32" and 37" LCD TVs

DX-32L151A11/DX-37L130A11

USER GUIDE

DX-32L151A11-37L130A11_10-0567.book Page 1 Tuesday, June 1, 2010 9:26 AM

Dynex DX-32L151A11/DX-37L130A11

32" and 37" LCD TVs

Contents

CHILD SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installing the stand or removing the stand column . . . . . . . . . . . . . 4

Installing the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Removing the stand column . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Installing a wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

TV components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Using the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installing remote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Aiming the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Programming a universal remote control to work with your TV . . . . . . . . . .8

Making connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Selecting a location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Connecting the power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Connecting an HDMI device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Connecting a component video device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Connecting an antenna, cable TV, or satellite TV box . . . . . . . . . . . . . . . . . . . .9

Connecting a VCR, camcorder, or game console . . . . . . . . . . . . . . . . . . . . . . 10

Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Connecting a home theater system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Connecting headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Turning on your TV for the first time . . . . . . . . . . . . . . . . . . . . . . . . . .11

Understanding the basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Turning your TV on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Selecting the video input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Selecting a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Displaying program information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

On-screen menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Navigating the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Adjusting basic settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Adjusting the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Adjusting the TV picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Adjusting the computer image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Adjusting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Adjusting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Selecting the audio mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Playing TV audio only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

DX-32L151A11-37L130A11_10-0567.book Page ii Tuesday, June 1, 2010 9:26 AM

iii

Changing channel settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Automatically scanning for channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Selecting the signal source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Hiding channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Setting up a favorite channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Adding or changing a channel label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Checking digital TV signal strength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Setting parental controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Turning parental controls on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Setting or changing the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Turning the button lock on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Setting parental control levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Using closed captioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Turning closed captioning on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Selecting the closed captioning mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Customizing digital TV closed captioning styles . . . . . . . . . . . . . . . . . . . . . . . 24

Adjusting time settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Setting the date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Adjusting menu settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Selecting the menu language and transparency . . . . . . . . . . . . . . . . . . . . . . 26

Labeling an input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Restoring default settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Video and audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

One-year limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

US and Canada Markets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Mexico Market . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

DX-32L151A11-37L130A11_10-0567.book Page iii Tuesday, June 1, 2010 9:26 AM

DX-32L151A11-37L130A11_10-0567.book Page iv Tuesday, June 1, 2010 9:26 AM

DX-32L151A11/DX-37L130A11

As you enjoy your new product, keep these

safety tips in mind

The issue

The home theater entertainment experience is a growing trend, and larger TVs are popular

purchases. However, TVs are not always supported on the proper stands or installed

according to the manufacturer’s recommendations. We and the consumer electronics

industry are committed to making home entertainment enjoyable and safe.

TVs that are inappropriately placed on dressers, bookcases, shelves, desks, speakers,

chests, or carts may fall over and cause injury.

Tune into safety

•One size of TV stand does not fit all. Use only a TV stand

rated for the weight of your TV.

•Carefully read and understand all enclosed instructions for

proper use of this product.

•Don’t let children climb on or play with entertainment system

furniture and TVs.

•Don’t place TVs on furniture that can easily be used as

steps, such as a crate or chest of drawers.

•Remember that children can become excited while watching

a program, especially on a “larger-than-life” TV. Make sure

that you place or install the TV where it cannot be pushed,

pulled over, or knocked down.

•Make sure that you route all cords and cables so that they

cannot be pulled or grabbed by curious children.

Wall mounting

If you decide to wall mount your TV, always remember:

•One size of wall mount does not fit all. Use only a wall mount rated for the weight of your

TV and that has been recommended by this TV manufacturer, listed in this manual, or

otherwise listed by an independent laboratory as suitable for your TV.

•Follow all instructions supplied by the TV and wall mount manufacturers.

•If you have any doubts about your ability to safely wall mount your TV, get help from a

professional installer.

•Make sure that the wall where you are mounting the TV is

appropriate. Some wall mounts are not designed to be mounted

to walls backed with steel studs or cinder blocks. If you are

unsure, ask a professional installer.

•TVs can be heavy. At least two people are required for safe wall mount installation.

CHILD SAFETY

It makes a difference how and where you use

your flat panel display

DX-32L151A11-37L130A11_10-0567.book Page 1 Tuesday, June 1, 2010 9:26 AM

2Important safety instructionsDX-32L151A11/DX-37L130A11

Important safety instructions

1Read these instructions.

2Keep these instructions.

3Heed all warnings.

4Follow all instructions.

5Do not use this apparatus near water.

6Clean only with a dry cloth.

7Do not block any ventilation openings. Install in accordance with

the manufacturer's instructions.

8Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that

produce heat.

9Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with one

wider than the other. A grounding type plug has two blades and

a third grounding prong. The wide blade or the third prong are

provided for your safety. If the provided plug does not fit into

your outlet, consult an electrician for replacement of the obsolete

outlet.

10 Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point

where they exit from the apparatus.

11 Only use attachments/accessories specified by the manufacturer.

12 Use only with a cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with

the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to

avoid injury from tip-over.

13 Unplug this apparatus during lightning storms or when unused

for long periods of time.

14 Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way, such

as power-supply cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally, or has

been dropped.

15 The wall plug is the disconnecting device. The plug must remain

readily operable.

16 An apparatus with a three-prong, grounding-type plug is a Class I

apparatus, which needs to be grounded to prevent possible

electric shock. Make sure that you connect this Class I television

to a grounding-type, three-prong outlet.

17 Remote control batteries should not be exposed to excessive heat

such as sunshine, fire, or the like.

18 The apparatus should not be exposed to dripping or splashing,

and no objects filled with liquids, such as vases, should be placed

on the apparatus.

Warnings

Electric shock hazard

To reduce the risk of fire or electric shock, do not remove any cover or

expose the device to rain or moisture. No user-serviceable parts are

inside. Refer servicing to qualified service technicians.

Lightning

For added protection for your device receiver during a lightning storm,

or when it is left unattended and unused for long periods of time,

unplug it from the power outlet and disconnect any antenna or cable

system. This helps prevent property damage and personal injury from

lightning and power line surges.

Power lines

An outside antenna system should not be located in the vicinity of

overhead power lines or other electric light or power circuits, or where it

can fall into such power lines or circuits. When installing an outside

antenna system, extreme care should be taken to keep from touching

such power lines or circuits as contact with them might be fatal.

Handling the LCD panel

• Your TV’s screen is made of glass. Do not drop your TV or hit, jolt,

or press hard against the LCD panel. If the screen breaks, be

careful of broken glass.

• If the LCD panel is broken, make absolutely sure that you do not

touch the liquid in the panel. This may cause skin inflammation.

• If the liquid gets in your mouth, immediately gargle, rinse, and

consult with your doctor. Also, if the liquid gets in your eyes or

touches your skin, consult with your doctor after rinsing for at

least 15 minutes or longer in clean water.

Replacement parts

When replacement parts are required, make sure that the service

technician uses replacement parts specified by the manufacturer that

have the same characteristics as the original part. Unauthorized

substitutions may result in fire, electric shock, personal injury, or other

hazards.

Safety check

After completing any service or repair to this device, ask the service

technician to perform routine safety checks to determine that your TV is

in correct operating condition.

Power source

Operate your TV only from the type of power source indicated on the

marking label. If you are not sure of the type of power supplied to your

home, consult an electrician or your local power company.

Cautions

Damage requiring service

Unplug this TV from the power outlet and refer servicing to qualified

service personnel under the following conditions:

• When the power supply cord or plug is damaged or frayed.

• If liquid has been spilled or objects have fallen into your TV.

• If your TV has been exposed to rain or water.

CAUTION

RISK OF ELECTRIC

SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within your TV. This

label is located on the back of your TV.

This symbol indicates that there are

important operating and maintenance

instructions in the literature

accompanying your TV.

3125A

DX-32L151A11-37L130A11_10-0567.book Page 2 Tuesday, June 1, 2010 9:26 AM

Important safety instructions 3

DX-32L151A11/DX-37L130A11

• If your TV does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the

operating instructions because incorrect adjustment of other

controls may result in damage and will often require extensive

work by a qualified technician to restore your TV to its normal

operation.

• If your TV has been dropped or damaged in any way.

• When your TV exhibits a distinct change in performance.

Outdoor antenna grounding

If an outside antenna or cable system is connected to your TV, make sure

that the antenna or cable system is grounded to provide some

protection against voltage surges and built-up static charges. Article

810 of the National Electrical Code, ANSI/NFPA No. 70, provides

information with respect to correct grounding of the mast and

supporting structure, grounding of the lead-in wire to an antenna

discharge unit, size of grounding conductors, location of the

antenna-discharge unit, connection to grounding electrodes, and

requirements for the grounding electrode.

Note to CATV system installer

Article 820 of the National Electrical Code, ANSI/NFPA No. 40 provides

guidance for correct grounding. Specifically, it states that the cable

ground must be connected to the grounding system of the building as

close to the point of cable entry as practical.

Condensation

Moisture will form on the TV if the TV is brought from cool surroundings

into a warm room or if the temperature of the room rises suddenly.

When this happens, the TV's performance may be impaired. To prevent

this, let the TV stand in its new surroundings for about an hour before

switching it on, or make sure that the room temperature rises gradually.

Condensation may also form during the summer if the TV is exposed to

the breeze from an air conditioner. In such cases, change the location of

the TV.

Mobile telephone warning

To avoid interference with your TV picture and sound, operating

problems, or even damage, keep your cordless and cellular telephones

away from the TV.

