ONE SPDT MAINTAINED BUTTON $25.00

x2P14 ADD TWO SPDT MAINTAINED BUTTONS $50.00

x3P14 ADD THREE SPDT MAINTAINED BUTTONS $75.00

x4P14 ADD FOUR SPDT MAINTAINED BUTTONS $100.00

SPDT MOMENTARY BUTTONS

xP15 ADD ONE SPDT MOM PUSH BUTTON $25.00

x2P15 ADD TWO SPDT MOM PUSH BUTTONS $50.00

x3P15 ADD THREE SPDT MOM PUSH BUTTONS $75.00

x4P15 ADD FOUR SPDT MOM PUSH BUTTONS $100.00

DPDT MOMENTARY BUTTONS

xP25 ADD ONE DPDT MOMENTARY BUTTON $50.00

x2P25 ADD TWO DPDT MOMENTARY BUTTONS $100.00

x3P25 ADD THREE DPDT MOMENTARY BUTTONS $150.00

x4P25 ADD FOUR DPDT MOMENTARY BUTTONS $200.00

DPDT MAINTAINED BUTTONS

xP24 ADD ONE DPDT MAINTAINED BUTTON $55.00

x2P24 ADD TWO DPDT MAINTAINED BUTTONS $110.00

x3P24 ADD THREE DPDT MAINTAINED BUTTONS $165.00

x4P24 ADD FOUR DPDT MAINTAINED BUTTONS $220.00

HEAVY DUTY ALL METAL BUTTONS

xP24-H ADD 1 DPDT MAINTAINED HEAVY DUTY BUTTON $80.00

x2P24-H ADD 2 DPDT MAINTAINED HEAVY DUTY BUTTONS $160.00

xP25-H ADD 1 DPDT MOMENTARY HEAVY DUTY BUTTON $80.00

x2P25-H ADD 2 DPDT MOMENTARY HEAVY DUTY BUTTONS $160.00

xT24 ADD 1 DPDT MAINTAINED TOGGLE $55.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 23 5000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ACTUATORS

PART # DESCRIPTION LIST PRICE

5276 SERIES WEATHER PROOF HEAVY DUTY

WR5276-HD22 SS BUTTONS

WR5276-HD22 5/8" ROUND STAINLESS WEATHER PROOF BUTTON

IP66 RATED w/ DPNO MMOMENTARY CONTACTS

MOUNTED ON SINGLE GANG SS PLATE

$125.00

NWR5276-HD22 5/8" ROUND STAINLESS WEATHER PROOF BUTTON

IP66 RATED w/ DPNO MMOMENTARY CONTACTS

MOUNTED ON 1-3/4" NARROW SS PLATE

$131.00

1GANG WR5276 SS BUTTONS

WR5276-HD28 3/4" ROUND STAINLESS BUTTON WEATHER PROOF

IP65 w/ DPST MAINTAIN (1-NO & 1-NC CONTACT)

MOUNTED ON SINGLE GANG SS PLATE

$175.00

WR5276-HD22XE8

WR5276-HD29 3/4" ROUND STAINLESS BUTTON WEATHER PROOF

IP65 w/ DPST MOMENTARY (1-NO & 1-NC CONTACT)

MOUNTED ON SINGLE GANG SS PLATE

$175.00

1 GANG ILLUMINATED WR5276 SS BUTTONS

WR5276-HD28

xLRG

3/4" ROUND STAINLESS BUTTON w/ ILLUMINATED LED

RING WEATHER PROOF IP65 w/ DPST MAINTAIN (1-NO

& 1-NC CONTACT) 1 GANG SS PLATE

$195.00

WR5276-HD29

xLRG

3/4" ROUND STAINLESS BUTTON w/ ILLUMINATED LED

RING WEATHER PROOF IP65 w/ DPST MOMENTARY (1-

NO & 1-NC CONTACT) 1 GANG SS PLATE

$195.00

NARROW WR5276 SS BUTTONS

WR5276-HD28

NWR5276-HD28 3/4" ROUND STAINLESS BUTTON WEATHER PROOF

IP65 w/ DPST MAINTAIN (1-NO & 1-NC CONTACT)

MOUNTED ON NARROW 1-3/4" SS PLATE

$181.00

NWR5276-HD29 3/4" ROUND STAINLESS BUTTON WEATHER PROOF

IP65 w/ DPST MOMENTARY (1-NO & 1-NC CONTACT)

MOUNTED ON NARROW 1-3/4" SS PLATE

$181.00

NARROW ILLUMINATED 5276 SS BUTTONS

NWR5276-HD28

xLRG

3/4" ROUND STAINLESS BUTTON w/ ILLUMINATED LED

RING WEATHER PROOF IP65 w/ DPST MAINTAIN (1-NO

& 1-NC CONTACT) MOUNTED ON NARROW 1-3/4" SS

PLATE

$191.00

NWR5276-HD29

xLRG

3/4" ROUND STAINLESS BUTTON w/ ILLUMINATED LED

RING WEATHER PROOF IP65 w/ DPST MOMENTARY (1-

NO & 1-NC CONTACT) MOUNTED ON NARROW 1-3/4"

SS PLATE

$191.00

NWR5276-HD28xLRG (SUFFIX) (ADD)

xAT 1-60 SECOND TIMER DPDT RELAY OUTPUT $100.00

xFT FIXED 30 SECOND TIMER DPDT RELAY OUTPUT $100.00

(PREFIX)

DDOUBLE GANG SWITCH PLATE $20.00

(SUFFIX) ENGRAVING OPTIONS

xE1 PLATE ENGRAVED "PUSH TO EXIT" $18.00

xE2 PLATE ENGRAVED "PANIC" $18.00

xE3 PLATE ENGRAVED "EMERGENCY RELEASE" $18.00

xE4 PLATE ENGRAVED "PUSH TO RELEASE" $18.00

xE5 PLATE ENGRAVED "EMERGENCY DOOR RELEASE" $18.00

xE6 PER PLATE FEE AFTER SET UP $24.00

(ORDER AS LINE ITEM)---- XE6SETUP CUSTOM ENGRAVING 1 SET UP FEE PER RUN $60.00

xE8 PLATE ENGRAVED "DOOR BELL" $18.00

XHCP HANDICAP LOGO BLUE ENGRAVING $40.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 24 5000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ACTUATORS

PART # DESCRIPTION LIST PRICE

5276 SERIES 1" DIAMETER PUSH BUTTONS

5276-G SERIES 1" GUARDED PUSH BUTTONS

5276-GP8/* ALTERNATE ACTION PUSH BUTTON SWITCH DPST

GUARD MOUNTED ON SINGLE GANG PLATE $150.00

5276-GP9/* MOMENTARY ACTION PUSH BUTTON SWITCH DPST

GUARD MOUNTED ON SINGLE GANG PLATE $90.00

5276-GP23DA/* PNEUMATIC 2-60 SEC. DELAY (FORM Z) GUARDED

SWITCH ON SINGLE GANG BACK PLATE $290.00

5276-MP9/BxE1

5276 SERIES HEAVY DUTY PUSH BUTTONS

5276-HD23DA HEAVY DUTY (VANDAL RESISTANT) 1" STEEL PUSH

BUTTON PNEUMATIC 2-60 SEC. DELAY (FORM Z) ON

SINGLE GANG STAINLESS STEEL BACK PLATE

$385.00

5276-HD28 HEAVY DUTY (VANDAL RESISTANT) 1" STEEL PUSH

BUTTON ALTERNATE ACTION (DPDT) SWITCH

MOUNTED ON STANDARD S/S SINGLE GANG PLATE

$175.00

5276-HD29 HEAVY DUTY (VANDAL RESISTANT) 1" STEEL PUSH

BUTTON MOMENTARY (DPDT) SWITCH MOUNTED ON

STANDARD S/S SINGLE GANG PLATE

$175.00

(SUFFIX) 5276 SERIES OPTIONS ADD TO ABOVE (ADD)

N5276-HD28xE2

xAT ADJUSTABLE 1 - 60 SEC. TIMER DPDT OUTPUT $100.00

xFT FIXED 30 SECOND TIMER DPDT RELAY OUTPUT $100.00

xL

(

FOR HEAVY DUTY xHD SERIES CHROME BEZEL

)

$24.00

(PREFIX)

