Dynamics BLIZZARDIII Mobile Phone User Manual

Dynamics Hong Kong Limited Mobile Phone

user manual

-1-
User Manual
GSM Mobile Phone
Model / BrandBlizzard III / Ice Mobile
FCC ID: C89BLIZZARDIII
-2-
Content
1General Information ................................................................................................................................................. 4
1.1Profile .............................................................................................................................................................. 4
1.2Safety Information .......................................................................................................................................... 4
1.3Safety warning and Attentions ........................................................................................................................ 4
2Your phone ................................................................................................................................................................. 7
2.1Functions of Keys ........................................................................................................................................... 7
3Getting started ........................................................................................................................................................... 9
3.1Installing the SIM Cards and the Battery ........................................................................................................ 9
3.2Installing T-Flash Card ................................................................................................................................... 11
3.3Charging the Battery ...................................................................................................................................... 11
3.4Powering On/Off the Mobile Phone ............................................................................................................. 14
3.5Linking to the Network ................................................................................................................................. 14
3.6Dialing Calls ................................................................................................................................................. 14
3.7Using the Headset ......................................................................................................................................... 15
4Input method ........................................................................................................................................................... 16
-3-
4.1Icons for Input Methods ................................................................................................................................ 16
4.2To Shift Entry Methods ................................................................................................................................. 16
4.3Numeric Input ............................................................................................................................................... 16
4.4English input and numeric input: .................................................................................................................. 17
4.5Inserting a Symbol ........................................................................................................................................ 18
5Using the menu ........................................................................................................................................................ 18
5.1Call logs ........................................................................................................................................................ 18
5.2Multimedia .................................................................................................................................................... 20
5.3Phonebook..................................................................................................................................................... 22
5.4Profiles .......................................................................................................................................................... 22
5.5Message ........................................................................................................................................................ 23
5.6Tools .............................................................................................................................................................. 24
5.7Settings .......................................................................................................................................................... 26
5.8Applications .................................................................................................................................................. 29
5.9Services ......................................................................................................................................................... 29
6Appendix .................................................................................................................................................................. 30
-4-
1 General Information
1.1 Profile
Please read this pamphlet carefully in order to make your phone in perfect condition.
Our company may change this mobile phone without prior written notice and reserves the final right to
interpret the performance of this mobile phone.
Due to different software and network operators, display on your phone may be different, please refer to
your phone for details.
1.2 Safety Information
If your phone has lost or been stolen, notify the telecommunication office the SIM card is disabled
(network support is required). This can avoid economic loss caused by unauthorized use.
Please take measures as following to avoid your phone being unauthorized use:
Set PIN code of SIM card
Set phone password
1.3 Safety warning and Attentions
Safety warning
¾ ROAD SAFETY COMES FIRST
Do not use a hand-held phone while driving. Use hands-free fittings when calls are unavoidable while driving.
In some countries, dialing or receiving calls while driving is illegal!
-5-
¾ SWITCH OFF IN AIRCRAFT
Wireless devices can cause interference in aircraft. Using a mobile phone in flight is illegal and risky.
Please make sure that your mobile phone is powered off in flight.
¾ SWITCH OFF BEFORE ENTERING RISKY AREAS
Strictly observe the relevant laws, codes, and regulations on the use of mobile phones in risky areas. Turn off
your mobile phone before entering a place susceptible to explosion, such as an oil station, oil tank, chemical
plant or a place where a blasting process is under way.
¾ OBSERVE ALL SPECIAL REGULATIONS
Follow any special regulations in force in any area such as hospitals and always switch off your phone
whenever it is forbidden to use it or, when it may cause interference or danger. Properly use your mobile
phone near medical apparatuses, such as pacemakers, hearing aids and some other electronic medical devices,
as it may cause interference to such apparatuses.
¾ INTERFERENCE
The conversation quality of any mobile phone may be affected by radio interference. An antenna is built
inside the mobile phone and located below the microphone. Do not touch the antenna area during a
conversation, lest that the conversation quality deteriorate.
¾ QUALIFIED SERVICE
Only qualified personnel may install or repair phone equipment. Installing or repairing the mobile phone on
your own may bring great danger and violates the warranty rules.
