ELANsat Technologies Inc. Wireless Video Camera MANUAL
Revised Users Manaul
2.4 GHz WIRELESS
SURVEILLANCE SYSTEM
USER’S MANUAL
SAFETY INFORMATION
CAUTION:
RISK OF ELECTRONIC SHOCK DO NOT OPEN
CAUTION:
DO NOT REMOVE THE COVER FOR REDUCING THE RISK OF ELECTRIC
SHOCK.
NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED
SERVIEC PERSONNEL.
WARNING:
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
Safety term and Symbols
△ Warning: Warning statements identify conditions or practices that could
result in injury or loss of life.
△ Caution: Caution statements identify conditions or practices that could
result in damage to this product or other property.
△ Danger: Do not remove the cover for reducing the risk of electric shock.
IMPORTANT SAFETY INSTRUCTIONS
1. All the safety and operating instructions should be read before the product is
operated.
2. The safety and operating instructions should be retained for future reference.
3. All warnings on the product and in the operating instructions should be adhered to.
4. All operating and use instructions should be followed.
5. Unplug this products from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for the cleaning.
6. Do not use attachments not recommended by the products manufacturer if they
may cause hazards.
7. Do not use this product near water – for example, near a bath tub, wash bowl,
kitchen sink, or laundry tub, in a wet basement, or near a swimming pool; and the
like.
8. Any mounting of the product should follow the manufacturer’s instructions, and
!
!
should use a mounting accessory recommended by the manufacturer.
9. This product should be operated only from the type of power source indicated on
the marking label. If you are not sure of the type or power supply to your home,
consult your product dealer or local power company. For products intended to
operate form battery power, or other sources, refer to the operating instruction.
10. Power supply cord should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords
at plugs, or other sources, refer to the operating instructions.
11. For added protection for this product during a lightning storm, or it is left
unattended and unused for long periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent damage to the product
due to lightning and power-line surges.
12. Never push objects of any kind into this product through openings as they may
touch dangerous voltage points or short-out parts that could result in a fire or
electronic shock. Never spill liquid of any of any kind on the product.
13. Do not overload wall outlets, extension cords, or integral convenience receptacles
as this can result in a risk of fire or electric shock.
14. Unplug this product from the wall outlet and refer servicing to qualified service
personnel under the following conditions.
-When the power-supply cord or plug is damaged.
-If liquid have been spilled, or objects have fallen into the products
-If the product does not operate normally by following the operating instructions,
adjust only those controls that are covered by the operating instructions as an
improper adjustment of other controls may result in damage and will often require
extensive work by a qualified technician to restore this product to its normal
operation.
-If the products has been dropped or damaged in any way.
-When the product exhibits a distinct change in performance – this indicates a
need for service.
15. When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer or that have the same
characteristics as the original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.
16. Upon completion of any service or repair to this product, ask the service
technician to perform safety checks to determine that the product is in proper
operating condition.
17. The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products including amplifiers that produce heat.
FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
The users manual or instruction manual for an intentional or unintentional radiator shall
caution the user that changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
TABLE OF CONTENTS
1. Introduction
1.1. Overview
1.2. Main features
2. Check Package before Use
2.1. One unit of Wireless Camera
2.2. One unit of Rechargeable Battery
2.3. One unit of Receiver
2.4. Two units of Power Adaptors
2.5. One unit of Mounting Bracket
2.6. One unit of RCA/SCART Cable
2.7. One unit of USB Cable (Optional)
2.8. One unit of Disk/CD for USB Driver (Optional)
3. Controls / Functions
3.1. Wireless Camera
3.2. Receiver
4. How to Connect
4.1. Wireless Camera
4.2. Receiver
5. Operations
6. Trouble Shooting
6.1. No Picture or Sound
6.2. Unclear Picture
6.3. Interference in the Image and Sound
7. Specifications
7.1. Wireless Camera
7.2. Receiver
1. Introduction
1.1. Overview
The Wireless Surveillance System with infrared illumination is just as your 24hrs
baby sitter, home/camp guard and company monitoring. The rechargeable battery
can let the camera working without power adaptor.
1.2. Features:
1. High-Resolution Color CMOS Camera
2. USB Video Capture Adaptor (Optional)
3. High Performance Audio/ Video Receiver
4. Built-In Rechargeable Battery
5. Built-In Microphone for Audio Monitoring
6. Infrared Illumination Provides Images in the Darkest Location
7. With CDS Sensor, Auto Switch “Color” on day time and B/W on night time
8. Antenna embedded
9. Operating frequency of ISM band 2.4 ~ 2.4835 GHz
10. 4 channels selectable
11. Range up to 300 feet (L.O.S.)
12. Easy installation
2. Check Package before Use
2.1. One unit of Wireless Camera
The Wireless Camera emits Audio and Video signals over 2.4GHz radio
frequency carrier.
2.2. One unit of Rechargeable Battery
The battery provides power to the Wireless Camera when you don’t use the
attached power adaptor.
Note: *Caution & Warranty of Battery:
1. Reverse charging is not acceptable.
2. Charge before use, although the batteries are delivered in a
charged state.
3. Do not charge / discharge with more than the specified current.
4. Do not short circuit the battery. Permanent damage to the battery
may result.
5. Do not incinerate or mutilate the battery.
6. Do not solder directly to the battery.
7. The life expectancy may be reduced if the battery is subjected to
adverse conditions like: extreme temperature, deep cycling,
excessive overcharge / over discharge.
8. Store the battery in a cool dry place.
9. For storage of batteries over one year. In order to prevent the
degrading the function of cells, batteries should be at least charged
and discharged once within one year.