End of life directives

Your TV contains tin-lead solder and a fluorescent lamp containing a

small amount of mercury. Disposal of these materials may be regulated

for environmental reasons. Your TV also contains material that can be

recycled and reused. For disposal or recycling information, contact your

local authorities or the Electronic Industries Alliance at www.eia.org to

find a recycler in your area.

Non-active pixels

The LCD panel contains almost 3 million thin film transistors, which

provide exceptionally sharp video quality. Occasionally, a few

non-active pixels may appear on the screen as a fixed blue, green, or red

point. These non-active pixels do not adversely affect the performance

of your TV, and are not considered defects.

Antenna lead-in wire

Grounding clamp

Antenna discharge unit

Grounding conductors

Ground clamps

Power service grounding electrode

system

Electric service equipment

DX-32L151A11-37L130A11_10-0567.book Page 3 Tuesday, June 1, 2010 9:26 AM

4Installing the stand or removing the stand columnDX-32L151A11/DX-37L130A11

Installing the stand or removing

the stand column

Cautions

• Read these instructions carefully before you try to assemble the

stand or remove the stand column.

• Make sure that you handle the TV carefully when attempting to

assemble or remove the stand. If you are not sure of your ability

to do this, contact a professional installer or service technician.

Dynex is not responsible for any damages or injuries that occur

because of mishandling or incorrect assembly.

• Use a soft cushion or covering to prevent scratching or damage to

the TV screen or cabinet.

• The speaker is not intended to support the weight of the TV. Do

not move or handle the TV by the speaker. This can cause damage

that is not covered by your warranty.

• Before assembly or removal of the stand, unplug the power cord.

You must install your TV into the stand in order for it to stand upright on

a cabinet or other flat surface. If you intend to mount your TV on a wall

or other vertical surface, you must remove the stand column.

Installing the stand

You must install the stand to use the TV in an upright position on a flat

surface.

Note: Your TV may differ from the illustrations shown.

To install the stand:

1Remove the stand from the box and place it on a table or bench.

2Lay the TV (screen down) on the edge of the table or bench. Make

sure that you put a soft cloth or cushion between the table or

bench and the TV.

3Align the locators on the stand column with the locating holes on

the stand, then secure the stand to the column with the four M5

screws (provided).

4Carefully lift the TV into an upright position.

To remove the stand, perform these steps in reverse order.

Removing the stand column

You must remove the stand column before you can wall-mount the TV.

Note: Your TV may differ from the illustrations shown.

To remove the stand column:

1Lay the TV (screen down) on the edge of the table or bench. Make

sure that you put a soft cloth or cushion between the table or

bench and the TV.

2Remove the four screws holding the stand column to the TV, then

remove the stand column.

Installing a wall-mount bracket

If you want to attach the TV to a wall-mount bracket (not provided), you

should first remove the stand pedestal, if it is already attached.

To install a wall-mount bracket:

1Lay your TV face down on a table or bench. Make sure that you

put down a soft cushion or cloth so that your TV is not scratched.

2Remove the pedestal stand.

3Remove the stand column. See “Removing the stand column” on

page 4.

4Secure the wall-mount bracket to the back of your TV using the

four M6 screws provided with the bracket.

TV components

Accessories

Make sure the following accessories are included in the box with your

TV:

•Remote control

• Composite video & audio cable

•AC power cord

•AAA batteries (2)

•Stand

•Quick Start Guide

Stand column

Table edge

Stand

Locators

Locating holes

Stand

Four M5 screws

Table edge

Stand column

DX-32L151A11-37L130A11_10-0567.book Page 4 Tuesday, June 1, 2010 9:26 AM

TV components 5

DX-32L151A11/DX-37L130A11

Front Side

Item Name Description

Remote control

sensor

Receives signals from the remote control.

Do not block. For more information, see

“Aiming the remote control” on page 8.

Power indicator

Lights red when your TV is in standby mode.

Flashes red when your TV is turned on, then

turns off when the TV stabilizes.

Item Name Description

CH / CH

In TV mode, press to select the next or

previous channel.

In menu mode, press to move up or down.

VOL+ / VOL-

In TV mode, press to increase or decrease the

volume.

In menu mode, press to move right or left or to

adjust menu settings.

MENU Press to open the on-screen menu.

INPUT

Press to open the INPUT SOURCE menu. For

more information, see “Selecting the video

input source” on page 12.

(power)

Press to turn on the TV or put the TV in standby

mode.

Caution: The TV continues to receive power

even in standby mode. Unplug the power cord

to disconnect power.

DX-32L151A11-37L130A11_10-0567.book Page 5 Tuesday, June 1, 2010 9:26 AM

6TV componentsDX-32L151A11/DX-37L130A11

Back

Remote control

Item Name Description

SERVICE PORT For software updates only. Do not use.

(headphone)

jack

Plug headphones into this jack. For more

information, see “Connecting headphones”

on page 11.

HDMI 2 jack

Connect an HDMI device to this jack. For

more information, see “Connecting an HDMI

device” on page 9.

AV IN jacks Connect a standard AV device, such as a

camcorder or game console, to these jacks.

AC IN

Plug the power cord into this jack and into a

power outlet. For more information, see

“Connecting the power” on page 8.

DIGITAL OUTPUT

jack

Connect a digital optical cable to this

connector, then to a digital sound system.

For more information, see “Connecting

using a digital audio cable” on page 11.

HDMI 1 jack

Connect an HDMI device to this jack. For

more information, see “Connecting an HDMI

device” on page 9.

PC IN VGA /

AUDIO jacks

Connect a computer to these jacks. For more

information, see “Connecting a computer”

on page 10.

AV IN

VIDEO AUDIO HDMI 2

SERVICE PORT

HDMI 1 PC IN COMPONENT IN

ANT/ CABLE IN

AUDIO OUT

PBPR

DIGITAL OUTPUT

VGA

AUDIO YAUDIO

AUDIO

COMPONENT IN

jacks

Connect component video devices to these

jacks. For more information, see “Connecting

a component video device” on page 9.

AUDIO OUT jacks

Connect an audio amplifier to these jacks.

For more information, see “Connecting a

home theater system“ on page 10.

ANT/CABLE IN

jack

Connect an antenna or cable TV to this jack.

For more information, see “Connecting an

antenna, cable TV, or satellite TV box” on

page 9.

Item Name Description

POWER

Press to turn on the TV or put the TV in standby

mode.

Caution: The TV continues to receive power

even in standby mode. Unplug the power cord

to disconnect power.

COMP Press to select the device connected to the

COMPONENT IN jacks

Item Name Description

DX-32L151A11-37L130A11_10-0567.book Page 6 Tuesday, June 1, 2010 9:26 AM

Using the remote control 7

DX-32L151A11/DX-37L130A11

Using the remote control

Installing remote control batteries

To install remote control batteries:

1Press down on the battery compartment cover lock, then remove

the remote control cover.

2Insert two AAA batteries into the battery compartment. Make

sure that the + and – symbols on the batteries match the +

and – symbols in the battery compartment.

3Replace the cover. Make sure that the lock snaps into place.

Battery precautions:

• Dispose of batteries as hazardous waste.

• Do not mix batteries of different types.

• Do not mix old and new batteries. Mixing old and new batteries can

shorten the life of new batteries and can cause old batteries to leak.

• Remove batteries as soon as they become inoperable. Chemicals that

can leak from the batteries can cause a rash. If the batteries leak,

clean the battery compartment with a cloth.

• If the remote control is not used for an extended period of time,

remove the batteries.

• Do not expose batteries to excessive heat such as sunshine, fire, or

other heat sources.

HDMI

Press once to select a device connected to the

HDMI 1 jack.

Press twice to select a device connected to the

HDMI 2 jack.

Numbers/.

Press the number buttons to enter channel

numbers or the parental control password.

Press the dot button to select a digital

sub-channel.

For more information, see “Selecting a channel”

on page 12.

INPUT

Press to open the INPUT SOURCE menu. For

more information, see “Selecting the video

input source” on page 12.

VOL+ / VOL– Press to increase or decrease the volume.

MENU Press to open the on-screen menu.

Press or to move up or down in on-screen

menus.

Press or to move left or right in on-screen

menus or to adjust menu settings.

ENTER Press to confirm selections in on-screen menus

or to open sub-menus.

GUIDE

Press to open the DTV program guide (if

available). For more information, see

“Displaying program information” on page 13.

MTS/SAP

In analog TV mode, press to select STEREO,

SAP (secondary audio language), or MONO.

In digital TV mode (DTV), press to select the

audio track. For more information, see

“Selecting the audio mode” on page 16.

CCD

Press to turn closed captioning on or off. For

more information, see “Turning closed

captioning on or off” on page 23.

ZOOM

Press to select the screen aspect ratio. You can

select Auto, Normal, Zoom, Wide, and

Cinema. For more information, see “Adjusting

the TV picture” on page 14.

FAVORITE

Press to open the favorite channel list. For more

information, see “Setting up a favorite channel

list” on page 18.

VIDEO Press to select the device connected to the AV

IN Jack.

Press to select the TV as the video input source.

For more information, see “Selecting the video

input source” on page 12.

RECALL

Press to go to the last viewed channel. For more

information, see “Selecting a channel” on page

12.

CH /CH

Press to go to the next or previous channel in

the channel list. For more information, see

“Automatically scanning for channels” on

page 17 and “Selecting a channel” on page 12.

MUTE Press to mute the sound. Press again to restore

the sound.

INFO

Press to display the information banner. For

more information, see “Displaying program

information” on page 13.

EXIT Press to close the on-screen menu.

SLEEP

Press to set the sleep timer. For more

information, see “Setting the sleep timer” on

page 26.

Item Name Description

CH-LIST

Press to open the channel list. For more

information see “Selecting a channel” on

page 12.