¾ ACCESSORIES AND BATTERIES
Use only approved accessories and batteries.
¾ USE SENSIBLY
-6-
Use only in a normal and proper manner.
¾ EMERGENCY CALLS
Ensure the phone is switched on and in service, enter the emergency number, e.g. 112, then press the Dial key.
Give your location and state your situation briefly. Do not end the call until told to do so.
Note: Just like all other mobile phones, this mobile phone does not necessarily support all the features
described in this manual due to network or radio transmission problems. Some networks even do not support
the emergency call service. Therefore, do not rely solely on the mobile phone for critical communications
such as first aid. Please consult the local network operator.
Precautions
This mobile phone is well designed with fine art. Please exercise special care when using it. The following
suggestions will help your mobile phone survive the warranty period and extend its service life:
¾ Keep the mobile phone and all its fittings beyond children's reach.
¾ Keep the mobile phone dry. Keep away from rain, moisture, liquid or other substances that may corrode
electronic circuits.
¾ Do not use or store the mobile phone in dusty places, lest that active parts of the mobile phone be damaged.
¾ Do not store the mobile phone in a high-temperature place. High temperature will shorten the life of
electronic circuits and damage the battery and some plastic parts.
¾ Do not store the mobile phone in a chilly place. Otherwise, moistures will be formed inside the mobile
phone to damage electronic circuits when the mobile phone is moved to a constant temperature place.
¾ Do not throw, knock or shock the mobile phone, as that will destroy the internal circuits and high-precision
components of the mobile phone.
-7-
2 Your phone
2.1 Functions of Keys
The mobile phone provides the following keys:
Dial key
Press it to originate a call by entering the called number or selecting a contact from the phonebook; or
press it to receive an incoming call; or press it in standby state to show the latest call records
End key
Press it to end a call being dialed or end an ongoing call; or press it to exit the menu and return to the
standby state; or hold it for two or three seconds to power on or off the mobile phone.
Direction key
Press them to scroll the options when browsing function list. In standby state, press a direction key to
enter the specified function page. You can also customize direction keys to match the desired functions.
In conversation status, press up or down direction key to tune volume.
OK key
Press it to confirm your selection.
Left and right soft key
-8-
The bottom line on the screen displays the functions of the Left and Right soft key.
Flashlight
In idle screen, long press number key 0 can turn on/off flashlight which situates at the top of the phone.
TV shortcut key
Press it in idle screen to access TV interface.
Number keys, * key and # key
Press number keys 0 through 9 in edit state to input numbers and characters; hold any of number keys 2
through 9 for over two seconds in standby state to fast dial the corresponding telephone number in the
speed-dial number list (need to set in advance).
Note: Holding number key 1/2 on standby will call the voice mailbox service center. The voice mailbox
center number, however, must be preset.
The # key and the * key represent different functions in different states or different function menus.
Hold the # key up to 2s in standby state to activate or deactivate the silent, vibrate or standard mode.
Pressing the * key in edit status to select a symbol.
When the keypad is locked, you can press left soft key then * key to unlock it.
Press and hold the * key up for 2s to input "+" in standby interface. "+" are used for dialing an
international call.
-9-
3 Getting started
3.1 Installing the SIM Cards and the Battery
An SIM card carries useful information, including your mobile phone number, PIN (Personal
Identification Number), PIN2, PUK (PIN Unlocking Key), PUK2 (PIN2 Unlocking Key), IMSI
(International Mobile Subscriber Identity), network information, contacts data, and short messages data.
Note:
After powering off your mobile phone, wait for a few seconds before removing or inserting an SIM card.
Exercise caution when operating an SIM card, as friction or bending will damage the SIM card.
Properly keep the mobile phone and its fittings such as the SIM cards beyond children's reach.
Installation
Hold the End key for a while to power off the mobile phone
Push the back cover above the battery and remove it.
Pull the left battery buckle outward and then lift the battery away.
Insert the SIM card into the SIM card slot lightly with the corner cutting of the card aligning to the
notch of the slot and the gold plate of the card facing download, till the SIM card cannot be further
pushed in.
