Toshiba Corporation 802.11b WLAN Mini-PCI Module PA3231U User manual

Contents

User Manual

1
Wireless LAN Card FeaturesWireless LAN Card Features
The Wireless LAN Card is a wireless network card that fits into a Mini-PCI TypeIII slot.
Wireless LAWireless LAN Card TypesN Card Types
The Wireless LAN Card is a wireless network card that complies with the IEEE 802.11 standard on wireless
LANs (Revision B). Revision B supports data rates up to 11 Mbit/s.
n Wi-Fi (Wireless Fidelity) certified by the Wi-Fi Alliance. This means that your Wireless hardware will
communicate with other vendors’ IEEE 802.11 compliant wireless LAN product. The 'Wi-Fi CERTIFIED'
logo is a certification mark of the Wi-Fi Alliance.
n Fully compatible with any other wireless LAN system based on Direct Sequence Spread Spectrum (DSSS)
radio technology that complies with the “IEEE 802.11 standard on wireless LANs (Revision B).
Wireless LAN CardsWireless LAN Cards
The Wireless LAN Card supports the following wireless LAN features:
n Automatic Transmit Rate Select mechanism in the transmit range of 11, 5.5, 2 and 1 Mbit/s.
n Frequency Channel Selection
n Roaming over multiple channels.
n Card Power Management.
n Wired Equivalent Privacy (WEP) data encryption, based on 128bit encryption algorithm.
Card SpecificationsCard Specifications
Form Factor - Mini PCI TypeIII
Capability - IEEE 802.11 Standard for Wireless LANS
Wi-Fi (Wireless Fidelity) certified by the Wi-Fi Alliance.
Network Operating - Microsoft Windows® Networking
System
Media Access Protocol - CSMA/CA (Collision Avoidance) with Acknowledgment (ACK)
Data Rate - 11/5.5/2/1 Mb/s (Revision B)
Radio CharacteristicsRadio Characteristics
Radio Characteristics of Wireless LAN Cards may vary according to:
n country/region where the product was purchased
n Type of product
Wireless communication is often subject to local radio regulations. Although Wireless LAN Wireless
networking products have been designed for operation in the license-free 2.4GHz band, local radio regulations
may impose a number of limitations to the use of wireless communication equipment.
NOTE: NOTE: Refer to the flyer "Information to the User” for regulatory information that may apply in your
country/region.
RF Frequency -Band2.4GHz (2400-2483.5 MHz)
Modulation Technique -DSSS-CCK, DSSS-DQPSK, DSSS-DBPSK
The range of the wireless signal is related to the Transmit Rate of the wireless communication.
Communications at lower Transmit range may travel larger distances.
2
n The range of your wireless devices can be affected when the antennas are placed near metal surfaces and
solid high-density materials.
n Range is also impacted due to “obstacles” in the signal path of the radio that may either absorb or reflect
the radio signal.
Information sheet
Wireless Interoperability
The CISCO Aironet® 350 Series Mini-PCI (MPI350) products are designed to be interoperable with any wireless
LAN product that is based on Direct Sequence Spread Spectrum(DSSS) radio technology, and is compliant to:
The IEEE 802.11 Standard on Wireless LANs(Revision B), as defined and approved by the Institute of
Electrical and Electronics Engineers.
The Wireless Fidelity(Wi-Fi) certification as defined by the Wi-Fi Alliance.
CAUTION
Bluetooth™ and WirelessLAN devices operate within the same radio frequency range and may interfere with
one another. If you use Bluetooth™ and WirelessLAN devices simultaneously, you may occasionally experience
a less than optimal network performance or even lose your network connection.
If you should experience any such problem, immediately turn off either one of your Bluetooth™ or
WirelessLAN.
Please contact Toshiba PC product support on web site
http://www.toshiba-europe.com/computers/tnt/bluetooth.htm in Europe or
http://www.pc.support.global.toshiba.com in the United States for more information.
Wireless LAN and your Health
Wireless LAN products, like other radio devices, emit radio frequency electromagnetic energy. The level of
energy emitted by Wireless LAN devices however is far much less than the electromagnetic energy emitted by
wireless devices like for example mobile phones.
Because Wireless LAN products operate within the guidelines found in radio frequency safety standards and
recommendations, TOSHIBA believes Wireless LAN is safe for use by consumers. These standards and
recommendations reflect the consensus of the scientific community and result from deliberations of panels and
committees of scientists who continually review and interpret the extensive research literature.
