E Lead Electronic EL40302315 Tire Pressure Monitoring System (TPMS) User Manual UserMan2
E-Lead Electronic Co., Ltd Tire Pressure Monitoring System (TPMS) UserMan2
Contents
- 1. UserMan1
- 2. UserMan2
UserMan2
▼Tool Required:
▼Caution:
Read and follow this installation instruction carefully,
before installing -sensor. It is recommended
preparing for the required installation tools and seeking
the service of a qualified technician to install and disassembly -sensor. Each
-sensor has blank software inside at initial status and -tool will program
proper software to -sensor. Improper installation and programming wrong
software will cause TPMS in vehicles to fail to operate properly.
▼Warranty:
Within warranty period, E-LEAD will take responsibility of defective parts.
However, E-LEAD do not assume any liability in case of faulty, incorrect
installation of -sensor or improper programming.
●Pull in tool*1
●T10 screw driver*1
52014030024-00
▼Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
●Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Tire Pressure Monitoring System (TPMS)
Model:EL-403R-0002
Step 3.
Step 5.
Step 7.
Step 6.
▼Disassembly Procedures:▼Installation Procedures:
1. Dismount tire and original sensor from the wheel rim.
2. Clean away any corrosion and debris around wheel hole.
3. Remove the cap from the -sensor.
7. Inflate the tire and put on the cap.
6. Using the pull in tool, pull the valve stem straight
through the valve hole and not at an angle.
5. Line in sensor up with rim hole as shown and attach
a pull in tool to the end of the valve ready for pull in.
4. Apply lube to rubber portion of the valve stem.
1. By using T10 screw driver, it can remove the screw.
2. Pull -sensor body straight back off the valve.
3. Cut the rubber bulb.
4. Remove the valve from the rim by pulling the valve
through the rim.
Step 4.
Step 1.
Step 2.
Step 4.
Step 3.
