Eastern Times Technology MSEC Wireless Optical Mouse User Manual 2135
Eastern Times Technology Co., Ltd. Wireless Optical Mouse 2135
Users Manual
Chargeable Wireless Optical Mouse User
Manual
Welcome
Thank you for selecting this product! This
mouse is one kind of newly developed
wireless RF mice in our company, and it uses
the global-used frequency of 27MHz. The
comfortable and perfect shape is designed
according to somatology. With it, You can get
rid of the bondage of wires and enjoy your
beautiful life from the high technology
Product Features
1. Radio frequency 27MHz,It has 256 ID
code, there is no interference even
many mice being used at the same
time.
2. With receiver hidden inside and the
whole design looks more ntimate and
scientific.
3. Automatically save power sleeping
functions, battery life be prolonged.
4. With charge and regular circuit, it can
use the attached retraceable line to
charge for the mouse. Even if there is
no battery in the mouse, you can use
the mouse directly, thus it resolve the
problem of lack the battery.
Systems Compatibility
IBM PC and Windows Me/2000/XP
Build-in mini receiver
As bellow, press the receiver-out button,
and the receiver can spring out
automatically, at this time, mouse begin to
work. If you push the receiver back to the
transmitter, power will be cut down
automatically.
The Steps of Install Battery
1, Please prepare for two PCS new AAA
alkaline batteries
2, Press the button of the mouse upper
cover and pull the battery cover rearward
(Please see the reference picture)
3, Please insert the batteries correctly
according to the polarity marks of the
battery grooves.
4, Pull the battery covers forward, when
you hear “crack” sound which shows the
battery cover is locked successfully.。
Receiver Installation
1, please use extended cable, and put the
receiver and transmitter on one desktop,
in this way, you may have higher working
efficiency.
2, If you use PS/2 connector, please use the
USB to PS/2 adaptor and connect with the
connector before your computer start-up.
3, For laptop, you may connect the receiver
directly with the USB connector.
ID Setup
1, Please move the mouse near to the
receiver
2, Press the ID button of the mouse
bottom with some hard and
Push battery
cover
acuate object within 10 seconds, the
receiver light will flash very fast, a few
seconds later it will be on which shows
it is successfully to finish the digital
transmission between the mouse and
the receiver. You may start to use it.
3. Working distance: within 0.6-1.5 m
ID connect
Charge Function
When using mouse, if the red led of the
low battery beside the wheel flashes, please
change batteries or charge them .The mouse
can use USB line to charge, connect one side
of USB line to the connector of the board, and
the other side to USB connector before the
mouse, thus it can successfully charge the
battery. It can charge while you use the mouse.
It is full within about 8-10 hours, and then
unplug the connector to stop the charge.
Please note that the time of charge may vary
when the degree of discharge is different.
Charge
connector
Low battery
Attention Please
1. Please don’t make the mouse far
away from the receiver in order to
work more smoothly.
2. You’d better use the mouse on the
white desk, in this way the batteries
can be used longer time. Please
remove the batteries if the mouse will
not be used for a long time or if you
travel outside.
3. This mouse with save power sleeping
functions, please press any key or
scroll the wheel to wake up the mouse
when it is sleeping.
4. If you want to take off the mouse
power,please continue to press the ID
switch of the mouse bottom over 3
secons.If you want to take on the
power,please click the ID switch once
again.
5. The optical mouse will not work freely
on a smooth desk ,glass, any
reflecting surface, 3D mouse pad.
6. When you move the mouse, if the light
of the battery before the receiver
flashes, which shows that the power
is nearly finished. Please change the
proper-sized new battery or charge it
immediately.
7. You can place the receiver in the
mouse when you want to carry the
mouse on business, and press the
switch of ID for a long time so as to
switch off the power.
Caution
Any changes or modifications not
expressly approved by the party
responsible for compliance could
void the user's authority to operate
the equipment.
Note
Note: This device complies with Part 15 of
the FCC Rules.
Operation is subject to the following
two conditions:
(1) This device may not cause
harmful interference, and
(2) This device must accept any
interference received,
including interference that
may cause undesired
operation.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and
can radiate radio frequency energy and,
if not installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications. However, there is no
guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the
user is encouraged to try to correct the
interference by one or more of the
following measures:
* Reorient or relocate the
receiving antenna.
* Increase the separation between
the equipment and receiver.
* Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
* Consult the dealer or an
experienced radio/TV technician
for help.