NNARROW 1-3/4" PLATE $6.00

DDOUBLE GANG SWITCH PLATE $12.00

(SUFFIX) AVAILABLE ON 5276-MP & GP SERIES ONLY

/R * DESIGNATES RED BUTTON CAP N/C

/B * DESIGNATES BLACK BUTTON CAP N/C

/G * DESIGNATES GREEN BUTTON CAP (NON STOCK) N/C

(SUFFIX) ENGRAVING OPTIONS

xE1 PLATE ENGRAVED "PUSH TO EXIT" $18.00

xE2 PLATE ENGRAVED "PANIC" $18.00

xE3 PLATE ENGRAVED "EMERGENCY RELEASE" $18.00

xE4 PLATE ENGRAVED "PUSH TO RELEASE" $18.00

xE5 PLATE ENGRAVED "EMERGENCY DOOR RELEASE" $18.00

xE6 PER PLATE FEE AFTER SET UP $24.00

(ORDER AS LINE ITEM)---- XE6SETUP CUSTOM ENGRAVING 1 SET UP FEE PER RUN $60.00

XHCP HANDICAP LOGO BLUE ENGRAVING $40.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 25 5000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ACTUATORS

PART # DESCRIPTION LIST PRICE

5277 SERIES PIEZO ELECTRIC SWITCHES

5277 SERIES PIEZO ELECTRIC SWITCHES

W5277-PZL TIME DELAY (1-60 SECOND) PIEZO SWITCH

1 SET N.O. 1 SET N.C. CONTACTS WITH ILLUMINATED

BI COLOR LED RING MOUNTED ON STANDARD

STAINLESS STEEL 1 GANG PLATE COMPLETELY

SEALED FOR WEATHER RESISITANCE

$275.00

W5277-PZLXE1

N5277-PZL TIME DELAY (1-60 SECOND) PIEZO SWITCH

1 SET N.O. 1 SET N.C. CONTACTS WITH ILLUMINATED

BI COLOR LED RING MOUNTED ON NARROW 1-3/4"

STAINLESS STEEL PLATE COMPLETELY SEALED FOR

WEATHER RESISITANCE

$275.00

(SUFFIX) 5277 STOCK ENGRAVING (ADD)

(ADD)

xE1 ADD "PUSH TO EXIT" IN RED LETTERS (W Series only) $20.00

xE3 ADD "EXIT" IN RED LETTERS $20.00

N5277-PZLXE3

5277 CUSTOM ENGRAVING (ADD)

xE6 PER PLATE FEE AFTER SET UP $24.00

(ORDER AS LINE ITEM)---- XE6SETUP CUSTOM ENGRAVING 1 SET UP FEE PER RUN $60.00

5278 SERIES TOUCHLESS ELECTRIC SWITCHES

5278 SERIES TOUCHLESS ELECTRIC SWITCHES

W5278-25 INFRARED PROXIMITY ACTIVATED SWITCH

DOUBLE POLE DOUBLE THROW RELAY CONTACTS

WITH ILLUMINATED BI COLOR LED RING MOUNTED

ON STAINLESS STEEL 1 GANG PLATE (12VDC)

$106.00

D5278-25 INFRARED PROXIMITY ACTIVATED SWITCH

DOUBLE POLE DOUBLE THROW RELAY CONTACTS

WITH ILLUMINATED BI COLOR LED RING MOUNTED

ON STAINLESS STEEL 2 GANG PLATE (12VDC)

$118.00

W5278-25XE1W

(SUFFIX) 5278 STOCK ENGRAVING (ADD)

xE1W ADD "WAVE TO OPEN" IN BLACK LETTERS $12.00

xE3 ADD "EXIT" IN BLACK LETTERS $12.00

5278 CUSTOM ENGRAVING (ADD)

xE6 PER PLATE FEE AFTER SET UP $24.00

(ORDER AS LINE ITEM)---- XE6SETUP CUSTOM ENGRAVING 1 SET UP FEE PER RUN $60.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 26 5000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ACTUATORS

PART # DESCRIPTION LIST PRICE

5286 SERIES PUSH PLATE SWITCHES

NARROW STYLE PUSH PLATE SWITCHES

N5286-P24 DPDT MAINTAINED ACTION SWITCH WITH 1-1/2" WIDE

PUSH PLATE ON 1-3/4" ALUMINUM BACK PLATE $114.00

N5286-P25 DPDT MOMENTARY ACTION SWITCH WITH 1-1/2" WIDE

PUSH PLATE ON 1-3/4" ALUMINUM BACK PLATE $100.00

N5286-P25xE1

N5286-P23DA PNEUMATIC 2-60 SECOND DELAY (FORM Z) SWITCH

WITH 1-1/2" WIDE PUSH PLATE ON 1-3/4" ALUMINUM

BACK PLATE

$332.00

N5286-AT ADJUSTABLE 2-60 SECOND TIMER DPDT OUTPUT $186.00

N5286-FT FIXED 30 SECOND TIMER DPDT RELAY OUTPUT $186.00

N5286-ET ADJUSTABLE 2-60 SEC. EXIT TIMER DPDT OUTPUT $220.00

SINGLE GANG PUSH PLATE SWITCHES

W5286-P24 DPDT MAINTAINED ACTION SWITCH WITH 1-1/2" WIDE

PUSH PLATE ON 3" WIDE ALUMINUM BACK PLATE $114.00

W5286-P25 DPDT MOMENTARY ACTION SWITCH WITH 1-1/2" WIDE

PUSH PLATE ON 3" WIDE ALUMINUM BACK PLATE $100.00

W5286-P25xE1

W5286-P23DA PNEUMATIC 2-60 SEC. DELAY (FORM Z) SWITCH WITH

1-1/2" WIDE PUSH PLATE ON 3" WIDE BACK PLATE $332.00

W5286-AT ADJUSTABLE 2-60 SECOND TIMER DPDT OUTPUT $186.00

W5286-FT FIXED 30 SECOND TIMER DPDT RELAY OUTPUT $186.00

W5286-ET ADJUSTABLE 2-60 SEC. EXIT TIMER DPDT OUTPUT $220.00

DOUBLE GANG PUSH PLATE SWITCHES

D5286-P24 DPDT MAINTAINED ACTION SWITCH WITH 4" WIDE

PUSH PLATE ON 4-5/8" WIDE ALUMINUM BACK PLATE $138.00

D5286-P25 DPDT MOMENTARY ACTION SWITCH WITH 4" WIDE

PUSH PLATE ON 4-5/8" WIDE ALUMINUM BACK PLATE $126.00

D5286-P25xE1

D5286-P23DA PNEUMATIC 2 - 60 SEC. DELAY (FORM Z) SWITCH

WITH 4" PUSH PLATE ON 4-5/8" WIDE BACK PLATE $356.00

D5286-AT ADJUSTABLE 2-60 SECOND TIMER DPDT OUTPUT $210.00

D5286-FT FIXED 30 SECOND TIMER DPDT RELAY OUTPUT $210.00

D5286-ET ADJUSTABLE 2-60 SEC. EXIT TIMER DPDT OUTPUT $245.00

(SUFFIX) (ADD)

xL ADD 1 LED BLACK BEZEL (BICOLOR RED / GREEN)

RECESSED INTO PUSH PAD

(NOT AVAILABLE ON "D" SERIES)

$28.00

********* PLEASE SEE PAGE 29 FOR ENGRAVING & FINISH OPTIONS*********

PUSH

TO

EXIT

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 27 5000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ACTUATORS

PART # DESCRIPTION LIST PRICE

5286 SERIES ROUND PUSH PLATE SWITCHES

ROUND PUSH PLATE SWITCHES

R5286-P24 DPDT MAINTAINED ACTION SWITCH WITH 2-1/2"

ROUND PALM BUTTON ON 3" WIDE ALUMINUM BACK

PLATE

$120.00

R5286-P25 DPDT MOMENTARY ACTION SWITCH WITH 2-1/2"

