Lithium/Manganese Dioxide
Ultra 245
Li/MnO2
This data is subject to change. Performance information is typical. Contact Duracell for the latest information
Delivered capacity is dependent on the applied load, operating temperature and cut-off voltage. Please refer to the charts
and discharge data shown for examples of the energy / service life that the battery will provide for various load conditions.
**
6/08
Dimensions shown are IEC/ANSI standards
Duracell Ultra 245 Typical Performance
17.0
16.0 mm
34.0
32.5
16.4
15.6
mm
mm
45.0
43.0 mm
L
C
Nominal Voltage: 6 V
Typical Voltage: 6.4-6.6 V
Nominal Internal
Impedance: 0.45 ohm @ 1kHz
Average Weight: 38.6 gm
Typical Volume: 24.1 cm
3
Terminals: Flat, Recessed Contacts
Nickel Plated Steel
Operating Temperature
Range: -20
o
C to 75
o
C
(-4
o
F to 167
o
F)
ANSI:
IEC: 5032LC
2CR5
Delivered Energy vs. Power Drain
@ Various Cutoff Voltage - Room Temperature
4
10
0.1 14
Power (W)
Energy (Wh)
3.6 V
4.0 V
4.4 V
0 500 1000 1500 2000
Pulse Cycles
35mm SLR Photo
35mm Point &
Shoot Camera
1.2A, 3 sec on 7sec off, cont.
to 3.6 V @ 20°C
1.8A, 3 sec on 7sec off, cont.
to 3.6 V @ 20°C
0.9A, 3 sec on 27sec off, cont.
to 3.6 V @ 20°C
3
4
5
6
7
0.1 1 10 100 1000
Service (Hours)
Voltage (V)
10 mA
50 mA
100 mA
250 mA
500 mA
750 mA
1000 mA
6/08
Delivered capacity is dependent on the applied load, operating temperature and cut-off voltage. Please refer to the charts
and discharge data shown for examples of the energy / service life that the battery will provide for various load conditions.
**
This data is subject to change. Performance information is typical. Contact Duracell for the latest information
Berkshire Corporate ParkBerkshire Corporate ParkBerkshire Corporate ParkBerkshire Corporate Park
Bethel, CT 06801 U.S.A.Bethel, CT 06801 U.S.A.Bethel, CT 06801 U.S.A.Bethel, CT 06801 U.S.A.
Telephone: Toll-free 1-800Telephone: Toll-free 1-800Telephone: Toll-free 1-800-544-5454Telephone: Toll-free 1-800-544-5454
Internet: www.Internet: www.duracellduracell .com.com
Lithium/Manganese Dioxide
Ultra 245
Li/MnO2
Continuous Discharge
RT to 3.4 Volts
3
4
5
6
7
0.1
0.1 1
10
10
100
100
1000
1000
Service (Hours)
Service (Hours)
Voltage (V)
Voltage (V)
10 mA
10 mA
50 mA
50 mA
100 mA
100 mA
250 mA
250 mA
500 mA
500 mA
750 mA
750 mA
0.9 Amp, 3 sec on/27 sec off
@ Various Temperatures
3
4
5
0 400 800 1200 1600 2000
Pulses
Battery Voltage (V)
RT
1.2 Amp, 3 sec on/ 7 sec off
@ Various Temperatures
3
4
5
00210080040
Pulses
Battery Voltage (V)
RT
1.8 Amp 3 sec on/ 7 sec off
@ Various Temperatures
3
4
5
0090060030
Pulses
RT
-20C
-10C
1000 mA
1000 mA
-10C
-10C
-20C
Battery Voltage (V)
