Eaton's Cooper Power Systems RFN430EL-A3 Module EkaNet Mobile Collection Software
User Manual
RFN430EL-A3 User’s Guide
Document Number
XXXX
Revision 1
Cooper Power Systems
20201 Century Boulevard, Suite 250
Germantown, MD 20874 USA
www.cooperpowereas.com
Tel (301) 515-7118
Fax: (301) 515-4965
XXXXX-01 2 RFN430EL-A3 User’s Guide
Contents
1 About the RFN430EL-A3 ........................................................................................................ 3
2 Regulatory Notices ................................................................................................................ 4
3 RFN430EL-A3 Specifications .................................................................................................. 7
XXXXX-01 3 RFN430EL-A3 User’s Guide
1 About the RFN430EL-A3
The RFN430EL-A3 is a radio communications device designed for use in Elster A3 meters.
The RFN430EL-A3 provides a 915 MHz radio interface to an RF mesh network.
The RFN430EL-A3 operates from a power source of 13.5 VDC, received from the host
device. The radio modules operate in license-free bands at 915 MHz (902.75 to 927.25
MHz). RFN430EL-A3 Nodes are fully compatible with mesh network hardware, protocols
and operations. Two radio transmission data rates are available: 76.8 kb/s and153.6 kb/s.
The transmission power of the 915 MHz radio is adjustable from 27 dBm to -20 dBm.
XXXXX-01 4 RFN430EL-A3 User’s Guide
2 Regulatory Notices
Warning
The Original Equipment Manufacturer (OEM) must ensure that FCC Labeling
requirements are met. This includes a clearly visible label on the outside of
the OEM enclosure specifying the Cooper Power Systems FCC identifier (FCC
ID: P9X-RFN430EL-A3) and IC Number (IC: 6766A-RFN430ELA3) as well as
the FCC Notice below.
Warning
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
Warning
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
Warning
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
XXXXX-01 5 RFN430EL-A3 User’s Guide
Warning
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning
The installer of this radio equipment must ensure that the antenna is located
or pointed such that it does not emit RF field in excess of Health Canada
limits for the general population; consult Safety Code 6, obtainable from
Health Canada’s website www.hc-sc.gc.ca/rpb.
XXXXX-01 6 RFN430EL-A3 User’s Guide
Warning
To comply with FCC RF exposure compliance requirements, the antenna
used for this transmitter must be installed to provide a separation distance
of at least 20 cm from all persons and must not be co-located or operate in
conjunction with any other antenna or transmitter.”
As such, the radio component of this device is intended only for OEM
integrators under the following two conditions:
The antenna must be installed such that 20 cm is maintained between the
antenna and users.
The transmitter module may not be co-located with any other transmitter or
antenna.
As long as the two conditions above are met, further transmitter testing will
not be required. However, the OEM integrator is still responsible for testing
their end product for any additional compliance requirements required with
this module installed (e.g., digital device emissions, PC peripheral
requirements).
In the event that these conditions cannot be met (for example, co-location
with another transmitter), then the FCC authorization is no longer
considered valid and the FCC ID cannot be used on the final product. In
these circumstances, the OEM integrator will be responsible for re-
evaluating the end product (including the transmitter) and obtaining a
separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in devices where the
antenna may be installed such that 20 cm may be maintained between the
antenna and users (for example access points, routers, wireless ASDL
modems, certain laptop configurations, and similar equipment). The final
end product must be labeled in a visible area with the following:
“Contains FCC ID: P9X-RFN430EL-A3, IC: 6766A-RFN430ELA3”.
The radio component is an integral part of the RFN430EL-A3 and
cannot be removed.
Warning
Transmitters with Detachable Antennas
This device has been designed to operate with the antennas listed below,
and having a maximum gain of 8 dB. Antennas not included in this list or
having a gain greater than 8 dB are strictly prohibited for use with this
device. The required antenna impedance is 50 ohms.
Antennas that may be used with this product include:
GH908U-PRO 900MHz Omnidirectional – 8dBi Gain
TRA9023NP - Antenex Phantom 902-928MHz – 3dB Gain
915MHz Co-linear Antenna -2dB gain
To reduce potential radio interference to other users, the antenna type and
its gain should be so chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that permitted for successful communication.
XXXXX-01 7 RFN430EL-A3 User’s Guide
3 RFN430EL-A3 Specifications
Radio Specifications
Operating frequency
902.75 – 927.25 MHz
Reliable data transmission
Error detection, correction and retransmission
RF output power
915 MHz: 27 dBm to -20 dBm
Data rate
76.8 kb/s, 153.6 kb/s
Receiver sensitivity
-101 dBm (@ 1% PER, 76.8 kbps, +25° C)
Range (w/ omni antenna)
Outdoor
1,000 m (3200 ft)
Indoor
75 – 150 m (225 – 490 ft)
Mode
Frequency hopping spread spectrum
Mechanical Specifications
Weight
Unavailable
Dimensions
100 mm x 120 mm
Operating Conditions
Environmental
-40° C to +85° C
0 – 95% non-condensing humidity
Power supply
DC 13.5V (regulated to 3.3 VDC on-board)
Power consumption
< 1W