In some situations or environments, the use of Wireless LAN may be restricted by the proprietor of the building
or responsible representatives of the organization. These situations may for example include:
Using the Wireless LAN equipment on board of airplanes, or
In any other environment where the risk of interference to other devices or services is perceived or
identified as harmful.
If you are uncertain of the policy that applies on the use of wireless devices in a specific organization or
environment (e.g. airports), you are encouraged to ask for authorization to use the Wireless LAN device prior to
turning on the equipment.
3
Regulatory Information
The CISCO Aironet® 350 Series Mini-PCI (MPI350) must be installed and used in strict accordance with the
manufacturer’s instructions as described in the user documentation that comes with the product. This device
complies with the following radio frequency and safety standards.
Canada Industry Canada (IC)
This device complies with RSS 210 of Industry Canada.
Operation is subject to the following two conditions: (1) this device may not cause interference , and (2) this
device must accept any interference, including interference that may cause undesired operation of this device.”
L ‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de
brouillage et (2) l’ utilisateur du dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu, même si
ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
The term "IC" before the equipment certification number only signifies that the Industry Canada technical
specifications were met.
Approval Number : 248H-DPA3231W
Europe EU Declaration of Conformity
This device complies with the essential requirements of the R&TTE Directive 1999/5/EC with essential test
suites as per standards:
EN 60950 Safety of Information Technology equipment
EN 300 328-1 and-2 Technical requirements for radio equipment
EN 300 489-1 and-17 General EMC requirements for radio equipment.
For outdoor usage only channel 10 (2457 MHz) and 11 (2462 MHz) is allowed.
For private usage outside buildings across public grounds over less than 300m no special registration with IBPT/BIPT is
required. Registration to IBPT/BIPT is required for private usage outside buildings across public grounds over more
than 300m. An IBPT/BIPT license is required for public usage outside building.
For registration and license please contact IBPT/BIPT.
Gebruik buiten gebouw alleen op kanalen 10 (2457 MHz) en 11 (2462 MHz). Voor privé-gebruik buiten gebouw over
publieke groud over afstand kleiner dan 300m geen registratie bij BIPT/IBPT nodig; voor gebruik over afstand groter
dan 300m is wel registratie bij BIPT/IBPT nodig. Voor publiek gebruik buiten gebouwen is licentie van BIPT/IBPT
verplicht. Voor registratie of licentie kunt u contact opnemen met BIPT.
België/
Belgique:
L’utilisation en extérieur est autorisé sur le canal 10 (2457 MHz) et 11 (2462 MHz).
Dans le cas d’une utilisation privée, à l’extérieur d’un bâtiment, au-dessus d’un espace public, aucun enregistrement
n’est nécessaire pour une distance de moins de 300m. Pour une distance supérieure à 300m un enregistrement auprès de
I’IBPT est requise. Pour une utilisation publique à I’extérieur de bâtiments, une licence de I’IBPT est requise. Pour les
enregistrements et licences, veuillez contacter I’IBPT.
License required for outdoor installations. Check with reseller for procedure to follow Deutschland: Anmeldung im Outdoor-Bereich notwendig, aber nicht genehmigungspflichtig.Bitte mit Händler die Vorgehensweise
abstimmen.
Restricted frequency band: only channels 10 and 11 (2457 MHz and 2462 MHz respectively) may be used in France.
License required for every installation, indoor and outdoor installations. Please contact ART for procedure to follow.
France:
Bande de fréquence restreinte : seuls les canaux 10 à 11 (2457 et 2462 MHz respectivement) doivent être utilisés en
France.
Toute utilisation, qu’elle soit intérieure ou extérieure, est soumise à autorisation. Vous pouvez contacter I’Autorité de
Régulation des Télécommuniations (http://www.art-telecom.fr) pour la procédure à suivre.
License required for indoor use. Use with outdoor installations not allowed Italia: E’necessaria la concessione ministeriale anche per l’uso interno.
Verificare con i rivenditori la procedura da seguire. L’uso per installazione in esterni non e’ permessa.
License required for outdoor installations. Check with reseller for procedure to follow Nederland Licentie verplicht voor gebruik met buitenantennes. Neem contact op met verkoper voor juiste procedure
USA-Federal Communications Commission(FCC)
4
This device complies with Part 15 of FCC Rules. Operation of the devices in a Wireless LAN System is subject to
the following two conditions:
This device may not cause harmful interference.
This device must accept any interference that may cause undesired operation.
TOSHIBA is not responsible for any radio or television interference caused by unauthorized modification of the
devices included with this CISCO Aironet® 350 Series Mini-PCI (MPI350), or the substitution or attachment of
connecting cables and equipment other than specified by TOSHIBA.
