JIMMY NEUTROU ULTRA ORB
OWNER'S MANUAL
and -Press at the same time to turn right spinning.
and -Press at the same time to turn left spinning.
INTRODUCTION
Your Echo Jimmy Genius Ultra Orb is an all-terrain toy
vehicle. It has two big wheels extending over the top of it,
allowing it to travel in any direction you choose and perform
many exciting stunts. Built to 1/14 scale, it reaches speeds
up to 400 feet per minute.
The Ultra Orb comes in two frequencies (27 MHz & 49 MHz).
You can race with a friend, provided your Ultra Orbs operate
on different frequencies.
INSTALLING BATTERIES
Having a parent or adult to help your install batteries in your
Ultra Orb is strongly recommended.
Warning: Dispose of old batteries promptly and properly. Do
not burn or bury them.
Cautions:
• Use only fresh batteries of the required size and
recommended type.
• Do not mix old and new batteries, different types of
batteries (standard, alkaline, or rechargeable), or
rechargeable batteries of different capacities.
• If you do not plan to use the Ultra Orb for several days,
remove the batteries. Batteries can leak chemicals that
can destroy electronic parts.
• Never leave dead or weak batteries in the Ultra Orb and
transmitter.
A) TRANSMITTER
The transmitter requires one 9V battery (not included) for
power.
1. Slide ON/OFF on the transmitter to OFF.
2. Slide the battery compartment cover in the direction of the
arrow to remove it .
3. Place the 9V battery in the compartment according to the
polarity symbols (+ and -) marked inside.
4. Replace the cover and snap it shut.
When the range of your transmitter decreases, replace its
battery.
B) THE ULTRA ORB
Your Ultra Orb uses a 9.6V Ni-Cd rechargeable battery pack
(not included) for power. Before using the battery pack, you
must charge it.
1. Slide ON/OFF switch on the bottom of the Ultra Orb to
OFF.
2. Use a coin to turn the battery compartment cover's latches
in the direction of the arrows until they stop, then remove
the cover.
3. Attach the battery pack's white plastic connector to the
Ultra Orb's matching connector. Do not force them
together. They only fit one way. Carefully tuck the wire into
the compartment recess and place the battery pack into
the compartment.
4. Replace the cover, making sure not to pinch the wires.
Then secure the latches with a coin.
5. When the Ultra Orb stops operating properly, recharge the
battery pack.
BATTERY CHARGING
Note: Follow the instruction on your 9.6V rechargeable
Ni-Cd battery pack and charger system.
• The 9.6V rechargeable Ni-Cd battery pack must be charged
prior to use.
• When charging Ni-Cd battery pack, plug charger into
household outlet. Connect the charger with the Ni-Cd
battery pack.
• Four hours is all that is required for a fully charged battery
pack. Charging the battery pack for more than 4 hours will
not give you the longer running time.
• After use, the battery pack will be hot. Wait at least 10
minutes until the battery pack cools down before charging.
Recharging a hot battery pack will greatly reduce the
recharging life of your battery pack.
DRIVING THE ULTRA ORB
1. Insert the two supplied outriggers into the holes on each
side of the Ultra Orb with the outriggers curved upwards.
2. Slide ON/OFF on the bottom of the Ultra Orb to ON.
3. Slide ON/OFF on the transmitter to ON.
4. Use the transmitter's control buttons to control the
movement and direction of the Ultra Orb.
5. When you finish driving, slide ON/OFF on both the Ultra
Orb and the transmitter to OFF.
EXPERT SKILLS
When the Ultra Orb leans to either side and you are riding on
the outriggers, press either or to drive upright again.
While moving forward, quickly release Left and Right and
press Left and Right . The Ultra Orb rolls over!
While driving upside down:
• Hold down to move backwards in a rocking motion.
• Hold down to move forward in a rocking motion.
NOTE: While driving upside down, the buttons become
opposite of their original function. For example, causes the
Ultra Orb to move backward, and spin left causes it to spin
right.
Warnings:
• Never play with the Ultra Orb in the street.
• Be careful to avoid collisions with people and objects.
• Don't touch the wheels when you turn on the Ultra Orb. This
can cause injury.
HELPFUL HINTS
• Running your Ultra Orb continuously for long periods
generates high heat levels. Heat causes wear and tear on
the motor. To help keep heat levels down, when your Ultra
Orb's battery pack dies, let the Ultra Orb cool at least 10
minutes before installing a new or newly charged battery
pack.
• If someone uses a CB nearby, it might interfere with control
of the Ultra Orb. If this happens, move the Ultra Orb away
from the CB.
• You cannot operate your Ultra Orb near devices with
transmitters that use the same frequency as your Ultra Orb
(27 MHz or 49 MHz). Check your Ultra Orb' s box to see
which frequency your Ultra Orb uses.
• If the Ultra Orb moves slowly and you just installed a fully
charged battery pack, check the wheel mechanisms for lint,
thread, hair, or dust.
CARE
• Do not drive the Ultra Orb through puddles or mud, on a
wet floor, or in sand, rain, or snow. These can damage it .
• Do not expose the Ultra Orb or transmitter to temperature
extremes, and do not store them in direct sunlight or near a
heat source.
• Do not leave the Ultra Orb or transmitter outside overnight.
Night dampness can damage their electronic circuits.
• To protect the Ultra Orb's mechanisms from lint and hair, do
not drive the car on carpet.
• Wipe the Ultra Orb and transmitter with a damp cloth
occasionally to keep them looking new. Do not use harsh
chemicals to clean them.
THE FCC WANTS YOU TO KNOW
NOTE: The manufacturer is not responsible for any radio or
TV interference caused by unauthorized modifications to this
equipment. Such modifications could void the User's
authority to operate the equipment.
Modifying or tampering with the Ultra Orb or transmitter's
internal components can cause a malfunction and void your
FCC authorization to operate it.
JIMMY NEUTROU ULTRA ORB
ON/OFF SWITCH
9.6V Ni-Cd or NiMH rechargeable
battery pack
110V
charger
outriggers
OPEN
OPEN
OPEN OPEN
CLOSE
CLOSE CLOSE
9.6V Ni-Cd or rechargeable
battery pack
ON/OFF SWITCH
battery cover
- Press
to move
forward.
Release
to stop.
- Press
to move
forward.
Release
to stop.
ON/OFF
Switch
OWNER'S MANUAL
© 2003 ECHO TOYS LTD. ALL RIGHTS RESERVED.
ROOM 1108, PENINSULA CENTRE, 67 MODY ROAD,
TSIM SHA TSUI EAST, KOWLOON, HONG KONG.
WEB SITE: http://www.echotoys.com.hk
ITEM:91229
PRINTED IN CHINA
