Micro-Zoomer
Mini Cooper S
1:24 Scale
User’s Guide
www.ExcaliburElectronics.com Model No.: 9355
9355 (MA) MiniCoop.indd 1 9/26/08 3:24:38 PM
Congratulations on your purchase of Excalibur Electronics’
Micro-Zoomer Mini Cooper S. Now you can race anywhere
with this super-fast, full-function replica of the real Mini
Cooper. Go in all directions with its smooth, fully directional steering,
and enjoy hours of fun. The radio transmitter is included.
Your Mini Cooper is easy to use, but be sure to use it safely. Before
starting, please read this guide thoroughly, especially noting safety,
care and battery information. Keep this guide for reference.
Ba t t e r y In s t a l l a t I o n
VE h i c l E
1. The battery compartment is
located on the underside of the
unit. Use a Phillips screwdriver to
open the battery compartment.
2. Install 3 AA batteries,
making sure to match the
polarity (+ and -) with the
diagram on the inside of the
battery compartment.
3. Replace the battery cover and
no t E : When installing batteries into
the vehicle be careful to not damage
the antenna.
tr a n s m i t t E r
1. The battery compartment is
located on the back of the unit.
Use a small Phillips screwdriver
to release the screw then slide the
battery compartment cover off.
2. Install a 9V battery, making sure
to match the polarity (+ and -)
with the diagram on the inside of
the battery cover.
3. Replace battery cover and screw
Co n t e n t s
1 - Mini Cooper S
1 - Transmitter
9355 (MA) MiniCoop.indd 2 9/26/08 3:24:38 PM
Operation
There is an OFF/ON switch on the
transmitter and on the bottom of the
car. Turn both switches to ON
How to Race:
Your transmitter features two
joysticks. The one on the left moves
up (forward) and down (reverse) to
control the forward and backward
motion of the car. The joystick on the
right moves right and left to control
the turning of your car.
Range:
When the vehicle goes beyond
radio signal contact, loss of control
or slowness will occur. Extend the
transmitting antenna higher for better
signal. Make sure the antenna is
screwed on tightly.
Trim Switch Control:
The switch is located on the
underside of the vehicle between
the two front wheels, just above
the battery compartment. It is used
to align the wheels so that vehicle
drives consistently in a straight line.
If your car turns when it should go
straight, adjust the trim switch until
the problem is eliminated.
Battery Life
Extend the battery life by switching
the unit off when not in use.
Battery life affects how your car
responds. When the transmitter range
decreases, replace the batteries in the
controller and vehicle.
Interference
It is advisable not to use the vehicle
close to high tension wires or CB
radios. Interference from radio waves
may affect the vehicle’s performance.
Helpful Hints
dusty surfaces or sand. Off-
road vehicles run easier on grassy
surfaces.
Collisions against hard surfaces
may damage the vehicle.
thick carpets or dusty floors.
one vehicle at a time, you must
purchase another vehicle on
another frequency.
transmitter, move closer to the car
and try again.
performance may decrease. If this
happens, simply recharge your car
again.
9355 (MA) MiniCoop.indd 3 9/26/08 3:24:38 PM
Troubleshooting:
If the vehicle does not move:
1. Are the battery contacts matched
correctly in the transmitter?
2. Are the metal contact tabs
touching, rusty or dirty in the
transmitter?
3. Are there batteries in the
transmitter?
4. Is the power switch on the
transmitter turned on?
5. Are the batteries exhausted?
Special Care & Handling
bumping or dropping.
temperatures. For best results, use
between the temperatures of 39ºF
and 100ºF (4º C and 38º C) and
keep away from fire.
long periods under direct sunlight.
Sunlight or excessive heat may
damage electronic parts.
dry, cool place away from heaters
or warm areas.
agent. Clean using only slightly
damp cloth. Then use a dry
cloth to wipe off the moisture.
can also be removed from your
vehicle by using a brush or by
tying a small bit of cloth to the tip
of a toothpick or tweezers and
using that to wipe off your car.
Battery & Other Information
replaced only by an adult.
Also wires and plugs should be
periodically checked by an adult.
polarity.
batteries and one 9V battery
for the transmitter, not included.
(carbon-zinc) or rechargeable
(nickel-cadmium/ Ni-MH)
batteries.
the unit.
leaking or damaged batteries.
not dispose of batteries in a fire or
attempt to recharge alkaline or
other non-rechargeable batteries.
is not used for an extended
period of time.
terminals.
cool, dry place when not in use.
9355 (MA) MiniCoop.indd 4 9/26/08 3:24:38 PM