Press to select the picture mode. You can select

Vivid, Standard, Theater, Sports, Energy

Saving, and Custom. For more information, see

“Adjusting the TV picture” on page 14.

AUDIO

Press to select the sound mode. You can select

Standard, Movie, Music, News, or Custom. For

more information, see “Adjusting the sound” on

page 15.

Item Name Description

DX-32L151A11-37L130A11_10-0567.book Page 7 Tuesday, June 1, 2010 9:26 AM

8Making connectionsDX-32L151A11/DX-37L130A11

Aiming the remote control

To aim the remote control:

• Point the remote control towards the remote sensor on the front

of your TV.

Notes:

• Do not expose the remote control to shock or liquids.

• Do not use the remote control in an area with high humidity.

• Do not place the remote control in direct sunlight.

• Do not place objects, such as furniture, between the remote control

and the remote sensor.

• The remote control may not work if direct sunlight or bright light

shines on the remote sensor. Either move your TV or change the angle

at which you use the remote control.

Programming a universal remote control

to work with your TV

You can operate your TV with a new or existing universal remote

control.

To program your existing universal remote control:

1To program your existing remote control to work with your Dynex

TV, see the table below for common codes. If you have problems

programming your remote, or need a different remote control

code, visit www.dynexproducts.com for the latest remote control

code information.

Codes for other remote controls are available online at:

http://www.dynexproducts.com/universalcontrolcodes.aspx

Tips:

• The brand name is often visible on the front of the universal remote

control, and the model number is often visible on the back.

• The codes shown above are common codes, but are subject to change.

Please refer to Dynexproducts.com for the most up to date codes.

• If your universal remote control isn’t listed on the chart, refer to your

universal remote control’s instructions and try codes for the brands

Orion, Emerson, Memorex, Sansui, Sylvania, or Zenith. You may need

to try several codes before finding a match.

2Follow your universal remote control’s instructions to enter the

code you found in Step 1.

Tips:

• If your universal remote control has a code search feature, run a code

search to identify a code that matches your TV. See your universal

remote control’s instructions for details.

• If your universal remote control has a “learn” feature, you can

manually program it using your TV remote to “teach” the commands

one at a time. See your universal remote control’s instructions for

details.

3If all else fails, you must use a different universal remote control

that can operate both your set-top box and your TV. Five such

remotes are listed on the chart, but many other compatible

models are available in the market.

4For more help, call technical support for your universal remote

control or set-top box manufacturer, or call the Dynex Customer

Care Center. For US and Canada markets, call 1-800-305-2204.

For Mexico markets, call 01-800-926-3020.

Making connections

Before you make any connections:

• Check the plugs on the ends of cables to make sure that they are

the correct type before you try plugging them into jacks on the

TV.

• Make sure that all plugs are securely inserted into the jacks.

Loose connections can result in image or color problems.

• When connecting devices to the TV, make sure that the TV and

the device are turned off and that the power cords are

unplugged.

Selecting a location

You should select a location for the TV:

• Where direct light does not reflect on the screen

• That has indirect and soft lighting

• Where the TV has access to an antenna or cable TV connection

• Where the TV has access to a power outlet

Note: Watching TV in total darkness or with a reflection on the screen

may cause eye strain.

Connecting the power

To connect the power cord:

• Connect the power cable to the AC IN jack on the back of the TV,

then connect the other end to a power outlet.

Dynex TV codes for universal remote controls

(for all Dynex TVs manufactured after Jan. 1, 2007)

Universal remote control manufacturer and model

Philips

PHDVD5,

PH5DSS,

PMDVR8,

PDVR8

RCA

RCU807

One for All

URC-6690

Sony

RM-VL600

115 135 0464 8043

Set-top box manufacturer and model

Comcast

M1057

Dish

Network

VIP508,

VIP622

Motorola

DRC800

TIVO

Series 3, HD

DirectTV

RC23

0463 720 0463 0091 10463

Power cord

Power outlet

DX-32L151A11-37L130A11_10-0567.book Page 8 Tuesday, June 1, 2010 9:26 AM

Making connections 9

DX-32L151A11/DX-37L130A11

Notes:

• The AC plug on the TV may be different from the one shown.

• Make sure that you only use the type of power source indicated on the

marking label.

• Always unplug the power cord when not using the TV for a long

period of time.

Connecting an HDMI device

Note: If your device has an HDMI connection, we recommend you use that

to get the best quality possible.

To connect an HDMI device:

• Connect one end of an HDMI cable (not included) to the HDMI 1

jack on the back of your TV or HDMI 2 jack on the side of your TV,

then connect the other end of the cable to the HDMI OUT jack on

the HDMI device.

Note: To connect a DVI device, use a DVI to HDMI adapter cable to connect

to the HDMI jack on the TV, then connect an audio cable to the

PC IN AUDIO jack on the back of the TV.

To play from the HDMI device:

1Turn on the TV, then press INPUT. The INPUT SOURCE menu

opens.

2Press or to select HDMI 1 or HDMI 2, then press ENTER.

Note: You can also press HDMI once to select HDMI 1 or twice to select

HDMI 2.

3Turn on the HDMI device, then set it to the correct mode. Refer to

the instructions that came with the HDMI device.

Connecting a component video device

Component cables often have red, green, and blue color-coded video

connectors and red and white audio connectors. Match the colors when

making connections.

To connect a component video device:

1Make sure that your TV’s power cord is unplugged and the

component video device is turned off.

2Connect a component video cable to the COMPONENT OUT jacks

on the component video device.

3Connect the other end of the component video cable to the

COMPONENT jacks on the back of your TV.

4Connect an audio cable (not included) to the AUDIO OUT jacks

(L/R) on the component device.

5Connect the other end of the audio cable to the COMPONENT

AUDIO-R and AUDIO-L jacks on the back of your TV.

To play from the component video device:

1Turn on the TV, then press INPUT. The INPUT SOURCE menu

opens.

2Press or to select Component, then press ENTER.

Note: You can also press COMP once to select Component.

3Turn on the component video device and start playback. Refer to

the instructions that came with the component video device.

Connecting an antenna, cable TV, or

satellite TV box

To connect an antenna, cable TV, or satellite TV box:

• Connect one end of a 75-Ohm, coaxial cable to the ANT/CABLE

IN jack on the back of the TV, then connect the other end of the

cable to the antenna or cable TV wall jack.

• If you are connecting a satellite TV or cable box, you can use one

of the following (if available):

• Acceptable - 75-ohm coaxial cable.

Back of TV

HDMI device

HDMI cable

Back of TV

Component video device

Component video cable

Audio cable

75-Ohm coaxial cable

Wall jack

Back of TV

DX-32L151A11-37L130A11_10-0567.book Page 9 Tuesday, June 1, 2010 9:26 AM

10 Making connectionsDX-32L151A11/DX-37L130A11

• Good - Video composite cable

• Better - Video component cables

• Best - HDMI cable

Notes:

• We recommend using a 75-Ohm, coaxial cable to reduce interference

and noise that may be caused by radio wave transmissions.

• Do not bundle the coaxial cable with the power cord or any other

cables.

• If you are using an antenna and reception is not good, contact a

service technician to adjust the antenna.

Connecting a VCR, camcorder, or game

console

Note: If the VCR, camcorder, or game console has component jacks

(better), or an HDMI jack (best), connect them using the best available

connection.

To connect a VCR, camcorder, or game console:

1Make sure that your TV’s power cord is unplugged and the VCR,

camcorder, or game console is turned off.

2Connect one end of a standard AV cable (not included) into the

AV IN VIDEO jack on the side of the TV, then connect the other

end of the cable to the AV OUT VIDEO jack on the external

device.

3Connect the audio connectors of the AV cable (the red and white

connectors) to the AV OUT AUDIO jacks of the external device,

then connect them to the AV IN AUDIO-L and AUDIO-R jacks on

the side of your TV.

To play the external AV device:

1Turn on the TV, then press INPUT. The INPUT SOURCE menu

opens.

2Press or to select AV, then press ENTER.

Note: You can also press VIDEO once to select AV.

3Turn on the device, then start playback on the device.

Connecting a computer

To connect a computer:

1Make sure that your TV’s power cord is unplugged and the

computer is turned off.

2Connect one end of a VGA cable (not included) to the PC IN VGA

jack on the back of the TV, then connect the other end of the

cable to the VGA jack on the computer.

3Connect one end of an audio cable (not included) to the

PC IN AUDIO jack on the back of the TV, then connect the other

end of the cable to the AUDIO OUT jack on the computer.

Note: The audio cable should have a stereo mini-plug.

To play video from the computer:

1Turn on the TV, then press INPUT. The INPUT SOURCE menu

opens.

2Press or to select VGA, then press ENTER.

3Turn on the computer, then adjust the computer display

properties as needed.

Connecting a home theater system

Connecting using an analog audio cable

To connect using an analog audio cable:

1Make sure that your TV’s power cord is unplugged and the audio

amplifier is turned off.

2Connect one end of a audio cable (not included) to the AUDIO

OUT jacks (L/R) on the back of the TV.

Note: Cable connectors and jacks are often color-coded. Match the colors

when you connect the AV cable.

3Connect the other end of the audio cable to the AUDIO IN jacks

on the home theater system.

AV IN

VIDEO

AUDIO

HDMI 2

SERVICE PORT

VCR

AV cable

Side of TV

Note: Cables are often

color-coded to connectors.

Connect yellow to yellow,

red to red, and white to

white.

Game console

Camcorder

Back of TV

Computer

VGA cable

Audio cable

Back of TV

Audio amplifier

Audio cable

DX-32L151A11-37L130A11_10-0567.book Page 10 Tuesday, June 1, 2010 9:26 AM

Turning on your TV for the first time 11

DX-32L151A11/DX-37L130A11

Connecting using a digital audio cable

To connect using a digital optical cable:

1Make sure that your TV’s power cord is unplugged and the digital

audio system is turned off.