The correction of interference caused by such unauthorized modification, substitution or attachment will be the
responsibility of the user.
Caution: Exposure to Radio Frequency Radiation.
The CISCO Aironet® 350 Series Mini-PCI (MPI350) will be installed with one of three types of antennas. All
of antenna types, when installed are located at the upper edge of the LCD screen.
All antennas, the radiated output power of the CISCO Aironet® 350 Series Mini-PCI (MPI350) is far below the
FCC radio frequency exposure limits. Nevertheless, the CISCO Aironet® 350 Series Mini-PCI (MPI350) shall
be used in such a manner that the potential for human contact during normal operation is minimized. In
normal operating configuration, the LCD in the upright position, the distance between the antenna and the user
should not be less than 20cm.
Refer to the Regulatory Statements as identified in the documentation that comes with those products for
additional information. Relevant transmitters include FCC IDs: CJ6UPA3231WL, CJ6UPA3232BT.
Taiwan
Article 14 Unless approved, for any model accredited low power radio frequency electric machinery, any
company, trader or user shall not change the frequency, increase the power or change the features
and functions of the original design.
Article 17 Any use of low power radio frequency electric machinery shall not affect the aviation safety and
interfere with legal communications. In event that any interference is found, the use of such
electric machinery shall be stopped immediately, and reusing of such products can be resumed
until no interference occurs after improvement.
The legal communications mentioned in the above item refer to radio communications operated in
accordance with telecommunication laws and regulations.
Low power radio frequency electric machinery shall resist against interference from legal
communications or from industrial, scientific and medical radio emission electric machinery.
Using this equipment in Japan
In Japan, the frequency bandwidth of 2,4002,483.5MHz for second generation low-power data communication
systems such as this equipment overlaps that of mobile object identification systems (premises radio station and
specified low-power radio station).
5
1. Sticker
Please put the following sticker on devices incorporating this product.
2. Indication
The indication shown below appears on this equipment.
(1) 2.4this equipment uses a frequency of 2.4GHz.
(2) DSThis equipment uses DS-SS modulation.
(3) 4The interference range of this equipment is less than 40m.
(4) This equipment uses a frequency bandwidth from 2,400MHz to 2,483.5MHz.
It is possible to avoid the band of mobile object identification systems.
3. TOSHIBA Direct PC
Monday Friday : 10:00 17:00
Toll Free Tel : 0120-13-1100
Direct Dial : 03-3457-5916
Fax : 03-5444-9450
Device Authorization
This device obtains the Technical Regulation Conformity Certification and it belongs to the device class of radio
equipment of low-power data communication system radio station stipulated in the Radio Law of Japan.
The Name of the radio equipment: AIR-MPI350
TELECOM ENGINEERING CENTER
Approval Number : 01NYDA1263, 01GZDA1137
The following restrictions apply:
Do not disassemble or modify the device.
Do not install the embedded wireless module into other device.
Trademark
CISCO Aironet is a registered trademark of Cisco Systems,Inc..
Bluetooth is a trademark owned by its proprietor and used by TOSHIBA under license.
2.4DS4
(1) (2) (3)
(4)
In the frequency bandwidth of this equipment, industrial device,
scientific device, medical device like microwave oven, licensed
premises radio station and non-licensed specified low-
power radio
station for mobile object identification system (RF-
ID) that is used
in product line of factories,(Other Radio Stations)are used.
1 Please make sure before using this equipment that no Other Radio
Stations are used in the neighborhood.
2 In case that RF interference occurs to Other Radio Stations from
this equipment, please change promptly the frequency for use, place
to use, or stop emitting Radio.
3 Please contact TOSHIBA Direct PC
if you have a problem, such as
interference from this equipment to Other Radio Stations
1
Information sheet
Wireless Interoperability
The CISCO Aironet® 350 Series Mini-PCI (MPI350) products are designed to be interoperable with any wireless
LAN product that is based on Direct Sequence Spread Spectrum(DSSS) radio technology, and is compliant to:
The IEEE 802.11 Standard on Wireless LANs(Revision B), as defined and approved by the Institute of
Electrical and Electronics Engineers.
The Wireless Fidelity(Wi-Fi) certification as defined by the Wi-Fi Alliance.
CAUTION
Bluetooth™ and WirelessLAN devices operate within the same radio frequency range and may interfere with
one another. If you use Bluetooth™ and WirelessLAN devices simultaneously, you may occasionally experience
a less than optimal network performance or even lose your network connection.
If you should experience any such problem, immediately turn off either one of your Bluetooth™ or
WirelessLAN.