Aim the positive pole and negative pole of the battery at the battery connector of the mobile phone, and
press the left of the battery to install the battery into the battery tank.
Using code
The mobile phone and the SIM cards support sorts of passwords, in order to prevent the phone and the
SIM cards from being misused. When you are prompted to input any of the codes mentioned below, just
-10-
input the correct code and then press the OK key. If you input a wrong code, press the Right soft key to clear
it and then input the correct code.
Phone lock code
The phone lock code may be set to prevent your mobile phone from being misused. In general, this code
is provided along with the mobile phone by the manufacturer. The initial phone lock code is set to 1234 by
the manufacturer. If the phone lock code is set, you need to input the phone lock code when powering on the
mobile phone.
PIN
The PIN (Personal identification number, 4 to 8 digits) code prevents your SIM card from being used by
unauthorized people. In general, the PIN is supplied with SIM card by the network operator. If PIN check is
enabled, you need to input the PIN each time when you power on your mobile phone. The SIM card will be
locked if you input wrong PIN code for three times.
Unlocking methods as follows:
-Input the correct PUK according to the screen tips to unlock the SIM card.
-Then input the new PIN and press the OK key.
-Input the new PIN again and then press the OK key.
-If the input PUK is correct, the SIM card will be unlocked and the PIN will be reset.
Note: The SIM card will be locked if you input wrong PIN code for three times. To unlock the SIM card,
you need to input the PUK. In general, the PUK can be obtained from the network operator.
PUK
The PUK code (Personal Unlocking Key, 8digits) is required to change a blocked PIN. It is supplied
with SIM card. If not, contact your network operator. If you input wrong PUK code for 10 times, SIM card
-11-
will be invalid. Please contact the network operator to replace the SIM card.
Barring code
A barring code is required for setting the call barring function. You can obtain this code from the
network operator to set the call barring function.
3.2 Installing T-Flash Card
The T-Flash card is a pluggable mobile storage card inside the mobile phone.
To install the T-Flash card, open its latch, place its indented side downward, insert the card into the card
slot, and then close the latch.
To remove the T-flash card, open its latch and slightly press the card inward. The card will automatically
pop out. Close the latch.
Note:
1. The mobile phone cannot automatically identify the T-flash card being inserted when the mobile phone is
powered on. You must power off the mobile phone and then power it on, so that the phone can identify the
T-Flash card.
2. The T-Flash card is a miniature object. Keep it out of the reach of children for fear that children swallow
it!
3.3 Charging the Battery
The lithium battery delivered with the mobile phone can be put into use immediately after being
unpacked.
Battery level indication:
Your mobile phone can monitor and display the battery state.
-12-
Normally the remaining energy of the battery is indicated by the battery level icon at the upper right
corner of the display screen.
When the battery energy is insufficient, the mobile phone prompts "Battery low". If you have set an
alert tone, an alert tone will be given off when the battery level is too low.
A charging animation appears when the battery is being charged. When the charging is complete, the
animation disappears.
Using a travel adapter:
Install the battery into the mobile phone before charging the battery.
Connect the adapter of the travel charger with the charging slot in the mobile phone. Ensure that the
adapter is fully inserted.
Insert the plug of the travel charger to an appropriate power outlet.
During the charging, the battery level grids in the battery icon keep flickering till the battery is fully
charged.
It is normal of the battery to become hot during the charging period.
The battery icon does no longer flicker when the charging process ends.
Note:
Ensure that the plug of the charger, the plug of the earphone, and the plug of the USB cable are inserted
in the right direction. Inserting them in a wrong direction may cause charging failure or other problems.
Before the charging, ensure that the standard voltage and frequency of the local mains supply match the
rated voltage and power of the travel charger.
Using the Battery
The performance of a battery is subject to multiple factors: radio network configuration, signal strength,
-13-
ambient temperature, chosen functions or settings, phone fittings, and the voice, data or other application
mode you choose to use.
To guarantee the optimal performance of your battery, please stick to the following rules:
Use only the battery provided by the vendor. Otherwise, damages or even injuries could be caused
during the charging.
Power off the mobile phone before removing the battery.
