E Core Technology HP5139N 2.4GHz WIRELESS DEVICE User Manual USERS MANUAL
E-Core Technology (China) Co., Ltd. 2.4GHz WIRELESS DEVICE USERS MANUAL
USERS MANUAL
RF2.4G PSII WIRELESS CONTROLLER（HP5139）
USER MANUAL
IMPORTANT INFORMATION REQUIRED BY THE FCC
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO
THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S
AUTHORITY TO OPERATE THE EQUIPMENT.
E-CORE TECHNOLOGY (CHINA) CO., LTD
Thanks for select our RF 2.4G PSII controller! For play more
conviently and correctly, please read the manual carefully before
playing.
Product brief Introduction
HP5139 wireless controller adopt 2.4GHz RF technology, with
steady connection capacity, far distance, low function wastage; beautiful
outlook, good handle , make you feel be personlly on the scene!
Technology Specification
1. Compatible with PSX、PS1and PSII game console
2. Two selection model（ANALOG、DIGITAL）
3. Support TURBO function
4. Signal connect indicate
5. Auto/un-unto connection
6. Fixup ID code defending fault fucntion
7. Power deplete low, low voltage indicate
8. Auto sleep saving electricity function
9. 12 buttons and 256 level simulate funciton
10. Grip with soft plastic to prevent slipping
11. Availability distance≥10M
12. Work voltage：6V 4×1.5V AAA battery
13. Work current：work current 6.5mA sleep status:15μA
14. Size：controller 155*110*75mm；receiver 80×50×20mm
15. Weight：156g
Prodcut Introduciton
1. Product function introduction as following picture:
Controller function sketch map
Receiver function sketch map
Use Introduction
1）. Open battery cover，put in 4pcs 1.5V AAA battery as
battery box polarity indication, then close it.
2）. Connect PSII console to TV, put in the game dish,
insert receiver.
3）. Draw the switch in controller (HP5139) front to “ON”
switch on，POWER LED bright，then switch on the
game console,”CONNECT” in receiver bright ；
If ”CONNECT” trun from winking to lasting,
connection for controller and receiver is ok, play is
ok；If “CONNECT” continue winking，show that
connection of controller and receiver is off.
4）.Press”CONNECT” ， winking speed fast, then
press”CONNECT” in controller，until “CONNECT” in
receiver continue bright, conncetion of controller and
receiver is ok.
5）. When connection is ok, no work for 5 minutes，enter
to auto sleep model. Press ”CONNECT” in controller
for 3 seconds awake , POWER LED is on , get
right.
6）. When battery in low, POWER LED continue winking
remind of changing battery.
7）. Press any function button, then press”TURBO” to set
this button with TUTBO function；Press this button by
setting, then press”TURBO” to cancel TURBO
function；press”TURBO”, then press”START” select the
speed of TURBO, total 4 speed for selection, press
once for changing one speed.
8）.When controller beyond the receive distance,
the”CONNECT” in receiver continue winking, then
controller in this status without function or fucntion is
abnormal
9）.When connection of controller and receiver finish, then
play need notconnect by person, auto connect as
switching on.
Attention
a) When put in battery, please set as battery box polarity indication,
don’t put in different class battery
b) After play, switch to the power switch to “ON”, avoiding waste
power supply.
c) When warn of low voltage, please change battery immediately.
d) No work for long time, please take out battery , avoid leaking
from battery to damage inner current.
e) Don’t dismantle this products.
f) The final explantation right for this manual belong to ECORE
TECHNOLOGY(CHINA) CO., LTD.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
