OPERATING INSTRUCTIONS
Please read carefully before starting to operate. It
is recommended to operate the vehicle under adult
supervision. Not recommended for children under
4 years of age.
Note: Can not play 2 vehicles together in the
same frequency.
FEATURES
Full Function- runs forward, backward, turns left
and right, stops and turbo speed.
BATTERY REQUIREMENT
- One "9V" battery for transmitter.
- 5 "AA" batteries for vehicle.
Batteries are not included.
BATTERY INSTALLTION
(A) TRANSMITTER
1) Slide ON/OFF to OFF.
2) Press and pull the battery compartment cover in
the direction of the arrow to remove it.
3) Put the "9V" battery in the compartment
according to the polarity symbols (+ and -)
marked inside.
4) Replace the battery compartment cover.
(B) VEHICLE
1) Slide ON/OFF on the bottom of the
vehicle to OFF.
2) Use a coin to turn the battery door stopper until
it stops and open the battery door.
3) Install the batteries in the compartment as
indicated by the polarity symbols (+ and -)
marked inside.
4) Replace the battery door and use a coin to turn
the stopper back.
HOW TO OPERATE:
1) Slide ON/OFF on the bottom of the vehicle to
ON.
2) Slide ON/OFF on the transmitter to ON.
3) Use the transmitter's levers to control the
movement and direction of the vehicle.
Note: If the vehicle moves slowly or does not
move at all, replace the batteries with fresh ones.
Left Control Lever
- Push forward to move forward.
- Pull backward to move backward.
- Release to stop.
- Push forward and press upper key to
move turbo speed.
Right Control Lever
- Push left to turn left.
- Push right to turn right.
- Release to go straight.
CAUTION
- Do not mix battery types.
- Do not mix old and new batteries.
- Replace all together.
- Observe correct polarity.
- Remove batteries when not in use.
- Non-rechargeable batteries are not to be
recharged.
- Rechargeable batteries are to be removed from
the toy before being charged.
- Rechargeable batteries are only to be charged
under adult supervision.
- Only batteries of the same or equivalent type as
recommended are to be used.
- Exhausted batteries are to be removed from
the toy.
- The supply terminals are not to be short circuited.
Note: Dispose of old batteries promptly and
properly; do not burn or bury them.
TRIM CONTROL SWITCH
Trim switch is located on the underside of vehicle
between the front tires. It is used to align the
wheels of your vehicle for consistent turning and
drive. Turn switch clockwise and anti-clockwise
until desired alignment is reached.
THE FCC WANTS YOU TO KNOW:
NOTE: The manufacturer is not responsible for
any radio or TV interference caused by
unauthorized modifications to this equipment.
Such modifications could void the User's authority
to operate the equipment.
ITEM: 91255
PRINTED IN CHINA
ON/OFF SWITCH
Before tuning
Transmitter
Under bumper Front bumper Spare wheels fenders
Vehicle Spoiler A Spoiler B
After tuning
1) use a Philips screwdriver to loosen
the four wheels.
2) Remove the spoiler A and the wheels.
TUNING
1) Use a Philips screwdriver to secure
the four spare wheels to the car.
2) Snap on the front bumper, under bumper,
two side fenders and spoiler B.
STREET CUSTOMS INCLUDES
ATTACH THE TUNE-UP PARTS
SCALE 1:16
STREET CUSTOMS
STREET CUSTOMS
TM
ON/OFF SWITCH
STOP
Press the key to turbo funtion
