E Power SP3174 Pebble Bluetooth speaker User Manual SPLASH MANUAL
E-Power Limited Pebble Bluetooth speaker SPLASH MANUAL
E Power >
User Manual
7199-96 Pebble Bluetooth Speaker
User Manual
IPX5 Water-Resistant
①
②
③
④
COMPONENTS INCLUDED:
1 x Pebble Bluetooth Speaker
1 x User Manual
1 x Charging Cable
DESCRIPTIONS OF EACH KEY:
①
②
③
④ Switch AUX to Bluetooth automatically. Answer an incoming
call or end a call
Long press: Power On/Off
Short press: Pause or play the music
Short press: Volume up
Long press: Move to previous music
Short press: Volume down
Long press: Move to next music
⑤ ⑥ ⑦ ⑧
⑤ Reset.
⑥ Light indicator
⑦ Aux Port.It can connect audio device
through the AUX IN port.
⑧ USB Port. Use the USB cable
supported connects the USB end
to the computer, which can charge
the speaker.
BLUETOOTH SPEAKER OPERATION:
>>Turn on the speaker, Blue indicator light will flash rapidly
to detect nearby Bluetooth enabled devices.
>> Look for “Pebble” appear on the list of Bluetooth
devices from your device. Type Password “0000” or “1234”
if requested.
>>Once unit is successfully paired and connected. Blue
lights stop to flashing and always on.
SOFT REMIND:
The waterproof grade is IPX5, it only can prevent splash
water. Please don’t drop it into water, otherwise will damage
this speaker.
SAFTY INFORMATION:
Avoidsources of intense heat or flame.
Do not insert metal objects into item. (Shirt circuit risk)
Do not attempt to repair the device. Rather, contact a service
Professional.
Page 1
Page 4
Page 2
Page 3
Page 4
Page 3
75mm
55mm
FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 5 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
RF warning statement:
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure condition
without restriction.