2Connect one end of a digital optical audio cable (not included) to

the DIGITAL OUTPUT jack on the back of the TV.

3Connect the other end of the audio cable to the digital optical

input jack on the digital audio system.

Note: The DIGITAL OUTPUT jack only works with digital TV channels.

To play TV sound through a home theater system:

1Turn on the TV and select a program to watch.

2Turn on the home theater system and select the TV sound source,

then adjust the volume to a comfortable level.

Connecting headphones

Warning: When using headphones, adjust the headphone volume to

avoid excessively loud volume which can damage your hearing.

To connect headphones:

• Plug the headphones (not included) into the (headphone)

jack on the side of the TV.

Turning on your TV for the first

time

To configure your TV:

1Make sure that you have inserted the batteries in the remote

control, connected your devices to the TV, and connected the AC

power.

2Press (Power), then wait several seconds. The initial Setup

Wizard screen opens (only the first time you turn on your TV).

3Press or to select the menu language you want, then press

ENTER. The Time screen opens.

4Press or to highlight Time Zone, then press or to

select your time zone. You can select Pacific, Alaska, Hawaii,

Atlantic, Eastern, Central, or Mountain.

5If your viewing area observes daylight savings time, press or

to highlight DST, then press or to select On.

6Press or to highlight Mode, then press or to select

Manual (to set the date/time manually), or Auto (the date/time

are automatically set by the TV signal source, based on the time

zone you selected).

7If you select Manual mode, make the settings as follows:

• Press or to highlight Year, Month, or Day, then press

or to adjust the setting.

• Set the time by pressing or to highlight Time, then

press or to highlight the hour, minute, or AM/PM field.

Press or to adjust the setting.

8Press ENTER. The Choose your Picture Mode screen opens.

Back of TV Digital sound system

Digital optical cable

AV IN

VIDEO

AUDIO

HDMI 2

SERVICE PORT

DX-32L151A11-37L130A11_10-0567.book Page 11 Tuesday, June 1, 2010 9:26 AM

12 Understanding the basicsDX-32L151A11/DX-37L130A11

9Press or to select Home Mode or Retail Mode, then press

ENTER.

If you select Home Mode, the Choose your TV source screen

opens.

-OR-

If you select Retail Mode, a message stating “Are you sure you

want Retail mode? Since in this mode Energy saving is not

realized.” appears. Select Yes to proceed, or No to exit.

10 Press or to select Antenna, Cable, or Cable/Satellite

Box, depending on the type of connection you have.

• If you are using an antenna for a standard or HD TV signal,

select Antenna.

• If your cable is connected directly to the TV (without a tuner

box), select Cable.

• If your cable is connected to your TV through a tuner box,

select Cable/Satellite Box.

11 Press when you have made your selection. The channel scan

screen opens.

If you selected Antenna or Cable, your TV automatically scans

for available channels in your area and stores the channel

information in the channel list. This may take several minutes.

While scanning, the TV displays a progress report.

– OR –

If you selected Cable/Satellite Box, the auto scan is not

necessary and the screen will ask you to select the correct input

source for your set top box. Press EXIT to close the menu.

Notes:

• During auto scan, digital programs will be scanned first, then analog

programs. When all available digital programs have been searched,

the screen will ask you to “Press MENU or EXIT if you don’t need

analog channel scan.” At this point you can press EXIT to exit the

analog channel scan, or just ignore it and the TV will go on scanning.

• Channel scan can take up to 30+ minutes.

• You can press EXIT at any time to stop the auto scan, but you will

need to run the auto scan again to create a channel list.

12 Select the corresponding video input source through the INPUT

SOURCE menu.

Understanding the basics

Turning your TV on or off

To turn your TV on or off (standby mode):

1Plug the power cord into an AC power outlet.

2Press (power). Your TV turns on.

3Press again to turn off your TV. When you turn off your TV, it

goes into standby mode.

Warning: When your TV is in standby mode, it is still receiving power. To

completely disconnect power, unplug the power cord.

Note: If your TV does not receive an input signal for several minutes, it

automatically goes into standby mode.

Selecting the video input source

To select the video input source:

1Turn on your TV, then press the INPUT key on the remote, or the

INPUT button on the TV. The INPUT SOURCE menu opens.

2Press or to highlight the video source, then press ENTER.

You can also select the input source using the following remote

control buttons:

•VIDEO—Press switch to AV input.

•HDMI–Press repeatedly to cycle between HDMI inputs.

•TV—Press to switch to TV mode.

•COMP—Press to switch to Component input.

Selecting a channel

To select a channel:

• Press CH / CH to go to the next or previous channel.

• Press the number buttons to enter the channel number you want,

then wait for the channel to change, or press ENTER to change

the channel immediately.

• To select a digital channel, press the number buttons to

select the main digital channel, then press the dot (.) button,

then the number buttons again to select the sub-channel.

Wait for the channel to change or press ENTER to change the

channel.

Note: Button presses must be within three seconds of each other.

• Press RECALL to go to the last channel viewed.

• Press CH-LIST to display a list of memorized channels, press or

to select the channel you want from the list, then press ENTER

to go to that channel.

• Press FAVORITE to display a list of your saved favorite channels,

press or to select the channel you want from the list, then

press ENTER to go to that channel.

INPUT SOURCE

Component

VGA

HDMI1

HDMI2

DX-32L151A11-37L130A11_10-0567.book Page 12 Tuesday, June 1, 2010 9:26 AM

Understanding the basics 13

DX-32L151A11/DX-37L130A11

Note: If the list has more than one page, press or to scroll through

the pages.

Adjusting the volume

To adjust the volume:

• Press VOL+ or VOL– to increase or decrease the volume.

• Press MUTE to temporarily turn off all sound. Press MUTE again

to restore the sound.

Displaying program information

To display program information:

• Press INFO to show an information banner. The information

banner shows current program information such as channel

number, video input source, and resolution.

•Digital signal information—Displays channel number,

station name, channel label (if preset), broadcast program

name, TV rating, signal type, audio information, resolution,

CC mode, current time, and current program start and end

times when watching a digital channel.

•Analog signal information—Displays channel number,

channel label (if preset), signal type, audio information, and

resolution when watching an analog channel.

• Press GUIDE to show the digital program guide, which may show

a list of available programs, program times, and program

summaries, depending on the information provided by the

broadcaster.

On-screen menu overview

Picture menu

Audio menu

Setup menu

Channel menu

Notes:

Depending on the signal source selected, you may see different options on

your screen. The above menus are shown in TV mode.

Menu items that are not selectable are grayed out. Menus in this manual

are described in TV mode, unless otherwise indicated.

The illustrations and screens shown in the manual are for explanation

purposes and may vary from the actual screens on your TV.


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30


MENU Exit

Sound Mode

Bass

Treble

Balance

Surround

Digital Output

Audio Language

Setup Channel

Custom

AVC

Audio

O

English

RA W

O

Select

Move

MENU Exit

Time

Closed Caption

Menu Settings

VGA Settings

Input Label

Restore Default

Audio Only

Audio Channel

Parental Controls

O

SetupPicture

Select

Move

Select

Move MENU Exit

Auto Scan

Favorites

Show/Hide

Channel No.

Channel Label

DTV Signal:

Audio

TV Source

SetupPicture

Antenna

Channel

2.1

Normal

WGBH-SD

DX-32L151A11-37L130A11_10-0567.book Page 13 Tuesday, June 1, 2010 9:26 AM

14 Adjusting the pictureDX-32L151A11/DX-37L130A11

Navigating the menus

Adjusting basic settings

To adjust basic settings:

1Press MENU. The Picture menu opens.

2Press or to highlight Setup, then press . The Setup menu

opens.

3Press or to highlight an option, then press ENTER to enter

the sub-menu. You can select:

•Parental Controls—Control which programs/movies your

children can watch, based on industry ratings.

•Time—Set the clock and sleep timer.

•Closed Caption—Turn closed captioning on or off. Also lets

you set closed caption options.

•Menu Settings—Set menu language and menu

transparency.

•VGA Settings—Lets you adjust picture settings to optimize

a computer display. (This menu becomes available only

when a computer display is connected to the television.)

•Input Label—Create a unique name for a device connected

to your TV’s input jacks.

•Restore Default—Reset most TV settings for the current

source to factory default values.

•Audio Only—Turn off the TV picture and listen to audio

only.

4Press MENU to return to the previous menu, or press EXIT to

close the menu.

Adjusting the picture

Adjusting the TV picture

To adjust the picture:

1Press MENU. The on-screen menu opens with the Picture menu

displayed.

2Press or to highlight an option, then press or to adjust

the option. You can select:

•Picture Mode—Selects the picture mode. You can select:

•Vivid (a bright and vivid picture)

•Standard (a standard picture)

•Sports (a dynamic picture)

•Theater (a finely detailed picture)

•Energy Saving (the backlight brightness is decreased)

•Custom (customized picture).

Note: You can also press PICTURE on the remote control to

select the picture mode.

•Contrast—Adjusts the contrast.

•Brightness—Adjusts the brightness.

•Color—Adjusts the color saturation.

•Tint—Adjusts the image tint.

•Sharpness—Adjusts the sharpness.

•Backlight—Adjusts the screen backlight.

3Press or to highlight Advanced Video, then press ENTER

to enter the sub-menu.

Press to display the Main menu.

Press to select menus, to adjust selected

items, or move on-screen cursor left or right.

Press to select the menu items.

Press to confirm your selection or enter a

sub-menu.