ROUND PALM BUTTON ON 3" WIDE ALUMINUM BACK

PLATE

$110.00

R5286-P23DA PNEUMATIC 2-60 SECOND DELAY (FORM Z) SWITCH

WITH 2-1/2" ROUND PALM BUTTON ON 3" WIDE

ALUMINUM BACK PLATE

$332.00

R5286-P25xE1

R5286-AT ADJUSTABLE 2-60 SECOND TIMER DPDT OUTPUT $196.00

R5286-FT FIXED 30 SECOND TIMER DPDT RELAY OUTPUT $196.00

R5286-ET ADJUSTABLE 2-60 SEC. EXIT TIMER DPDT OUTPUT $245.00

(SUFFIX) (ADD)

xL ADD 1 LED BLACK BEZEL (BICOLOR RED / GREEN) $20.00

********* PLEASE SEE NEXT PAGE FOR ENGRAVING & FINISH OPTIONS*********

PUSH

TO

EXIT

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 28 5000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ACTUATORS

PART # DESCRIPTION LIST PRICE

5286 SERIES CUSTOM FINISHES & ENGRAVING

5286 STOCK ENGRAVING (ADD)

(SUFFIX) (ADD)

xE1 ADD "PUSH TO EXIT" IN BLACK LETTERS $18.00

xE1R ADD "PUSH TO EXIT" IN RED LETTERS $18.00

xE2 ADD "PANIC" IN RED LETTERS $18.00

xE3 ADD "EXIT" IN RED LETTERS $18.00

xE4 ADD "DOOR RELEASE" IN BLACK LETTERS $18.00

xE5 ADD "EMERGENCY DOOR RELEASE" IN RED LETTERS $20.00

xE6 PER PLATE FEE AFTER SET UP $24.00

(ORDER AS LINE ITEM)---- XE6SETUP CUSTOM ENGRAVING 1 SET UP FEE PER RUN $60.00

(SUFFIX) 5286 STANDARD HANDICAP LOGOS (ADD)

xHCP ADD FOR BLUE LOGO ON CLEAR ALUMINUM ONLY $42.00

xHCP2 ADD FOR BLUE LOGO W/ "PUSH TO OPEN" ON CLEAR

ALUMINUM $50.00

xHCP3 ADD FOR WHITE LOGO ON BLUE PLATE

W / "PUSH TO OPEN" ENGRAVED (D-SERIES ONLY) $90.00

ENGRAVING ON RED, BLACK & DARK BRONZE PUSH

PLATES WILL BE WHITE

D5286-P25xHCP

(SUFFIX) 5286 SERIES FINISH OPTIONS (ADD)

xBRE ADD FOR BAKED RED ENAMEL FINISH (NON-STOCK) $32.00

xDBA ADD FOR DARK BRONZE ANODIZED (STOCKED) $32.00

(IF BUTTON IS XBRE OR XDBA TEXT IS WHITE)

xUS26 ADD FOR POLISHED CHROME -

xUS26D ADD FOR SATIN CHROME -

xUS3 ADD FOR POLISHED BRASS -

xUS4 ADD FOR SATIN BRASS -

ALL PLATED FINISHES - (N,W & R SERIES) $225.00

ALL PLATED FINISHES - (D SERIES) $270.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 29 5000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ACTUATORS

PART # DESCRIPTION LIST PRICE

5287 SERIES HEAVY DUTY PUSH BUTTON SWITCHES

SINGLE GANG PUSH BUTTON SWITCHES

W5287-P24 DPDT MAINTAINED ACTION SWITCH WITH 1-1/2"

DIAMETER BUTTON ON ALUMINUM BACK PLATE $140.00

W5287-P25 DPDT MOMENTARY ACTION SWITCH WITH 1-1/2"

DIAMETER BUTTON ON ALUMINUM BACK PLATE $138.00

W5287-P23DA PNEUMATIC 2 - 60 SEC. DELAY (FORM Z) SWITCH

WITH 1-1/2" DIAMETER BUTTON ON ALUMINUM BACK

PLATE

$360.00

W5287xE3

W5287-AT ADJUSTABLE 1 - 60 SECOND TIMER DPDT OUTPUT

WITH 1-1/2" DIAMETER BUTTON ON ALUMINUM BACK

PLATE

$205.00

W5287-FT FIXED 30 SECOND TIMER DPDT OUTPUT WITH

1-1/2" DIAMETER BUTTON ON 3" WIDE ALUMINUM

BACK PLATE

$205.00

W5287-ET ADJUSTABLE 1 - 60 SECOND EXIT TIMER DPDT

OUTPUT WITH 1-1/2" DIAMETER BUTTON ON

ALUMINUM BACK PLATE

$230.00

DOUBLE GANG PUSH PLATE SWITCHES (ADD)

D5287- CHANGE "W" TO "D" TO SPECIFY A DOUBLE GANG

4-5/8" WIDE ALUMINUM BACK PLATE WITH 1-1/2"

DIAMETER BUTTON

$40.00

(SUFFIX) 5287 STOCK ENGRAVING (ADD): (ADD)

D5287xE1

xE1 ADD "PUSH TO EXIT" IN BLACK LETTERS $18.00

xE1R ADD "PUSH TO EXIT" IN RED LETTERS $18.00

xE3 ADD "EXIT" IN RED LETTERS $18.00

xE6 PER PLATE FEE AFTER SET UP $24.00

(ORDER AS LINE ITEM)---- XE6SETUP CUSTOM ENGRAVING 1 SET UP FEE PER RUN $60.00

5287 STANDARD HANDICAP LOGOS

xHCP ADD HANDICAP BLUE LOGO ON CLEAR ALUMINUM $40.00

xHCP3 ADD HANDICAP WHITE LOGO ON BLUE ALUMINUM $40.00

(SUFFIX) 5287 SERIES FINISH OPTIONS (ADD)

xDBA ADD FOR DARK BRONZE ANODIZED $32.00

xBRE ANODIZED RED FINISH (ON BUTTON ONLY) BACK

PLATE CLEAR ANODIZED OR PLATED FINISH $32.00

(IF BUTTON IS XBRE XSBA OR XDBA TEXT IS WHITE)

xUS26 ADD FOR POLISHED CHROME -

xUS26D ADD FOR SATIN CHROME -

xUS3 ADD FOR POLISHED BRASS -

xUS4 ADD FOR SATIN BRASS -

ALL PLATED FINISHES - (W SERIES) $225.00

ALL PLATED FINISHES - (D SERIES) $270.00

(SUFFIX) (ADD)

xL ADD 1 LED (BICOLOR RED / GREEN) $24.00

CHROME BEZEL FOR HEAVY DUTY SERIES

EXIT

PUSH

EXIT

TO

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 30 5000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ACCESSORIES

PART #

DESCRIPTION

LIST PRICE

6200 SERIES DOOR CORD

6200 SERIES DOOR CORD

6220 18" ARMORED DOOR CORD WITH SURFACE MOUNT

J-BOX 1-5/8" WIDE x 3" LONG x 1-1/8" DEEP

(INCLUDES 4 CONDUCTOR 22 AWG CABLE)

STANDARD COLOR ALUMINUM

$58.00

(SUFFIX)

ARMORED DOOR CORD FINISHES (ADD):

xDBA

A

DD FOR DARK BRONZE COLORED CORD AND

J-BOX ARMORED DOOR CORD N/C

6400 SERIES EGRESS BARS

6400 SERIES EGRESS SWITCH BARS

6420-S25 EGRESS BAR FOR 36" DOOR WITH DUAL SPDT

SWITCHES STANDARD ALUMINUM FINISH $425.00

6495 RIM STYLE MECHANICAL LATCHING FOR 36" DOOR

UL LISTED PANIC DEVICE (NO SWITCH) $340.00

6495-S25 RIM STYLE MECHANICAL LATCHING FOR 36" DOOR

PANIC DEVICE WITH 2 SPDT SWITCHES $440.00

(SUFFIX)

WEATHERPROOF SWITCHES

(ADD)

xWR

DUAL SEALED WEATHERPROOF SPDT

SWITCHES FOR OUTDOOR APPLICATIONS

$90.00

(SUFFIX)

EGRESS BAR SPECIAL FINISHES:

(ADD)

xDBA ADD FOR DARK BRONZE ANODIZED FINISH $16.00

X48 ADD FOR DOORS OVER 36" UP TO 48" (NON STOCK) $40.00

6450 SERIES LEVER TRIM

6450 SERIES LEVER TRIM DEVICE

LEVER TRIM WORKS WITH 6495 SERIES RIM PANIC $245.00

xK STANDARD 1-1/8" MORTISE CYLINDER & 2 KEYS $40.00

xDBA DARK BRONZE FINISH N.C.

