E Core Technology HT1072 Adventure Box User Manual 1
ECORE TECHNOLOGY COMPANY LIMITED Adventure Box 1
Users Manual
PN:HT1072
User's Manual
Thank you for purchasing our Adventure Box Read carefully and follow
all instructions in this User's Manual before you use the Adventure Box. Keep this
User's Manual in a convenient locatio for future reference
Safety Instructions
This product is specially designed based on the full attention to safety; in order to
make sure the accident-free operation, please abide the guidelines listed below:
Always position the unit on a stable and level surface. Unstable surface can
cause the unit to topple and fall, resulting in possible damage or injury
Do not drop, unpack, open, beat, curve, prink and burn the unit
Avoid using the unit nearby basins or sinks where it may come in contact with
water
Do not place any ware with full water on the top of the unit, such as vase, glass,
pot, and please avoid placing candle on the speaker surface as well
Protect the using of the unit from any overheating devices (such as radiator,
heating installation, cooking stove or other heating devices)
Regardless of what reasons cause the unit damage, please ask for the
maintenance personnel to repair
If you want to do the cleaning, please turn off the unit and unplug the power
cable from the outlet first
Set the volume properly to prevent injury to the unit and your health
Correct Disposal of this product. This marking indicates that this product
should not be disposed with other household wastes throughout the EU.
To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the retailer where
the product was purchased. They can take this product for environmental
safe recycling.
WARNING:
The battery (battery or batteries or battery pack) shall not be exposed to excessive heat
such as sunshine, fire or the like.
No naked flame sources, such as lighted candles, should be placed on the apparatus.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type.
Package Contents
1. Adventure Box x 1
2. Micro USB charging cable x 1
3. 3.5 mm AUX cable x 1
4. User's manual x 1
5. Carabiner x1
6.Handstrap × 1
Fit Models
Apply to：all iPhone and iPad series, Samsung smart phones, Tablets and other
Bluetooth devices
Work with any device with standard 3.5mm earphone jack via the included Aux
cable for connecting, such as MP3,PSP, Mobile phone...,etc
Outstanding Features
Adventure Box is compatible with all wireless Bluetooth devices such as iPhone,
iPad, Samsung smartphones, Tablets and other Bluetooth devices. It is
portable, wireless, hands-free. Just place it anywhere in a room and enjoy pristine
streaming audio from your phone, computer, or other Bluetooth devices. Bring
music, movies, and all your mobile audio vibrantly to life--all in the palm of your
hand
Go Anywhere and Go Wireless
Easily connects with mobile phones, computers, tablets, iPods or any other
Bluetooth device
Wireless working range is up to 8 meters, no cords, hassle-free.
Calling and Conference on the Go
With a powerful, built-in microphone, it can frees you to share clean-sounding
conference calls or personal calling anywhere--in the office, car, at home, alone,
or with a group, even outdoor.
User-friendly
Built-in rechargeable battery, up to 5 hours of continuous play
Unique outlook and function design
Unique ball shape outlook, with rubber case, expressing you sport vitality.
Compact size, ideal for travel and mobility.
LINE IN, to play with almost any audio device.
Water resistance design; enable outdoor application for your trip, mountain, forest
trip, adventure etc.
Part Names
Main unit
1 Hole
2 Volume –
3 Charging indicator
4 Volume +
5 Multi-function button
(play/pause button &
answer key)
6 Bluetooth indicator
7 ON/OFF Button
8 Line in
9 USB charging port
10 Microphone
11 Back Cover
1
2
3
4
5
6
7
8
9
10
11
Basic Operation
Power on/power off
1 Take off back cover
2 Power on the unit: slide the ON/OFF button to turn on the unit, the Bluetooth
indicator lights up at once
3 Power off the unit: slide the ON/OFF button again to turn off the unit, the
Bluetooth indicator goes out in the meanwhile.
Connection
1. Work with phone
Power on the unit, and coming with a short Bluetooth hint sound form the unit, the
Bluetooth function is on, the Bluetooth indicator lights up at the same time, these
show the unit is enter pairing mode.
