Users Manual
R
2
Product Overview
Thank you for purchasing the be¯m wireless Party Block. Our
speaker will bring you a new found freedom from wires while
delivering an incredible sound. The Party Block is compatible with
all devices enabled with Bluetooth© technology... which is currently
a lot of devices!
Make sure to read through the following directions, fully charge
your device and perform the initial Bluetooth© syncing process and
you should be up and running in no time. If you have any problems
stop on by bemwireless.com for the answers to all your questions.
Package contents:
Sender x 1
Satellite Speaker x 1
Power adapter x 2
Aux cable x 1
User’s Manual x 1
If any of these were missing or damaged, please visit
bemwirelesss.com to obtain replacement.
Compatibility
All devices enabled with Bluetooth technology, including iPhones,
iPads, iPods, smartphones, laptops, tablets and more.
Also compatible with any device that has a standard 3.5mm
earphone jack such as MP3 players, PSP, mobile phones, etc.
3
1. Bluetooth Indicator
2. Power/ Pair
3. Connection Indicator
4. Cradle
5. USB Charging Port
6. DC In
7. Aux In
8. Power Indicator
Meet the Party Block
Before learning your Party Block, take a moment to look it over
and familiarize yourself with its features.
Product Interface: The Sender
1 2 3
usb charge dc in aux in
5 6 7 8
4
4
Product Interface: Satellite Speaker
1. Connection Indicator
2. Power/Pair
3. Light On/Off
4. Light Mode
5. Music Sensor On/Off
6. Volume -
7. Volume +
8. Power Indicator
9. Handle
10. LED Lights
11. Rubber Cap
12. DC In
11
1 2 3 4 5 6 7 8
9
10
12
5
Getting Started
We know you are excited to experience your new Party Block.
These two easy steps will get you up and running quickly.
Step 1: Power It
• Connect your Party Block to an outlet using the included
5V,2A power adapter. It will start charging the Sender. The
power indicator will slowly flash during charging and goes out
when it has reached a complete charge (Approx. 3.5 hours).
• Connect the Satellite Speaker to an outlet using the included
12V,2A power adapter. The power indicator on speaker
will slowly flash during charging and goes out when it has
reached a complete charge (Approx. 4 hours).
Step 2: Connect it
There are two options for connecting to your Party Block —
wirelessly by Bluetooth© or wired using the included aux cable.
Connect Wirelessly
Turn on the power of the Sender followed by powering on each
of the 2 satellite speakers. Once the base is powered on the
Bluetooth© indicator will light and a tone conrming that the unit
is currently in paring mode will sound.
Go to the Bluetooth© settings on your mobile phone, tablet or
computer to nd the device named “Party Block”. A tone will
sound to conrm the device has paired successfully.
6
Operation Details
Power on / Power off
Sender: Press the power button to turn on the Sender of Party
Block. The Bluetooth© indicator will light up to signify the unit is
on and ready to be paired. Press the power button again to turn
off the base and the Bluetooth indicator light will go out.
Satellite Speakers: Press the power button to turn the speaker
on. The Indicator on the speaker will light up to signify the unit is
on. Press the power button again to turn off the speaker and the
Indicator will also go out.
Please note, always make sure to rst turn on the sender unit
before turning on the speaker.
Step 2: Connect it (continued)
Next time the Party Block and connected device will pair
automatically. After completing this step you are ready to start
playing audio from your connected device.
Holding the Play/Pause button for 5 seconds will disconnect the
connected device and enter pairing mode for pairing a
new device.
Direct Connection
The Party Block can also be connected to any device that has a
headphone jack or line out using the included aux cable.
Please note the play/pause button only operates when
connected via Bluetooth©.
7
Play modes
• Bluetooth mode: plays an audio signal from the connected
Bluetooth© device.
• AUX mode: plays an audio signal from the connected
“wired” device.
Please note, the Bluetooth has the priority to play, if an Aux cable is connected to
the speaker, please turn off the Bluetooth© music or disconnect Bluetooth device
first for playing an audio signal from AUX.
Audio Use
Follow the above connection steps to pair a Bluetooth© device
with the Party Block. At this point you can send any kind of audio
signal to your speaker (music, video, gaming, etc.). Just use your
device as normal and the audio will play through your Party Block
Controls on the Speaker
• Press the Power/Pair button to play or pause the music when
using a music player
• Press Light on/off to turn on / off the LED decoration light.
• Press Light Mode to shift among 3 color (Red, Green,
White),Lighting mode (warm white) and color change
• Press Music Sensor on/off to turn on/off the music sensor,
when the music is on, the light will flash following the pace of
playing music.
• Pressing the + and - buttons will increase or decrease the
volume on the Party Block. Please note that this will not
affect the volume levels on the connected device.
Operation Details (cont.)
8
Connection
Laptop / notebook / PC
As the Bluetooth© versions for these types of devices varies
greatly, the connection methods will differ as well. If you can
not connect with the Party Block using the previous method
instructed you may need to install a new version of the
Bluetooth© driver.
Please reference the instructions of device for details.
Speaker Placement
The Sender has built-in battery and is portable. This allows the
perfect placement of the sender for maximum distance.
The speaker can be set anywhere you like. Approximate range
is 50ft away from the sender (open area). The Party Block uses
5.8gHz signal so you’re free to put the speakers where you like!