The charging process lasts a longer time for a new battery or a battery not in use for long. If the battery
voltage is too low to enable the mobile phone to be powered on, charge the battery for a longer time. In
this case, the battery icon does not flicker until a long time after the battery enters the charge status.
During the charging, ensure the battery is placed in a room temperature environment or in an
environment close to room temperature.
Immediately stop using the battery if the battery produces odor, overheats, cracks, distorts or has other
damage, or if the electrolyte leaks.
The battery wears out with use. A longer charging time is required as the battery is put into use for a
long time. If the total conversation duration decreases but the charging time increases even though the
battery is properly charged, purchase a standard battery from the OEM or use a battery approved by
our company. Using any poor-quality fittings will cause harm to your mobile phone or even incur
danger!
Note: To guarantee your personal safety and protect the environment, do not litter the battery! Return the old
battery to the mobile phone manufacturer or place it in specified battery reclamation areas. Do not litter any
battery with other rubbish.
Warning: Short-circuits of the battery may cause explosion, fire, personal injury or other severe
-14-
consequences!
3.4 Powering On/Off the Mobile Phone
Hold the End key for a while to power on the mobile phone. A power-on animation appears on the display
screen.
Input the phone lock code and press the OK key if the mobile phone prompts you to input the phone lock
code. The original code is 1234.
Input the PIN and press the OK key if the mobile phone prompts you to input the PIN. The PIN is provided
by the network operator for new opening SIM card.
Enter the standby interface.
To power off the mobile phone, hold the End key for a while.
3.5 Linking to the Network
After the SIM card and the mobile phone are successfully unlocked, the mobile phone automatically
searches for an available network. After finding a network, the mobile phone enters the standby state. When
the mobile phone is registered in the network, the name of the network operator is displayed on the screen.
Then you can dial or receive a call.
3.6 Dialing Calls
In the standby interface, press number keys to input the area code and the telephone number, and then
press the Dial key to dial a call. To end the call, press the End key.
Dialing an international call
Hold the * key and input "+". Then input the country code, the area code and the telephone number.
-15-
Finally, press the Dial key.
Dialing a call to a number in the phonebook
Enter the phonebook and use the up or down direction key to find the telephone number you want to call.
Press the Dial key. The mobile phone automatically dials the chosen telephone number.
Redialing the last number
In the standby interface, press the dial key to show the dialed calls.
Press the up or down direction key to select a number you want to dial and then press the Dial key.
Answering incoming calls
Press the Dial key or the Left soft key to answer an incoming call.
Press the End key to end the current conversation.
To reject an incoming call, press the End key or the Right soft key.
Note: If the caller can be identified, the mobile phone will present the calling number. If the calling number
exists in the phonebook, the mobile phone will present both the name and the phone number of the caller. If
the caller cannot be identified, the mobile phone will present the calling number only. You can answer an
incoming call when using a function list or browsing the phonebook.
Using options during a conversation
Select Options during a conversation to pause, end the ongoing call, originate a new call, browse the
phonebook, view information, set the mute, set the DTMF, or perform other operations. For details, refer to
the menu guide.
3.7 Using the Headset
It would enter headset mode automatically when you insert headset to the slot. Make sure of inserting it
-16-
at the bottom of the slot, or you can’t use it normally.
4 Input method
This mobile phone provides multiple input methods, including numeric input, English input in both
upper and lower case. You can use these input methods when editing the phonebook, short messages, the files
and greeting text.
4.1 Icons for Input Methods
After you enter an edit interface such as an interface for editing the phonebook, short messages or the
memorandum, an icon is displayed to indicate the current input method:
Numeric input:123
Normal English inputABC, Abc, abc
Smart English input:EN, En, en
4.2 To Shift Entry Methods
Press # key to switch between input methods.
4.3 Numeric Input
You can input numbers with the numeric input method. Press a number key to input the corresponding
number.