Turn on the Bluetooth function in your phone, and search the Bluetooth device,
then, your phone will find the device named “BIJELA HT1072”, click and with a
short Bluetooth hint sound come from the unit, that remind you it has been paired
successfully.
2. Work with tablet PC
Please refer to the above phone connection operation steps.
3. Work with laptop/ notebook computer /PC
As the Bluetooth version for laptop/ notebook computer /PC is various, the
connection methods are different as well, if you cannot connect with the unit for
play on first use, you may need to install a new version of the Bluetooth driver in
your laptop in advance. Please reference the instructions of laptop for details.
Play mode
1. Bluetooth mode: Play the audio signal from Bluetooth device connected with
the unit.
2. AUX mode: Play the audio signal from the audio device with “AUX” port.
Note: As long as the Aux cable is connected to the speaker, it will not play the
music from Bluetooth
Play the music
Play the audio signal from Bluetooth device
1. Follow the above connection steps to pair the Bluetooth device and the unit.
2. Enter in the Bluetooth device audio play menu, choose your favorite music
Model Name：HT1072
Power Supply: Micro USB
Built-in Lithium Ion batteries: 1400mAh,3.7V
Touch the volume button on the unit or control the audio device volume directly to
adjust the volume
Hands free function
1. The unit will play ringtone when there is a incoming call
2. At this time, press the multi-function button to answer the call, and talk through
the microphone
Charge
1. Connect the standard USB end of the supplied USB cable to a USB power
source (like PC, USB power adapter…etc.)
2. Connect the Micro USB jack to the USB charging port on the DC IN . The
charging indicator will light up while charging
3. It will take about 5 hours for fully charge the Bluetooth speaker
4. The charging indicator working mode:
When charging, red LED indicator will be lit up.
When the battery is fully charged, red LED indicator will go out.
Note: if the unit is not to be used longer than 7 days, please charge the uni for 10
minutes before turn on the unit.
Technical parameters
Note: All specifications are subject to change without notice.
Product Name: Adventure Box
（1） Check if the blue Bluetooth indicator lights on, if the indicator goes off, please
switch the ON/OFF button to turn on the unit, if the blue Bluetooth indicator
doesn't light on yet, please charge the unit
（2）P erhaps there are many Bluetooth devices around the surroundings to
interfere the searching, please close the Bluetooth function in the device you
don't need
（3）P ower off and then power on the unit, to restart the Bluetooth function of the
unit or your Bluetooth device
（4）U nplug the AUX cable from the unit, and re-pair the unit and the
Bluetooth device
Question: The sound occurs staccato when play？
Solution：
to play.
3. Press the multi-function button to pause or play your music as you need.
Line IN：
1. Plug one end of the supplied Aux cable to the “AUX” port in the back of unit, and
then plug the other end of the cable to audio device.
2. Choose directly your favorite music in the audio device to play
3. Press the multi-function button to pause or play your music as you need.
Adjusting the volume
Output power: 3W
Bluetooth Profile Supported: A2DP V1.2, AVRCP V1.4
Working range: up to 8m
Working atmosphere: 0℃-40℃/20%-90%RH
Maintenance
Please follow the instructions below before clear the unit
Power off the unit first before clear
Use a soft, dry, lint-free cloth to wipe gently
Do not use alcohol, benzene, thinners or other chemical detergents as
these can cause the casing to be warped or discolored
Storage
If the unit will not be used for an extended period of time, power off the unit and
place the unit with accessories into the package
Do not set the unit in a damp, high temperature or the sun point-blank place
Troubleshooting
Question: Can't pair successfully after multiple connections？
Solution：
（1） Make sure the working distance is in 8m
（2）C lear away the block between the unit and the Bluetooth device to prevent the
poor connecting
（3）P lease check if the unit and the Bluetooth device is in low battery, if so, please
charge the unit and your Bluetooth device
CE 2200
BIJELA
www.bijela.com.cn
ECORE TECHNOLOGY COMPANY LIMITED
Made in China
2200
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
