Preface
This product is the USB adapter corresponding to the
TransferJetTM standard. Using TransferJetTM communication,
you can transfer the data in your computer.
＊This product functions only at the computer which is
equipped the USB interface (Type A).
＊This product functions only by the combination with
dedicated the file transfer software. This product cannot do
the use in single or combination other file transfer software.
＊The OS (Operating System) of the computer is only for
32bit/64bit of Windows® 7 and 32bit/64bit of Windows® 8
supports.
＊The switch which the USB adapter has is for Extensions. At
present, it cannot use.
About TransferJetTM
TransferJetTM is the close proximity wireless transfer
technology that can transfer data just to shade it directly with
the apparatus which wants to communicate. High-speed data
transmission without carrying out a troublesome activity such
as the cable connection is possible.
Before use
Please be sure to use correctly read this User’s Manual (the
following this manual), and the operation manual of use
apparatus. Please keep it at hand after reading.
Safety Precautions and Request
Explanation
of the
Indicates
Indicates a hazardous
situation which, if not avoid,
could result in death or serious
injury.
Indicates a potentially
hazardous situation which, if
not avoided, may result in
minor or moderate injury.
●Accidentally swallowing the product may cause suffocation or injury.
Keep out of reach of children or pets.
●Do not bend, drop, place heavy objects upon the product, or
otherwise expose the product to shoring force or impact.
●If the product produces an odor, overheats or smokes, immediately
turn off the device with which the product is used, including the
computer and peripherals, immediately and disconnect the power
card/cable from the outlet. Failure to follow these instructions could
result in fire, damage to the product, and/or personal injury including
burns and electric shock. Do not use the product again.
Do not let the bare skin touch this product directly for a long
time.
The surface of the main body is charged with heat for long-time use.
There is a possibility of becoming a low-temperature burn by
long-time touching the main body. Please warn the person having
weak skin in particular.
Handling Precautions
●If you do not follow the instructions below, there is a risk of
malfunction or failure.
●Do not touch directly the interface pins, and do not put
hard metal them and do not short them. The adapter
might destroy by static electricity.
●Do not get it wet. Do not keep it with the use in the range
more than the movement environment (temperature,
humidity). Do not put it near a place with much dust, a
place with static electricity, an electricity noise, strong
magnetism it, a place with the corrosive medicine and gas,
a fever thing, an ignition thing.
●Do not switch it off, and do not remove from an
apparatus during the communication of this product.
●When you attach this product to the computer and
communicate, do not hit with the adapter of the partner
apparatus. This product and the computer might be
broken by a shock at the time of the hit.
●Particularly high quality, reliability is required, and please
never use this product to an apparatus (including atomic
energy control equipment, an aerospace apparatus,
transportation equipment, a traffic light apparatus, a
combustion control, medical equipment, various safety
devices, etc.) which the trouble and malfunction threaten
direct human life, and might give harm to the human
body.
●The transfer rate of this product changes by the position
relations of TransferJetTM device.
TransferJetTM USB adapter
User’s Manual
WARNING
WARNING
CAUTION
CAUTION
Installation procedure of the file transfer
software
It is necessary to install the file transfer software in the
computer beforehand to use a file transfer function.
Installation procedure to the computer
① Access our following web site, and, please download the
Windows® version file transfer software.
http://www.toshiba.co.jp/p-media/transferjet/index_j.htm
② Please install it according to the procedure of above
mentioned web site mention.
Usage of the file transfer function
Insert the USB adapter to the USB port of the computer.
Let the computer where insert the USB adapter in and a
facing TransferJetTM device in face both.
Start the file transfer software in both side TransferJetTM
device and execute file transfer. (Please obtain the file
transfer software for computers from the above
mentioned web site. In addition, Please refer to the
utility operation manual which you click the "User's
Guide" button of the main screen appearing after the file
transfer software start and installation manual written in
the above web site for the acquisition method of the file
transfer software and the detailed usage. )
When you remove the USB adapter from the computer,
you terminate file transmission and reception. And
remove it.
Main Specification
Movement
environment
temperature ５～35℃
humidity 20～80%RH（not be dew
condensation）
External
dimensions
Approx. 24.3mm(L)ｘ15.0mm(W)ｘ
7.0mm(H) (excl. protruding parts)
Weight
Approx. 1.5g
Rating
supply
voltage
5V
Interface
USB2.0
Bundling
product
TransferJetTM USB adapter（1pcs.）
User’s manual（this manual） （1pcs.）
＊It may change design, the specifications without a notice.
Trademarks
●© 2013 TOSHIBA CORPORATION, All Rights Reserved.
●TransferJetTM and TransferJetTM logos are licensed by the
TransferJet Consortium.
●Windows® is registered trademark of Microsoft Corporation in
the USA and other countries.
LIMITATIONS
●Toshiba do not take responsibility about a fire, an
earthquake, the act by the third party, other accidents, the
intention of the visitor or a fault, misuse, the damage by the
use under other abnormal conditions at all.
●About the use of this product or the damage, the loss of
profits that nonuse caused and the request from a third party,
Toshiba do not take responsibility at all.
●Toshiba do not take responsibility not to follow the mention
content of the instruction(user’s) manual about the damage
that occurred at all.
●When the destruction of data or disappearance occurs in
the use of this product, regardless of contents, degree of a
cause and the damage, Toshiba do not take responsibility at
all.
●About the damage that a connection apparatus, the
malfunction by the combination with the software caused,
Toshiba do not take responsibility at all.
●This product is an article for exclusive use of the file transfer
software made in Toshiba. The operation of this product by
the software except this is not guaranteed. Toshiba do not
take responsibility to have used this product about the
damage that occurred at all.
Regulatory Information
FCC information
FCC notice "Declaration of Conformity Information"
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV
technician for help.
FCC Caution: Any changes or modifications not
expressly approved by the party responsible for
compliance could void the user's authority to operate
this equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
This device and its antenna(s) must not be co-located
or operating in conjunction with any other antenna or
transmitter.
To reduce potential radio interference to other users,
the antenna type and its gain should be so chosen
that the equivalent isotropically radiated power (EIRP)
is not more than that required for successful
communication
This equipment may only be operated
indoors. Operation outdoors is in violation of 47
U.S.C. 301 and could subject the operator to serious
legal penalties.
IC information
This device complies with Industry Canada
licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept
any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie
Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux
conditions suivantes : (1) l'appareil ne doit pas
produire de brouillage, et (2) l'utilisateur de l'appareil
doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en
compromettre le fonctionnement.
This device is restricted to indoor use.
CAN ICES-3 (B)/NMB-3(B)
Manufacturer TOSHIBA CORPORATION