Press to return to the previous screen.

Press to close the menu.


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

MENU Exit

Time

Closed Caption

Menu Settings

VGA Settings

Input Label

Restore Default

Audio Only

Audio Channel

Parental Controls

O

SetupPicture

Select

Move


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

DX-32L151A11-37L130A11_10-0567.book Page 14 Tuesday, June 1, 2010 9:26 AM

Adjusting the sound 15

DX-32L151A11/DX-37L130A11

4Press or to highlight an option, then press or to adjust

the option. You can select:

•Color Temperature—Selects the color temperature. You

can select Warm (to enhance the reds), Cool (to enhance

the blues), or Normal.

•Zoom Mode— Selects the aspect ratio of the picture. You

can select:

•Auto (selects the correct aspect ratio automatically.

Available only when Auto Zoom is turned ON).

•Normal (selects the correct aspect ratio to match the

source image).

•Wide (shows a full-screen picture).

•Zoom (enlarges the picture but may crop the top and

bottom).

•Cinema (stretches the picture at the edges, but

maintains a good aspect ratio at the center of the

screen).

Notes:

• The above aspect ratios are all available only when Overscan is

turned ON when watching a digital program.

• You can also press ZOOM on the remote control to select the aspect

ratio of the picture.

•Noise Reduction—Selects the noise reduction mode to

reduce picture noise (snow). You can select Weak, Middle,

Strong, or Off.

•Overscan—Turn this On to adjust the picture’s

reproduction rate.

•Adaptive Contrast—Turn this On to optimize the picture

display for a more vivid image.

•DCR—Turn this On to activate the Dynamic Backlight

Control function. Depending on the signal, the TV

automatically adjusts the backlight level, which affects the

overall brilliance of the picture.

•Auto Zoom—In TV mode, setting Auto Zoom to On lets you

set the Zoom Mode to Auto.

5Press MENU to return to the previous menu, or press EXIT to

close the menu.

Adjusting the computer image

To adjust the computer image:

1Make sure that your TV is in VGA mode. For more information, see

“Selecting the video input source” on page 12.

2Press MENU. The on-screen menu opens.

3Press or to highlight Setup, then press . The Setup menu

opens.

4Press or to highlight VGA Settings, then press ENTER. The

VGA settings menu opens.

5Press or to highlight an option, then press or to adjust

the option. You can adjust:

•H-Position—Moves the image right or left

•V-Position—Moves the image up or down

•Clock—Adjusts the sample frequency

•Phase—Adjusts the focus of stable images

•Auto—Automatically adjusts the image settings such as

position and phase

6Press MENU to return to the previous menu, or press EXIT to

close the menu.

Adjusting the sound

To adjust the sound:

1Press MENU. The on-screen menu opens.


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

MENU Exit

Time

Closed Caption

Menu Settings

Input Label

Restore Default

Audio Only

Audio Channel

Parental Controls

O

SetupPicture

Select

Move

VGA Settings

Move MENU Exit

V . Position

Clock

Phase

Audio Channel

H . Position

SetupPicture

Auto

Select


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

DX-32L151A11-37L130A11_10-0567.book Page 15 Tuesday, June 1, 2010 9:26 AM

16 Adjusting the soundDX-32L151A11/DX-37L130A11

2Press or to highlight Audio, then press . The Audio menu

opens.

3Press or to highlight an option, then press or to adjust

the option. You can select:

•Sound Mode—Selects the sound mode. You can select:

•Standard (for normal programs)

•News (for news programs)

•Music (for musical programs)

•Movie (for movies)

•Custom (for a customized sound mode).

Note: You can also press AUDIO one or more times to select the

sound mode.

•Bass—Adjusts the low sounds.

•Treble—Adjusts the high sounds.

•Balance—Adjusts the balance between the left and right

audio channels.

•Surround—Turns the surround sound effect on or off.

•AVC—(Auto volume control) Equalizes the overall volume

levels for all channels.

•Digital Output—(digital channels only) Selects the digital

audio output mode. You can select RAW (outputs audio in its

original format) or PCM (outputs the audio in PCM mode, if

available).

•Audio Language—(digital channels only) Selects an

alternate audio language, if available.

4Press MENU to return to the previous menu, or press EXIT to

close the menu.

Selecting the audio mode

You can select the audio mode for analog channels.

To select the audio mode for analog channels:

• Press MTS/SAP on the remote one or more times. You can select:

•MONO—Select this option if there is noise or static on weak

stereo broadcasts.

•STEREO—Select this option for programs broadcast in

stereo.

•SAP—Select this option to listen to a secondary audio

program, if available.

Note: Mono is automatically selected if the program is broadcast in

mono.

To select an audio track for a digital channel:

• Press MTS/SAP. The audio track plays if one is available.

Playing TV audio only

You can turn off the picture on your TV and listen to only the program

audio.

To play only the TV audio:

1Press MENU. The on-screen menu opens.

2Press or to highlight Setup, then press . The Setup menu

opens.

3Press or to highlight Audio Only, then press or to

select On.

4Press EXIT to close the menu. After pressing EXIT, the picture will

turn off in approximately 5 to 10 seconds.

Notes:

Audio Only works only when the input source is TV and your TV is receiving

a broadcast signal.

To exit Audio Only mode, press any button. When you exit Audio Only

mode, the Audio Only option is automatically reset to Off.


MENU Exit

Sound Mode

Bass

Treble

Balance

Surround

Digital Output

Audio Language

Setup Channel

Custom

AVC

Audio

O

English

RA W

O

Select

Move


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

MENU Exit

Time

Closed Caption

Menu Settings

Input Label

Restore Default

Audio Channel

Parental Controls

SetupPicture

Select

Move

VGA Settings

Audio Only On

DX-32L151A11-37L130A11_10-0567.book Page 16 Tuesday, June 1, 2010 9:26 AM

Changing channel settings 17

DX-32L151A11/DX-37L130A11

Changing channel settings

Automatically scanning for channels

To auto scan for channels:

1Press MENU. The on-screen menu opens.

2Press or to highlight Channel, then press . The Channel

menu opens.

3Press or to select Antenna or Cable, depending on your

setup.

4Press or to highlight Auto Scan, then press ENTER. A

confirmation box opens.

5Press or to select Yes, then press ENTER to start the scan. A

progress box shows the progress of the scan.

Selecting the signal source

To select the signal source:

1Press MENU. The on-screen menu opens.

2Press or to highlight Channel, then press . The Channel

menu opens.

3Press or to select Antenna, Cable, or Cable/Satellite

Box.

4Press EXIT to close the menu.

Hiding channels

You can delete channels from the channel list so that your TV skips the

channels when you press CH /CH . You can still tune to the hidden

channel by using the number buttons.

To hide a channel:

1Press MENU. The on-screen menu opens.


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

Select

Move MENU Exit

Auto Scan

Favorites

Show/Hide

Channel No.

Channel Label

DTV Signal:

Audio SetupPicture Channel

2.1

Normal

WGBH-SD

TV Source Antenna

Press ”ENTER” Key to Select


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

Select

Move MENU Exit

Auto Scan

Favorites

Show/Hide

Channel No.

Channel Label

DTV Signal:

Audio SetupPicture Channel

2.1

Normal

WGBH-SD

TV Source Antenna


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

DX-32L151A11-37L130A11_10-0567.book Page 17 Tuesday, June 1, 2010 9:26 AM

18 Changing channel settingsDX-32L151A11/DX-37L130A11

2Press or to highlight Channel, then press . The Channel

menu opens.

3Press or to highlight Show/Hide, then press ENTER. The

channel list opens.

4Press or to highlight the channel you want to hide (the

default is to show the channel), then press ENTER to remove the

check mark from the channel.

Note: If the list has more than one page, press or to scroll through

the pages.

5Press EXIT to close the menu.

Setting up a favorite channel list

You can create a favorite channel list so you can quickly browse through

your favorite channels by pressing FAVORITE, then selecting a channel

from the favorite channel list.

To set up the favorite channel list:

1Press MENU. The on-screen menu opens.

2Press or to highlight Channel, then press . The Channel

menu opens.

3Select the signal source of the channel you want to set up on the

favorites list.

4Press or to highlight Favorites, then press ENTER. The

favorite channel list opens.

5Press or to highlight the channel you want to add to the

favorite list, then press ENTER to mark the channel. A check mark

appears if the channel is added to the list. The check mark

disappears if you delete the channel from the list.

Note: If the list has more than one page, press or to scroll through

the pages.

6Press EXIT to close the menu.

7To select a channel in the favorite channel list, press FAVORITE,

press or to highlight the channel, then press ENTER.

Adding or changing a channel label

If a channel is not already labeled, you can label the channel to make it

easier to identify. You can also relabel a channel that is already labeled.

To label a channel:

1Press MENU. The Picture menu opens.

Select

Move MENU Exit

Auto Scan

F avo ritese

Channel No.

Channel Label

DTV Signal:

Audio SetupPicture Channel

2.1

Normal

WGBH-SD

TV Source Antenna

Show/Hide


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

Select

Move MENU Exit

Auto Scan

Channel No.

Channel Label

DTV Signal:

Audio SetupPicture Channel

2.1

Normal

WGBH-SD

TV Source Antenna

Show/Hide

Favorites


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

DX-32L151A11-37L130A11_10-0567.book Page 18 Tuesday, June 1, 2010 9:26 AM

Setting parental controls 19

DX-32L151A11/DX-37L130A11

2Press or to highlight Channel, then press . The Channel

menu opens.

3Select the signal source of the channel you want to label.

4Press or to highlight Channel No., then press or to

select the channel you want to label.

5Press or to highlight Channel Label, then press ENTER.

The Channel Label screen opens.

