Model DC14

DYR-6300

Motor Carbon Brushes

VACUUM DC14 DYSON, INC

Diagram

Number Part # Description

STEEL DUCT LOWER MOTOR COVER ASSEMBLY

(STEEL/LAV/TRANS VIOLET (ANIMAL), STEEL/SCARLET

/TRANS VIOLET (LOW REACH) , STEEL/PURPLE

/SCARLET (FULL GEAR)

DARK STEEL DUCT LOWER MOTOR COVER ASSEMBLY

(STEEL/STEEL/TRANS VIOLET (COMPLETE)

INK BLUE LOWER MOTOR COVER ASSEMBLY

(STEEL/INK BLUE TRANS ORANGE (FULL ACCESS)

STEEL/LAVENDER U BEND ASSEMBLY (STEEL/LAV

/TRANS VIOLET (ANIMAL)

STEEL/PURPLE FLECK U BEND ASSEMBLY

(STEEL/PURPLE/SCARLET (FULL GEAR)

STEEL/STEEL U BEND ASSEMBLY (STEEL/STEEL/TRANS

VIOLET (COMPLETE)

STEEL/INK BLUE U BEND ASSEMBLY (STEEL/INK BLUE

TRANS ORANGE (FULL ACCESS)

1 DY-90865601

1A DY-90865602

1B DY-90865603

2 DY-90806201 SPADE CONNECTOR BOOT (QTY 5)

3 DY-90141701 TERMINAL BOOT

7 DY-90819401 INTERNAL POWER CORD

8 DY-90424306

8A DY-90424308

8B DY-90424313

8C DY-90424315

4 DY-90751701 GREY CABLE PROTECTOR

5 FA-3035 SILVER POWERCORD ASSEMBLY

STEEL /SCARLET U BEND ASSEMBLY (STEEL/SCARLET

TRANS VIOLET (LOW REACH)

11A 900049-06

LAVENDER GLAMOUR CAP (QTY 2) (STEEL/LAV/TRANS

VIOLET (ANIMAL)

SCARLET GLAMOUR CAP (QTY 2) (STEEL/SCARLET

TRANS VIOLET (LOW REACH), STEEL/PURPLE SCARLET

(FULL GEAR)

LIGHT STEEL GLAMOUR CAP (QTY 2) STEEL/STEEL

/TRANS VIOLET (COMPLETE)

INK BLUE GLAMOUR CAP (QTY 2) STEEL/INK BLUE

TRANS ORANGE (FULL ACCESS)

PURPLE FLECK REAR WHEEL (QTY 2) (STEEL /PURPLE

/SCARLET (FULL GEAR)

STEEL REAR WHEEL (QTY 2) (STEEL/LAV/TRANS

VIOLET (ANIMAL), STEEL/SCARLET/TRANS VIOLET (LOW

REACH), STEEL/INK BLUE TRANS ORANGE (FULL

ACCESS)

DARK STEEL REAR WHEEL (QTY 2) STEEL/STEEL

/TRANS VIOLET (COMPLETE)

STEEL PRE FILTER CATCH (STEEL/LAV/TRANS VIOLET

(ANIMAL), STEEL/SCARLET TRANS VIOLET (LOW

REACH)

DARK STEEL PRE FILTER CATCH (STEEL/STEEL/TRANS

VIOLET (COMPLETE)

INK BLUE PRE FILTER CATCH (STEEL/INK BLUE TRANS

ORANGE (FULL ACCESS)

PURPLE FLECK PRE FILTER CATCH (STEEL/PURPLE

/SCARLET (FULL GEAR)

PURPLE FLECK VALVE CARRIAGE (STEEL/PURPLE

/SCARLET (FULL GEAR)

STEEL VALVE CARRIAGE (STEEL/LAV/TRANS VIOLET

(ANIMAL), STEEL/SCARLET TRANS VIOLET (LOW

REACH)

LIGHT STEEL VALVE CARRIAGE (STEEL/STEEL/TRANS

VIOLET (COMPLETE)

INK BLUE VALVE CARRIAGE (STEEL/INK BLUE TRANS

ORANGE (FULL ACCESS)

