Ecolink Intelligent Technology TX-24-2 Transmitter User Manual
Ecolink Intelligent Technology, Inc. Transmitter
User manual
Federal Communications Commission Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instruction, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try and correct the interferene by one of the following measures:
Reorient or relocate the receiving antenna,
Increase the separation between the equipment and receiver,
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undersired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
Limited Warranty
Vision Guarantees that every transmitter is free from physical defects in material and
workmanship under normal usage for one year from the date of purchase. If the product
proves defective during this one-year warranty period, Vision will replace it free of charge.
Vision does not issue any refunds. This warranty is extended to the original end user
purchase only and is not transferable. This warranty does not apply to : (1) damage to
units caused by accident, dropping or abuse in handling, or any negligent usage; (2)
units which have been repaired, taken apart, or modified by an authorized personnel; (3)
units not used in accordance with instruction; (4) damages exceeding the cost of the
product; (5) transit damage, initial installation costs, removal cost, or reinstallation cost.
-3-
Operation Manual
TX-24-2
Transmitter
Introduction
Thanks for choosing the transmitter of the home security device. This product is a
one-way RF technology enabled device.
Specification
Specification:
Frequency Range: 319.5 MHz
Operating Range: Up to 100 feet line of sight
Operating Temp.: -10°C~ 50°C (14°F~122°F)
Battery: CR2032 Batteries
Remote
This is a remote control transmitter can control door lock
& unlock.
If TX-24-2 is in low battery status, then door lock
won’t activate. Please change battery according.
TX-24-2
Operation
1. To unlock the lock:
Press “Unlock” button and then light flash 0.5 sec.
2. To lock the lock:
Press “Lock” button and then light flash 0.5sec.
Light