6Press or to select a character, then press or to move to

the next position. Repeat to add more characters.

7Press MENU to exit to the previous menu.

Checking digital TV signal strength

You can check the signal strength of digital channels to determine if you

need to adjust your antenna or digital cable input. The higher the signal

strength, the less likely you are to experience picture degradation.

To check signal strength:

1Press MENU. The on-screen menu opens.

2Press or to highlight Channel, then press . The Channel

menu opens. The DTV signal strength is shown at the bottom of

the menu.

3Press EXIT to close the menu.

Setting parental controls

Parental controls let you prevent your children from watching

inappropriate material on TV. When set, parental controls read the

rating of the program (with some exceptions, such as news and sports)

and deny access to programs that exceed the ratings level you select. To

watch programs that exceed the selected rating, you must enter a

password.

Turning parental controls on or off

To turn parental controls on or off:

1Press MENU. The on-screen menu opens.

2Press or to highlight Setup, then press . The Setup menu

opens.

Select

Move MENU Exit

Auto Scan

Channel No.

DTV Signal:

Audio SetupPicture Channel

2.1

Normal

TV Source Antenna

Show/Hide

Favorites

Channel Label WGBH-SD

Select

Move MENU Exit

Audio SetupPicture Channel

ABCದ


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

Select

Move MENU Exit

Auto Scan

Favorites

Show/Hide

Channel No.

Channel Label

DTV Signal:

Audio

TV Source

SetupPicture

Antenna

Channel

2.1

Normal

WGBH-SD


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

MENU Exit

Time

Closed Caption

Menu Settings

Input Label

Restore Default

Audio Only

Audio Channel

O

SetupPicture

Select

Move

VGA Settings

Parental Controls

DX-32L151A11-37L130A11_10-0567.book Page 19 Tuesday, June 1, 2010 9:26 AM

20 Setting parental controlsDX-32L151A11/DX-37L130A11

3Press ENTER. The Enter Password screen opens.

4Press the number buttons to enter the four-digit password. The

default password is 0000. The Parental Controls sub-menu opens.

5Press or to highlight System Lock, then press or to

select On (to enable the blocking scheme you set up and to set

up the blocking scheme (otherwise the rating setting cannot be

accessed) or Off (to disable the blocking scheme you set up).

6Press EXIT to close the menu.

Setting or changing the password

To set the parental password:

1Press MENU. The on-screen menu opens.

2Press or to highlight Setup, then press . The Setup menu

opens.

3Press ENTER. The Enter Password screen opens.

4Press the number buttons to enter the four-digit password. The

default password is 0000. The Parental Controls sub-menu opens.

5Press or to highlight Change Password, then press

ENTER. The password entry screen opens.

6Press the number buttons to input old password, then input a

new password. On the next line, enter the new password again to

confirm it. The Parental Controls sub-menu reopens.

Note: If you forget your password, enter 9999.

7Press EXIT to close the menu.

Turning the button lock on or off

To turn the parental controls button lock on or off:

1Press MENU. The on-screen menu opens.

Audio Channel

Enter Password _ _ _ _

SetupPicture


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

MENU Exit

Time

Closed Caption

Menu Settings

Input Label

Restore Default

Audio Only

Audio Channel

O

SetupPicture

Select

Move

VGA Settings

Parental Controls

Audio Channel

Enter Password _ _ _ _

SetupPicture

Select

Move MENU Exit

Audio Channel

Enter Old Password _ _ _ _

SetupPicture

Enter New Password

Conrm Password

_ _ _ _


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

DX-32L151A11-37L130A11_10-0567.book Page 20 Tuesday, June 1, 2010 9:26 AM

Setting parental controls 21

DX-32L151A11/DX-37L130A11

2Press or to highlight Setup, then press . The Setup menu

opens.

3Press ENTER. The Enter Password screen opens.

4Press the number buttons to enter your four-digit password. The

Parental Controls sub-menu opens.

5Press or to highlight Button Lock, then press or to

select ON (to turn the Button Lock on) or OFF (to turn the Button

Lock off).

6Press EXIT to close the menu.

With the Button Lock on, the buttons on the TV control panel are locked.

The message “Use remote to enable button” will appear every time you

press a button on the TV control panel. Unplug your TV, then reconnect

it to turn the Button Lock off.

Setting parental control levels

You can set parental controls for the U.S. and Canada. The following

procedure shows how to set controls for U.S. TV ratings. You use similar

steps for controlling U.S. movie and Canadian TV ratings.

To set parental controls:

1Press MENU. The on-screen menu opens.

2Press or to highlight Setup, then press . The Setup menu

opens.

3Press ENTER. The Enter Password screen opens.

4Press the number buttons to enter your four-digit password. The

Parental Controls sub-menu opens.

MENU Exit

Time

Closed Caption

Menu Settings

Input Label

Restore Default

Audio Only

Audio Channel

O

SetupPicture

Select

Move

VGA Settings

Parental Controls

Audio Channel

Enter Password _ _ _ _

SetupPicture


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

MENU Exit

Time

Closed Caption

Menu Settings

Input Label

Restore Default

Audio Only

Audio Channel

O

SetupPicture

Select

Move

VGA Settings

Parental Controls

Audio Channel

Enter Password _ _ _ _

SetupPicture

DX-32L151A11-37L130A11_10-0567.book Page 21 Tuesday, June 1, 2010 9:26 AM

22 Setting parental controlsDX-32L151A11/DX-37L130A11

5Press or to highlight System Lock, then press or to

select On.

6Press or to highlight US, then press ENTER. The US Settings

sub-menu opens.

Note: Select Canada to set Canadian TV controls.

7Press or to highlight TV, then press ENTER. The US TV

RATING sub-menu opens.

Note: You can also select MPAA to set controls for US movie ratings.

8Press or to highlight the rating you want to block,

then press ENTER. A lock symbol appears when a rating is

blocked.

Note: On the MPAA RATING screen, press or to select the rating. That

rating and all other higher ratings are blocked.

9Press EXIT to close the menu.

MPAA

Audio Channel SetupPicture

Select

Move Exit

Select

Move MENU Exit

Audio Channel SetupPicture

: Block Press ENTER to Block or Unblock

U.S. TV ratings (age-based)

TV-Y All children.

TV-Y7 Suitable for children 7 and older.

TV-G General audiences.

TV-PG Parental guidance suggested.

TV-14 Parental guidance strongly suggested.

TV-MA Mature audiences only.

U. S. TV ratings (content-based)

FV Fantasy violence.

VViolence.

S Sexual situations.

L Strong language.

DSuggestive dialog.

U.S. movie (MPAA) ratings

G General audiences.

PG Parental guidance suggested.

PG-13 Suitable for children 13 and older.

R Parental guidance suggested for children

under 17.

NC-17 Not suitable for children under 17.

XAdults only.

N/A Movie is not rated.

Canadian English ratings

C Suitable for all children.

C8+ Suitable for children 8 and older.

G General audiences.

PG Parental guidance suggested.

14+ Suitable for children 14 and older.

18+ Adults only.

EXEMPT Exempt programming.

Canadian French ratings

G General audiences.

8+ Suitable for children 8 and older.

13+ Suitable for children 13 and older.

16+ Suitable for children 16 and older.

18+ Adults only.

EXEMPT Exempt programming.

DX-32L151A11-37L130A11_10-0567.book Page 22 Tuesday, June 1, 2010 9:26 AM

Using closed captioning 23

DX-32L151A11/DX-37L130A11

Downloading rating information

You can download rating information to use when setting parental

controls.

To download rating information:

1Press MENU. The on-screen menu opens.

2Press or to highlight Setup, then press . The Setup menu

opens.

3Press ENTER. The Enter Password screen opens.

4Press the number buttons to enter your four-digit password. The

Parental Controls sub-menu opens.

5Press or to highlight System Lock, then press or to

select On.

6Press or to highlight RRT Setting, then press ENTER. If the

program is broadcast with RRT5 rating information, the

information is downloaded automatically and can be used for

parental controls.

Note: If you want to clear the downloaded rating information, select

Reset RRT. The rating information is cleared. If rating information is

broadcast by another program, your TV downloads the new

information.

Using closed captioning

Turning closed captioning on or off

To turn closed captioning on or off:

1Press MENU. The on-screen menu opens.

2Press or to highlight Setup, then press . The Setup menu

opens.

3Press or to highlight Closed Caption, then press or

ENTER. The closed caption menu opens.


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

MENU Exit

Time

Closed Caption

Menu Settings

Input Label

Restore Default

Audio Only

Audio Channel

O

SetupPicture

Select

Move

VGA Settings

Parental Controls

Audio Channel

Enter Password _ _ _ _

SetupPicture


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

MENU Exit

Time

Menu Settings

Input Label

Restore Default

Audio Only

Audio Channel

O

SetupPicture

Select

Move

VGA Settings

Parental Controls

CaptionClosed

Select

Move MENU Exit

Basic Selection

Advanced Selection

Option

Audio Channel

CC Mode

Service1

SetupPicture

CC1

DX-32L151A11-37L130A11_10-0567.book Page 23 Tuesday, June 1, 2010 9:26 AM

24 Using closed captioningDX-32L151A11/DX-37L130A11

4Press or to highlight CC Mode, then press or to select

the CC mode. You can select On (turns on closed captioning),

CC on Mute (turns on closed captioning when the sound is

muted), or Off (turns off closed captioning).

5Press EXIT to close the menu.

Tip: You can also press CCD on the remote control to turn closed

captioning on or off.

Selecting the closed captioning mode

To select the closed captioning mode:

1Press MENU. The on-screen menu opens.

2Press or to highlight Setup, then press . The Setup menu

opens.