8D DY-90424316

9 DY-90053401 WHEEL WASHE (QTY 2)

10 DY-90014601 WHEEL E CLIPS (QTY 2)

11 DY-90004901 YELLOW GLAMOUR CAP

11B DY-90004908

11C DY-90004913

11D DY-90004914

12 DY-90419306

12A DY-90419308

12B DY-90419311

13 DY-90027901 WHEEL AXLE

14 DY-90176904 BLACK BEARING CLIPS (QTY 2)

15 DY-90334605

15A DY-90334608

15B DY-90334610

15C DY-90334611

16 DY-90338001 PORT PLATE SEAL

17 DY-90122303 BLACK FORWARD LOCK

18 DY-90019989 PORT PLATE SPRING

19 DY-90027005 BLACK PORT PLATE

20 DY-90337802

20A DY-90337804

20B DY-90337807

20C DY-90337808

STEEL/LAVENDER VALVE PIPE ASSEMBLY (STEEL/LAV

/TRANS VIOLET (ANIMAL)

STEEL/PURPLE FLECK VALVE PIPE ASSEMBLY

(STEEL/PURPLE/SCARLET (FULL GEAR)

STEEL/STEEL VALVE PIPE ASSEMBLY (STEEL/STEEL

/TRANS VIOLET (COMPLETE)

STEEL/SCARLET VALVE PIPE ASSEMBLY

(STEEL/SCARLET TRANS VIOLET (LOW REACH)

STEEL/STEEL VALVE PIPE ASSEMBLY (STEEL/INK BLUE

TRANS ORANGE (FULL ACCESS)

STEEL CREVICE TOOL CLIP (STEEL/LAV/TRANS VIOLET

(ANIMAL), STEEL/SCARLET /TRANS VIOLET (LOW

REACH), STEEL/PURPLE/SCARLET (FULL GEAR)

DARK STEEL CREVICE TOOL CLIP (STEEL/STEEL

/TRANS VIOLET (COMPLETE)

INK BLUE CREVICE TOOL CLIP (STEEL/INK BLUE TRANS

ORANGE (FULL ACCESS)

STEEL SWITCH COVER ASSEMBLY (STEEL/LAV/TRANS

VIOLET (ANIMAL), STEEL/SCARLET TRANS VIOLET (LOW

REACH) , STEEL/PURPLE /SCARLET (FULL GEAR)

DARK STEEL SWITCH COVER ASSEMBLY (STEEL/STEEL

/TRANS VIOLET (COMPLETE)

INK BLUE SWITCH COVER ASSEMBLY (STEEL/INK BLUE

/TRANS ORANGE (FULL ACCESS)

TRANS ORANGE SWITCH BUTTON (STEEL/INK

BLUE/TRANS ORANGE (FULL ACCESS)

TRANS VIOLET SWITCH BUTTON (STEEL/LAV/TRANS

VIOLET (ANIMAL), STEEL/SCARLET TRANS VIOLET (LOW

REACH) , STEEL/PURPLE /SCARLET (FULL GEAR),

STEEL/STEEL/TRANS VIOLET (COMPLETE)

LAVENDER CLEANER HEAD PIVOT CIRCLIPS (QTY 2)

(STEEL/LAV/TRANS VIOLET (ANIMAL)

SCARLET CLEANER HEAD PIVOT CIRCLIPS (QTY 2)

(STEEL/SCARLET/TRANS VIOLET (LOW REACH),

STEEL/PURPLE /SCARLET (FULL GEAR)

STEEL CLEANER HEAD PIVOT CIRCLIPS (QTY 2)

STEEL/INK BLUE/TRANS ORANGE (FULL ACCESS),

STEEL/STEEL/TRANS VIOLET (COMPLETE)

STEEL BRUSH HOUSING ASSEMBLY (STEEL/INK BLUE

/TRANS ORANGE (FULL ACCESS)

LAVENDER BRUSH HOUSING ASSEMBLY (STEEL/LAV

/TRANS VIOLET (ANIMAL)

21 DY-90337601 VALVE CARRIAGE SEAL

22 DY-90424606

22A DY-90424608

22B DY-90424613

22C DY-90424615

22D DY-90424616

23 DY-90786001 ENTRY SEAL

24 DY-90776401

24A DY-90776402

24B DY-907764-03

25 DY-90749101 EXHAUST SEAL

26 DY-90776501

26A DY-90776502

26B DY-90776504

27 DY-90777602

27A DY-90777603

29 DY-90019926 UPRIGHT LOCK SPRING

30 DY-90882101 UPRIGHT LOCK

31 DY-90171605

31A DY-90171608

31B DY-90171613

32 DY-90865401

32A DY-90865402

28 SWITCH DYR-3400

DARK STEEL BRUSH HOUSING ASSEMBLY

(STEEL/STEEL/TRANS VIOLET (COMPLETE)

SCARLET BRUSH HOUSING ASSEMBLY

(STEEL/SCARLET/TRANS VIOLET (LOW REACH),

STEEL/STEEL/TRANS VIOLET (COMPLETE)

