Echo Toys 91138T49 49 MHz Radio Transmitter User Manual 912
Echo Toys Ltd 49 MHz Radio Transmitter 912
users manual
ON/OFF
TRIM CONTROL SWITCH
ON/OFF
9V
SCALE 1:18
OPERATING INSTRUCTIONS
Please read carefully before starting to operate.It is
recommended to operate the vehicle under adult
supervision.
CAUTION-ELECTRIC TOY
Not recommended for children under 3 years of
age.
As with all electrical products, precautions should
be observed during handling and use to prevent
electric shock.
FEATURES
7 Functions - runs forward, backward, turns left and
right, stop.
BATTERY REQUIREMENT
One "9V" battery for transmitter.
Four "AA" batteries for vehicle
TRANSMITTER
1) Slide ON/OFF to OFF.
2) Press and pull the battery compartment cover in
the direction of the arrow to remove it.
3) Put the "9V" battery in the compartment
according to the polarity symbols (+ and -)
marked inside.
4) Replace the battery compartment cover.
VEHICLE
1) Slide ON/OFF to OFF.
2) Use a coin to turn the battery door stoppers and
remove the battery door.
3) Insert 4 x 1.5V "AA" batteries according to the
polarity symbols
(+ and -) marked inside.
4) Replace the battery door and a coin to turn the
stoppers back.
HOW TO OPERATE:
1) Slide ON/OFF on the bottom of the vehicle to
ON.
2) Slide ON/OFF on the transmitter to ON.
3) Use the transmitter's levers to control the
movement and direction of the vehicle.
Left Control Lever
* Push forward to move forward.
* Pull backward to move backward.
* Release to stop.
Right Control Lever
* Push left to turn left.
* Push right to turn right.
* Release to go straight.
TRIM CONTROL SWITCH
Trim switch is located on underside of vehicle
between the front tires. It is used to align your
vehicle for consistent turning and drive. Move
switch left or right until desired alignment is
reached.
HI-SPEED AND NORMAL DRIVE SETTINGS
"H" MODE (HI-SPEED DRIVE)
Best for high speed on flat surfaces. Setting the
speed level to "H" gives the vehicle a higher
running speed than the "L" mode but a shorter
running time because the battery power will be
used in faster rate.
"L" MODE (NORMAL DRIVE)
Setting the lever to "L" gives good power and a
longer running time.
CAUTION:
1. Do not dispose the battery in fire.
2. Use only fresh batteries of the required size and
recommended type.
3. Do not mix old and new batteries, different types
of batteries (standard, alkaline, or rechargeable),
or rechargeable batteries of different capacities.
4. If you do not plan to use the vehicle for several
days, remove the batteries since batteries can
leak chemicals that can damage electronic parts.
5. If the vehicle moves slowly and you have
installed fresh batteries, check the wheel
mechanism for lint, thread, hair, and dust.
FCC WANTS YOU TO KNOW
NOTE: The manufacturer is not responsible for any
radio or TV interference caused by unanthorized
modifications to this equipment. Such modifications
could void the User's anthority to operate the
equipment.
USE A COIN TO OPEN
ITEM . 91138
PRINTED IN CHINA
HIGH/LOW SPEED
123
4
© 2003 ECHO TOYS LTD. ALL RIGHTS RESERVED.
ROOM 1108, PENINSULA CENTRE, 67 MODY ROAD,
TSIM SHA TSUI EAST, KOWLOON, HONG KONG.
WEB SITE: http://www.echotoys.com.hk