3Press or to highlight Closed Caption, then press or

ENTER. The closed caption menu opens.

4Press or to highlight CC Mode, then press or to select

On.

5Press or to highlight Basic Selection.

Note: If the channel is analog, the Basic Selection will be available and

the Advanced Selection will be grayed out (inactive).

6Press or to select a closed captioning mode. You can select:

•CC1 through CC4—Closed captioning appears in a small

banner across the bottom of the screen. CC1 is usually the

“printed” version of the audio. CC2 through CC4 display

content provided by the broadcaster.

•Text1 through Text4—Closed captioning that covers half

or all of the screen. Text1 through Text4 display content

provided by the broadcaster.

7Press EXIT to close the menu.

Customizing digital TV closed captioning

styles

To customize digital TV closed captioning:

1Press MENU. The on-screen menu opens.

2Press or to highlight Setup, then press . The Setup menu

opens.


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

MENU Exit

Time

Menu Settings

Input Label

Restore Default

Audio Only

Audio Channel

O

SetupPicture

Select

Move

VGA Settings

Parental Controls

CaptionClosed

Select

Move MENU Exit

Basic Selection

Advanced Selection

Option

Audio Channel

CC Mode

Service1

SetupPicture

CC1

Select

Move MENU Exit

Advanced Selection

Option

Audio Channel

CC Mode

Service1

SetupPicture

Basic Selection CC1


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

MENU Exit

Time

Menu Settings

Input Label

Restore Default

Audio Only

Audio Channel

O

SetupPicture

Select

Move

VGA Settings

Parental Controls

CaptionClosed

DX-32L151A11-37L130A11_10-0567.book Page 24 Tuesday, June 1, 2010 9:26 AM

Adjusting time settings 25

DX-32L151A11/DX-37L130A11

3Press or to highlight Closed Caption, then press or

ENTER. The closed caption menu opens.

4Press or to highlight CC Mode, then press or to select

On.

5Press or to highlight Advanced Selection (only available

for digital stations), then press or to select an advanced

digital closed captioning option. You can select Service1 -

Service6 (displays content provided by the broadcaster).

6Press or to highlight Option, then press ENTER. The DTV

closed captioning styles menu opens.

7Press or to highlight Mode, then press or to select

Custom.

Note: To reset the closed captioning styles to their defaults, set Mode to

Default.

8Press or to highlight a style, then press or to adjust

the style. You can select:

•Font Style—To select a style for the words.

•Font Size—To select a edge style for the words.

•Font Edge Style—To select a size for the words.

•Font Edge Color—To select a color for the edges.

•FG Color—To select a color for the text.

•BG Color—To select a color for the background.

•FG Opacity—To select the opacity for the text.

•BG Opacity—To select the opacity for the background.

9Press MENU to return to the previous menu, or press EXIT to

close the menu.

Adjusting time settings

Setting the date and time

To set the date and time:

1Press MENU. The on-screen menu opens.

2Press or to highlight Setup, then press . The Setup menu

opens.

3Press or to highlight Time, then press ENTER. The time

setting menu opens.

4Press or to highlight Time Zone, then press or to

select your time zone. You can select Pacific, Alaska, Hawaii,

Atlantic, Eastern, Central, or Mountain.

Select

Move MENU Exit

Basic Selection

Advanced Selection

Option

Audio Channel

CC Mode

Service1

SetupPicture

CC1

Select

Move MENU Exit

Basic Selection

Option

Audio Channel

CC Mode

SetupPicture

CC1

Advanced Selection

Service1

Select

Move MENU Exit

Font Edge Style

Font Edge Color

FG Color

BG Color

FG Opacity

BG Opacity

Audio Channel

Mode

Font Style

Font Size

SetupPicture

Default


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

MENU Exit

Closed Caption

Menu Settings

Input Label

Restore Default

Audio Only

Audio Channel

O

SetupPicture

Select

Move

VGA Settings

Parental Controls

Time

DX-32L151A11-37L130A11_10-0567.book Page 25 Tuesday, June 1, 2010 9:26 AM

26 Adjusting menu settingsDX-32L151A11/DX-37L130A11

5If your viewing area observes daylight savings time, press or

to highlight DST, then press or to select On.

6Press or to highlight Mode, then press or to select

Manual (to set the date/time manually), or Auto (the date/time

are automatically set by the TV signal source, based on the time

zone you selected).

7If you select Manual mode, make the settings as follows:

• Press or to highlight Year, Month, or Day, then press

or to adjust the setting.

• Set the time by pressing or to highlight Time, then

press or to highlight the hour, minute, or AM/PM field.

Press or to adjust the setting.

8Press EXIT to close the menu.

Setting the sleep timer

You can specify the amount of time before your TV automatically turns

off.

To set the sleep timer:

1Press MENU. The on-screen menu opens.

2Press or to highlight Setup, then press . The Setup menu

opens.

3Press or to highlight Time, then press ENTER. The time

setting menu opens.

4Press or to highlight Sleep Timer, then press or to

select the amount of time you want your TV to wait before it

automatically turns off.

Note: To turn off the sleep timer, select Off.

5Press EXIT to close the menu.

Note: You can also press SLEEP on the remote control to set the sleep

timer.

Adjusting menu settings

Selecting the menu language and

transparency

To select the on-screen menu language and menu transparency:

1Press MENU. The on-screen menu opens.

2Press or to highlight Setup, then press . The Setup menu

opens.

3Press or to highlight Menu Settings, then press ENTER.

The Menu Settings menu opens.


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

MENU Exit

Closed Caption

Menu Settings

Input Label

Restore Default

Audio Only

Audio Channel

O

SetupPicture

Select

Move

VGA Settings

Parental Controls

Time


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

Select

Move MENU Exit

Menu Language

Audio Channel

Transparency

SetupPicture

25%

English

DX-32L151A11-37L130A11_10-0567.book Page 26 Tuesday, June 1, 2010 9:26 AM

Adjusting menu settings 27

DX-32L151A11/DX-37L130A11

4Press or to highlight Menu Language, then press or

to select the menu language you want. Options include English,

French, and Spanish.

5Press or to select Transparency, then press or to

select the menu transparency you want. Options include 0%,

25%, 50%, 75%, and 100%.

6Press EXIT to close the menu.

Labeling an input source

You can add a label to an input source to make it easier to identify.

To label an input source:

1Press MENU. The on-screen menu opens.

2Press or to highlight Setup, then press . The Setup menu

opens.

3Press or to highlight Input Label, then press ENTER. The

Input Label screen opens.

4Press or to highlight a preset label from several options, or

select Custom to enter your own label.

5If you select Custom, press or to highlight Custom Label,

then press .

6Press or to select a character, then press or to move to

the next position. Repeat this step to add more characters.

7To reset the label to factory default, press or to highlight

Reset Label then press ENTER. Follow the on-screen

instructions.

8Press EXIT to close the menu. The next time you press the INPUT

button on the remote control, you will see your new label in the

INPUT SOURCE menu.

Restoring default settings

Caution: When you restore default settings, all the settings (except the

password and parental rating) you have customized are reset.

To restore default settings:

1Press MENU. The on-screen menu opens.

2Press or to highlight Setup, then press . The Setup menu

opens.

3Press or to highlight Restore Default, then press ENTER.

A confirmation box opens.

4Press or to select Yes, then press ENTER.

5Press EXIT to close the menu.


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

MENU Exit

Closed Caption

Menu Settings

Restore Default

Audio Only

Audio Channel

O

SetupPicture

Select

Move

VGA Settings

Parental Controls

Time

Input Label

Reset Label

Present Label

Select

Move MENU Exit

Audio Channel SetupPicture

Custom

Custom Label T V


Select

Move MENU Exit

Picture Mode

Contrast

Brightness

Color

Tint

Advanced Video

Audio Setup Channel

Custom

Sharpness 50

Backlight 30

MENU Exit

Closed Caption

Menu Settings

Input Label

Audio Only

Audio Channel

O

SetupPicture

Select

Move

VGA Settings

Parental Controls

Time

Restore Default

DX-32L151A11-37L130A11_10-0567.book Page 27 Tuesday, June 1, 2010 9:26 AM

28 TroubleshootingDX-32L151A11/DX-37L130A11

Troubleshooting

Before calling for service, check the following information for possible

solutions to problems you may experience. If none of these solutions

work, turn off the TV, then turn it on again.

Caution: Do not try to repair the TV yourself. Refer all servicing to

qualified repair personnel.

Video and audio

Remote control

General

Problem Solution

No picture (screen is not lit)

and no sound.

• Make sure that the power cord is

plugged in.

• Press POWER on the TV or the

remote control.

• Make sure that the correct video

input source is selected. For more

information, see “Selecting the

video input source” on page 12.

• Try another channel. The station

may be experiencing problems.

Dark, poor, or no picture

(screen is lit), but sound is

good.

•Adjust the brightness. For more

information, see “Adjusting the

TV picture” on page 14.

• Make sure that the correct picture

mode is selected. For more

information, see “Adjusting the

TV picture” on page 14.

• Make sure that the antenna or

cable TV is connected correctly

and securely. For more

information, see “Connecting an

antenna, cable TV, or satellite TV

box” on page 9.

No color, dark picture, or

color is not correct.

• Adjust the color saturation. For

more information, see “Adjusting

the TV picture” on page 14.

Only snow (noise) appears

on the screen.

• Try another channel. The station

may be experiencing problems.

• Make sure that the antenna or

cable TV is connected correctly

and securely. For more

information, see “Connecting an

antenna, cable TV, or satellite TV

box” on page 9.

• Check the signal strength. See

“Checking digital TV signal

strength” on page 19.

Dotted lines or stripes

appear on the screen.

