Users Manual
Model Name
BLP-A04-NR07
Doc. Number
EP01-15-011
Code
1.00
Date
2015.09.03
Drafter
Dongok Gang
Approver
하태양
Title
Product Specifications
Model Name : BLP-A04-NR07
Document No. : EP01-15-011
Pages : 8 pages (cover, revision history included)
Draft Review Approval
Distributor:
Product Specification
Original
General
DIF-113-01 DUALi Inc. 1/8
Model Name
BLP-A04-NR07
Doc. Number
EP01-15-011
Code
1.00
Date
2015.09.03
Drafter
Dongok Gang
Approver
하태양
Title
Product Specifications
Revision History
No Revision
date PAGE Contents
1 2015.09.03 all First edition
2
3
4
5
6
7
8
9
10
11
12
13
14
15
DIF-113-01 DUALi Inc. 2/8
Model Name
BLP-A04-NR07
Doc. Number
EP01-15-011
Code
1.00
Date
2015.09.03
Drafter
Dongok Gang
Approver
하태양
Title
Product Specifications
CONTENTS
1 Overview ......................................................................................... 오류! 책갈피가 정의되어 있지 않습니다.
1.1 Product Overview ......................................................................
오류
!
책갈피가
정의되어
있지
않습니다
.
1.2 Product specification .................................................................
오류
!
책갈피가
정의되어
있지
않습니다
.
1.3 Bluetooth specification ................................................................................................................................ 4
2 Configuration ................................................................................ 오류! 책갈피가 정의되어 있지 않습니다.
2.1 Hardware configuration ...........................................................
오류
!
책갈피가
정의되어
있지
않습니다
.
2.2 Block diagram ..........................................................................
오류
!
책갈피가
정의되어
있지
않습니다
.
2.3 Block description .....................................................................
오류
!
책갈피가
정의되어
있지
않습니다
.
3 Electrical specification ................................................................ 오류! 책갈피가 정의되어 있지 않습니다.
3.1 Power specification .................................................................
오류
!
책갈피가
정의되어
있지
않습니다
.
3.2 Current consumption (3.7V battery) .......................................................................................................... 6
4 Fuction specification.................................................................... 오류! 책갈피가 정의되어 있지 않습니다.
4.1 LED ........................................................................................................................................................... 7
4.2 Battery ....................................................................................................................................................... 7
4.3 Bluetooth ................................................................................................................................................... 7
5 Environment specification .......................................................... 오류! 책갈피가 정의되어 있지 않습니다.
5.1 Use environmnet ...................................................................
오류
!
책갈피가
정의되어
있지
않습니다
.
5.2 Storage environment ...............................................................
오류
!
책갈피가
정의되어
있지
않습니다
.
6 Certification ................................................................................... 오류! 책갈피가 정의되어 있지 않습니다.
DIF-113-01 DUALi Inc. 3/8
Model Name
BLP-A04-NR07
Doc. Number
EP01-15-011
Code
1.00
Date
2015.09.03
Drafter
Dongok Gang
Approver
하태양
Title
Product Specifications
1 Overview
1.1 Product overview
This is a smart card reader that reads the data from RF tag and sends them to HOST (PC, Smart phone) through
Bluetooth communication
1.2 Product specification
ITEM Specification Remark
CPU CC2540F (8051) 2.4-GHz Bluetooth® low energy System-on-Chip
Program Memory 128/256KByte FLASH
Data Memory 8KByte SRAM
RF Chip SIC9410 (MIFARE, NFC Tag)
DISPLAY Status LED
Communication Bluetooth LE, USB HID
Input voltage USB 5V(MINI USB), Battery 3.7V
Current specification 3.7V 550mA
Bluetooth Bluetooth 4.0 LE
Battery DC3.7V, 550, Li-Polymer,
(sustained operation: 8 hours , (stand by mode : Up to 18 hours)
1.3 Bluetooth Specification
ITEM Specification Remark
specification Bluetooth® low energy (BLE) 4.0 Certified ISM 2.4GHz
module.
Profiles embedded Bluetooth Protocols and Profiles
Transmit Power -23,-6,0,4dBm
Range 10 meters line-of-sight
Antenna embedded antenna
DIF-113-01 DUALi Inc. 4/8
Model Name
BLP-A04-NR07
Doc. Number
EP01-15-011
Code
1.00
Date
2015.09.03
Drafter
Dongok Gang
Approver
Ha Tae Yang
Title
Product Specifications
3 Electric specification
3.1 Power specification
- Rechargeable with USB 5V
- DC3.7V, 550mAh
3.2 Current consumption (3.7V battery)
- General current consumption: 20mA
- Maximum: 80mA
- measured by USB ammeter
DIF-113-01 DUALi Inc. 5/8
Model Name
BLP-A04-NR07
Doc. Number
EP01-15-011
Code
1.00
Date
2015.09.03
Drafter
Dongok Gang
Approver
Ha Tae Yang
Title
Product Specifications
4 Function specification
4.1 LED
- Battery and device status.
4.2 Battery
- Rechargeable with USB Power (5V), Use Battery (4.2V) when fully recharged
- 3.7V, 550mAh .
4.3 Bluetooth
Advertising Packet Format
Preamble
(1)
Access
Address(4)
PDU Header
(2)
Adv MAC
Addr(6)
Adv Data
(0~26) CRC(3)
Adv Data (0~10)
0x02 0x01 0x05 0x07 0x08 “BadaMR”
Adv Data (11~26)
0x0F 0xFF CID[0,1]
Device ID[0..7] (10)
NFC Service
UUID(2)
TxPowe
r
(1)
Battery
Level (1)
- CID: 0x1DB2
- Device ID: unique ID
- NFC Service UUID : 0xFFB0
- TxPower: -6,0
- Battery Level: 1~100
Scan Request Response Packet Format
Preamble
(1)
Access
Address(4)
PDU Header
(2)
Adv MAC Addr
(6)
Scan Response
(0~31) CRC(3)
Scan Response
0xLL 0xFF NFC Data Version
(1)
NFC Data Length
(1)
NFC Data
(4~17)
Sequence Number
(1)
DIF-113-01 DUALi Inc. 6/8
Model Name
BLP-A04-NR07
Doc. Number
EP01-15-011
Code
1.00
Date
2015.09.03
Drafter
Dongok Gang
Approver
Ha Tae Yang
Title
Product Specifications
5 Environment specification
5.1 Use environment
- Use temperature: -10 ~ 60 ℃
- Use humidity: 30 ~ 90 % (relative humidity)
5.2 Storage environment
- Storage temperature: -20 ~ 70 ℃
- Storage humidity: 30 ~ 90 % (relative humidity)
DIF-113-01 DUALi Inc. 7/8
Model Name
BLP-A04-NR07
Doc. Number
EP01-15-011
Code
1.00
Date
2015.09.03
Drafter
Dongok Gang
Approver
Ha Tae Yang
Title
Product Specifications
6 Certification
- FCC, KC certification required.
DIF-113-01 DUALi Inc. 8/8
: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Caution: Any changes or modifications to the equipment not expressly approved by the party responsible for
compliance could void user’s authority to operate the equipment.
This appliance and its antenna must not be co-located or operation in conjunction with any other antenna or transmitter.
A minimum separation distance of 20 ㎝ must be maintained between the antenna and the person for this appliance to
satisfy the RF exposure requirements.