A DOOR CORD IS TYPICALLY REQUIRED TO TRANSFER POWER TO AN EGRESS BAR

PUSH TO EXIT

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 31 6000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ACCESSORIES

PART #

DESCRIPTION

LIST PRICE

6500 SERIES EMERGENCY PULL STATIONS

6500 SERIES EMERGENCY PULL STATIONS

6510/*-S35 PULL STATION W/ TWO SPDT (FORM C) SWITCHES $175.00

6510/*-S35xCS PULL STATION W/ TWO SPDT (FORM C) SWITCHES

WITH LOCAL PIEZO 12-24VDC

$205.00

*

SPECIFY COLOR:

/BL = BLUE ENAMEL FINISH

/BK = BLACK ENAMEL FINISH

/YL = YELLOW ENAMEL FINISH

SURFACE MOUNT COLORED BACK BOXES

4-7/8 H x 3-1/2 W x 2" D

6510/BX-BK BLACK SURFACE MOUNT BACK BOX $65.00

6510/BX-BL BLUE SURFACE MOUNT BACK BOX $65.00

6510/BX-YL YELLOW SURFACE MOUNT BACK BOX $65.00

6510 SERIES ANTI TAMPER COVERS

FLUSH MOUNT STYLE 2-1/2" DEEP ID

6510/COV 4-7/8"W x 5-1/2"H x 2-1/2"D LIFT TO ACCESS PULL $145.00

6510/COV/S SAME AS ABOVE WITH PIEZO ALARM SOUNDER $250.00

6510/COV/SR ANTI-TAMPER COVER W/SOUNDER & SPDT RELAY $275.00

6510/COV

SURFACE MOUNT STYLE 3-7/8" DEEP ID

W/ EXTENSION FOR USE WITH 6510 BACK BOX

6510/COV-X 4-7/8"W x 5-1/2"H x 3-7/8"D LIFT TO ACCESS PULL $180.00

6510/COV/S-X SAME AS ABOVE WITH PIEZO ALARM SOUNDER $285.00

6510/COV/SR-X ANTI-TAMPER COVER W/SOUNDER & SPDT RELAY $375.00

6510/COV-X

(SUFFIX) ACCESSORIES (ADD)

(ORDER AS LINE ITEM)---- XE6SETUP CUSTOM LABELING SETUP $60.00

XE6 PER UNIT FEE AFTER SET UP $20.00

651000K SPARE KEY FOR 6510-S35 PULL $12.00

6510/BR BREAK RODS 12 PER PACK $24.00

65-6581 BACK PLATE FOR 6510/COV ,COV/S & COV/SR $38.00

FOR MOUNTING TO UNEVEN SURFACE

6600 SERIES MOTION DETECTORS

6612 UL LISTED REQUEST-TO-EXIT PIR MOTION

DETECTOR (12/24 VDC) w/ ADJUSTABLE (1-120

SECOND) TIME DELAY IN A SLIM LINE 7.1" x 1.65" x

1.65" IVORY COLORED CASE (ONE DPDT FORM C

ALARM OUTPUT)

$250.00

OPEN DOOR

EMERGENCY

PULL HANDLE

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963 Page 32 6000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ANNUNCIATORS

PART # DESCRIPTION LIST PRICE

7101 SERIES DELAYED EGRESS CONTROLLERS

EDR SYSTEM-101 CONTROLLER

7101-P EDR-101 DELAYED EGRESS CONTROL PANEL

KEYPAD CONSOLE, AUDIBLE ALERT, 3 SECOND

NUISANCE / 15 SECOND ALARM DELAY,

PROGRAMMABLE CLOCK / DAY SCHEDULER, 3

STATUS OUTPUTS, PROGRAMMABLE ESCORT

CODE FOR KEYPAD (OR OPTIONAL KEY SWITCH)

$1,280.00

INCLUDES 12 VDC 1 AMP POWER SUPPLY, WITH 9

VOLT RECHARGEABLE BATTERY, 3 GANG S/S

FLUSH MOUNT PLATE, 3 GANG (IVORY) SURFACE

MOUNT BOX, AND 20 FOOT LONG HOOK-UP

CABLES

EDR SYSTEM-101 ACCESSORIES:

7101-KP AUXILIARY KEYPAD - SUPPLIED WITH 15 FOOT

CABLE, WEATHER RESISTANT FOR AUTHORIZED

ACCESS FROM SECURED SIDE

$430.00

5141-24xK DPDT MAINTAINED KEY SWITCH - EDR-101 ALARM

SHUNT / BY-PASS SEE PAGE 19 FOR DETAILED

DESCRIPTION $166.00

5216-MP23xE3 PUSH BUTTON SWITCH - EMERGENCY RELEASE

SEE PAGE 20 FOR DETAILED DESCRIPTION $148.00

6420-S25 EGRESS BAR w/ TWO SPDT SWITCHES

(ACTIVATES EDR-101 & HAS 1 EXTRA OUTPUT)

SEE PAGE 31 FOR DETAILS

$425.00

6200 SERIES DOOR CORD

6220 18" ARMORED DOOR CORD WITH SURFACE

MOUNT J-BOX (INCLUDES 4 CONDUCTOR 22 AWG

CABLE) STANDARD COLOR ALUMINUM

$58.00

1110xD SINGLE DOOR 1200 LB LOCK w/ DOOR SWITCH

(FOR USE w/ EDR-101 & 6420-S25 EGRESS BAR

RELEASE)

$460.00

1107xEDR SINGLE DOOR 600 LB LOCK w/ DPS & ATTEMPTED

EGRESS SWITCH (FOR USE w/ EXISTING HDWR.)

$600.00

1110xEDR SINGLE DOOR 1200 LB LOCK w/ DPS &

ATTEMPTED EGRESS SWITCH (FOR USE w/

EXISTING HDWR.)

$640.00

NOTE: FOR DOUBLE DOORS USE TWO (2) LOCKS

WHICH MAY REQUIRE ADDITIONAL POWER @12V

PUSH TO EXIT

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963

Page 33 7000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ANNUNCIATORS

PART # DESCRIPTION LIST PRICE

7201 SERIES HI-INTENSITY LED INDICATORS

7201-H HI-INTENSITY LEDS 11/16" DIA.

7201xL1*-H 1 HIGH INTENSITY LED MOUNTED ON A 1 GANG

STAINLESS STEEL PLATE $60.00

7201xL1*-HxCS 1 HIGH INTENSITY LED 1 PIEZO MOUNTED ON A 1

GANG STAINLESS STEEL PLATE $90.00

7201xL2-H 1 EACH RED/GREEN HIGH INTENSITY LED

MOUNTED ON A 1 GANG STAINLESS STEEL PLATE $112.00

7201xL2-H 7202xL2-HxCS 1 EACH RED/GREEN HIGH INTENSITY LED 1 PIEZO

MOUNTED ON A 2 GANG STAINLESS STEEL PLATE $142.00

* SPECIFY LED COLOR R=RED G=GREEN

7201-HWR WATER PROOF HI-INTENSITY LEDS 1" DIA.