-17-
4.4 English input and numeric input:
The keyboards for English input and numeric input are defined in the following table:
Key Character or Function Remarks
Number key 1 . , - ? ! ’@ : # $ /_ 1
Number key 2 ABCabc2
Number key 3 DEFdef3
Number key 4 GHIghi4
Number key 5 JKLjkl5
Number key 6 MNOmno6
Number key 7 PQRSpqrs7
Number key 8 TUVtuv8
Number key 9 WXYZwxyz9
Number key 0 0
* key Press it to input a symbol
# key Press it to switch between input methods
Left direction
key
Press it to move to the left
Right direction
key
Press it to move to the right
Left soft key Equivalent to OK or Options
Right soft key Equivalent to Back or Clear
-18-
End key Press it to return to the standby interface
English input:
Each key is used to represent multiple characters. Quickly and continuously press a key till the
character you want appears. Input the next character after the cursor moves.
Press the # key to switch between input methods
To clear wrong inputs, press the right soft key.
4.5 Inserting a Symbol
Press the * key to enter the Select symbol interface, use direction keys to select a symbol you want.
5 Using the menu
5.1 Call logs
Dialed calls
You can view the latest dialed calls. Choose dialed calls and then select a dialed call to delete, save, dial,
or edit (or send a short message to it).
Received calls
You can view the latest received calls. Choose received calls and then select a received call to delete,
-19-
save, dial, or edit (or send a short message to it).
Missed Calls
Show a list of missed calls.
Rejected calls
A list of calls you’ve rejected.
Delete all
You can delete the latest call records. Choose Delete call and then select to delete all the numbers in the
call history, or delete only the numbers in the missed calls list, the dialed calls list or the received calls list.
Call Timers
Choose call timers to view the last call time, the total time of all dialed calls and the total time of all
received calls, and/or to reset all the time.
Call Cost
Choose call cost to view the costs of the last call.
Note: The call cost function relates to the SIM card. Some SIM cards do not support this function. The
PIN2 is provided by the network operator. To obtain the PIN2, contact the network operator.
GPRS volume
Access this menu to view GPRS volume you’ve sent or received or to reset counter.
-20-
5.2 Multimedia
Camera
The phone is provided with a camera, which supports the photographing functions. Roll the phone to
align the camera to the picture and then press OK key to capture photos. Pictures will be saved in the file
system of the phone or the memory card. You can change the image/camera settings, by accessing the options
after entering the camera mode.
TV
You are able to access this menu to watch mobile TV programs and add the programs you like to
channel list. Before you watch TV programs, you’d better select the right area. Then you can search available
channels and select channel to play. Up and down direction key are corresponding to increase and decrease
volume.
Video recorder
This function enables you to record dynamic pictures. Adapt the VCR to the scene or the figure, the
press OK to start or pause recording. Press STOP to end recording, and the phone would save the file
automatically.
Video player
You can perform the following operations on video player: view play list, full screen play, order play, set
video clips as power on/off animation or refer to its file attribute.
-21-
Image viewer
You can view the pictures or images through this function. After accessing the image browser, you can
perform further operations, such as send, rename, delete or sort the file and so on, by pressing left soft key.
Audio Player
The audio player provides four buttons: Play/Pause, Stop, Back and Forward which are corresponding to
the up direction key, down direction key, left direction key and right direction key. The audio player supports
MP3 format. You can press* or # key to tune volume.
Recorder
The phone support WAV. The recording file you stopped would be stored in file list automatically. You
can select storage location as needed. The path is Multimedia>recorder>option>storage location>Udisk/
Memory card.
FM Radio
Your phone is equipped with an FM radio. You can use the application as a traditional FM radio with
automatic tuning and saved channels.
File manager
The phone provides a certain space for users to manage files and supports the T-Flash card. The capacity
of the T-Flash card is selectable. You can use the file manager to conveniently manage various directories and
files on the phone and the T-Flash card.
Choose File manager to enter the root directory of the memory. The root directory will list the default
-22-
folders, new folders and user files. When the mobile phone is powered on for the first time or when you have
not changed the directory, the root directory contains the default folders only.
You can use this function to format all the data in the memory. The system will re-create a default folder.
The formatted data cannot be recovered. Therefore, think twice before using the formatting function.
5.3 Phonebook
The mobile phone can store up to 500 telephone numbers. The telephone numbers that an SIM card can
store depends on the storage capacity of the SIM card. The telephone numbers stored in the mobile phone
and in the SIM cards form a phonebook.