SCARLET OUTER CLUTCH ACTUATOR (STEEL/PURPLE

/SCARLET (FULL GEAR)

TRANS VIOLET OUTER CLUTCH ACTUATOR (STEEL/LAV

/TRANS VIOLET (ANIMAL), STEEL/SCARLET/TRANS

VIOLET (LOW REACH), STEEL/STEEL/TRANS VIOLET

(COMPLETE)

TRANS ORANGE OUTER CLUTCH ACTUATOR (STEEL/INK

BLUE /TRANS ORANGE (FULL ACCESS)

DARK STEEL CLEANER HEAD ASSEMBLY (STEEL/STEEL

/TRANS VIOLET (COMPLETE)

INK BLUE CLEANER HEAD ASSEMBLY (STEEL/INK BLUE

/TRANS ORANGE (FULL ACCESS)

STEEL CLEANER HEAD ASSEMBLY (STEEL/LAV/TRANS

VIOLET (ANIMAL), STEEL/SCARLET/TRANS VIOLET (LOW

REACH)

PURPLE FLECK CLEANER HEAD ASSEMBLY

(STEEL/PURPLE /SCARLET (FULL GEAR)

STEEL EXHAUST PIPE ASSEMBLY (STEEL/LAV/TRANS

VIOLET (ANIMAL), STEEL/SCARLET/TRANS VIOLET (LOW

REACH), STEEL/PURPLE/SCARLET (FULL GEAR)

32B DY-90865403

32C DY-90865404

35 DY-90029807

35A DY-90029810

35B DY-90029812

36 DY-90020006 TORX SCREWS (QTY 16)

38 DY-90865503 SILVER SOLEPLATE ASSEMBLY

39 DY-90410201 SOLEPLATE BRISTLES (QTY 2)

40 DY-90013004 STEEL SOLEPLATE FASTENERS (QTY 3)

41 DY-90013101 SOLEPLATE AXLE (QTY 5)

42 DY-90456201 SOLEPLATE WHEEL (QTY 5)

44 DY-90240506 BLACK CLUTCH COVER ASSEMBLY

46 DY-90231229

46A DY-90231231

46B DY-90231232

46C DY-90231233

46D DY-90231274 Cleaner Head Assy, (WHITE) (03/10/09)

47A DY-90418601 POST FILTER PAD

48 DY-90868201 HEPA FILTER SEAL

49 DY-90335101 TOP HOUSING MOUNT

50 DY-90334901 BLACK MOTOR HOUSING

52 DY-90414001 EXHAUST PIPE SEAL

53 DY-904242-04

34 CLUTCH TO MOTOR BELT DYR-1000

43 CLUTCH ASSEMBLY DYR-7500

45 INTERNAL HOSE ASSEMBLY DYR-7200

37 BRUSH BAR ASSEMBLY DYR-2000

47 HEPA POST FILTER DYR-1802

DARK STEEL EXHAUST PIPE ASSEMBLY (STEEL/STEEL

/TRANS VIOLET (COMPLETE)

INK BLUE EXHAUST PIPE ASSEMBLY (STEEL/INK BLUE /

TRANS ORANGE (FULL ACCESS)

STEEL MOTOR INLET COVER (STEEL/LAV/TRANS

VIOLET (ANIMAL),STEEL/SCARLET/TRANS VIOLET (LOW

REACH)

DARK STEEL MOTOR INLET COVER (STEEL/STEEL

/TRANS VIOLET (COMPLETE)

INK BLUE MOTOR INLET COVER (STEEL/INK

BLUE/TRANS ORANGE (FULL ACCESS)

PURPLE FLECK MOTOR INLET COVER (STEEL/PURPLE

/SCARLET (FULL GEAR)

STEEL UPPER MOTOR COVER (STEEL/LAV/TRANS

VIOLET (ANIMAL), STEEL/SCARLET/TRANS VIOLET (LOW

REACH)

DARK STEEL UPPER MOTOR COVER (STEEL/STEEL

/TRANS VIOLET (COMPLETE)

INK BLUE UPPER MOTOR COVER (STEEL/INK

BLUE/TRANS ORANGE (FULL ACCESS)

PURPLE FLECK UPPER MOTOR COVER (STEEL/PURPLE

/SCARLET (FULL GEAR)

STEEL POST FILTER LID (STEEL/LAV/TRANS VIOLET

(ANIMAL), STEEL/SCARLET/TRANS VIOLET (LOW

REACH)

DARK STEEL POST FILTER LID (STEEL/STEEL/TRANS

VIOLET (COMPLETE)

INK BLUE POST FILTER LID (STEEL/INK BLUE/TRANS

ORANGE (FULL ACCESS)

