EUTRONSEC S p A AAH SIM Reader Combo User Manual SIMReader Combo Overview 1 0
EUTRONSEC S.p.A. SIM Reader Combo SIMReader Combo Overview 1 0
Users Manual
EUTRONSEC S.p.A - Key Solutions for IT Security email: info@eutronsec.com web: www.eutronsec.com
Registered office: Via A. Cantore 8 H – I-16149 Genova Tel.: +39010.642011 Fax: +39010.6590756
Administrative, commercial and productive premises: Via Gandhi 12 – I-24048 Treviolo, BG Tel.: +39035.697080 Fax: +39035.697092
Fiscal code, VAT number and registration in the R. C. Genoa IT 016 3614 099 6 – f.p. corporate capital Euro 130,000.00 - REA GE 424111
Eutronsec S.p.A. is a company managed and coordinated by Selesta S.p.A. (fiscal code IT 02825520105)
Overview V.1.0
EUTRONSEC S.p.A - Key Solutions for IT Security email: info@eutronsec.com web: www.eutronsec.com
Registered office: Via A. Cantore 8 H – I-16149 Genova Tel.: +39010.642011 Fax: +39010.6590756
Administrative, commercial and productive premises: Via Gandhi 12 – I-24048 Treviolo, BG Tel.: +39035.697080 Fax: +39035.697092
Fiscal code, VAT number and registration in the R. C. Genoa IT 016 3614 099 6 – f.p. corporate capital Euro 130,000.00 - REA GE 424111
Eutronsec S.p.A. is a company managed and coordinated by Selesta S.p.A. (fiscal code IT 02825520105)
© Copyright 2007 by Eutronsec Spa- Italy - 24048 Treviolo BG Via Gandhi, 12
© 2007Eutronsec Spa. All rights reserved
The names of the other products mentioned are trademarks of their respective owners.
This hardware key is in compliance with the following test specification:
CEI EN 61000-4-2; CEI EN 61000-4-3; CISPR22
as required by:
CEI EN 61000-6-1, CEI EN 61000-6-2, CEI EN 61000-6-3, CEI EN 61000-6-4
which are specified for the following test:
• “ESD Immunity test”
• “Radiated radio-frequency and electromagnetic field immunity test”
• “Radiated Emission Verification”
In compliance with the “Essential Requisites” for the EMC Directive 89/336/EEC.
FCC ID: TFC-AAH
Eutronsec Spa
SIMReaderCombo
Supply: 5V DC
Absorption: 250 mA
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Caution: changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
IMPORTANT REMARKS
Due to the limited space on the product shell, all FCC certification references are on this technical manual.
EUTRONSEC S.p.A - Key Solutions for IT Security email: info@eutronsec.com web: www.eutronsec.com
Registered office: Via A. Cantore 8 H – I-16149 Genova Tel.: +39010.642011 Fax: +39010.6590756
Administrative, commercial and productive premises: Via Gandhi 12 – I-24048 Treviolo, BG Tel.: +39035.697080 Fax: +39035.697092
Fiscal code, VAT number and registration in the R. C. Genoa IT 016 3614 099 6 – f.p. corporate capital Euro 130,000.00 - REA GE 424111
Eutronsec S.p.A. is a company managed and coordinated by Selesta S.p.A. (fiscal code IT 02825520105)
SIMReaderCombo
Eutronsec, one of the world´s leading manufacturers of secure devices, has developed a new
portable USB smart card reader. The SIMReaderCombo is a fully functional smart card reader for
SIM-sized smart cards and is especially well suited for the use with mobile devices.
High-Speed
Based on revolutionary chip technology, jointly
developed with Atmel, the portable
SIMReaderCombo supports reader-to-
card data
transmission rates of up to 420 KBits
per second,
exceeding the performance of other smart card
readers.
Standards
Because the SIMReaderCombo
complies with all
relevant industry standards (ISO 7816, EMV
(Europay, Mastercard, Visa) 2000, Microsoft®
WHQL, USB CCID, PC/SC, HBC
I (Home
Banking Computer Interface, the PC-
2001
Specification and many more) it is open for any
smart card for any application on any computer .
