ELPRO Technologies SS1 DIGITAL SPREAD SPECTRUM TRANSCEIVER User Manual FCC Man SS
ELPRO Technologies Pty Ltd DIGITAL SPREAD SPECTRUM TRANSCEIVER FCC Man SS
Users Manual
To be included in the full manual to be
generated by Cooper Crouse-Hinds
ATTENTION!
Incorrect termination of supply wires may cause internal damage and will void
warranty. To ensure your SmartSwitch module enjoys a long life, double
check ALL your connections with the user manual before turning the power
on.
CAUTION:
To comply with FCC RF Exposure requirements in section 1.1310 of the FCC
Rules, antennas used with this device must be installed to provide a separation
distance of at least 20 cm from all persons to satisfy RF exposure compliance.
Avoid:
• Operating the transmitter when someone is within 20 cm of the antenna
• Operating the transmitter unless all RF connectors are secure and any open
connectors are properly terminated
• Operating the equipment near electrical blasting caps or in an explosive
atmosphere
All equipment must be properly grounded for safe operations.
All equipment should be serviced only by a qualified technician
SAFETY Notice:
Exposure to RF energy is an important safety consideration. The FCC has
adopted a safety standard for human exposure to radio frequency
electromagnetic energy emitted by FCC regulated equipment as a result of its
actions in Docket 93-62 and OET Bulletin 65 Edition 97-01.
FCC Notice:
This SmartSwitch module complies with Part 15.247 of the FCC Rules.
Operation is subject to the following two conditions:
This device may not cause harmful interference and must accept any interference received,
including interference that may cause undesired operation.
This device must be operated as supplied by Cooper Crouse-Hinds. Any changes or
modifications made to the device without the written consent of Cooper Crouse-Hinds may
void the user’s authority to operate the device.
This device must be installed by professional installers in compliance with 47 CFR Part 15
Subpart C Section 15.204 and 15.205, who will be responsible for maintaining EIRP no
greater than 36 dBm in accordance with 47 CFR Part 15 Subpart C Section 15.247 (b)(2)(4).
In accordance with 47 CFR Part 15 Subpart C Section 15.204 only the following
antenna/coax cable combinations can be used.
Manufacturer Model Number Coax Cable Net
Laird N24-5-NM-B Direct 5dBi Gain
Laird S2406BFNM 1m of LMR100 6.5dBi Gain
• Part 15 –This device has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part15 of the FCC rules (Code of Federal Regulations
47CFR Part 15). Operation is subject to the condition that this device does not cause
harmful interference.
• Notice Any changes or modifications not expressly approved by Cooper Crouse-
Hinds could void the user’s authority to operate this equipment.
This Device should only be connected to PCs that are covered by either FCC DoC or are
FCC certified.
IMPORTANT Notice:
Cooper Crouse-Hinds products are designed to be used in industrial environments, by
experienced industrial engineering personnel with adequate knowledge of safety design
considerations.
Cooper Crouse-Hinds radio products are used on unprotected license-free radio bands with
radio noise and interference. The products are designed to operate in the presence of noise
and interference, however in an extreme case, radio noise and interference could cause
product operation delays or operation failure. Like all industrial electronic products, Cooper
Crouse-Hinds products can fail in a variety of modes due to misuse, age, or malfunction. We
recommend that users and designers design systems using design techniques intended to
prevent personal injury or damage during product operation, and provide failure tolerant
systems to prevent personal injury or damage in the event of product failure. Designers must
warn users of the equipment or systems if adequate protection against failure has not been
included in the system design. Designers must include this Important Notice in operating
procedures and system manuals.
These products should not be used in non-industrial applications, or life-support systems,
without consulting Cooper Crouse-Hinds first.
• A radio license is not required in some countries, provided the module is installed
using the aerial and equipment configuration described in the SmartSwitch
Installation Guide. Check with your local distributor for further information on
regulations.
• Operation is authorized by the radio frequency regulatory authority in your country on
a non-protection basis. Although all care is taken in the design of these units, there is
no responsibility taken for sources of external interference. Systems should be
designed to be tolerant of these operational delays.
• To avoid the risk of electrocution, the aerial, aerial cable, serial cables and all
terminals of the SmartSwitch module should be electrically protected. To provide
maximum surge and lightning protection, the module should be connected to a
suitable earth and the aerial, aerial cable, serial cables and the module should be
installed as recommended in the Installation Guide
• To avoid accidents during maintenance or adjustment of remotely controlled
equipment, all equipment should be first disconnected from the SmartSwitch module
during these adjustments. Equipment should carry clear markings to indicate remote
or automatic operation. E.g. "This equipment is remotely controlled and may start
without warning. Isolate at the switchboard before attempting adjustments."
• The SmartSwitch module is not suitable for use in explosive environments without
additional protection.
• The SmartSwitch operates unlicensed Radio frequencies and proprietary protocols to
communicate over the radio. Nevertheless, if your system is not adequately secured,
third parties may be able to gain access to your data or gain control of your
equipment via the radio link. Before deploying a system make sure you have
considered the security aspects of your installation carefully.