Please contact Toshiba PC product support on web site
http://www.toshiba-europe.com/computers/tnt/bluetooth.htm in Europe or
http://www.pc.support.global.toshiba.com in the United States for more information.
Wireless LAN and your Health
Wireless LAN products, like other radio devices, emit radio frequency electromagnetic energy. The level of
energy emitted by Wireless LAN devices however is far much less than the electromagnetic energy emitted by
wireless devices like for example mobile phones.
Because Wireless LAN products operate within the guidelines found in radio frequency safety standards and
recommendations, TOSHIBA believes Wireless LAN is safe for use by consumers. These standards and
recommendations reflect the consensus of the scientific community and result from deliberations of panels and
committees of scientists who continually review and interpret the extensive research literature.
In some situations or environments, the use of Wireless LAN may be restricted by the proprietor of the building
or responsible representatives of the organization. These situations may for example include:
Using the Wireless LAN equipment on board of airplanes, or
In any other environment where the risk of interference to other devices or services is perceived or
identified as harmful.
If you are uncertain of the policy that applies on the use of wireless devices in a specific organization or
environment (e.g. airports), you are encouraged to ask for authorization to use the Wireless LAN device prior to
turning on the equipment.
Regulatory Information
2
The CISCO Aironet® 350 Series Mini-PCI (MPI350) must be installed and used in strict accordance with the
manufacturer’s instructions as described in the user documentation that comes with the product. This device
complies with the following radio frequency and safety standards.
Canada Industry Canada (IC)
This device complies with RSS 210 of Industry Canada.
Operation is subject to the following two conditions: (1) this device may not cause interference , and (2) this
device must accept any interference, including interference that may cause undesired operation of this device.”
L ‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de
brouillage et (2) l’ utilisateur du dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu, même si
ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
The term "IC" before the equipment certification number only signifies that the Industry Canada technical
specifications were met.
Approval Number : 248H-DPA3231W
Europe EU Declaration of Conformity
This device complies with the essential requirements of the R&TTE Directive 1999/5/EC with essential test
suites as per standards:
EN 60950 Safety of Information Technology equipment
EN 300 328-1 and-2 Technical requirements for radio equipment
EN 300 489-1 and-17 General EMC requirements for radio equipment.
For outdoor usage only channel 10 (2457 MHz) and 11 (2462 MHz) is allowed.
For private usage outside buildings across public grounds over less than 300m no special registration with IBPT/BIPT is
required. Registration to IBPT/BIPT is required for private usage outside buildings across public grounds over more
than 300m. An IBPT/BIPT license is required for public usage outside building.
For registration and license please contact IBPT/BIPT.
Gebruik buiten gebouw alleen op kanalen 10 (2457 MHz) en 11 (2462 MHz). Voor privé-gebruik buiten gebouw over
publieke groud over afstand kleiner dan 300m geen registratie bij BIPT/IBPT nodig; voor gebruik over afstand groter
dan 300m is wel registratie bij BIPT/IBPT nodig. Voor publiek gebruik buiten gebouwen is licentie van BIPT/IBPT
verplicht. Voor registratie of licentie kunt u contact opnemen met BIPT.
België/
Belgique:
L’utilisation en extérieur est autorisé sur le canal 10 (2457 MHz) et 11 (2462 MHz).
Dans le cas d’une utilisation privée, à l’extérieur d’un bâtiment, au-dessus d’un espace public, aucun enregistrement
n’est nécessaire pour une distance de moins de 300m. Pour une distance supérieure à 300m un enregistrement auprès de
I’IBPT est requise. Pour une utilisation publique à I’extérieur de bâtiments, une licence de I’IBPT est requise. Pour les
enregistrements et licences, veuillez contacter I’IBPT.
License required for outdoor installations. Check with reseller for procedure to follow Deutschland: Anmeldung im Outdoor-Bereich notwendig, aber nicht genehmigungspflichtig.Bitte mit Händler die Vorgehensweise
abstimmen.
Restricted frequency band: only channels 10 and 11 (2457 MHz and 2462 MHz respectively) may be used in France.
License required for every installation, indoor and outdoor installations. Please contact ART for procedure to follow.
France:
Bande de fréquence restreinte : seuls les canaux 10 à 11 (2457 et 2462 MHz respectivement) doivent être utilisés en
France.
Toute utilisation, qu’elle soit intérieure ou extérieure, est soumise à autorisation. Vous pouvez contacter I’Autorité de
Régulation des Télécommuniations (http://www.art-telecom.fr) pour la procédure à suivre.
License required for indoor use. Use with outdoor installations not allowed Italia: E’necessaria la concessione ministeriale anche per l’uso interno.