7201xL1*-HWR 1 WATER PROOF HIGH INTENSITY LED MOUNTED

ON A 1 GANG STAINLESS STEEL PLATE $66.00

7202xL2-HxCS

7201xL1*-HWRxCSW 1 WATER PROOF HIGH INTENSITY LED 1 WATER

PROOF (12VDC) PIEZO MOUNTED ON A 1 GANG

STAINLESS STEEL PLATE

$122.00

7201xL2-HWR 1 EACH WATER PROOF RED/GREEN HIGH

INTENSITY LED MOUNTED ON A 1 GANG

STAINLESS STEEL PLATE

$120.00

7202xL2-HWRxCSW 1 EACH WATER PROOF RED/GREEN HIGH

INTENSITY LED 1 WATER PROOF (12VDC)PIEZO

MOUNTED ON A 2 GANG STAINLESS STEEL PLATE

$176.00

STANDARD LED INDICATORS

7201 STANDARD LEDS SMALL DIA. 3/16"

7201xL1R-HWRxCSW 7201xL1 1 BICOLOR LED WITH CHROME BEZEL MOUNTED

ON A 1 GANG STAINLESS STEEL PLATE $52.00

7201xL2 2 BICOLOR LEDS WITH CHROME BEZEL MOUNTED

ON A 1 GANG STAINLESS STEEL PLATE $76.00

PIEZO SOUNDERS CONTINUOUS 12-24VDC

7201xCS PIEZO CONTINUOUS SOUNDER ON 1 GANG SS $46.00

7201xCSW WATER PROOF PIEZO SOUNDER ON 1 GANG SS $72.00

(SUFFIX) ADD OPTIONAL PIEZO CONTINUOUS SOUNDERS (ADD)

7201xL1 xCS ADD PIEZO SOUNDER $30.00

xCSW ADD WATER PROOF PIEZO SOUNDER $60.00

7201xL1 xCSW-A ADD WATER PROOF PIEZO W/ADJ. VOLUME $80.00

(SUFFIX) ADD OPTIONAL LEDS (ADD)

xL ADD FOR EACH BICOLOR LED W/CHROME BEZEL $24.00

(SUFFIX) ADD OPTIONAL SWITCHES (ADD)

xT24 ADD FOR EACH DPDT-MAINTAINED TOGGLE $40.00

xT25 ADD FOR EACH DPDT-MOMENTARY TOGGLE $40.00

xP14

A

DD FOR EACH SPDT-MAINT.PUSH BUTTON $25.00

xP15 ADD FOR EACH SPDT-MOM PUSH BUTTON $25.00

xP25 ADD FOR EACH DPDT-MOM PUSH BUTTON $45.00

ADD CUSTOM ENGRAVING

xE6 PER PLATE FEE AFTER SET UP $24.00

(ORDER AS LINE ITEM)---- XE6SETUP CUSTOM ENGRAVING 1 SET UP FEE PER RUN $60.00

(PREFIX) ADD OPTIONAL MOUNTING PLATES (ADD)

DDOUBLE GANG SWITCH PLATE $12.00

NNARROW 1-3/4" PLATE FOR FRAME MOUNTING $8.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963

Page 34 7000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ANNUNCIATORS

PART # DESCRIPTION LIST PRICE

7200 SERIES MULTI-ZONE ANNUNCIATORS

7200 SERIES CUSTOM ANNUNCIATORS

7204 3 GANG PLATE WITH 4-ZONE OVERLAY ADD FOR

LEDS, TOGGLE SWITCHES, PUSH BUTTONS,

KEYSWITCH AND SOUNDER - COMPONENTS ALL

HAVE FLYING LEADS (NO LOGIC OR TERMINALS

INCLUDED)

$275.00

7204 7204 3 GANG PLATE WITHOUT 4-ZONE OVERLAY $140.00

STAINLESS STEEL PLATE ADD PARTS & ENGRAVING

7208 4 GANG PLATE WITH 8-ZONE OVERLAY ADD FOR

LEDS, TOGGLE SWITCHES, PUSH BUTTONS,

KEYSWITCH AND SOUNDER - COMPONENTS ALL

HAVE FLYING LEADS (NO LOGIC OR TERMINALS

INCLUDED)

$310.00

7208 4 GANG PLATE WITHOUT 4-ZONE OVERLAY $180.00

7208 STAINLESS STEEL PLATE ADD PARTS & ENGRAVING

8 + ZONE PANELS ADD $25.00 FOR EACH ZONE OVER 8 ZONES EA. ZONE $25.00

NOTE: CUSTOM & RACK MOUNT CONFIGURATIONS

AVAILABLE TO SUIT INDIVIDUAL APPLICATIONS (Call for quote)

7202-ENCL SLOPED DESK TOP CONSOLE 2 GANG PLATE $300.00

7604/8-ENCL SLOPED DESK TOP CONSOLE 4-8 ZONES $400.00

9" X 6" X 2-3/4" ALUMINUM BLACK ENAMEL FINISH

(SUFFIX) 7200 SERIES ADD ON COMPONENTS (ADD)

xL ADD FOR EACH BICOLOR LED W/CHROME BEZEL $24.00

xT24 ADD FOR EACH DPDT-MAINT.TOGGLE SWITCH $60.00

xT25 ADD FOR EACH DPDT-MOM.TOGGLE SWITCH $60.00

xP14 ADD FOR EACH SPDT-MAINT.PUSH BUTTON $30.00

xP15 ADD FOR EACH SPDT-MOM. PUSH BUTTON $30.00

xP24 ADD FOR EACH DPDT-MAINT. PUSH BUTTON $60.00

xP25 ADD FOR EACH DPDT-MOM. PUSH BUTTON $60.00

xCS ADD PIEZO SOUNDER $40.00

xK24 ADD SPDT MAINTAINED KEY SWITCH $80.00

xTERM 10 POSITION DOUBLE ROW TERMINAL 6 1/2" LONG $40.00

xDI Pack of 4 LOOSE DIODES FOR SOUNDER/LED OPERATION $10.00

ADD CUSTOM ENGRAVING

FOR STAINLESS 3&4 GANG PLATES WITHOUT OVERLAY

xE6 PER PLATE FEE AFTER SET UP (1 word per zone) $80.00

ADD PER GANG FEE OVER 4 GANG PLATE $50.00

(ORDER AS LINE ITEM)---- XE6SETUP CUSTOM ENGRAVING 1 SET UP FEE PER RUN $140.00

NOTE: 7200 SERIES ANNUNCIATORS ARE SUPPLIED WITH

FLYING LEADS ONLY.

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963

Page 35 7000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ANNUNCIATORS

PART # DESCRIPTION LIST PRICE

7281 SERIES LOCAL DOOR EXIT ALARMS

EXIT ALARM

7281-EA DOOR ALARM WITH ADJUSTABLE (2 TO 60

SECONDS) DELAY, ALARM OUTPUT (DPDT)

RELAY, TRI-STATE LED, AND LOCAL ALARM PIEZO

(RESET ON DOOR RE-SECURE) ON STANDARD

SINGLE GANG PLATE

$335.00

7281-EA EXIT ALARM WITH KEY SWITCH RESET

7281-EAxK332 DOOR ALARM WITH ADJUSTABLE (2 TO 60

SECONDS) DELAY, ALARM OUTPUT (DPDT)

RELAY, TRI-STATE LED, AND LOCAL ALARM PIEZO

RESET BY DPDT MAINTAINED ELECTRIC

KEYSWITCH PROVIDED. KEY REMOVABLE IN 2

POSITIONS ON STANDARD DOUBLE GANG PLATE

$395.00

7281-EAxK332

EXIT ALARM WITH PUSH BUTTON

7281-EAxMP23 DOOR ALARM WITH ADJUSTABLE (2 TO 60

SECONDS) DELAY, ALARM OUTPUT (DPDT)

RELAY, TRI-STATE LED, AND LOCAL ALARM PIEZO

(RESET ON DOOR RE-SECURE). INCLUDES

MOMENTARY REX BUTTON 1-9/16" DIAMETER ON

STANDARD DOUBLE GANG PLATE

$465.00

7281-EAxMP23xE1 7281-EAxK24 EXIT ALARM FOR MORTISE CYLINDER

DOOR ALARM WITH ADJUSTABLE (2 TO 60

SECONDS) DELAY, TRI-STATE LED, ALARM

OUTPUT (DPDT) RELAY WITH LOCAL ALARM PIEZO

(RE-SET BY MORTISE KEY SWITCH), INCLUDES 2

(DPDT) KEY SWITCH CONTACTS 1 MOMENTARY 1

MAINTAINED FOR ALARM SHUNT OR RESET ON

DOUBLE GANG PLATE (CYLINDER NOT

INCLUDED ADD "XK" PER OPTIONS BELOW)