PURPLE FLECK POST FILTER LID (STEEL/PURPLE

/SCARLET(FULL GEAR)

STEEL/TRANS VIOLET CYCLONE ASSEMBLY

(STEEL/STEEL/TRANS VIOLET (COMPLETE)

53A DY-904242-06

53B DY-90424207

54 DY-90414101 EXHAUST PREFILTER SEAL

55 DY-90775001

55A DY-90775002

55B DY-90775004

55C DY-90775005

56 DY-90335801 FILTER SEAL

57 DY-90335901 SILVER MOTOR RETAINER

58 DY-90335201 PANASONIC FANCASE SEAL

60 DY-90400101 PANASONIC BEARING MOUNT

61 DY-90335001 MOTOR HOUSING MOUNT

62 DY-90774901

62A DY-90774902

62B DY-90774904

62C DY-90774905

63 DY-90413701 DIFFUSER

64 DY-90423801 MOTOR HOUSING ASSEMBLY

65 DY-90020004 DIFFUSER SCREW

66 DY-90775101

66A DY-90775102

66B DY-90775104

66C DY-90775105

67 DY-90540101 PRE-FILTER ASSEMBLY

68 DY-90865805

59 DYR-6000 MOTOR

SCARLET/TRANS VIOLET CYCLONE ASSEMBLY

(STEEL/SCARLET/TRANS VIOLET (LOW REACH),

STEEL/PURPLE/SCARLET(FULL GEAR)

STEEL/TRANS ORANGE CYCLONE ASSEMBLY

(STEEL/INK BLUE/TRANS ORANGE (FULL ACCESS)

LAVENDER /TRANS VIOLET CYCLONE ASSEMBLY

(STEEL/LAV/TRANS VIOLET (ANIMAL)

MINI TURBINE HEAD (STEEL/LAV/TRANS VIOLET

(ANIMAL), STEEL/PURPLE/SCARLET(FULL GEAR),

STEEL/STEEL/TRANS VIOLET (COMPLETE)

STEEL TUBE GRIP CLIP (STEEL/LAV/TRANS VIOLET

(ANIMAL), STEEL/SCARLET/TRANS VIOLET (LOW

REACH), STEEL/[PURPLE/SCARLET (FULL GEAR),

STEEL/STEEL/TRANS VIOLET (COMPLETE)

PURPLE TUBE GRIP CLIP (STEEL/PURPLE/SCARLET

(FULL GEAR)

STEEL/STEEL/HOSE ASSEMBLY (STEEL/STEEL/TRANS

VIOLET (COMPLETE)

STEEL/LAVENDER HOSE ASSEMBLY (STEEL/LAV/TRANS

VIOLET (ANIMAL)

STEEL/SCARLET HOSE ASSEMBLY (STEEL/SCARLET

/TRANS VIOLET (LOW REACH)

STEEL/INK BLUE HOSE ASSEMBLY (STEEL/INK BLUE

/TRANS ORANGE (FULL ACCESS)

STEEL/PURPLE FLECK HOSE ASSEMBLY

(STEEL/PURPLE/SCARLET (FULL GEAR)

STEEL/TRANS VIOLET /LAVENDER WAND

ASSEMBLY(STEEL/LAV/TRANS VIOLET (ANIMAL)

STEEL/STEEL/TRANS VIOLET WAND ASSEMBLY

(STEEL/STEEL/TRANS VIOLET (COMPLETE)

PURPLE/SCARLET/TRANS VIOLET WAND ASSEMBLY

(STEEL/PURPLE/SCARLET (FULL GEAR)

STEEL/TRANS VIOLET/SCARLET WAND ASSEMBLY

(STEEL/SCARLET/TRANS VIOLET (LOW REACH)

INK BLUE/TRANS ORANGE /STEEL WAND ASSEMBLY

(STEEL/INK BLUE/TRANS ORANGE (FULL ACCESS)

STEEL WAND CAP (STEEL/LAV/TRANS VIOLET (ANIMAL),

STEEL/SCARLET/TRANS VIOLET (LOW REACH),

STEEL/INK BLUE/TRANS ORANGE (FULL ACCESS),

68A DY-90865806

68B DY-90865807

68C DY-90865808

69 DY-90739901 FINE DUST COLLECTOR SEAL

70 DY-90865701 BIN ASSEMBLY

71 DY-90900101 BIN BASE ASSEMBLY

72 DY-90704903

74 DY-90776301 STEEL CREVICE TOOL

76 DY-90775606

76A DY-90775608

77A DY-90577701 HELPLINE STICKER

77 DY-90685101 HELPLINE STICKER

78 DY-90847401

78A DY-90847402

78B DY-90847405

78C DY-90847406

78D DY-90847407

79 DY-90866101

79A DY-90866102

79B DY-90866105

79C DY-90866106

79D DY-90866107

80 DY-90775406

75 DYR-5200 UPHOLSTERY TOOL

73 LARGE GREY BRUSH TOOL DYR-5300

STEEL/STEEL/TRANS VIOLET (COMPLETE)