10. Keep away from children. If swallowed, contact a physician at
once.
11. One year limited warranty against workmanship and material
defects.
2.3. One unit of Receiver
The Receiver receives 2.4GHz wireless Audio and Video signals from the
Wireless Camera.
2.4. Two units of power Adaptors
Two power adaptors supply +9V(300mA) DC power to the Wireless Camera
and the Receiver.
2.5. One unit of Mounting Bracket
The mounting bracket is used to bolster up the Wireless Camera.
2.6. One unit of RCA/SCART Cable
The RCA cable is used to connect the Receiver to your A/V displays.
A/V displays: computer monitor (converted card required), powered
speakers, TV monitor etc.
2.7. One unit of USB Cable (Optional)
The USB cable connects the Receiver to computer and changes the analog
signal to digital USB signal.
2.8. One unit of Disk/CD for USB Driver (Optional)
This disk/CD includes the USB driver. Please refer to the attached USB
Cable manual.
Note: If any accessories listed above are missing, please contact the sales
representative where you purchase the Wireless Surveillance System.
13. Controls / Functions
1. Wireless Camera
Front & Side
Rear
1. IR LED 2. Lens 3. Microphone 4. Rechargeable battery 5. Power
6. DC jack 7. Power indication LED 8. Charge jack
Inside Channel Selection
Open the battery cover and connect the jumper to the connector.
3.2. Receiver
Front & Side
Rear
1. 2. 3. 4. 5. 6.
Channel Selection
Channel Ⅰ: Flash once In one time
Channel Ⅱ: Flash twice In one time
Channel Ⅲ: Flash thrice In one time
Channel Ⅳ: Flash quartic In one time
14. How to Connect
4.1. Wireless Camera
4.1.1. Plug the Wireless Camera into the power outlet with attached adaptor
or load the charged battery.
4.1.2. Combine the Wireless Camera and the mounting bracket.
4.1.3. Fasten the mounting bracket on the wall or ceiling
4.2. Receiver
4.2.1. Connect the Receiver to the TV with Audio/Video cable, or connect the
Receiver to your computer with RCA cable and USB cable. (Please
insert the attached disk into floppy and install the USB driver before
connecting the Receiver to your computer.)
4.2.2. Plug the Receiver into the power outlet with attached adaptor.
5. Operations
-Turn on the power of Wireless Camera, Receiver and A/V display.
-The power indication LED on Wireless Camera will light up.
-Change the Wireless Camera / Receiver to the same channel.
-Wireless Surveillance System watch wherever you want day and night
Note: *Gaze at IR LED closely for a long time results in uncomfortable eyes.
*The operation temperature is from 0℃ ~ 60℃.
6. Trouble Shooting
Please read this user’s manual carefully before using the Wireless Surveillance
System. If you still have difficulties to use the Wireless Surveillance System
consult the following syndrome, which will guide you to solve most common
problems.
6.1. No picture or Sound
-Check the DC adaptor rightly connected.
-Power ON/OFF switch is in right position.
-Check the battery is loaded and charged when you don’t plug the DC
adaptor.
-Check all the cables well and rightly connected.
6.2. Unclear picture
-When you cycle the lens for focus, you can’t touch the lens and plastic cover
from dirtying.
-Wipe the lens with lens cloth.
-Please circle right the lens. If the picture is not clearer, circle left the lens then
it can focus rightly.
6.3. Interference in the Image and Sound
-Move your Wireless Camera or Receiver slowly to find a best reception
position.
-Shorten the distance between your Wireless Camera and Receiver.
-Check if there is any interference radio frequency source near your Receiver
source such as microwave oven.
7. Specifications
7.2. Wireless Camera
Item Specifications
Scanning System 2:1 Interlace
NTSC
2:1 Interlace
PAL
Image Sensor 1/3" CMOS Image Sensor
Efficiency Pixels 510 (H) X 492 (V) 628 (H) X 582 (V)
Horizontal Scan Frequency 15750 Hz 15625 Hz
Vertical Scan Frequency. 60 Hz 50 Hz
Synchronize Internal
Resolution More Than 230TV Lines
Min. Illumination 3 LUX (F1.2)
S/N Ratio More Than 42 dB (AGC OFF)
Video Output 1.0 Vpp / 75Ωcomposite Video Signal
Auto Electronic Exposure 1/50 ~ 1/15000 sec.
Auto white Balance Auto
Supply voltage 9V dc
Power Consumption
IR LED On 200mA
IR LED Off 80mA
(800 mW ~ 1600 mW)
Operation Temperature 0℃ ~ 60℃
Lens (Optional) F3.6 mm, F 2.0 (Fix Board Lens)
IR Control Auto
IR LED 6 pcs
Audio output 84 db / 600Ω load
Weight Approximate 144.2g (W/O Battery)
Approximate 228.8g (W/ Battery)
Size 129.6L x 70W x 58.6H (mm)
7.2. Receiver:
Item Specification
Frequency 2400 MHz ~ 2483 MHz
Receiver Sensitivity -90 dBm (min.)
Channel Number 4 (2414,2432,2450,2468MHz)
L.O. Stability ±100 KHz (typ.)
Video Output Level 1Vp-p (typ.)
Audio Output Level 1Vp-p (typ.)
Supply Voltage 9V
Power Consumption 200mA (typ.)
Antenna Embeded
Dimension 145D x 92W x 40H (mm)
Operating Temperature -10℃~ +60℃
To provide the latest technologies product to our customer is our responsibility, therefore, we reserve
the right to change the specifications without prior notice.