$430.00

7281-EA-K24xK

(SUFFIX) 7281 EXIT ALARM OPTIONS (ADD)

xCT COVER TAMPER SWITCH SPDT $59.00

xK STANDARD 1-1/8" MORTISE CYLINDER & 2 KEYS $40.00

xKNR CYLINDER WITH KEY NON-REMOVABLE IN THE ON

POSITION $50.00

xW OFF WHITE BAKED ENAMEL PLATE FINISH $20.00

(SUFFIX) 7281-EAxMP23 ENGRAVING OPTIONS (ADD)

xE1 "PUSH TO EXIT" (RED TEXT) $18.00

xE5 "EMERGENCY DOOR RELEASE" (RED TEXT) $20.00

ADD CUSTOM ENGRAVING

xE6 PER PLATE FEE AFTER SET UP $24.00

(ORDER AS LINE ITEM)---- XE6SETUP CUSTOM ENGRAVING 1 SET UP FEE PER RUN $60.00

PUSH

TO

EXIT

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963

Page 36 7000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ANNUNCIATORS

PART # DESCRIPTION LIST PRICE

7286 SERIES LOCAL DOOR PROP ALARMS

LOCAL DOOR PROP ALARM

7286-PT5 DOOR PROP ALARM WITH ADJUSTABLE (0-

SECONDS TO 90-MINUTES) DOOR OPEN DELAY,

ALARM OUTPUT (DPDT) RELAY, TRI-STATE LED,

AND LOCAL ALARM PIEZO, ADJUSTABLE LOCAL

WARNING TIME DELAY & MIRRORED DOOR

SWITCH OUTPUT

$565.00

7286-PT5

DOOR PROP ALARM WITH KEY SWITCH

7286-PT5-24 $670.00

7286-PT5-24xK

SHOWN

DOOR PROP ALARM WITH PUSH BUTTON

7286-PT5xMP23 DOOR PROP ALARM WITH ADJUSTABLE (0-

SECONDS TO 90-MINUTES) DOOR OPEN DELAY,

TRI-STATE LED, ALARM OUTPUT (DPDT) RELAY

WITH LOCAL ALARM PIEZO, ADJUSTABLE LOCAL

WARNING TIME DELAY & MIRRORED DOOR

SWITCH OUTPUT

(AUTOMATIC ALARM RESET BY TIMER OR DOOR

RE-SECURE), AND MOMENTARY ACTION PUSH

BUTTON SWITCH (1-NO/1-NC) ON DOUBLE

GANG PLATE

$610.00

7286-PT5xMP23xE1

SHOWN

(SUFFIX) 7286 DOOR PROP ALARM OPTIONS (ADD)

xCT COVER TAMPER SWITCH SPDT $59.00

xK STANDARD 1-1/8" MORTISE CYLINDER & 2 KEYS $40.00

xKNR CYLINDER WITH KEY NON-REMOVABLE IN THE ON

POSITION $50.00

xW OFF WHITE BAKED ENAMEL PLATE FINISH $20.00

(SUFFIX) 7286xMP23 ENGRAVING OPTIONS (ADD)

xE1 "PUSH TO EXIT" (RED TEXT) $18.00

xE5 "EMERGENCY DOOR RELEASE" (RED TEXT) $20.00

ADD CUSTOM ENGRAVING

xE6 PER PLATE FEE AFTER SET UP $24.00

(ORDER AS LINE ITEM)---- XE6SETUP CUSTOM ENGRAVING 1 SET UP FEE PER RUN $60.00

DOOR PROP ALARM WITH ADJUSTABLE (0-

SECONDS TO 90-MINUTES) DOOR OPEN DELAY,

TRI-STATE LED, ALARM OUTPUT (DPDT) RELAY

WITH LOCAL ALARM PIEZO, ADJUSTABLE LOCAL

WARNING TIME DELAY & MIRRORED DOOR

SWITCH OUTPUT

(RE-SET BY TIMER, DOOR RE-SECURE OR KEY

SWITCH), INCLUDES 2 (DPDT) KEY SWITCH

CONTACTS 1 MOMENTARY 1 MAINTAINED FOR

ALARM SHUNT OR ALARM RESET ON DOUBLE

GANG PLATE (CYLINDER NOT INCLUDED ADD

"XK" PER OPTIONS BELOW)

PUSH

TO

EXIT

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963

Page 37 7000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ANNUNCIATORS

PART # DESCRIPTION LIST PRICE

7600 SERIES MULTI-ZONE ANNUNCIATOR/CONTROLLERS

7600 ANNUNCIATOR MULTI-GANG CONSOLES

7604-H

ANNUNCIATOR/CONTROLLER WITH LED

INDICATORS & TOGGLE SWITCHES FOR EACH

ZONE. SECURITY KEY SWITCH FOR LED TEST,

NORMAL CONTROL, RESTRICTED OPERATION,

AND SILENCED ALERT SOUNDER MODE.

CONFIGURED IN FOUR ZONE INCREMENTS

MOUNTED ON MULTI-GANG STAINLESS STEEL

SWITCH PLATES OR 19" WIDE RACK MOUNTABLE

PLATES WITH BLACK OVERLAY SUITABLE FOR

FLUSH MOUNTING.

7604-H 4 ZONE HARDWIRED ANNUNCIATOR/

CONTROLLER ON THREE GANG PLATE (6-1/2"

WIDE x 4-1/2" HIGH x 2-1/2" DEEP)

$1,050.00

4 ZONE EXPANSION ADD (TO #7604 ABOVE) FOR EACH ADDITIONAL 4

ZONE EXPANSION MODULE (EXAMPLES BELOW)

$500.00

#7608-H = $1,550.00 (EIGHT ZONES TOTAL)

#7612-H = $2,050.00 (TWELVE ZONES TOTAL)

#7616-H = $2,550.00 (SIXTEEN ZONES TOTAL)

#7620-H = $3.050.00 (TWENTY ZONES TOTAL)

OPTIONAL MOMENTARY SWITCHES ADD

7608-H

MOMENTARY PUSH BUTTONS ARE AVAILABLE.

SPECIFY UPON ORDERING. THESE ARE NON

STOCK, CHECK FOR AVAILABILITY. UTILIZING

MOMENTARY PUSH BUTTONS DISABLES THE

NORMALLY OPEN LOCK OUTPUT CAPABILITY;

ONLY THE NORMALLY CLOSED OUTPUT IS

ACTIVE

$140.00 FOR

EVERY 4 ZONES

760006-K SPARE KEY FOR 7600 ANNUNCIATOR $30.00

*****MINIMUM OF 10 KEYS PER ORDER******

ALL 7600'S HAVE 2 ORIGINAL KEYS SUPPLIED

MULTIPLE UNITS MAY BE SPECIFIED KEYED ALIKE

DESK TOP ANNUNCIATOR ENCLOSURES

7600 SERIES SLOPED FACE ENCLOSURES:

ALUMINUM CONSTRUCTION BLACK BAKED

ENAMEL FINISH

7604/8-ENCL

9 x 6 x 2-3/4"

DESKTOP SLOPE FACE ENCLOSURE FOR FOUR

OR EIGHT ZONE CONSOLES $400.00

7612/16-ENCL

15 x 6 x 2-3/4"

DESKTOP SLOPE FACE ENCLOSURE FOR TWELVE

OR SIXTEEN ZONE CONSOLES $470.00

7620/24-ENCL

19 x 6 x 2-3/4"

DESKTOP SLOPE FACE ENCLOSURE FOR TWENTY

OR TWENTY FOUR ZONE CONSOLES $505.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963

Page 38 7000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ANNUNCIATORS

PART # DESCRIPTION LIST PRICE

7600 SERIES ANNUNCIATOR DIMENSIONS

7600 SERIES MOUNTING PLATE SIZES:

Model # Plate Width x Height - Plate Type

#7604 6-1/2" x 4-1/2" 3-GANG SWITCH PLATE (4-Zones)

#7608 8-1/4" x 4-1/2" 4-GANG SWITCH PLATE (8-Zones)

#7612 11-3/4" x 4-1/2" 6-GANG SWITCH PLATE (12-Zones)

#7616 13-1/2" x 4-1/2" 7-GANG SWITCH PLATE (16-Zones)

#7620 17-1/2" x 4-1/2" 9-GANG SWITCH PLATE (20-Zones)

SUFFIX 7604 THRU 7620 OPTIONAL RACK MOUNT PLATE

xRM MOUNTED ON RACK MOUNT PLATE '19" x 5-1/4" ADD $100.00

NO ADDITIONAL CHARGE FOR 7624 & LARGER RACK MOUNT PLATES

N/C

#7624 19" x 5-1/4" RACK MOUNT PLATE (24-Zones)

#7628 * 19" x 7" RACK MOUNT PLATE (28-Zones)

#7632 19" x 7" RACK MOUNT PLATE (32-Zones)