The phonebook search function enables you to view contacts. You can search a contact as required from
the phonebook. Select this option, in the edit interface, input the name of the contact you want to search or
the first letter(s) of the name. All the contacts meeting the search condition are listed. Press the Up and Down
direction keys to browse the contacts and select contact. Press left or right soft key to view other groups:
Unclassified, family, business, classmates, blacklist and so on.
5.4 Profiles
The mobile phone provides multiple user profiles, so that you can customize some settings to adapt to
the specific events and environments.
Customize the user profiles according to your preference and then activate the user profiles. The user
profiles fall into five scenarios: General, Silent, Meeting, Indoor and Outdoor.
Select option and you can perform the following operations: Activate / Deactivate, Settings and Rename.
-23-
Note: Hold the # key up to 2s in standby state to activate or deactivate the silent, vibrate or standard
mode.
5.5 Message
If the short message memory is full, a blinking SMS icon appears on the top of the screen. To normally
receive short messages, you need to delete some of the existing short messages.
If the destination user has received the short message you sent and the short message delivery report
function is activated, the phone will give off a message report alert tone.
Note: When a short message is sent through the network, the mobile phone may give a prompt message
indicating that the short message has been sent. This indicates that the mobile phone has sent the short
message to the short message service center number set in the mobile phone but does not imply that the
destination user has received the short message. For further information, consult the service provider
Writing message
From the main menu select “Messages” to create text message or MMS. You can type a message, and
you're also able to insert a pre-defined message from “Templates”. While writing a message, select
Options” to access all the messaging options. You can save your messages that you send often to “Drafts”.
Inbox
If a new short message arrives, an icon will be displayed on the screen. If the short message memory
is full, you can no longer receive message. To receive messages, delete some or all the existed messages.
-24-
Outbox
Messages sent failed are stored in this item.
Drafts
Draft messages are listed in this item.
Sent box
The messages which are sent successfully are stored in this menu.
5.6 Tools
Alarm
Three alarm clocks are set but deactivated by default. You can activate one, multiple or all of them as
needed. For each alarm clock, the ringing date and the ringing time can be set. When the preset alert time is
up, the mobile phone gives off an alert tone whereas the current date and time blinks on the screen. Select
Stop to stop the ring or Snooze to temporarily stop the ring. If you select Snooze, the alarm clock will ring
four minutes later.
Calendar
Once you enter this menu, there is a monthly-view calendar for you to keep track of important
appointments, etc. Days with events entered will be marked.
-25-
Bluetooth
With Bluetooth, you can make a wireless connection to other compatible devices, such as mobile phones,
computers, headsets and car kits. You can use the Bluetooth to send images, video clips, music, sound clips
and notes, and transfer files from your compatible pc.
¾ Open/close Bluetooth: To activate or deactivate Bluetooth as needed.
¾ Bluetooth visibilitySet visibility as” show phone” to let other Bluetooth devices find you.
¾ Paired devices: List all paired devices and also you can add new devices.
¾ My Bluetooth name: It can be modified if you want.
¾ Shared folder settings: To set shared contents and authorities of FTP service.
¾ Storage: Select phone or memory card.
Calculator
The calculator can add, subtract, multiply and divide. To use the calculator:
Press the up, down, left and right key to select , , ×, ÷, respectively.
Press right soft key to delete the figure.
Note: This calculator provides limited precision and is only applicable to simple arithmetic calculation.
STK
STK service is the tool kit of SIM card. This phone supports the service function .The specific items are
depended by SIM card and network. Service menu will be auto added to the phone menu when supported by
network and SIM card.
-26-
5.7 Settings
Call Settings
Dual-SIM: Dual-SIM refers to two SIM card slots, and the two cards can standby at the same time or set
one of them to display on the idle screen.
Network selection: Set Network selection mode to Automatic or Manual. Automatic is recommended.
When Network selection mode is set to Automatic, the mobile phone will prefer the network where the
SIM card is registered. When Network selection mode is set to Manual, you need to select the network
operator's network where the SIM card is registered.
Call divert: this network function enables you to forward incoming calls to another number you have
previously specified.