Verificare con i rivenditori la procedura da seguire. L’uso per installazione in esterni non e’ permessa.
License required for outdoor installations. Check with reseller for procedure to follow Nederland Licentie verplicht voor gebruik met buitenantennes. Neem contact op met verkoper voor juiste procedure
USA-Federal Communications Commission(FCC)
3
This device complies with Part 15 of FCC Rules. Operation of the devices in a Wireless LAN System is subject to
the following two conditions:
This device may not cause harmful interference.
This device must accept any interference that may cause undesired operation.
TOSHIBA is not responsible for any radio or television interference caused by unauthorized modification of the
devices included with this CISCO Aironet® 350 Series Mini-PCI (MPI350), or the substitution or attachment of
connecting cables and equipment other than specified by TOSHIBA.
The correction of interference caused by such unauthorized modification, substitution or attachment will be the
responsibility of the user.
Caution: Exposure to Radio Frequency Radiation.
The CISCO Aironet® 350 Series Mini-PCI (MPI350) will be installed with one of three types of antennas. All
of antenna types, when installed are located at the upper edge of the LCD screen.
All antennas, the radiated output power of the CISCO Aironet® 350 Series Mini-PCI (MPI350) is far below the
FCC radio frequency exposure limits. Nevertheless, the CISCO Aironet® 350 Series Mini-PCI (MPI350) shall
be used in such a manner that the potential for human contact during normal operation is minimized. In
normal operating configuration, the LCD in the upright position, the distance between the antenna and the user
should not be less than 20cm.
Refer to the Regulatory Statements as identified in the documentation that comes with those products for
additional information. Relevant transmitters include FCC IDs: CJ6UPA3231WL, CJ6UPA3232BT.
Taiwan
Article 14 Unless approved, for any model accredited low power radio frequency electric machinery, any
company, trader or user shall not change the frequency, increase the power or change the features
and functions of the original design.
Article 17 Any use of low power radio frequency electric machinery shall not affect the aviation safety and
interfere with legal communications. In event that any interference is found, the use of such
electric machinery shall be stopped immediately, and reusing of such products can be resumed
until no interference occurs after improvement.
The legal communications mentioned in the above item refer to radio communications operated in
accordance with telecommunication laws and regulations.
Low power radio frequency electric machinery shall resist against interference from legal
communications or from industrial, scientific and medical radio emission electric machinery.
Using this equipment in Japan
In Japan, the frequency bandwidth of 2,4002,483.5MHz for second generation low-power data communication
systems such as this equipment overlaps that of mobile object identification systems (premises radio station and
specified low-power radio station).
4
1. Sticker
Please put the following sticker on devices incorporating this product.
2. Indication
The indication shown below appears on this equipment.
(1) 2.4this equipment uses a frequency of 2.4GHz.
(2) DSThis equipment uses DS-SS modulation.
(3) 4The interference range of this equipment is less than 40m.
(4) This equipment uses a frequency bandwidth from 2,400MHz to 2,483.5MHz.
It is possible to avoid the band of mobile object identification systems.
3. TOSHIBA Direct PC
Monday Friday : 10:00 17:00
Toll Free Tel : 0120-13-1100
Direct Dial : 03-3457-5916
Fax : 03-5444-9450
Device Authorization
This device obtains the Technical Regulation Conformity Certification and it belongs to the device class of radio
equipment of low-power data communication system radio station stipulated in the Radio Law of Japan.
The Name of the radio equipment: AIR-MPI350
TELECOM ENGINEERING CENTER
Approval Number : 01NYDA1263, 01GZDA1137
The following restrictions apply:
Do not disassemble or modify the device.
Do not install the embedded wireless module into other device.
Trademark
CISCO Aironet is a registered trademark of Cisco Systems,Inc..
Bluetooth is a trademark owned by its proprietor and used by TOSHIBA under license.
2.4DS4
(1) (2) (3)
(4)
In the frequency bandwidth of this equipment, industrial device,
scientific device, medical device like microwave oven, licensed
premises radio station and non-licensed specified low-
power radio
station for mobile object identification system (RF-ID) tha
t is used
in product line of factories,(Other Radio Stations)are used.
1 Please make sure before using this equipment that no Other Radio
Stations are used in the neighborhood.
2 In case that RF interference occurs to Other Radio Stations from
this equipme
nt, please change promptly the frequency for use, place
to use, or stop emitting Radio.
3 Please contact TOSHIBA Direct PC
if you have a problem, such as
interference from this equipment to Other Radio Stations

Navigation menu