PURPLE WAND CAP (STEEL/PURPLE/SCARLET (FULL

GEAR)

LAVENDER TUBE GRIP (STEEL/LAV/TRANS VIOLET

(ANIMAL) (as of 11/21/08)

SCARLET TUBE GRIP (STEEL/SCARLET/TRANS VIOLET

(LOW REACH), STEEL/PURPLE/SCARLET (FULL GEAR)

INK BLUE TUBE GRIP (STEEL/INK BLUE/TRANS ORANGE

(FULL ACCESS)

VIOLET TUBE GRIP (STEEL/STEEL/TRANS VIOLET

(COMPLETE)

STEEL ACCESSORY TOOL ADAPTOR (STEEL/INK

BLUE/TRANS ORANGE (FULL ACCESS), STEEL

STEEL/TRANS VIOLET (COMPLETE)

DUSTING BRUSH ASSEMBLY (STEEL/STEEL/TRANS

VIOLET (COMLETE)

MATTRESS TOOL ASSEMBLY (STEEL/STEEL/TRANS

VIOLET (COMLETE)

FLEXI CREVICE TOOL ASSEMBLY (STEEL/LAV/TRANS

VIOLET (ANIMAL)

INSTRUCTION PACK (STEEL/LAV/TRANS

VIOLET(ANIMAL), STEEL/SCARLET/TRANS VIOLET (LOW

REACH), STEEL/INK BLUE/TRANS ORANGE (FULL

ACCESS), (STEEL/STEEL/TRANS VIOLET (COMLETE)

INSTRUCTION PACK (STEEL/PURPLE/SCARLET (FULL

GEAR)

ANIMAL RETAIL BOX (STEEL/LAV/TRANS VIOLET

(ANIMAL)

LOW REACH RETAIL BOX (STEEL/SCARLET/TRANS

VIOLET (LOW REACH)

FULL GEAR RETAIL BOX (STEEL/PURPLE/SCARLET

(FULL GEAR)

FULL ACCESS RETAIL BOX (STEEL/INK BLUE /TRANS

ORANGE (FULL ACCESS)

COMPLETE RETAIL BOX (STEEL/STEEL/TRANS VIOLET

(COMLETE)

CLEANING KIT ASSEMBLY (STEEL/LAV/TRANS VIOLET

(ANIMAL), STEEL/PURPLE/SCARLET (FULL GEAR)

TRANS ORANGE/INK BLUE TURBO TOOL ASSEMBLY

(STEEL/INK BLUE /TRANS ORANGE (FULL ACCESS)

80A DY-90775409

81 DY-9077501

81B DY-90775503

81C DY-90775505

81A DY-90775508

82 DY-90703602

84 DY-90888701

85 DY-90702803

86 DY-90866201 INSTRUCTION PACK

86A DY-90866202

86B DY-908862-03

87 DY-90844805

87A DY-90844806

87B DY-90844807

87C DY-90844808

87D DY-90844809

88 DY-90836201 BOX INSERT (TOP)

89 DY-90880501 BOX INSERT (BOTTOM, UPPER)

90 DY-90880601 BOX INSERT (BOTTOM, LOWER)

91 DY-90593102 EDGEBOARD, WAND

92 DY-90865001 FORWARD LOCK INSERT (POLYSTYRENE)

93 DY-90430301 REAR WHEEL FASTENER RETAINING PACK

94 DY-90497503

95 DY-90656509

83 DYR-5300

PURPLE/SCARLET FT01.5 FLOOR TOOL (STEEL/PURPLE

/SCARLET (FULL GEAR)

STEEL/LAVENDER FT01.5 FLOOR TOOL (STEEL/LAV

/TRANS VIOLET (ANIMAL)

STEEL/SCARLET FT01.5 FLOOR TOOL (STEEL/SCARLET

/TRANS VIOLET (LOW REACH)

STEEL/STEEL FT01.5 FLOOR TOOL (STEEL/STEEL

/TRANS VIOLET (COMPLETE)

96 DY-90413619

96C DY-90413625

96A DY-90413627

96B DY-90413628

None DY-90895010 RELEASE CATCH
