DynaLockCorporation

705EmmettStreet

Bristol,CT06010

Phone:860.582.4761•Fax:860.585.0338

Email:info@dynalock.com•Website:www.dynalock.com

2000Series1200Lbs.HoldingForceElectromagneticLocks

The2000Seriesisafullsize1200lbs.holdingforceelectromagnet.Itisdesignedforlifesafetyand

highsecurityonratedornonrateddoorsandframes.Specifyforcommercial,industrial,orinstitutional

openingswhenlowcostandhighsecurityarerequired.

All2000Serieslocksaredesignedforeaseofinstallationwithadjustablemounting,fieldselectable

voltage,andconvenientwiringcompartments.Optionalintegrateddoorandlockstatussensorsallow

remotemonitoringwithouttheneedtoinstallseparate"doorcontacts".

The2000Seriesisofferedinsingle,double,andsplitarmaturemodelsforbothoutswingingand

inswingingdoors.Thecoilandhousingassemblymountsrigidlytothedoorframewhilethearmature

mountstothedoorinamannerthatallowsittopivotslightlytocompensatefordoorirregularities.When

thedoorisclosedandthelockisenergizedthearmatureismagneticallybondedtothelockface,thus

securingthedoorwithoututilizinganymovingparts.

EconomyPriced,FullSizeLocks

12/24VDC/VAC

MediumtoHighSecurity

AdjustablemountingBase

LifetimeWarranty

Results16of6

Item# Series Holding

Force Finish CoilResistance Discount

Multiplier

2011US28 2011SingleElectromagneticLock

Outswing 1200lb StandardSatin

Aluminum

53.2Ohms(+/10%)

Wht/Wht,Blk/Blk N/A

2012US28 2012SingleElectromagneticLockPair

Outswing 1200lb StandardSatin

Aluminum

53.2Ohms(+/10%)

Wht/Wht,Blk/Blk N/A

2022US28 2022DoubleElectromagneticLock

Outswing 1200lb StandardSatin

Aluminum

53.2Ohms(+/10%)

Wht/Wht,Blk/Blk N/A

2011TJ20

US28

2011TJ20SingleElectromagneticLock

Inswing 1200lb StandardSatin

Aluminum

53.2Ohms(+/10%)

Wht/Wht,Blk/Blk N/A

2012TJ21

US28

2012TJ21SingleElectromagneticLock

PairInswing 1200lb StandardSatin

Aluminum

53.2Ohms(+/10%)

Wht/Wht,Blk/Blk N/A

2022TJ22

US28

2022TJ22DoubleElectromagneticLock

PairInswing 1200lb StandardSatin

Aluminum

53.2Ohms(+/10%)

Wht/Wht,Blk/Blk N/A

Results16of6

4/7/2017|Page1of1
