Ecolink Intelligent Technology WST401 Garage Door Tilt Sensor User Manual
Ecolink Intelligent Technology, Inc. Garage Door Tilt Sensor
User manual
WST-401 Wireless Tilt Sensor
Specifications
Frequency: 319.5MHz Operating Temperature: -22° to 120°F (-30°to 49°C)
Battery: One 3Vdc lithium CR123A (1550 mAh) Operating Humidity: 5-95% RH non condensing
Battery life: 5-8 years Compatible with GE/Interlogix receivers
Tilt Sensor Supervisory signal interval: 60 min (approx.)
Enrolling
To enroll the sensor, set your panel into program mode, then go to the Learn Sensors menu. Refer
to your specific alarm panel manual for details on these menus. To activate the case tamper
simply slide the cover up and down, you will hear a click when the case latches are engaging and
disengaging. Continue until the panel responds to the sensor. Then select the appropriate sensor
group and number.
Tilt Sensitivity
The tilt sensor will activate when the device is approximately at a 45 degree angle. By moving the
actual ball sensor up or down you can adjust this angle by a few degrees.
Note that this device has a delay of approximately 1 second to eliminate false alarms cause by
wind and vibration commonly subjected to a large garage door.
Mounting
Included with this device are mounting screws and double sided tape. For reliable bonding with
the tape ensure the surface is clean and dry. Apply the tape to the sensor and then to the desired
location. Apply firm pressure for several seconds. It is not recommended to mount the tape at
temperatures below 50°F, although after 24 hours the bond will hold at low temperatures.
Replacing the Battery
When the battery is low a signal will be sent to the control panel. To replace the battery:
1. Remove the screw securing the top cover, then remove the top cover to reveal the battery.
2. Replace with a CR123A battery ensuring the + side of the battery faces as indicated on the
device.
3. Re-attached the cover and replace the screw to secure the cover.