• Adjust the antenna.

• Move the TV away from noise

sources such as cars, neon signs,

or hair dryers.

Double images. • Use a highly directional outdoor

antenna or cable TV.

The picture has a few bright

or dark spots.

• A few bright or dark spots on an

LCD screen is normal. It does not

affect the operation of this TV.

Good picture, but no

sound.

• Make sure that the sound is not

muted.

• Make sure that the sound mode is

set to Stereo or Mono. For more

information, see “Selecting the

audio mode” on page 16.

Audio noise. • Make sure that there is no

interference with infrared

equipment such as a cordless

telephone or headphones. Move

the infrared equipment away

from the TV to eliminate the

noise.

Problem Solution

Remote control does not

work.

• Make sure that the power cord is

plugged in.

• Make sure that there are no

obstructions between the remote

control and the remote control

sensor on the front of the TV.

• Make sure that the batteries are

installed correctly. For more

information, see “Installing

remote control batteries” on

page 7.

• Replace the batteries. For more

information, see “Installing

remote control batteries” on

page 7.

Trouble programming your

existing universal remote

control.

• See instructions and a table of

common codes in “Programming

a universal remote control to

work with your TV” on page 8.

• Codes are subject to change. For

up to date codes, go to

www.dynexproducts.com.

• Replace the batteries. For more

information, see “Installing

remote control batteries” on

page 7.

• Refer to the User Guide that

accompanied your universal

remote control and contact the

manufacturer if problems persist.

Problem Solution

One or more channels do

not display.

• Make sure that the channels are

not blocked. For more

information, see “Setting parental

control levels” on page 21.

• Make sure that the channels are

not hidden. For more information,

see “Hiding channels” on page 17.

• The channel may have been

deleted from the channel list. You

can tune to the channel by

pressing the number buttons or

you can add the channel back to

the channel list. For more

information, see “Changing

channel settings” on page 17.

Password is lost. • Enter 9999 to access parental

controls, then set a new

password. For more information,

see “Setting parental controls” on

page 19.

Some settings cannot be

accessed.

• If a setting is grayed, the setting is

not available in the current video

input mode.

TV cabinet creaks. • When the TV is in use, the

temperature rises naturally and

may cause the cabinet to expand

or contract which can cause a

creaking noise. This is not a

malfunction.

Control buttons on the TV

do not work.

• Disconnect the power cord, wait a

few seconds, then reconnect the

power cord and turn on the TV.

DX-32L151A11-37L130A11_10-0567.book Page 28 Tuesday, June 1, 2010 9:26 AM

Maintenance 29

DX-32L151A11/DX-37L130A11

Note: If the problem is not solved by using these troubleshooting

instructions, try turning off your TV, then turning it on again.

Maintenance

Cleaning

• Clean your TV with a soft, dry cloth. If surfaces are extremely

dirty, use a soft cloth dampened with a weak detergent solution.

• Use an eyeglass cleaner to clean the screen. Never use alcohol,

paint thinner, or benzine.

• Before using a chemically treated cloth, read the instructions that

came with the cloth.

Specifications

Specifications subject to change without notice.

Weight and dimensions shown are approximate.

Legal notices

FCC Part 15

This device complies with Part 15 of the FCC Rules. Operation of this

product is subject to the following two conditions: (1) this device may

not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired

operation.

This equipment has been tested and found to comply within the limits

for a class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee

that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or

more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced technician for help.

FCC warning

Changes or modifications not expressly approved by the party

responsible for compliance with the FCC Rules could void the user’s

authority to operate this equipment.

Cables

Connections to this device must be made with shielded cables with

metallic RF/EMI connector hoods to maintain compliance with FCC

Rules and Regulations.

Canada ICES-003 statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numerique de la classe B est conforme a la norme NMB-003

du Canada.

Standard Television Receiving Apparatus — Appareil de réception

télévision ordinaire, Canada BETS-7 / NTMR-7

HDMI

HDMI, the HDMI logo, and High-Definition Multimedia Interface are

trademarks or registered trademarks of HDMI Licensing LCC.

TV type LCD

TV panel 32-inch TFT LCD (DX-32L151A11)

37-inch TFT LCD (DX-37L130A11)

TV system NTSC-M, ATSC

Receiving channels VHF: 2 - 13

UHF: 14 - 69

CATV: 1 - 125

CADTV: 1-135

DTV: 2-69

Audio multiples BTSC system

Audio out 8W x 2 (32”)

10 W x 2 (37”)

Power requirement AC 120 V, 60 Hz

Power consumption 98 W (32”)

145 W (37”)

Dimensions

(W×H×D with stand)

30.55 × 21.5 × 10.4 inches

(776 × 546 × 255 mm) - 32”

35.4 × 24.8 × 11 inches

(899 × 631 × 280 mm) - 37”

Weight 25.35 lbs. (11.5 kg) - 32”

36.15 lbs. (16.4 kg) - 37”

Input terminals Composite video/L and R audio (1)

Component video/L and R audio (1)

HDMI (2)

VGA/audio (1)

Antenna (1)

Output terminals Audio left and right (1)

Digital optical (1)

Headphone (1)

Control terminals SERVICE PORT (1)

DX-32L151A11-37L130A11_10-0567.book Page 29 Tuesday, June 1, 2010 9:26 AM

30 Legal noticesDX-32L151A11/DX-37L130A11

DX-32L151A11-37L130A11_10-0567.book Page 30 Tuesday, June 1, 2010 9:26 AM

Legal notices 31

DX-32L151A11/DX-37L130A11

One-year limited warranty

US and Canada Markets

Definitions:

Dynex Products ("Dynex") warrants to you, the original purchaser of this new

Dynex-branded television ("Product"), that the Product shall be free of defects in the

original manufacturer of the material or workmanship for a period of one (1) year from

the date of your purchase of the Product ("Warranty Period"). For this warranty to apply,

your Product must be purchased in the United States or Canada from a Best Buy or

Future Shop authorized dealer of Dynex brand products only that are packaged with this

warranty statement.

How long does the coverage last?

The Warranty Period lasts for 1 year (365 days) from the date you purchased the

Product. Your purchase date is printed on the receipt you received with the Product.

What does this warranty cover?

During the Warranty Period, if the original manufacture of the material or workmanship

of the Product is determined to be defective by an authorized Dynex repair center or

store personnel, Dynex will (at its sole option): (1) repair the Product with new or

rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable

products or parts. Products and parts replaced under this warranty become the property

of Dynex and are not returned to you. If service of Products or parts are required after

the Warranty Period expires, you must pay all labor and parts charges. This warranty

lasts as long as you own your Dynex Product during the Warranty Period. Warranty

coverage terminates if you sell or otherwise transfer the Product.

How to obtain warranty service?

If you purchased the Product at a Best Buy or Future Shop retail store location and your

television Product has a screen size of less than 37 inches, please take your original

receipt and the Product to any Best Buy or Future Shop store. Make sure that you place

the Product in its original packaging or packaging that provides the same amount of

protection as the original packaging. If you purchased the Product from a Best Buy or

Future Shop online web site, mail your original receipt and the Product to the address

listed on the web site. Make sure that you put the Product in its original packaging or

packaging that provides the same amount of protection as the original packaging.

To obtain in-home warranty service for a television with a screen 37 inches or larger, in

the United States call 1-888-BESTBUY, Canada call 1-866-BESTBUY for Future Shop call

1-800-663-2275. Call agents will diagnose and correct the issue over the phone or will

have a Dynex-approved repair technician dispatched to your home.

Where is the warranty valid?

This warranty is valid only to the original purchaser of the product in the United States

and Canada at Best Buy or Future Shop branded retail stores or websites.

What does the warranty not cover?

This warranty does not cover:

• Customer instruction/education

•Installation

• Set up adjustments

• Cosmetic damage

• Damage due to acts of God, such as power surges

•Accident(s)

•Misuse

•Abuse

•Negligence

• Commercial purposes/use, including but not limited to use in a place of business

or in communal areas of a multiple dwelling condominium or apartment

complex, or otherwise used in a place of other than a private home.

• Modification of any part of the Product, including the antenna

• Plasma display panel damaged by static (non-moving) images applied for

lengthy periods (burn-in).

• Damage due to incorrect operation or maintenance

• Connection to an incorrect voltage or power supply

• Attempted repair by any person not authorized by Dynex to service the Product

• Products sold "as is" or "with all faults"

• Consumables, including but not limited to batteries (i.e. AA, AAA, C etc.)

• Products where the factory applied serial number has been altered or removed

• Loss or Theft of this product or any part of the product

REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE

REMEDY FOR BREACH OF WARRANTY. DYNEX SHALL NOT BE LIABLE FOR ANY INCIDENTAL

OR CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS OR IMPLIED

WARRANTY ON THIS PRODUCT, INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF

USE OF YOUR PRODUCT, LOST BUSINESS OR LOST PROFITS. DYNEX PRODUCTS MAKES NO

OTHER EXPRESS WARRANTIES WITH RESPECT TO THE PRODUCT, ALL EXPRESS AND

IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING, BUT NOT LIMITED TO, ANY

IMPLIED WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH

ABOVE AND NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THE

WARRANTY PERIOD. SOME STATES, PROVINCES AND JURISDICTIONS DO NOT ALLOW

LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION

MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU

MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE TO

PROVINCE.

Contact Dynex:

For customer service please call 1-800-305-2204

www.Dynexproducts.com

Distributed by Best Buy Purchasing, LLC

7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645

countries. All other products and brand names are trademarks of their respective

owners.

Mexico Market

{RETAILER SEAL}

PLACE STICKER OF PRODUCT MAKE & MODEL HERE

DATE OF PURCHASE:____________________________