#7636 19" x 10-1/2" RACK MOUNT PLATE (36-Zones)

#7640 19" x 7" RACK MOUNT PLATE (40-Zones)

#7644 * 19" x 10-1/2" RACK MOUNT PLATE (44-Zones)

#7648 19" x 9-1/4" RACK MOUNT PLATE (48-Zones)

#7652 * 19" x 10-1/2" RACK MOUNT PLATE (52-Zones)

#7656 * 19" x 10-1/2" RACK MOUNT PLATE (56-Zones)

#7660 19" x 10-1/2" RACK MOUNT PLATE (60-Zones)

#7664 19" x 12-1/4" RACK MOUNT PLATE (64-Zones)

#7668 * 19" x 18-1/2" RACK MOUNT PLATE (68-Zones)

#7672 19" x 18-1/2" RACK MOUNT PLATE (72-Zones)

#7676 * 19" x 12-1/4" RACK MOUNT PLATE (76-Zones)

#7680 19" x 12-1/4" RACK MOUNT PLATE (80-Zones)

#7684 * 19" x 18-1/2" RACK MOUNT PLATE (84-Zones)

#7688 * 19" x 18-1/2" RACK MOUNT PLATE (88-Zones)

#7692 * 19" x 18-1/2" RACK MOUNT PLATE (92-Zones)

#7696 19" x 18-1/2" RACK MOUNT PLATE (96-Zones)

#76100 19" x 15-1/4" RACK MOUNT PLATE (100-Zones)

#76104 * 19" x 18-1/2" RACK MOUNT PLATE (104-Zones)

#76108 * 19" x 18-1/2" RACK MOUNT PLATE (108-Zones)

#76112 * 19" x 18-1/2" RACK MOUNT PLATE (112-Zones)

#76116 * 19" x 18-1/2" RACK MOUNT PLATE (116-Zones)

#76120 19" x 18-1/2" RACK MOUNT PLATE (120-Zones)

ELECTRICAL BACK BOXES FOR FLUSH WALL MOUNTING

700353 3 GANG BACK BOX FOR 7604-H $46.00

700354 4 GANG BACK BOX FOR 7608-H $56.00

700356 6 GANG BACK BOX FOR 7612-H $70.00

*Due to the physical layout of these units there may be additional zones which

will be plu

gg

ed on the plate with black plastic inserts to match the black overla

y

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963

Page 39 7000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

ACCESS CONTROL

PART # DESCRIPTION LIST PRICE

8100 SERIES KEYPAD ACCESS CONTROLS

8112 SERIES DIGITAL KEY PADS

8112 USER PROGRAMMABLE DIGITAL KEY PAD $280.00

SINGLE DOOR STAND-ALONE ACCESS CONTROL

120 USER CODES PROGRAMMED FROM KEYPAD

1 TO 90 SECONDS ADJUSTABLE TIME DELAY

(RECOMMENDED FOR INTERIOR APPLICATIONS)

8112-WR WEATHER RESISTANT MEMBRANE KEY PAD $415.00

SINGLE DOOR STAND-ALONE ACCESS CONTROL

8112 120 USER CODES PROGRAMMED FROM KEYPAD

1 TO 90 SECONDS ADJUSTABLE TIME DELAY

WR500351 WEATHER RESISTANT SURFACE MOUNT SINGLE $25.00

GANG BOX FOR USE WITH 8112-WR

8160 SERIES HEAVY DUTY DIGITAL KEY PADS

HEAVY DUTY, ALL METAL, TOUCH SENSITIVE, WEATHERPROOF,

KEYPAD SINGLE DOOR STAND ALONE ACCESS CONTROL WITH

200 ACTIVE USER CODES

8160

8160xINT INTEGRATED UNIT SINGLE GANG MOUNT WITH ON-BOARD

ELECTRONICS 200 USER CODES SPDT. RELAY OUTPUT N.O.

PUSH BUTTON SWITCH INPUT

$450.00

8160xNSxINT NARROW INTEGRATED UNIT 1-3/4" WIDE WITH ON-BOARD

ELECTRONICS 200 USER CODES SPDT. RELAY OUTPUT N.O.

PUSH BUTTON SWITCH INPUT

$450.00

8160xNS

1 2

3 4

5 6

7 8

9 0

*#

123

456

789

0 #

*

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963

Page 40 8000 Series

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

MISCELLANEOUS

PART # DESCRIPTION LIST PRICE

MAG LOCK REPLACEMENT PARTS

MAGLOCK REPLACEMENT PARTS

1000701 LOCK MOUNTING KIT 1000 SERIES $12.00

1000702 TJ LOCK MOUNTING KIT 1000 SERIES $10.00

1100701 LOCK MOUNT KIT 1106,1107,1110,1150 $10.00

1100702 TJ-LOCK MOUNT KIT TJ1106,TJ1107,TJ1110,TJ1150 $11.50

1100721 DOUBLE LOCK MOUNTING KIT 1120, 1152 $11.50

1100722 DOUBLE TJ-LOCK MOUNTING KIT TJ1120, TJ1152 $14.00

1100703 ARMATURE MOUNTING KIT 1-3/4" DOOR $19.00

1100703.2 ARMATURE MOUNTING KIT 2" DOOR $26.00

1100703-SC ARMATURE MOUNTING KIT FOR XEDR LOCKS $18.00

1100704 TJ- ARMATURE MOUNTING KIT $14.00

1000051 1000 SERIES ARMATURE $75.00

1000054 1000 DPS ARMATURE W/ACTUATING MAGNET $82.00

1106051 1106 & 1107 SERIES ARMATURE $60.00

1106054 1106 & 1107 DPS ARMATURE W/ACTUATING MAGNET $66.00

1115051 1115 SERIES ARMATURE $50.00

1115054 1115 DPS ARMATURE W/ACTUATING MAGNET $66.00

1110051 1110 SERIES ARMATURE $68.00

1110054 1110 DPS ARMATURE W/ACTUATING MAGNET $75.00

1160011 DPS ACTUATING MAGNET ONLY $12.00

1160015 DPS SWITCH ONLY SPDT W/LEADS $28.00

1610051 1150 SERIES ARMATURE $80.00

1610054 1150 DPS ARMATURE W/ACTUATING MAGNET $85.00

1610155 1155 SERIES ARMATURE $64.00

1610154 1155 DPS ARMATURE W/ACTUATING MAGNET $70.00

SURFACE MOUNT PLATE FOR ARMATURE

(INCLUDES REQUIRED MOUNTING HARDWARE)

1110050 FOR 1000,1110,1150 (2 REQ. FOR 1120/1152/1155) $135.00

1115050 FOR 1106 & 1107 (2 REQUIRED FOR 1115 SERIES) $70.00

"Z" BRACKETS

TOP JAMB Z-BRACKETS w/ SEX NUT

1096-00 Z-BRACKET FOR 1000 "TJ" LOCKS $84.00

1196-06 Z-BRACKET FOR 1106 & 1107 "TJ" LOCKS $72.00

1196-10 Z-BRACKET FOR 1110 "TJ" LOCKS $84.00

1196-15L Z-BRACKET FOR 1115 "TJ" LOCKS $68.00

1196-15R Z-BRACKET FOR 1115 "TJ" LOCKS $68.00

1196-50 Z-BRACKET FOR 1150 "TJ" LOCKS $104.00

1196-55L Z-BRACKET FOR 1155 "TJ" LOCKS $80.00

1196-55R Z-BRACKET FOR 1155 "TJ" LOCKS $80.00

1196703 Z-BRACKET MOUNTING KIT $30.00

(SUFFIX) Z- BRACKET SPECIAL FINISHES

xDBA ADD FOR DARK BRONZE ANODIZED Z-BRACKET $60.00

xSBA ADD FOR SATIN BLACK ANODIZED Z- BRACKET $60.00

xUS3 ADD FOR POLISHED BRASS Z-BRACKET $250.00

xUS26 ADD FOR POLISHED CHROME Z-BRACKET $250.00

xUS4 ADD FOR SATIN BRASS Z-BRACKET $250.00

xUS26D ADD FOR SATIN CHROME Z-BRACKET $250.00

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963

Page 41 Misc Parts

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

MISCELLANEOUS

PART # DESCRIPTION LIST PRICE

SWITCH REPLACEMENT PARTS

5140 SERIES PARTS

5141090 CYLINDER W/ 2 KEYS FOR 5141 SERIES $40.00

5141703 CYLINDER MOUNTING KIT FOR 5141 KEY SWITCH $15.00

5215 SERIES SWITCHES

5215015 SPDT MOM ACTION SW. 8" LEADS $25.00

5230 SERIES SWITCHES

5230014L SPDT MAINTAINED SNAP ACTION SW. 8" LEADS $25.00

5230015L SPDT MOMENTARY SNAP ACTION SW. 8" LEADS $25.00

5230024L DPDT MAINTAINED SNAP ACTION SW. 8" LEADS $55.00

5230025L DPDT MOMENTARY SNAP ACTION SW. 8" LEADS $50.00

5140 & 5280 SERIES SWITCHES

(SPECIFY IF REPLACEMENT SWITCH IS FOR

A KEY SWITCH OR A PUSH BUTTON)