Charging
Connect your Party Block Sender to an outlet using the included
5V,2A power adapter. It will start charging the Sender.
The power indicator will slowly flash during charging and goes out
when it has reached a complete charge (Approx. 3.5 hours).
Connect the Satellite Speaker to an outlet using the included
12V,2A power adapter. The power indicator on speaker will
slowly flash during charging and goes out when it has reached a
complete charge (Approx. 4 hours).
Note: if the unit has not been used in the past 7 days please
charge for 30 minutes before using the Party Block.
9
Charging Your Device
The sender features a standard USB charging port with 5V,1A
output at the back which can charge most cell phone and tablet,
Please reference the instructions of device for details.
The charging cable is not included.
Using the Device Stand
Slide the sender open to use the device stand. The back rest
was designed to tilt your device at a 25 degree angle for
optimal viewing.
Adding Additional Speakers
You can run up to 99 Party Blocks off of 1 sender. Just power on
Party Block speakers within range of the sender.
Weather Resistance
Your Party Block speaker has an IP44 rating against solids and
water. This standard in the industry helps to define the products
resistance to particles and liquids. At this rating your Party Block
is protected against solid bodies larger than 1mm and against
projections of water from all directions.
10
Troubleshooting
Issue: Pairing is unsuccessfully after multiple attempts
Solution:
• Check if the Bluetooth© indicator light is on. If the indicator
light is off, please press the power button to turn the unit on.
If the Bluetooth© indicator light still doesn’t come on after
pressing the power button, please charge the unit.
• Check for other Bluetooth© devices around the surroundings
that may interfere with searching and turn devices off.
• Power off and then power on the unit to restart the
Bluetooth© Unplug any cables plugged into the AUX IN,
restart all devices and then attempt pairing again.
Issue: Interference or static during playback
Solution:
• Avoid using the device between concrete or other building
structures that may interfere with the signal.
• Please check if the battery level of the unit and the
Bluetooth© device and charge if necessary.
For more troubleshooting help go to http://bemwireless.com
Storage
• Power off the Party Block If the unit will not be used for an
extended period of time.
11
• Do not set the unit in a damp environment, high temperatures
or in direct sunlight.
Maintenance
Please follow the instructions below for cleaning your
Party Block
• Power off the unit and unplug the power adapter from
wall outlet
• Use a soft, dry, lint-free cloth and wipe gently
• Do not use alcohol, benzene, thinners or other chemical
detergents as these can cause the casing to be warped
or discolored
For questions, comments or to purchase more bem wireless
products go to bemwireless.com
FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received,
including interference that may cause undesired
operation.
2. Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
exposure condition without restriction.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
exposure condition without restriction.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
FCC Radiation Exposure Statement
12
be¯m wireless
http://bemwireless.com/
be¯m wireless LLC.
1725 Kilkenny Ct.
Woodstock, IL. USA
Made in China
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
FCC Statement (cont.)
- English: "
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference
that may cause undesired operation of the device."
- French:"
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil nedoit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement."
CAN ICES-3 (B)
NMB-3 (B)
IC STATEMENT
13
Product Name : Party Block
Model Number : HL2536
Power Supply: 5V,2A for Sender and 12V,2A for Speaker
Output power: 10W X 2
USB charging output: 5V,1A x 1
Battery capacity: 3.7V 2000mAh for the case ,7.4V 4000mAh for
the speaker
Bluetooth V4.0+EDR , profile Supported: A2DP, AVRCP
Bluetooth working range: Approximately 25ft, 8m
Working atmosphere: 0˚C-40˚C / 20%-90%RH
14
Safety Instructions
This product is specially designed based on the full attention to
safety; in order to make sure the accident-free operation, please
abide the guidelines listed below:
• Always position the unit on a stable and level surface. Unstable surface
can cause the unit to topple and fall, resulting in possible damage or injury
• Do not drop, unpack, open, beat, curve, prink and burn
the unit
• Avoid using the unit nearby basins or sinks where it may come in contact
with water
• Do not place any ware with full water on the top of the unit, such as vase,
glass, pot, and please avoid placing candle on the speaker surface as well
• Protect the using of the unit from any overheating devices (such as
radiator, heating installation, cooking stove or other heating devices)
• Regardless of what reasons cause the unit damage, please ask for the
maintenance personnel to repair
• If you want to do the cleaning, please turn off the unit and unplug the
power cable from the outlet first
• Set the volume properly to prevent injury to the unit and your
personal health
Correct Disposal of this product. This marking indicates that
this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to
the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable
reuse of material resources. To return your used device,
please use the return and collection systems or contact the
retailer where the product was purchased. They can take this
product for environmental safe recycling.
WARNING:
• The battery (battery or batteries or battery pack) shall not be exposed to
excessive heat such as sunshine, fire or the like.
• No naked flame sources, such as lighted candles, should be placed on the
apparatus.
• CAUTION: Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type.
Safety Instructions (cont.)
More Info
For questions, comments or to purchase more be¯m wireless
products go to: bemwireless.com
You can also follow us at:
facebook.com/bemwireless
twitter.com/bemwirelessco
youtube.com/bemwireless
For information on your product’s warranty go to:
bemwireless.com/support
be¯m wireless | 1725 Kilkenny Court | Woodstock IL 60098
TEL: 855-839-8616
© 2014 be¯m wireless