Call barring: The call barring function enables you to bar calls as needed. When setting this function,
you need to use a network barring code, which can be obtained from the network operator. If the code is
wrong, an error message will be prompted on the screen. After selecting a call barring option, continue to
select Activate or Deactivate. The mobile phone will prompt you to input the call barring code and then
contact the network. A moment later, the network will make a response and send the operation results to
the mobile phone.
Call waiting: After you choose Activate, the mobile phone will contact the network. A moment later, the
network will make a response and send a message to acknowledge your operation. If the call waiting
function is activated, the network will alert you and the mobile phone screen will display the incoming
call number if others are calling you while you are already in a conversation.
Hide ID: When you call someone, he or she can’t find out your number if you enable this function.
-27-
Select line: Switch to Line 1 or Line 2. By default, Line 1 is used.
Note: If you choose Line 2, dialing may fail. This depends on the implementation of the network
operator.
Flight mode: when this function is engaged, it will suspend many of the device's signal transmitting
functions – thereby disabling the device's capacity to place or receive calls or text messages– while still
permitting use of other functions that do not require signal transmission (e.g., games, built-in camera,
MP3 player.)
Others: It includes IP shortcut key, 50 seconds voice call alert, answer/reject mode and auto redial.
Phone setup
Time and date: Set time, date, time format and date display type.
Select language: Select the display language for the mobile phone.
Shortcuts settings: Select shortcuts function to display on idle screen.
Auto power on/off: Set the time when the mobile phone will be automatically powered on or off.
Power management: Show the remaining battery level.
Restore factory settings Use this function to restore factory settings. The initial password is 1234.
Display settings
Users can access this item to set wallpaper, idle screen style, idle display, backlight duration, keypad
light duration and animation effect.
Security settings
PIN: The PIN (Personal identification number, 4 to 8 digits) code prevents your SIM card from being
-28-
used by unauthorized people. In general, the PIN is supplied with SIM card by the network operator. If PIN
check is enabled, you need to input the PIN each time when you power on your mobile phone. The SIM card
will be locked if you input wrong PIN code for three times
PIN2: The PIN2 code (4 to 8 digits), supplied with SIM card, is required to access some functions such
as “call costs setup” and “fixed dialing setup”. Please contact the network operator to verify whether your
SIM card supports these functions. If you input wrong PIN2 for three times, the PIN2 will be locked.
Privacy: the initial password is 1234. After accessing this function, you can select some items. Once an
item is selected, you need to input correct password whenever you want to enter there items to perform
further operations.
Auto keypad lock: The function enables you to lock the keypad. Set the auto locking time, 5s, 30s,
1min or 5mins is available.
Lock screen by end-key: Users can activate/deactivate this function as needed.
Power-on password: Once this function is activated, password is required when powering on the phone.
Guard lock: When the Guard lock is on, once your SIM card is replaced, the phone will automatically
send stolen information to the number you’ve set.
Connection management
Network account: Access this function to set GPRS, MMS and WAP related parameters.
-29-
5.8 Applications
E-book reader
E-book reader enables you to read TXT file. Through the USB connecting line putting files to E-book
folder of phone or T-Flash card. After finishing downloading, you can find the folder and open the E-book to
read text directly.
Boxman
A game named boxman is embedded in the phone. For specific operation, please refer to ‘help’ option of the
game.
5.9 Services
This function enables you to surf the Internet using the mobile phone.
URL: input the website to be searched and press OK key to access to the network directly.
Homepage: indicates the default website of the internet.
Bookmark: used to save most commonly-used websites.
History: browse the record of the recently browsed web pages.
WAP Settings: set up WAP-related service.
Note: Consulting the local network operator for related fee and specific setup.
-30-
6 Appendix
Appendix 1Troubleshooting
If you find exceptions when operating the mobile phone, restore the factory settings and then refer to the
following table to solve the problem. If the problem persists, contact the distributor or service provider.
Fault Cause Solution
SIM card error
The SIM card
is damaged. Contact your network service provider
The SIM card
is not in
position.
Check the SIM card
The metal
face of the
SIM card is
polluted.
Clean the SIM card with a clean cloth
-31-
Poor received
signal quality
Signals are
obstructed.