5280024L DPDT MAINTAIN ACTION SWITCH W/8" LEADS $40.00

5280025L DPDT MOMENTARY ACTION SWITCH W/8" LEADS $40.00

5280024T DPDT MAINTAIN TOGGLE SWITCH W/8" LEADS $50.00

TIME DELAY REPLACEMENT PARTS

5220023L PNEUMATIC 2-60 SEC. TIME DELAY SWITCH $250.00

52800AT AT ADJUSTABLE 2-60 SEC.TIMER DPDT 12/24 VDC $100.00

52800FT FT FIXED 30 SEC.TIMER DPDT 12/24 VDC $100.00

4505001 ET TIMER 2-60 SEC. DPDT 12/24 VDC $125.00

ELECTRICAL BOXES & ACCESSORIES

500351 1-GANG STANDARD ELECTRICAL BOX $15.00

500352 2-GANG STANDARD ELECTRICAL BOX $20.00

WR500351 1-GANG WEATHER RESISTANT ELECTRICAL BOX $25.00

WR500352 2-GANG WEATHER RESISTANT ELECTRICAL BOX $30.00

N500351 NARROW 1-3/4" JAMB MOUNT BACK BOX BLACK

HIGH IMPACT PLASTIC CONSTRUCTION $44.00

SS500351 SS 1 GANG SURFACE BOX FOR 5277 SERIES $75.00

SSN500351 SS NARROW SURFACE BOX 1-3/4 FOR"N" 5277 $60.00

LED REPLACEMENT PARTS

7020251 BLACK PLASTIC BEZEL (BICOLOR RED / GREEN)

W/6" LEADS $12.00

7020256 CHROME BEZEL FOR HD AND 7200 SERIES

ANNUNCIATORS (BICOLOR RED / GREEN) $24.00

7020252-HI HI INTENSITY RED W/6" LEADS $60.00

7020255-HI HI INTENSITY GREEN W/6" LEADS $60.00

7020252-HI-WR WEATHER PROOF HI INTENSITY RED 6" LEADS $66.00

7020255-HI-WR WEATHER PROOF HI INTENSITY GREEN 6" LEADS $66.00

MISC. REPLACEMENT PARTS

6410015-J 6420 / 6495 SERIES SPDT REPLACEMENT SWITCH (2

REQUIRED PER DEVICE) $36.00

6410015-JWR WEATHER PROOF SWITCH FOR SAME AS ABOVE $50.00

1100640 xCT COVER TAMPER REPLACEMENT SWITCH $30.00

LA-LABEL DOOR SIGN 15-30 $14.00

DELAYED EGRESS NFPA 101 SIGNAGE

DORTRONICS SYSTEMS, INC.

1668 SAG HARBOR TURNPIKE

SAG HARBOR, NY 11963

Page 42 Misc Parts

Pricing subject to change without notice

PHONE: (800) 906-0137

FAX: (631) 725-8148

www.dortronics.com

SALES - POLICIES AND PROCEDURES

Papers Needed to Open an Account:

A credit application is filled out and returned for processing. If customer is approved, they are set

up on a Net-30 Day Terms. Note: If customer information received back (bank, trade references, Dunn &

Bradstreet) is inconclusive, the sales representative will help decide terms (Net or COD).

Credit cards are also accepted: Visa, Mastercard and American Express.

Dortronics Systems, Inc. will not accept Credit card information via e-mail.

Minimum Order:

There is no minimum order; however, if a customer is going to buy a small quantity, low dollar

amount on a one-time basis, the order will be shipped COD or credit card. Customer also has the option to

send payment in advance.

Freight Policy:

Freight is prepaid and billed on all invoices which are mailed the day after shipment.

Carriers used are UPS, FED-EX and trucking. Customer may choose to use own account.

Drop ship Info:

To be advised during verbal phone order, or specified on E-mail or faxed purchase orders.

Contact (Sales):

Mike Palermo –,QVLGHSales0DQDJHU

3DWW\%U\DQW±6DOHV&XVWRPHU6HUYLFH

Bryan Sanderford -National Sales Manager

Contact (Technical):

Joe Hanna –Engineer/Applications Specialist

6WXDUW$UWKXU±7HFK6DOHV$SSOLFDWLRQV6SHFLDOLVW

Contact (Credit):

.HOO\+LOOHUXG –Accounting;New Customer Accounts

Special Dealer Programs:

Large quantity discount pricing is negotiable and reviewed on a situationDO basis.

Product Warranties

All electromagnetic locks have a LIFETIME GUARANTEE against defects in material and workmanship.

Defective units will be replaced or repaired based upon incoming evaluation and inspection.

All other Dortronics components of the Electric Locking System shall be similarly warranted for a period

of one year. Expressed warranties are conditionally based on the requirement that the items covered within

the guarantee are used and maintained in accordance with the manufacturer's recommendations.

Returns:

A Return Authorization Number must be obtained and accompany all returns within 14 days of issue.

Unused items returned for credit must be complete and packed in original unit box and are subject to a 15%

restocking fee. Any shipping, damaged parts or order discrepancies must be reported within 5 days of

receipt.

/3/2011

CREDIT APPLICATION

COMPANY NAME: __________________________________________PH: _____________________

STREET ADDRESS: _________________________________________FX: _____________________

CITY: __________________________________STATE:_____________ZIP: ____________________

PRINCIPALS TITLE OR POSITION

NAME: ________________________________________ ____________________________________

NAME: ________________________________________ ____________________________________

NAME: ________________________________________ ____________________________________

NAME: ________________________________________ ____________________________________

BANK: _______________________________________ BRANCH: _____________________________

ADDRESS: ___________________________________ PH: ________________________EXT:______

CITY: ________________________________________STATE: _________ ZIP: __________________

PERSON TO CONTACT: ________________________ POSITION: ____________________________

AMOUNT OF CREDIT REQUESTED: $____________

TRADE REFERENCES

1:_________________________________________ 2:_______________________________________

_________________________________________ _________________________________________

_________________________________________ _________________________________________

PH: __________________ FX:_________________ PH: __________________ FX: ________________

ACCOUNT #: _______________________________ ACCOUNT #: ______________________________

3:_________________________________________ 4:________________________________________

_________________________________________ __________________________________________

_________________________________________ __________________________________________

PH: __________________ FX: _________________ PH: ___________________FX: ________________

ACCOUNT #: _______________________________ ACCOUNT #: ______________________________

TERMS & CONDITIONS:

In consideration of credit extended we agree to pay invoices due within 30 days of invoice date.

A 2% interest fee may be applied to past due invoices.

DEFAULT:

In the case of default, all collection charges, Lawyers fees and interest will be borne by the

applicant Company.

We understand your terms and conditions as stated above and agree to abide by them in making this

application for credit. I also under stand that an investigative consumer report may be made.

We hereby authorize the release of any information from the above business references and our bank.

ALL REPLIES WILL BE KEPT CONFIDENTIAL

Signature required below by Company officer or duly authorized representative.

SIGNATURE: _________________________________________ TITLE: __________________

PRINT NAME: ________________________________________ DATE: ___________________

1668 SAG HARBOR TURNPIKE SAG HARBOR NY 11963

WHAT YOU WANT - WHEN YOU WANT IT

www.dortronics.com • (800) 906-0137 • (631) 725-8148 FAX • sales@dortronics.com