The usage within an application is based on
standardized interfaces like PC/SC, OCF (Open
Card Framework) or CT-API.
Applications
Applications for the new reader include the
download of GSM applications from the internet
to the SIM card, W-
LAN authentication, secure
PC log-
on, PKI for mobile users, digital
signature, secure mobile banking and online
transactions, loyalty programs, h
ealthcare
solutions and many more future applications.
The SIMReaderCombo is CCID-
compliant and
features a full-
speed USB 2.0 interface. With
CCID drivers becoming a standard feature of
many operating systems, the SIMReaderCombo
can simply be plugged into
a USB port and
automatically be operated without the necessity
to install additional drivers..
EUTRONSEC S.p.A - Key Solutions for IT Security email: info@eutronsec.com web: www.eutronsec.com
Registered office: Via A. Cantore 8 H – I-16149 Genova Tel.: +39010.642011 Fax: +39010.6590756
Administrative, commercial and productive premises: Via Gandhi 12 – I-24048 Treviolo, BG Tel.: +39035.697080 Fax: +39035.697092
Fiscal code, VAT number and registration in the R. C. Genoa IT 016 3614 099 6 – f.p. corporate capital Euro 130,000.00 - REA GE 424111
Eutronsec S.p.A. is a company managed and coordinated by Selesta S.p.A. (fiscal code IT 02825520105)
Host Interface
USB 2.0 CCID
1
(also compliant with USB 1.1)
√
Transmission Speed 12 Mbps
Power supply Bus powered
Smart Card Interface
Compliant with ISO 7816 and EMV
2
2000 Level 1
√
Supports T=0, T=1
√
Supports 2-wire (SLE 4432/42),
3-wire (SLE 4418/28), SLE 4404
√
Supports I
2
C (S=8)
√
Card Size ID-000 (SIM size)
High performance smart card interface
(up to 420 Kbps when supported by
card)
√
Smart card clock frequency up to 8
MHz
√
Supports 5V, 3V & 1.8V smart cards
√
Supplies 60 mA current to power the
smart card
√
Smart card movement detection with
auto power-off
√
Automatic detection of smart card type
√
Short circuit and thermal protection
√
Other Features
Status indicator LED
Options
Customer specific logo or label On request
Customer specific colors On request
Compliance
Microsoft® WHQL
3
√
EMV
2
2000 level 1 certified √
ISO 7816 √
HBCI
4
√
USB 2.0 (USB 1.1 compatible) √
RoHS, WEEE √
Flash memory functionalities:
Flash memory capacity: 128MB–256MB–512MB–1GB–2GB
- Reading transfer rate from flash memory: 18 MB/s
- Writing transfer rate to flash memory: 11 MB/s
The flash memory embedded in the device is handled as a
single drive unit which can optionally be partitioned into 3 areas
selecting among the following types:
• Standard mass storage: where data are visibly stored
• Encrypted mass storage with AES 256
• CD-ROM with autorun function
API
PC/SC driver √
CT-API (on top of PC/SC) √
OCF (on top of (PC/SC) √
PC /SC Driver Support
Windows® 98/ME √
Windows® 2000/XP √
Windows® 2003 Server √
Windows® Vista 32/64 bit √
Windows® XP 64Bit (AMD64, EM64T,
IA64)
√
Windows® CE 5.0 / CE.NET (on
request)
Depending on
hardware
Linux® √
Mac® OS X (Power PC) √
Embedded Technology
CardMan
®
Smart@Link Chip set √
Hardware Specifications
Colors Gray-Red
Dimensions 74 x 21 x 10mm
2.43”x.70”x.30”
Weight
10 gr/0.35 ounces
Operating temperature
0-55°C/32-131°F
Operating humidity 10-90% rH
Composition Polycarbonate
Durability
100,000 Insertions
Meantime between failure
500,000 Hours
Safety and Environmental Standards
CE √
FCC √
UL √
1= Chip Card Interface Device 2= Europay® MasterCard® Visa® 3= Windows® Hardware Quality Lab 4= Homebanking Computer Interface
SIM
ReaderCombo
