Dov SHARKK K361 Bluetooth Keyboard User Manual K362 2
Dov Enterprises Inc / SHARKK Bluetooth Keyboard K362 2
User Manual
(1)
(2)
(3)
(4)
(5)
(6)
Wireless Keyboard
User Guide
If the keyboard is not working with the iPad (or other
Bluetoothdevices) make sure:
Troubleshooting
1)The Bluetooth function on the iPad (or other Bluetooth
devices)is enabled.
2)The Bluetooth keyboard is within 33 feet of the iPad.
3)The passkey is entered correctly.
4)Restart your device.
5)Make sure the keyboard is charged,recharge if low.
6)If you press the CONNECT button when both devices
have been connected already it will disrupt the
established connection.The keyboard will exhibit
as though it not connected with the keyboard .To
solve the issue simply restart the keyboard by
turning it OFF and then ON again.You do not need to
repair the device if it was done previously.
1)
2)Range of Frequency: 2.4GHz Spectrum
3)Operating Voltage: 3.7Vdc(powered by Li-ion)
4)Operation current: <5mA
5)Standby current: 1.0mA
6)Sleep current: <0.25mA
Transmit Range: up to 10 meters
This device complies with Part 15 of the FCC Rules:
Operation is subject to the following two conditions:
1.This device may not cause harmful interference and
2.This device must accept any interference that is
received,including any interference that may cause
undesired operation.
Product Specifications
Congratulation on selecting the Bluetooth Wireless
Keyboard for your high tech devices.The super slim
keyboard is quiet and crafted out of high grade plastic.
In this present age of portable tech gadgets this is an
ideal product for your iPad.
Welcome
Overview
Keyboard
How to Charge the battery:
To charge the keyboard, Connect the 5V.DC input from
the keyboard into the computer USB port with the
connector cableprovided. The Keyboard can function
while charging.
Step 2.Pairing your Bluetooth Keyboard with your
iPad/iMac/iPhone or other Bluetooth enabled device.
The following sample shows how to pair the Bluetooth
keyboardwith your iPad.
Before you can use your keyboard, you have to pair it with
your iPad.Pairing allows your keyboard to communicate
wirelessly with your iPad.You only have to perform the
pairing once.
1. Turn on the keyboard and press the CONNECT key on
the keyboard.The LED light will blink blue. Then on the
screen of the iPad, you search for Settings-->Bluetooth.
Prompted
Blue LED blinking: Pairing
Red LED on: Charging
Green LED on: Battery is fully charged
Green LED blinking: Low in Battery
Yellow LED on: Caps lock
2.Enable the Bluetooth function, and it will search for the
Bluetooth keyboard automatically. When the Bluetooth
keyboard is discovered, select the “Bluetooth keyboard”
from the ipad screen, a passkey will appear on the screen
of the iPad. Type in the passkey provided and press the
ENTER key on the keyboard. Your Bluetooth keyboard will
then be successfully paired with your iPad.
Installation Guide
1. For the first time user, Please charge the keyboard for
at least 6 hours before using it.Thereafter,charge for at
least 2 hours when the battery runs low.
2.The LED(green)will blink when battery is low.The
LED(green)will stay solid when fully charged.
3.Connect the charging cable(included)to charge
keyboard.
Step 1.Charging the battery
Caution:to properly operate this product please read the user manual thoroughly.
1) Open the protective case
2) Pull out the stand
3) Adjust the stand angle
4) Put the case on the groove of keyboard base
Using
Schematic diagram
Stand
Keyboard base
Protective Case
360
Vertical layout
360 degrees rotate
(1) (2)
(3) (4)
Installation and removal
1)Removing back protective piece.Hold tablet PC on
both sides(picture)gently push back cover off the
tablet PC with thumb(back piece held in place by
two tabs.)
2)Proceed to“peel”cover away from tablet PC
3) Take tablet PC out
4)Take table PC out upwards.
(1) (2)
(3) (4)
enter
return
caps lock
shift
DA F G H JK LS
W E R T Y UIOP
Q
XZ C V B N M < >
{ } |
~
delete
shift
tab
@
25
&
7
(
9
)
0
48
3
#
6
control
fn cmd cmd
alt
option
PgUp
Home EndPgDn
option
alt
[ ] / \
DC.5V. Input
OP|
delete
(
9
)
0
OP|
delete
(
9
)
0
Mute
Volume -
Volume +
PrevTrack
NextTrack
Play/pause
Main screen/Esc
Virtual Keyboard
Search
Preview photo
Brightness +
Brightness -
Lock screen
Change Language
Delete
Command
combination key, press FN key can
input the blue characters above on the
keyboard or control the blue keys.
fn-
Function
fn
Note: Keyboard should always remain on.
No need to power off. Because keyboard
has battery saving feature it will go to sleep
when not in use. This way connection will
never be lost. Keyboard will need to 5
seconds to wake up. Press a key and wait 5
seconds before using.
Federal Communications Commission (FCC) Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
z Reorient or relocate the receiving antenna.
z Increase the separation between the equipment and receiver.
z Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
z Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications made to this device not expressly approved by Dov Enterprises Inc / SHARKK may void the FCC authorization to operate this
device.
Note: The manufacturer is not responsible for any radio or tv interference caused by unauthorized modifications to this equipment. Such modifications could void the
user’s authority to operate the equipment.