For instance,
radio waves
cannot be
effectively
transmitted
nearby a high
building or in
a basement.
Move to a place where signals can be effectively transmitted
Line
congestions
occur when
you use the
mobile phone
in high-traffic
hours
Avoid using the mobile phone in high-traffic hours
-32-
The mobile
phone cannot
be powered on
The battery
energy is
exhausted.
Charge the battery
Calls cannot be
dialed
Call barring is
activated Cancel call barring
The mobile
phone cannot
connect the
network
The SIM card
is invalid Contact your network service provider
-33-
The mobile
phone is not
in a service
area of the
GSM network
Move to the network operator's service area
The signal is
weak Move to a place where the signal quality is high
The battery
cannot be
charged
The charging
voltage does
not match the
voltage range
indicated on
the charger
Ensure the charging voltage matches the voltage range
indicated on the charger
An improper
charger is
used
Use the charger specially designed for the mobile phone
Poor contact Ensure the charger plug is in good contact with the mobile
phone
FCC RF EXPOSURE INFORMATION:
WARNING!! Read this information before using your phone
In August 1986 the Federal Communications Commission (FCC) of the United States with its
action in Report and order FCC 96-326 adopted an updated safety standard for human
exposure to radio frequency (RF) electromagnetic energy emitted by FCC regulated transmitters.
Those guidelines are consistent with the safety standard previously set by both U.S. and
international standards bodies. The design of this phone complies with the FCC guidelines and
these international standards. Use only the supplied or an approved antenna. Unauthorized
antennas modifications, or attachments could impair call quality, damage the phone, or result in
violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged
antenna comes into contact with the skin, a minor burn may result. Please contact your local
dealer for replacement antenna.
BODY-WORN OPERATION:
This device was tested for typical body-worn operations with the back of the phone kept 1.5cm
from the body. To comply with FCC RF exposure requirements, a minimum separation distance
of 1.5cm must be maintained between the user's body and the back of the phone, including the
antenna, whether extended or retracted. Third-party belt-clips, holsters and similar accessories
containing metallic components shall not be used. Body-worn accessories
that cannot maintain 1.5cm separation distance between the user’s body and the back of the
phone, and have not been tested for typical body-worn operations may not comply with FCC RF
exposure limits and should be avoided.
For more information about RF exposure, please visit the FCC website at www.fcc.gov
Your wireless handheld portable telephone is a low power radio transmitter and receiver. When
it is ON, it receives and also sends out radio frequency (RF) signals. In August, 1996, the Federal
Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for
hand-held wireless phones. Those guidelines are consistent with the safety standards previously
set by both U.S. and international standards bodies:
<ANSIC95.1> (1992) / <NCRP Report 86> (1986) / <ICIMIRP> (1996)
Those standards were based on comprehensive and periodic evaluations of the relevant
scientific literature. For example, over 120 scientists, engineers, and physicians from universities,
government health agencies, and industry reviewed the available body of research to develop
the ANSI Standard (C95.1). Nevertheless, we recommend that you use a hands-free kit with
your phone (such as an earpiece or headset) to avoid potential exposure to RF energy. The
design of your phone complies with the FCC guidelines (and those standards).
Use only the supplied or an approved replacement antenna. Unauthorized antennas,
modifications, or attachments could damage the phone and may violate FCC regulations.
NORMAL POSITION:
Hold the phone as you would any other telephone with the antenna pointed up and over your
shoulder.
TIPS ON EFFICIENT OPERATION:
For your phone to operate most efficiently:
• Extend your antenna fully.
Do not touch the antenna unnecessarily when the phone is in use. Contact with the antenna
affects call quality and may cause the phone to operate at a higher power level than otherwise
needed.
RF
Exposure Information:
FCC RF Exposure requirements: The highest SAR value reported under this standard
during product certification for use next to the body with the minimum separation
distance of 1.5cm is 0.576W/kg, next to the head is 1.31W/kg. This transmitter must not
be collocated or operating in conjunction with any other antenna or transmitter.
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help
Do not use the device with the environment which below minimum -10 or maximum over
50, the device may not work.
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

Navigation menu
